Scholl B 0042 User manual

GBA B 0041 1 E
BA Page 1 of 27 Juni 11, 2014
Last revised 06-2014 Rev. 1
Scholl Apparatebau GmbH & Co. KG
Instructions for Use
Buffet-heat-lamp
Art. No. B 0041, B 0042, B 0047, B 0048
Art. No. B 0043, B 0044
Art. No. B 0051, B 0052, B 0061, B 0062
Scholl Apparatebau GmbH & Co. KG
Zinhainer Weg 4
D–56470 Bad Marienberg / Germany
Phone [phone]
Fax [phone] (Service)
Internet www.scholl-gastro.de
E-mail [email protected]

GBA B 0041 1 E
BA Page 2 of 27 Juni 11, 2014
Last revised 06-2014 Rev. 1
Scholl Apparatebau GmbH & Co. KG
TABLE OF CONTENTS
Table of contents............................................................................................................................................... 2
Preface............................................................................................................................................................... 4
Conventions....................................................................................................................................................... 5
Pictograms –General safety notes................................................................................................................ 5
Pictograms –Warning notes ......................................................................................................................... 7
Pictograms –Important notes....................................................................................................................... 8
Product information ........................................................................................................................................ 10
Information regarding compliance with standards, laws and directives .................................................... 10
Safety........................................................................................................................................................... 10
Unpacking and start-up ................................................................................................................................... 11
Packing......................................................................................................................................................... 11
Sensitivity .................................................................................................................................................... 11
Intermediate storage................................................................................................................................... 11
Scope of delivery ......................................................................................................................................... 11
Start-up........................................................................................................................................................ 11
Assembly instructions.................................................................................................................................. 12
Operation ........................................................................................................................................................ 13
Maintenance ................................................................................................................................................... 14
Maintenance and repair .............................................................................................................................. 14
Cleaning and care ........................................................................................................................................ 14
Troubleshooting .............................................................................................................................................. 15
Technical data ................................................................................................................................................. 16
Dimensioned Drawing ................................................................................................................................. 17
Circuit Diagram ............................................................................................................................................ 19
Spare Parts List ............................................................................................................................................ 20

GBA B 0041 1 E
BA Page 3 of 27 Juni 11, 2014
Last revised 06-2014 Rev. 1
Scholl Apparatebau GmbH & Co. KG
Disposal and environment............................................................................................................................... 25
Environmental notes ....................................................................................................................................... 25
Disposal of packing material........................................................................................................................ 25
Disposal of the appliance ............................................................................................................................ 25
Warranty and service ...................................................................................................................................... 26
Warranty conditions.................................................................................................................................... 26
Service address............................................................................................................................................ 27

GBA B 0041 1 E
BA Page 4 of 27 Juni 11, 2014
Last revised 06-2014 Rev. 1
Scholl Apparatebau GmbH & Co. KG
PREFACE
Congratulations!
In purchasing this new SCHOLL appliance you have chosen a product which meets highest technical stand-
ards while providing outstanding convenience in practical use.
This appliance has been designed with minimal energy consumption in mind. Used responsibly, it will serve
you well in an ecologically sound manner.
Please read the information in this manual carefully before starting up this appliance. On the following
pages you will find important notes regarding its operation, care and maintenance so that you will be able
to enjoy its use for a long time.
If a malfunction should nevertheless occur, please consult the "Troubleshooting" section first. In many cases
you should be able to remedy minor problems yourself, thus saving unnecessary service costs.
Please retain this manual carefully and pass it on to any subsequent user for his or her information and
safety.
A quality product, properly treated, will give you many years of satisfactory service.
We trust you will enjoy using this product!
Yours sincerely
Gustav Scholl Apparatebau GmbH & Co. KG

GBA B 0041 1 E
BA Page 5 of 27 Juni 11, 2014
Last revised 06-2014 Rev. 1
Scholl Apparatebau GmbH & Co. KG
CONVENTIONS
PICTOGRAMS –GENERAL SAFETY NOTES
Be sure to observe these Instructions for Use as well as the safety notes to prevent
injuries or damage to health or property. Do not alter or modify this appliance.
Never use a defective appliance. If you suspect the unit of being faulty or discover an
unusual noise or smell, turn off the power switch and pull the plug out of the socket-
outlet, or otherwise disconnect the appliance from the mains and de-energize it (i.e.,
ensure that it no longer carries any voltage). Do not use this appliance when its power
cord is damaged.
Failure to observe this warning may result in a fire hazard or electrical shock!
Maintenance and repair work must be carried out only by qualified professionals using
original spare parts and accessories. Do not attempt to carry out repairs on this appli-
ance yourself!
Connect this appliance to suitably earthed mains outlets only. Ensure that your mains
power supply conforms to the data stated on the nameplate of the appliance.
Failure to observe this warning may result in a fire hazard or electrical shock!
Place this appliance on a sturdy, level and heat-resistant surface to prevent fire haz-
ards and accidents.
This appliance is not intended to be used by persons (including children) of limited
physical, sensory or intellectual abilities, or lacking in experience and/or knowledge,
unless they are supervised by a person responsible for safety who instructs them in
the use of the device. Children should be supervised to ensure they will not play with
this appliance.

GBA B 0041 1 E
BA Page 6 of 27 Juni 11, 2014
Last revised 06-2014 Rev. 1
Scholl Apparatebau GmbH & Co. KG
Do not run the power cord near heat sources, over sharp edges, etc. Always pull on
the plug, not the cord, to remove it from a socket-outlet since the cord might be dam-
aged as a result. Do not allow cords to hang unsupported. Route the cord so that it will
not form a tripping hazard!
When using an extension cord, unwind the cord from the reel to prevent heat build-up
or cord fires, respectively. The socket-and-plug connection must be splash-proof and
be made of, or coated with, rubber. Each wire must have a cross-section of at least
1.5 mm².
Do not allow this appliance to operate unattended. Ensure that its power switch is set
to „0“ before inserting the plug into an electrical socket-outlet. Avoid starting the unit
unintentionally. Connecting the unit to the mains with its power switch set to ON may
cause accidents.
Protect this appliance from moisture (water spray, rain). Do not immerse the appliance
in water or other fluids and do not place it in a dishwasher. Any penetration of water
into the unit will increase the risk of an electrical shock.
Do not touch the surfaces of the appliance. The surfaces of this appliance may get hot.
Please allow the unit to cool down fully before cleaning or stowing it. Never cover this
appliance.
Burn injury or fire hazard!

GBA B 0041 1 E
BA Page 7 of 27 Juni 11, 2014
Last revised 06-2014 Rev. 1
Scholl Apparatebau GmbH & Co. KG
PICTOGRAMS –WARNING NOTES
Cleaning must only be performed by qualified persons who have read and under-
stood these Instructions for Use and are familiar with applicable hygiene rules. En-
sure that care is exercised during cleaning of the unit.
For light cleaning, wipe down the surface with a cloth or soft brush/sponge soaked
in warm water which contains a small amount of dishwashing detergent. Follow this
up by wiping with clear water until no cleaning agent residue remains on the sur-
face, as the latter might cause discoloration or stains. Finish by rubbing the surface
dry.
To remove more stubborn or extensive residue, a stainless steel cleaning product
may be used.
Never use any of the following for cleaning:
aggressive or bleaching products, i.e., containing active oxygen, chlorine, or
caustic/corrosive constituents.
abrasive cleaning products such as scouring creams/pastes, steel wool, sa-
ponified steel wool, metal or plastic sponges, or sponges with a scratchy
surface (scouring side).
Never use steam and/or pressure jet cleaning equipment to clean this appliance.
This might damage the appliance to the point where it may pose a hazard to your
life!
Before any cleaning, maintenance or repair work is carried out, the appliance must
be disconnected from the mains and de-energized. To do so, it is not enough to set
the power switch to OFF. Instead, the mains plug must be pulled or the electrical
circuit must be de-energized, respectively. Check that no voltage is present before
opening the appliance, and lock out the circuit to make it safe against re-energizing.
The total permitted regeneration and hot-holding time according to HACCP will be
exceeded after 3 hours.
Risk of potential health impairment!

GBA B 0041 1 E
BA Page 8 of 27 Juni 11, 2014
Last revised 06-2014 Rev. 1
Scholl Apparatebau GmbH & Co. KG
Allow the unit to cool down before starting any cleaning work.
Burn hazard
PICTOGRAMS –IMPORTANT NOTES
DANGER
indicates an immediately threatening hazard.
Failure to observe this warning notice will result in severe physical injury or
death.
WARNING
indicates a potentially dangerous situation.
Failure to observe this warning notice may result in severe physical injury or
death.
CAUTION
indicates a potentially harmful situation.
Failure to observe this notice may result in damage to property.
DANGER –electrical voltage
indicates an immediately threatening hazard.
Failure to observe this warning notice will result in severe physical injury or
death.

GBA B 0041 1 E
BA Page 9 of 27 Juni 11, 2014
Last revised 06-2014 Rev. 1
Scholl Apparatebau GmbH & Co. KG
IMPORTANT
Improper use may result in minor injuries or damage to property.
In addition to these Instructions for Use, a number of accident prevention and
other regulations apply with regard to the operation of this appliance. As re-
gards food handling, please observe HACCP rules concerning compliance with
hygiene requirements.
If you have any questions, please contact your supervisor(s) or safety repre-
sentative.
This product must not be disposed of in domestic waste.
Please arrange for proper recycling of this product via your local provider of
waste disposal services.

GBA B 0041 1 E
BA Page 10 of 27 Juni 11, 2014
Last revised 06-2014 Rev. 1
Scholl Apparatebau GmbH & Co. KG
PRODUCT INFORMATION
The buffet-heat-lamp may only be used to keep dishes short-term warm.
INFORMATION REGARDING COMPLIANCE WITH STANDARDS,LAWS AND DIRECTIVES
This appliance conforms to the following:
EC Directive:
2014/30/EG
EMC Directive
2014/35/EG
Low Voltage Directive
Harmonized standards:
DIN EN 60335-1: 2012-10
Household and similar electrical appliances –
Safety
DIN EN 61000-6-1: 2007-10
Electromagnetic compatibility (EMC) –Generic
standard –Immunity
DIN EN 61000-6-3:2011-09
Electromagnetic compatibility (EMC) –Generic
standard –Emission
SAFETY
This appliance conforms to accepted technical rules and relevant safety codes. How-
ever, proper use of the appliance is a prerequisite for effectively preventing damage or
accidents. Please comply with the notes provided in these Instructions for Use.
Further safety notes, refer to section
Pictograms –General safety notes
Pictograms –Warning notes
Pictograms –Important notes

GBA B 0041 1 E
BA Page 11 of 27 Juni 11, 2014
Last revised 06-2014 Rev. 1
Scholl Apparatebau GmbH & Co. KG
UNPACKING AND START-UP
PACKING
The type of packing employed will depend, to a large extent, on the adopted shipping mode and route.
Except where otherwise agreed by contract, packing will conform to the "HPE Packing Guideline" defined by
the German Federal Association of the Wooden Materials, Pallets and Export Packing Industry and by the
German Engineering Federation.
SENSITIVITY
Particular care must be exercised during shipping and handling of this appliance to prevent damage result-
ing from exposure to excessive force or careless loading/unloading.
Shocks during shipping and handling must be avoided.
The appliance itself must be handled with care.
INTERMEDIATE STORAGE
Appliances not to be installed immediately upon delivery must be carefully stored in a protected place. For
the duration of such storage they must be properly covered to prevent any ingress of dust and moisture
into the unit.
SCOPE OF DELIVERY
The content of the delivery is stated in the delivery note and must be checked for completeness upon re-
ceipt.
Any damage in transit and/or missing items must be reported in writing immediately.
START-UP
Before putting the appliance into service, observe the following:
Inspect the unit for any defect or damage sustained in transit.
Clean the unit using a moist cloth and a small quantity of dishwashing detergent, then wipe it
down dry with a piece of lintless cloth.
Check that the data appearing on the nameplate match those of your local mains supply.
Electrical safety functions must be carried out and checked for operability.
Check all screw connections for tightness.
Familiarize yourself with the Instructions for Use and with the conditions for the safe operation of
this appliance.
Faulty equipment must not be taken into operation!

GBA B 0041 1 E
BA Page 12 of 27 Juni 11, 2014
Last revised 06-2014 Rev. 1
Scholl Apparatebau GmbH & Co. KG
ASSEMBLY INSTRUCTIONS
Legal requirements and the connection conditions of your local power supply company must be fully
observed.
Before connecting or repairing the appliance, see to it that it is fully de-energized. Pull the CEE 7/4
two-pole and earthing-pin plug from the mains socket-outlet or switch off the circuit breaker.
Full protection against electric shock hazard must be ensured by the installation.
The appliance is supplied ready for plug-in and must only be connected to a two-pole and earthing-
pin type socket-outlet installed in compliance with applicable regulations. Any relocation of a socket
outlet or replacement of the connecting cord must only be carried out by an electrical specialist tak-
ing into account the relevant codes.
If the plug is no longer accessible once the appliance is installed, an all-pole disconnecting device
having a contact spacing of at least 3 mm must be provided on the installation side to comply with
applicable safety requirements.

GBA B 0041 1 E
BA Page 13 of 27 Juni 11, 2014
Last revised 06-2014 Rev. 1
Scholl Apparatebau GmbH & Co. KG
OPERATION
The buffet-heat-lamp has one main switch and the buffet-heat-lamp BiTherm has two main switches placed
in the stand.
The buffet-heat-lamp must be switched on/off by the main switch.
Indications:
Do not touch the infrared radiator! Burn injury!
Never cover the appliance while operating. Fire hazard!
Please read chapter Conventions.

GBA B 0041 1 E
BA Page 14 of 27 Juni 11, 2014
Last revised 06-2014 Rev. 1
Scholl Apparatebau GmbH & Co. KG
MAINTENANCE
MAINTENANCE AND REPAIR
Maintenance and repairs on the appliance must only be carried out by an authorized
professional observing applicable safety regulations.
Improperly executed work will put your safety at risk.
CLEANING AND CARE
Allow the unit to cool down before cleaning it. Burn hazard!
Stainless steel is particularly susceptible to scratching!
Remove lime, grease and starch residue immediately to avoid the formation of
stains.
When using a cleaning product, observe the instructions for use provided by its
manufacturer.
For light cleaning, wipe down the surface with a cloth or soft brush/sponge soaked in
warm water containing a small amount of dishwashing detergent. Follow this up by
wiping with clear water until no cleaning agent residue remains on the surface, as the
latter might cause discoloration or stains. Finish by rubbing the surface dry.
To remove more stubborn or extensive residue, a stainless steel cleaning product may
be used.
Never use any of the following for cleaning:
aggressive or bleaching products, i.e., containing active oxygen, chlorine, or
caustic/corrosive constituents;
abrasive cleaning products such as scouring creams/pastes, steel wool, sapon-
ified steel wool, metal or plastic sponges, or sponges with a scratchy surface
(scouring side).
We recommend you to clean the stainless steel surface once per week using a stand-
ard commercial stainless steel care product. This will result in the formation of a pro-
tective layer which prevents discoloration of the stainless steel surface.
In any event, observe the product manufacturer's instructions and try each product in
a small area first before applying it to a larger surface.

GBA B 0041 1 E
BA Page 15 of 27 Juni 11, 2014
Last revised 06-2014 Rev. 1
Scholl Apparatebau GmbH & Co. KG
TROUBLESHOOTING
Repairs must be carried out by an authorized specialist in compliance with applicable
safety codes and regulations.
Improperly executed work will put your safety at risk!
Note that some work must only be carried out by an electrical specialist. According to DIN EN 60204-1:
2011-01, specialists are „persons who by reason of their relevant training and experience are capable of
recognizing risks and avoiding potential hazards."
Some malfunctions you may be able to remedy yourself. Always check first if the problem is due to an oper-
ating error. Repairs are not free of charge, even within the warranty period, if the problem is caused by an
operating error or if you have failed to observe any of the following instructions.
Before any cleaning, maintenance or repair work is carried out, the appliance must
be disconnected from the mains and de-energized. To do so, it is not enough to set
the power switch to OFF. Instead, the mains plug must be pulled or the electrical
circuit must be de-energized, respectively. Check that no voltage is present before
opening the appliance, and lock out the circuit to make it safe against re-energizing.
Problem
Cause
Remedy
Appliance not working
Defective plug/electrical cord
DANGER!
Hazardous electrical voltage. Pull
out the mains plug and bar prod-
uct from further use.
To be remedied by an electrical
specialist.
Appliance not working
Infrared radiator faulty
Exchange infrared radiator
Appliance not working
Main switch faulty
To be remedied by an electrical
specialist.

GBA B 0041 1 E
BA Page 16 of 27 Juni 11, 2014
Last revised 06-2014 Rev. 1
Scholl Apparatebau GmbH & Co. KG
TECHNICAL DATA
Colour Chromium-plated Art. No. B 0041, B 0043, B 0051, B 0061
Chromium-plated, white Art. No. B 0047
Chromium-plated, black Art. No. B 0048
Gold Art. No. B 0042, B 0044, B 0052, B 0062
Voltage 230V~
Electrical power 250W Art. No. B 0041, B 0042, B 0047, B 0048,
Art. No. B 0051, B 0052, B 0061, B 0062
500W Art. No. B 0043, B 0044
Equipment Art. No. B 0041, B 0042, B 0043, B 0044, B 0047, B 0048:
Heat-lamp with lamp shade, flexible arm, stand, main switch,
connection line ca. 2,0m with two-pin earthed plug,
incl. 250W infrared radiator white light
Art. No. B 0051, B 0052:
Heat-lamp with lamp shade, flexible arm, connection line ca. 2,0m,
with screw fitting for built-in, incl. 250W infrared radiator white light
Art. No. B 0061, B 0062:
Heat-lamp with lamp shade, flexible arm, connection line ca. 2,0m,
table board fixing mobile, incl. 250W infrared radiator white light

GBA B 0041 1 E
BA Page 17 of 27 Juni 11, 2014
Last revised 06-2014 Rev. 1
Scholl Apparatebau GmbH & Co. KG
DIMENSIONED DRAWING
Dimensioned drawing Art. No. B 0041, B 0042, B 0047, B 0048
Dimensioned drawing Art. No. B 0043, B 0044

GBA B 0041 1 E
BA Page 18 of 27 Juni 11, 2014
Last revised 06-2014 Rev. 1
Scholl Apparatebau GmbH & Co. KG
Dimensioned drawing Art. No. B 0051, B 0052
Dimensioned drawing Art. No. B 0061, B 0062

GBA B 0041 1 E
BA Page 19 of 27 Juni 11, 2014
Last revised 06-2014 Rev. 1
Scholl Apparatebau GmbH & Co. KG
CIRCUIT DIAGRAM
Q1 –Switch Q1, Q2 - Switch
R1 –infrared radiator white light R1, R2 - infrared radiator white light
Circuit diagram Art. No. B 0041, B 0042, B 0047, B 0048 Circuit diagram Art. No. B 0043, B 0044
R1 –infrared radiator white light
Circuit diagram Art. No. B 0051, B 0052, B 0061, B 0062

GBA B 0041 1 E
BA Page 20 of 27 Juni 11, 2014
Last revised 06-2014 Rev. 1
Scholl Apparatebau GmbH & Co. KG
SPARE PARTS LIST
Maintenance and repairs on the appliance must only be carried out by an authorized
professional observing applicable safety regulations.
Improperly executed work will put your safety at risk.
Spare parts list Art. No. B 0041
component
label
TB-013106
tube for 24000/B/C
TB-012433
lamp holder
85,09,20
serrated locknut DIN 6923 M10x1
82,20,52
flexible lamp arm chromium-plated M12
82,20,27
lamp shade copper chromium-plated 1-part
74,70,52
unit base 20x20 mm
73,90,22
wiring harness 24000 B
73,80,65
fiberglass insulating tubing 6mm 400°C
73,70,30
connection cable 3x1,0 H05RN-F
73,42,02
threaded tube M10x1x15/ 24000
73,40,19
cable relief plastic
73,20,05
E27 porcelain socket 3-part SHT
73,15,03
switch 1801.1102/27001
71,40,06
infrared lamp 250W, 230V white light
Spare parts list Art. No. B 0042
component
label
TB-013143
tube for 24000/B/G
TB-012433
lamp holder
85,09,20
serrated locknut DIN 6923 M10x1
82,20,53
flexible lamp arm polished M12
82,20,28
lamp shade brass 1-part
74,70,52
unit base 20x20 mm
73,90,22
wiring harness 24000 B
73,80,65
fiberglass insulating tubing 6mm 400°C
73,70,30
connection cable 3x1,0 H05RN-F
73,42,02
threaded tube M10x1x15/ 24000
73,40,19
cable relief plastic
73,20,05
E27 porcelain socket 3-part SHT
73,15,03
switch 1801.1102/27001
71,40,06
infrared lamp 250W, 230V white light
