Scholl 22001/MM User manual

GBA B 0020 2 E
BA Page 1 of 30 Dezember 22, 2017
Last revised 12-2017 Rev. 2
Scholl Apparatebau GmbH & Co. KG
Instructions for Use
Heat lamps solid
Heat lamp rail design
Solid Solid Chromium Black
brass cooper plated
Art.-No. B 0020 B 0021 B 0022 B 0023
Model-No. 22001/MM 22001/MK 22001/C 22001/SW
CNS CNS CNS CNS CNS
Art.-No. B 0113 B 0114 B 0115 B 0116 B 0117
Model-No. 28060-2 28090-3 28120-4 28150-5 28180-6
Scholl Apparatebau GmbH & Co. KG
Zinhainer Weg 4
D–56470 Bad Marienberg/Germany
Phone [phone]
Fax [phone] (Service)
Internet www.scholl-gastro.de
E-mail [e-mail]

GBA B 0020 2 E
BA Page 2 of 30 Dezember 22, 2017
Last revised 12-2017 Rev. 2
Scholl Apparatebau GmbH & Co. KG
TABLE OF CONTENTS
Table of contents............................................................................................................................................... 2
Preface............................................................................................................................................................... 4
1Conventions............................................................................................................................................... 5
1.1 Pictograms –General safety notes .................................................................................................. 5
1.2 Pictograms –Warning notes............................................................................................................ 7
1.3 Pictograms –Important notes ......................................................................................................... 8
2Product information .................................................................................................................................. 9
2.1 Information regarding compliance with standards, laws and directives ......................................... 9
2.2 Safety ............................................................................................................................................... 9
3Packing, transport, intermediate storage, scope of delivery .................................................................. 10
3.1 Packing ........................................................................................................................................... 10
3.2 Transport........................................................................................................................................ 10
3.3 Intermediate storage ..................................................................................................................... 10
3.4 Scope of delivery............................................................................................................................ 10
4Installation and electrical installation ..................................................................................................... 11
4.1 Installation ..................................................................................................................................... 11
4.2 Electrical installation ...................................................................................................................... 12
5Operation ................................................................................................................................................ 13
5.1 Intended use .................................................................................................................................. 13
5.2 Unintended use.............................................................................................................................. 13
6Maintenance ........................................................................................................................................... 14
6.1 Maintenance and repair ................................................................................................................ 14
6.2 Cleaning and care........................................................................................................................... 14
7Troubleshooting ...................................................................................................................................... 16
7.1 Possible malfunctions .................................................................................................................... 17

GBA B 0020 2 E
BA Page 3 of 30 Dezember 22, 2017
Last revised 12-2017 Rev. 2
Scholl Apparatebau GmbH & Co. KG
8Technical data.......................................................................................................................................... 18
8.1 Execution ....................................................................................................................................... 18
8.2 Dimensioned drawings .................................................................................................................. 19
8.2.1 Dimensioned drawing heat lamp solid ...................................................................................... 19
8.2.2 Dimensioned drawing heat lamp rail design Art.-No. B 0114 ................................................... 20
8.3 Circuit diagrams ............................................................................................................................. 21
8.3.1 Circuit diagram heat lamp solid ................................................................................................. 21
8.3.2 Circuit diagram heat lamp rail design Art.-No. B 0113 .............................................................. 22
8.3.3 Circuit diagram heat lamp rail design Art.-No. B 0114 .............................................................. 23
8.3.4 Circuit diagram heat lamp rail design Art.-No. B 0115 .............................................................. 24
8.3.5 Circuit diagram heat lamp rail design Art.-No. B 0116 .............................................................. 25
8.3.6 Circuit diagram heat lamp rail design Art.-No. B 0117 .............................................................. 26
8.4 Spare parts list ............................................................................................................................... 27
9Disposal and Environmental Notes ......................................................................................................... 28
9.1 Disposal of packing material .......................................................................................................... 28
9.2 Disposal of the appliance ............................................................................................................... 28
10 Warranty and service ......................................................................................................................... 29
10.1 Warranty conditions ...................................................................................................................... 29
10.2 Service............................................................................................................................................ 29
10.3 Service address .............................................................................................................................. 30

GBA B 0020 2 E
BA Page 4 of 30 Dezember 22, 2017
Last revised 12-2017 Rev. 2
Scholl Apparatebau GmbH & Co. KG
PREFACE
Congratulations!
In purchasing this new SCHOLL appliance you have chosen a product which meets highest technical stand-
ards while providing outstanding convenience in practical use.
This appliance has been designed with minimal energy consumption in mind. Used responsibly, it will serve
you well in an ecologically sound manner.
Please read the information in this manual carefully before starting up this appliance. On the following
pages you will find important notes regarding its operation, care and maintenance so that you will be able
to enjoy its use for a long time.
If a malfunction should nevertheless occur, please consult the "Troubleshooting" section first. In many cases
you should be able to remedy minor problems yourself, thus saving unnecessary service costs.
Please retain this manual carefully and pass it on to any subsequent user for his or her information and
safety.
A quality product, properly treated, will give you many years of satisfactory service.
We trust you will enjoy using this product!
Yours sincerely
Gustav Scholl Apparatebau GmbH & Co. KG

GBA B 0020 2 E
BA Page 5 of 30 Dezember 22, 2017
Last revised 12-2017 Rev. 2
Scholl Apparatebau GmbH & Co. KG
1 CONVENTIONS
1.1 PICTOGRAMS –GENERAL SAFETY NOTES
Be sure to observe these Instructions for Use as well as the safety notes to prevent
injuries or damage to health or property. Do not alter or modify this appliance.
Never use a defective appliance. If you suspect the unit of being faulty or discover
an unusual noise or smell, turn off the power switch and pull the plug out of the
socket-outlet, or otherwise disconnect the appliance from the mains and de-
energize it (i.e., ensure that it no longer carries any voltage). Do not use this appli-
ance when its power cord is damaged.
Failure to observe this warning may result in a fire hazard or electrical shock!
Maintenance and repair work must be carried out only by qualified professionals
using original spare parts and accessories. Do not attempt to carry out repairs on
this appliance yourself!
Connect this appliance to suitably earthed mains outlets only. Ensure that your
mains power supply conforms to the data stated on the nameplate of the appliance.
Failure to observe this warning may result in a fire hazard or electrical shock!
This appliance is not intended to be used by persons (including children) of limited
physical, sensory or intellectual abilities, or lacking in experience and/or knowledge,
unless they are supervised by a person responsible for safety who instructs them in
the use of the device. Children should be supervised to ensure they will not play
with this appliance.
Do not allow this appliance to operate unattended. Ensure that its power switch is
set to „0“ before inserting the plug into an electrical socket-outlet. Avoid starting
the unit unintentionally. Connecting the unit to the mains with its power switch set
to ON may cause accidents.
Protect this appliance from moisture (water spray, rain). Do not immerse the appli-
ance in water or other fluids and do not place it in a dishwasher. Any penetration of
water into the unit will increase the risk of an electrical shock.

GBA B 0020 2 E
BA Page 6 of 30 Dezember 22, 2017
Last revised 12-2017 Rev. 2
Scholl Apparatebau GmbH & Co. KG
Do not touch the surfaces of the appliance. The surfaces of this appliance may get
hot. Please allow the unit to cool down fully before cleaning or stowing it. Never
cover this appliance.
Burn injury or fire hazard!
Caution: Do not look into the heat radiators/light source!
Risk of eye damage!

GBA B 0020 2 E
BA Page 7 of 30 Dezember 22, 2017
Last revised 12-2017 Rev. 2
Scholl Apparatebau GmbH & Co. KG
1.2 PICTOGRAMS –WARNING NOTES
Cleaning must only be performed by qualified persons who have read and under-
stood these Instructions for Use and are familiar with applicable hygiene rules. En-
sure that care is exercised during cleaning of the unit.
For light cleaning, wipe down the surface with a cloth or soft brush/sponge soaked
in warm water which contains a small amount of dishwashing detergent. Follow this
up by wiping with clear water until no cleaning agent residue remains on the sur-
face, as the latter might cause discoloration or stains. Finish by rubbing the surface
dry.
To remove more stubborn or extensive residue, a stainless steel cleaning product
may be used.
Never use any of the following for cleaning:
aggressive or bleaching products, i.e., containing active oxygen, chlorine, or
caustic/corrosive constituents.
abrasive cleaning products such as scouring creams/pastes, steel wool, sa-
ponified steel wool, metal or plastic sponges, or sponges with a scratchy
surface (scouring side).
Never use steam and/or pressure jet cleaning equipment to clean this appliance!
This might damage the appliance to the point where it may
pose a hazard to your life!
Before any cleaning, maintenance or repair work is carried out, the appliance must
be disconnected from the mains and de-energized. To do so, it is not enough to set
the power switch to OFF. Instead, the mains plug must be pulled or the electrical
circuit must be de-energized, respectively. Check that no voltage is present before
opening the appliance, and lock out the circuit to make it safe against re-energizing.
The total permitted regeneration and hot-holding time according to HACCP will be
exceeded after 3 hours.
Risk of potential health impairment!
Allow the unit to cool down before starting any cleaning work.
Burn hazard!

GBA B 0020 2 E
BA Page 8 of 30 Dezember 22, 2017
Last revised 12-2017 Rev. 2
Scholl Apparatebau GmbH & Co. KG
1.3 PICTOGRAMS –IMPORTANT NOTES
DANGER
indicates an immediately threatening hazard.
Failure to observe this warning notice will result in severe physical injury or death.
WARNING
indicates a potentially dangerous situation.
Failure to observe this warning notice may result in severe physical injury or
death.
CAUTION
indicates a potentially harmful situation.
Failure to observe this notice may result in damage to property.
DANGER –electrical voltage
indicates an immediately threatening hazard.
Failure to observe this warning notice will result in severe physical injury or death.
CAUTION! IMPORTANT
Improper use may result in minor injuries or damage to property.
In addition to these Instructions for Use, a number of accident prevention and other
regulations apply with regard to the operation of this appliance. As regards food
handling, please observe HACCP rules concerning compliance with hygiene require-
ments.
If you have any questions, please contact your supervisor(s) or safety representa-
tive.
This product must not be disposed of in domestic waste.
Please arrange for proper recycling of this product via your local provider of waste
disposal services.

GBA B 0020 2 E
BA Page 9 of 30 Dezember 22, 2017
Last revised 12-2017 Rev. 2
Scholl Apparatebau GmbH & Co. KG
2 PRODUCT INFORMATION
The heat lamp may only be used to keep dishes short-term warm.
The warm keeping temperature depends on the distance between heat lamp and dishes.
2.1 INFORMATION REGARDING COMPLIANCE WITH STANDARDS,LAWS AND DIRECTIVES
This appliance conforms to the following:
Standards, laws, directives
2014/35/EU
Low Voltage Directive
2014/30/EU
EMC Directive
2.2 SAFETY
This appliance conforms to accepted technical rules and relevant safety codes.
However, proper use of the appliance is a prerequisite for effectively preventing
damage or accidents. Please comply with the notes provided in these Instructions
for Use.
Further safety notes, refer to section
1.1 Pictograms –General safety notes
1.2 Pictograms –Warning notes
1.3 Pictograms –Important notes

GBA B 0020 2 E
BA Page 10 of 30 Dezember 22, 2017
Last revised 12-2017 Rev. 2
Scholl Apparatebau GmbH & Co. KG
3 PACKING,TRANSPORT,INTERMEDIATE STORAGE,SCOPE OF DELIVERY
3.1 PACKING
The type of packing employed will depend, to a large extent, on the adopted shipping mode and route.
Except where otherwise agreed by contract, packing will conform to the "HPE Packing Guideline" defined by
the German Federal Association of the Wooden Materials, Pallets and Export Packing Industry and by the
German Engineering Federation.
3.2 TRANSPORT
Particular care must be exercised during shipping and handling of this appliance to prevent damage result-
ing from exposure to excessive force or careless loading/unloading.
Shocks during shipping and handling must be avoided.
The appliance itself must be handled with care.
3.3 INTERMEDIATE STORAGE
Appliances not to be installed immediately upon delivery must be carefully stored in a protected place. For
the duration of such storage they must be properly covered to prevent any ingress of dust and moisture
into the unit.
3.4 SCOPE OF DELIVERY
The content of the delivery is stated in the delivery note and must be checked for completeness upon re-
ceipt.
Any damage in transit and/or missing items must be reported in writing immediately.

GBA B 0020 2 E
BA Page 11 of 30 Dezember 22, 2017
Last revised 12-2017 Rev. 2
Scholl Apparatebau GmbH & Co. KG
4 INSTALLATION AND ELECTRICAL INSTALLATION
4.1 INSTALLATION
Before the installation of the appliance, observe the following:
Inspect the unit for any defect or damage sustained in transit.
Check all screw connections for tightness.
Familiarize yourself with the Instructions for Use and with the conditions for the safe operation of this
appliance.
Clean the heat lamp before the first use according to chapter “Cleaning and care”.
Practice:
Mount the heat lamp at a suitable location.
Check or adjust the tension of the coiled cord draft mechanism.
The traction can be adjusted at the draft mechanism:
Unscrew the canopy and carefully push it down.
Justify the traction so that the heat lamp is easily adjustable in height but
not pulled down by its self-weight.
For less traction, turn the red pointer to the left.
For more traction, turn the red pointer to the right.
Carefully push the canopy upwards and screw it on again.

GBA B 0020 2 E
BA Page 12 of 30 Dezember 22, 2017
Last revised 12-2017 Rev. 2
Scholl Apparatebau GmbH & Co. KG
4.2 ELECTRICAL INSTALLATION
The appliance may only be installed by a qualified electrician whilst taking into
account the applicable regulations!
Connect this appliance to suitably earthed mains outlets only. Ensure that your
mains power supply conforms to the data stated on the nameplate of the appliance.
Failure to observe this warning may result in a fire hazard or electrical shock!
Before putting the appliance into service, observe the following:
Faulty equipment must not be taken into operation!
Legal requirements and the connection conditions of your local power supply company must be fully
observed.
Electrical safety functions must be carried out and checked for operability.
Full protection against electric shock hazard must be ensured by the installation.
Device with supply cable and plug:
If the plug is no longer accessible once the appliance is installed, an all-pole disconnecting device having
a contact spacing of at least 3 mm must be provided on the installation side to comply with applicable
safety requirements.

GBA B 0020 2 E
BA Page 13 of 30 Dezember 22, 2017
Last revised 12-2017 Rev. 2
Scholl Apparatebau GmbH & Co. KG
5 OPERATION
The heat lamp has a main switch placed in the lamp shade.
The heat lamp must be switched on/off by the main switch.
5.1 INTENDED USE
Practice:
Switch on the heat lamp with the main switch.
The heat lamp is ready for operation and the foods to be kept warm can be placed under the heat
lamp.
The food must be preheated and must not be deep-frozen!
For switching off after use of the heat lamp:
Switch off the heat lamp with the main switch.
Let the heat lamp cool off.
Do not touch the infrared radiator!
Danger of burns!
Caution: Do not look into the heat radiators/light source!
Risk of eye damage!
Do not touch the device surfaces. The surfaces of the device may grow hot. Please
let the device cool off entirely before cleaning it. Do not cover the device.
Danger of burns and fire!
5.2 UNINTENDED USE
Please observe strictly:
Heat lamps are not for defrosting/warming up of deep-frozen/cooled food.

GBA B 0020 2 E
BA Page 14 of 30 Dezember 22, 2017
Last revised 12-2017 Rev. 2
Scholl Apparatebau GmbH & Co. KG
6 MAINTENANCE
6.1 MAINTENANCE AND REPAIR
Maintenance and repairs on the appliance must only be carried out by an author-
ized professional observing applicable safety regulations.
Improperly executed work will put your safety at risk!
Before any cleaning, maintenance or repair work is carried out, the appliance must
be disconnected from the mains and de-energized. To do so, it is not enough to set
the power switch to OFF. Instead, the mains plug must be pulled or the electrical
circuit must be de-energized, respectively. Check that no voltage is present before
opening the appliance, and lock out the circuit to make it safe against re-energizing.
6.2 CLEANING AND CARE
Never use steam and/or pressure jet cleaning equipment to clean this appliance!
This might damage the appliance to the point where it may
pose a hazard to your life!
Allow the unit to cool down before cleaning it. Burn hazard!
Stainless steel is particularly susceptible to scratching!
Remove lime, grease and starch residue immediately to avoid the formation of
stains.
When using a cleaning product, observe the instructions for use provided by its
manufacturer.

GBA B 0020 2 E
BA Page 15 of 30 Dezember 22, 2017
Last revised 12-2017 Rev. 2
Scholl Apparatebau GmbH & Co. KG
Cleaning must only be performed by qualified persons who have read and under-
stood these Instructions for Use and are familiar with applicable hygiene rules. En-
sure that care is exercised during cleaning of the unit.
For light cleaning, wipe down the surface with a cloth or soft brush/sponge soaked
in warm water containing a small amount of dishwashing detergent. Follow this up
by wiping with clear water until no cleaning agent residue remains on the surface,
as the latter might cause discoloration or stains. Finish by rubbing the surface dry.
To remove more stubborn or extensive residue, a stainless steel cleaning product
may be used.
Never use any of the following for cleaning:
aggressive or bleaching products, i.e., containing active oxygen, chlorine, or
caustic/corrosive constituents;
abrasive cleaning products such as scouring creams/pastes, steel wool, sa-
ponified steel wool, metal or plastic sponges, or sponges with a scratchy
surface (scouring side).
We recommend you to clean the stainless steel surface once per week using a
standard commercial stainless steel care product. This will result in the formation of
a protective layer which prevents discoloration of the stainless steel surface.
In any event, observe the product manufacturer's instructions and try each product
in a small area first before applying it to a larger surface.

GBA B 0020 2 E
BA Page 16 of 30 Dezember 22, 2017
Last revised 12-2017 Rev. 2
Scholl Apparatebau GmbH & Co. KG
7 TROUBLESHOOTING
Repairs must be carried out by an authorized specialist in compliance with applica-
ble safety codes and regulations.
Improperly executed work will put your safety at risk!
Note that some work must only be carried out by an electrical specialist. According to DIN EN 60204-1:
2011-01, specialists are „persons who by reason of their relevant training and experience are capable of
recognizing risks and avoiding potential hazards."
Some malfunctions you may be able to remedy yourself. Always check first if the problem is due to an oper-
ating error. Repairs are not free of charge, even within the warranty period, if the problem is caused by an
operating error or if you have failed to observe any of the following instructions.
Before any cleaning, maintenance or repair work is carried out, the appliance must
be disconnected from the mains and de-energized. To do so, it is not enough to set
the power switch to OFF. Instead, the mains plug must be pulled or the electrical
circuit must be de-energized, respectively. Check that no voltage is present before
opening the appliance, and lock out the circuit to make it safe against re-energizing.
Work at the electrical installation must only be performed by qualified
electricians!
Maintenance and repair work must be carried out only by qualified professionals
using original spare parts and accessories. Do not attempt to carry out repairs on
this appliance yourself!

GBA B 0020 2 E
BA Page 17 of 30 Dezember 22, 2017
Last revised 12-2017 Rev. 2
Scholl Apparatebau GmbH & Co. KG
7.1 POSSIBLE MALFUNCTIONS
Malfunction
Cause
Remedy
Heat lamp does not heat
Defective plug/electrical cord
DANGER!
Hazardous electrical voltage.
Pull out the mains plug and bar
product from further use.
To be remedied by an electrical
specialist.
Heat lamp does not heat
Infrared radiator faulty
Exchange infrared radiator.
Heat lamp does not heat
Main switch faulty
To be remedied by an electrical
specialist.

GBA B 0020 2 E
BA Page 18 of 30 Dezember 22, 2017
Last revised 12-2017 Rev. 2
Scholl Apparatebau GmbH & Co. KG
8 TECHNICAL DATA
8.1 EXECUTION
Heat lamp solid with:
lamp shade 225 mm diameter made of
solid brass B 0020
solid copper B 0021
chromium plated B 0022
black B 0023
casing with on-off switch
black rosette 100 mm diameter
with helix cable continuously adjustable from 850 mm - 1.700 mm
with infrared radiator white light 250 W
Heat lamp rail design with:
one continuous rail made of chrome nickel steel 18/10
for several heat lamps (2 –6) adjacent to each other
Depth: 120 mm
Height: 30 mm
Model-No.
Art.-No.
Length
Heat lamp
Voltage
Power
28060-2
B 0113
600 mm
2
230 V
500 W
28090-3
B 0114
900 mm
3
230 V
750 W
28120-4
B 0115
1.200 mm
4
230 V
1.000 W
28150-5
B 0116
1.500 mm
5
230 V
1.250 W
28180-6
B 0117
1.800 mm
6
230 V
1.500 W

GBA B 0020 2 E
BA Page 19 of 30 Dezember 22, 2017
Last revised 12-2017 Rev. 2
Scholl Apparatebau GmbH & Co. KG
8.2 DIMENSIONED DRAWINGS
Dimensioned drawings are available upon request.
The information in the dimensioned drawings always take precedence over the summary of the technical
data in chapter 8.1.
8.2.1 DIMENSIONED DRAWING HEAT LAMP SOLID
Model-No. Art. No.
22001/MM B 0020
22001/MK B 0021
22001/C B 0022
22001/SW B 0023

GBA B 0020 2 E
BA Page 20 of 30 Dezember 22, 2017
Last revised 12-2017 Rev. 2
Scholl Apparatebau GmbH & Co. KG
8.2.2 DIMENSIONED DRAWING HEAT LAMP RAIL DESIGN ART.-NO.B0114
Model-No. Art. No.
28090-3 B 0114
