MODE 3 EV WALL CHARGER
SEV455

- 2 -
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Read the instructions before use. Keep these instructions for
further reference.
This manual will explain how to use the appliance safely and
eectively. Please read and follow these instructions and
safety guidelines carefully. Failure to do so could result in
severe injury or death.
Read, understand, and follow all instructions of the vehicle
and any equipment used.
Risk of electric shock.
Risk of fire.
Ground earth connection required.
Installation, maintenance, and servicing of the appliance must
be performed only by qualified personal per the applicable
local regulations.
1. The appliance is not intended to be used by persons (including
children) with reduced physical, sensory, or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instructions.
2. Children should be supervised to not play with the appliance.
3. Install and use in dry, well-ventilated area away from liquids.
4. Do not touch the charging cable if the connector emits smoke or
begins to melt. If possible, stop charging.
5. Dangers from electromagnetic fields (EMF) for persons with
pacemakers and defibrillators.
• Persons with pacemakers must maintain a distance of at least
60cm.
• Persons with defibrillators must maintain a distance of at least
40cm.
6. Do not use if the cable or the vehicle plug is damaged.
7. Ventilation not supported.
8. It is mandatory to use the plug holder provided with the unit to
protect the connector from dirt and other weather elements and
from slipping during usage.
9. The appliance is intended exclusively for charging compatible
electric vehicles.
EN - English

- 3 -
10. Refer to the instructions for cleaning and user maintenance.
11. Switch o main electrical power to the appliance before installing or
performing maintenance.
12. Do not operate the appliance outside the permissible ambient
temperature range from -30°C to 50°C.
13. Do not attempt to troubleshoot or repair the appliance yourself.
Any modification of the appliance are prohibited. Contact the
manufacturer or your distributor for more information.
14. Only pull the charging gun by the handle and never by the cable.
15. Before connecting the charging cable to the vehicle, unwind the
cable completely. Make sure that the charging cable does not have
any overlapping loops.
16. Do not put your fingers or other objects inside the charging port or
gun.
17. Never clean the appliance with a pressurised water jet. Never use it
with wet hands. Do not immerse the charging gun in liquid.
18. Adapters, conversion adapters, or extension cords should never be
used on this appliance.
19. Disconnect the charging cable from the electric vehicle before
driving away.
20. It is not recommended to install the appliance in a position that has
direct sunlight or under extreme weather conditions.
21. Ensure that the mounting surface can adequately support the
weight of the charger and withstand mechanical forces associated
with usage.
22. In case of fire, please contact the emergency service to seek help.
When safe conditions exist, turn o the power to the device that
is on fire or threatened by flames. Do not use water to extinguish
flames in electrical installations and live devices. To extinguish flames
from a charging station, use a fire extinguisher that is designed for
electrical use with a rating up to 1kV.
23. Electrical products should not be discarded with household
products. Electrical products used must be collected separately and
disposed of at collections points provided for this purpose. Talk with
your local authorities or dealer for advice on recycling.
GETTING STARTED
Before installing or operating the Schumacher Mode
3 EV Wall Charger, use the QR code on the right to
download the SchuPowerTM app, which will allow you to
monitor your EV charging status, schedule charging, or
track your vehicle’s charging history.
EN - English

- 4 -
FEATURES
TOOLS NEEDED FOR INSTALLATION
YOU WILL NEED THE FOLLOWING TO COMPLETE INSTALLATION OF
THE SCHUMACHER MODE 3 EV WALL CHARGER.
IN THE BOX
Please check to ensure all parts are included.
1. Charging station
2. Output cable with EV connector
3. Current transfer (CT) coil for Dynamic Power Management
4. Mounting Template
5. Cable cradle
6. Two 5.5 mm (.22 in.) x 50 mm (2 in.) lag screws for wall mounting
7. Two 4 mm (.16 in.) x 16 mm (.63 in.) self-tapping screws to attach the
cable cradle
1. Stud finder
2. Pencil
3. Tape
4. Level
5. Drill
6. Phillips head screwdriver
Durable, raintight
Housing
Charging
Status LED
Power LED
Wi-Fi® LED
O
Lockable, Ergonomic
Charging Gun
Charging
Gun LED
DLM
CT Coil
5m Cable
EN - English

- 5 -
INSTRUCTIONS PERTAINING TO A RISK OF
ELECTRIC SHOCK
For a permanently connected product: MODEL SEV455
GROUNDING INSTRUCTIONS
This product must be connected to a grounded, metal, permanent
wiring system, or an equipment-grounding conductor must be run with
the circuit conductors and connected to the equipment grounding
terminal or lead on the product.
INSTALLATION INSTRUCTIONS
CAUTION: The Schumacher Mode 3 EV Wall Charger
must be installed by a licensed electrician. Any
changes to the wall charger’s electrical settings (pages
11-14) must be made by a licensed electrician.
NOTE FOR INSTALLERS: Use a recidual current
detection (RCD) module type A or B for the installation
to protect the line from a short-circuit of the charger.
Follow all applicable local rules. The SEV455 is
equipped with a 30mA AC / 6mA DC RCD.
DLM
MCB
1
2
N
2
4
L
SPD
OUTPUT EC9 INPUT EC1
J9 DLM J1
N
L
EN - English

- 6 -
CHOOSING A LOCATION
1. This device shall be mounted at a sucient height from grade such
that the height of the storage means for the coupling device is
located between 600 mm and 1.2 m above grade.
2. Before starting the installation, choose a general mounting location
for the unit. The unit may be installed indoors or outdoors. Ensure
that the unit is within easy reach of where the hardwired circuit will
be installed by a licensed electrician. The wiring leading into the
charging station should have some slack. The mounting location
should also allow the output cable with EV connector to have some
slack while in use.
3. Using a stud finder, locate a stud within the general mounting
location identified in the previous step. Use a pencil to mark the
location of the stud.
4. Next, use a level and a
pencil to mark a line to
designate the top of the
charging station when
installation is complete.
This is usually about 125
cm above the finished
floor. Use tape to attach
the mounting template so
that the top edge of the
template lines up with the
pencil line you just made.
ASSEMBLING THE CHARGING STATION
1. Lay the charging station on a flat
surface and remove the lower
front cover. Unscrew the single M4
screw at the bottom of the unit.
Set the screw aside for reassembly.
Then, slide the cover down and lift
to disengage the tabs at the top of
the front cover. Set aside the lower
front cover for reassembly.
EN - English

Wiring
access panel
- 7 -
2. Remove the wiring access panel located underneath the lower front
cover by unscrewing three M4 screws from the front of the charging
station. Set the screws aside for reassembly. Lift o the wiring
access panel and set aside for reassembly.
3. Turn over the charging station before
installing the cable cradle. Align
the cable cradle’s screw holes with
the screw holes on the back of the
charging station. Use the two 4 mm
x 16 mm screws to attach the cable
cradle.
Note: If desired, the cable cradle may
be mounted to the wall separate
from the unit. Be sure to mount the
cable cradle securely to a stud or use
heavy-duty drywall anchors.
HARDWIRING THE POWER SUPPLY PERMANENTLY TO
THE CHARGING STATION
Turn o the power to circuit before installation. Do not restore power
until installation is complete. Failure to do so could result in injury or
death.
1. When installing a hardwired circuit, Schumacher Electric
recommends that the AC input uses a conduit into the rear opening
of the charging station.
2. Turn o the power to the circuit before mounting the charging
station.
EN - English

NPEL
- 8 -
L - Brown Wire
PE (Ground) - Green/Yellow Wire
N (Neutral) - Blue Wire
3. Feed the conduit and wires through the back of the charging station,
removing the back head plug. Feed the cables through the back of
the charging station until the silver conductors are no longer visible.
Note: If installing the charging station outdoors and using the back
opening to route the conduit, apply liquid sealant or a gasket and
nut around the rear opening to prevent water ingress.
4. Inside the wiring access panel, there are two terminal blocks.
Securely insert wires into the left-hand terminal block as indicated
by the wiring diagram below.
EN - English

PE L N
Signal
J1
- 9 -
N (Neutral) - Blue Wire
L - Brown Wire
PE (Ground) - Green/
Yellow Wire
Signal - Red and
White Wire
3. Insert the two-pin plug (red and white wires) into the connector to
the left of the right terminal block.
4. Feed the output cable up into the charging station and secure by
screwing the outer plastic nut to the threaded ring. The threaded
ring must be securely tightened.
MOUNTING THE CHARGING STATION TO THE WALL
1. Using a drill fitted with a 5.5 mm drill
bit, drill two pilot holes into the stud
where indicated by the mounting
template.
2. Drive the 5.5 mm x 50 mm lag screw
without a rubber washer into the top
pilot hole, leaving the head of the screw
6-7 mm above the wall surface.
CONNECTING THE OUTPUT CABLE TO THE CHARGING
STATION
1. The output cable should have five wires visible at the end opposite
the EV connector. Insert the wires through the right-hand opening
on the bottom of the charging station.
2. Insert the wires into the appropriate connectors in the right terminal
block as illustrated in the wiring diagram below.
EN - English

- 10 -
3. Lift the charging station and then use the notch on the back of the
unit to hang the unit from the screw axed to the stud.
4. Align the charging station’s lower mounting hole with the lower pilot
hole you drilled in step 1. Drive the 5.5 mm x 50 mm lag screw with
the rubber washer through the lower mounting hole and into the
pilot hole. Tighten until the charging station is secure.
1. Before starting, the licensed electrician should consult all applicable
codes for breaker and wire sizing requirements. Set the amperage of
the unit according to the connected dedicated breaker associated
with the hardwired connection. Then, set the unit’s DIP switch
following the diagram below that corresponds with the dedicated
breaker’s voltage and amperage and the model’s requirements.
FINAL STEPS
For model SEV455, the following steps must be completed by a
licensed electrician.
EN - English

- 11 -
SETTING*MAX OUTPUT
CURRENT
MAX OUTPUT
POWER
6A 1.38kW
10A 2.30kW
14A 3.22kW
20A 4.60kW
26A 5.98kW
32A 7.40kW
SET DIP SWITCHES WITHOUT CT COIL INSTALLED
The correct installation requires the calibration of the maximum charge
current in order to provide the respective available charging current on
the house.
1. Identify the selector with 8 “DIP switches” on the bottom center of
the electronic board.
2. Set the “DIP switches” by choosing the appropriate combination
identified in table below. Each combination of DIP switches
corresponds to the maximum power (kW) of the user’s building
meter.
* Gray shading in Setting illustrations indicates the DIP switch position.
EN - English

- 12 -
SET DIP SWITCHES WITH CURRENT TRANSFER (CT) COIL
INSTALLED
The current transfer (CT) coil is a current sensor for Dynamic Power
Management. To use the dynamic power management function, a
sensor must be installed downstream of the electricity meter. Based
on the current measured by the sensor, the SEV455 calculates the
building’s energy requirements and modulates the charging current of
the electric vehicle in order to prevent blackouts.
1. The current sensor must be attached to the main cable coming from
the building’s electricity meter and connected to the SEV455 EV
charger. Use the CT coil supplied in the box. Ensure the CT coil is
installed with the arrow on the CT coil pointing to the main box.
2. Installation of the CT coil must be completed by a licensed
electrician.
3. The CT coil’s cables should enter the SEV455 EV charger through
a cable gland at the bottom of the unit. Remove one of the two
rubber caps within the cable gland and pass the cable through the
hole.
4. The two unsheathed cables are then connected to terminals 1
and 2 and the shielded cable should be connected to terminal 3.
Then connect the cable to the J9 connector in the charger. Once
the electrical connection has been completed, the current can be
adjusted.
5. To prolong the CT’s cable, use at least 2 mm x 0.5 mm2 shielded
cable or a CAT5e SF/UTP cable.
Terminal Blocks
J9 Connector
Red 1
2
3
Black
Grounded
EN - English

- 13 -
6. Note: The correct installation requires the calibration of the
maximum charge current.
7. Identify the selector with 8 “DIP switches” on the bottom center of
the electronic board.
8. Set the “DIP switches” by choosing the appropriate combination
identified in table below. Each combination of DIP switches
corresponds to the maximum power (kW) of the user’s building
meter.
EN - English

- 14 -
SETTING
TURNS RATIO
2500:1*
SETTING
TURNS RATIO
3000:1*
DLM
CURRENT
RATING**
MAX
OUTPUT
CURRENT
MAX
OUTPUT
POWER
100A 6A 1.28kW
100A 10A 2.30kW
100A 14A 3.22kW
100A 20A 4.60kW
100A 26A 5.98kW
100A 32A 7.4kW
* Gray shading in Setting illustrations indicates the DIP switch position.
** When replacing the existing CT coil, ensure the current transfer rating
is between 50A and 100A for better precision and reliability.
EN - English

- 15 -
FINAL REASSEMBLY
1. Reattach the wiring access panel you set aside previously. Position
the wiring access panel on the charging station and secure it with
three of the M4 screws you removed earlier. Next, reattach the lower
front cover. Insert the tabs into the slots on the front of the charging
station and slide the cover up and in place. Secure the lower front
cover at the bottom of the charging station with the last M4 screw.
2. Coil the output cable into the cable cradle and insert the EV
connector into the dock on either side of the charging station.
3. Turn the power back on at the circuit breaker. If correctly installed,
the Power LED will illuminate a steady green.
EN - English

- 16 -
OPERATING INSTRUCTIONS
1. Check to make sure the wall charger’s Power LED is illuminated a
steady, solid green color.
2. Remove charging gun from the wall charger’s dock.
3. Connect the charging gun to your vehicle’s charging port.
Note: The charging gun is fitted with a Type 2 connector that will fit
most electric vehicles.
4. Charging begins automatically. Your electric vehicle will control the
charging progress.
5. When charging has stopped, remove the charging gun from your
vehicle’s charging port and return it to the wall charger’s dock.The
charging session may be stopped manually by pressing the O
button on the right side of the charger.
6. Make sure the output cable is neatly stored in the cable cradle.
7. To monitor your EV charging status or track your vehicle’s charging
history, use the wall charger’s Wi-Fi connection and the SchuPowerTM
app. Simply download the SchuPowerTM app and follow the app’s
instructions.
8. Warning: Do not tamper with the charger or its components.
LED BEHAVIORS
• Power LED (green) solid: Power is connected to the wall charger.
• Charging Gun LED (green) fade in/out: Charging is in progress.
• Charging Gun LED (green) solid: Connected to vehicle. The charging
process is complete, paused, or in scheduled charging mode.
• Charging Status LED (blue) solid: The wall charger is powered on and
in standby mode.
• Charging Status LED (green) fade in/out: Charging is in progress.
• Charging Status LED (cyan) flashing: The charging process is
complete or in scheduled charging mode.
• Charging Status LED (red) flashing: Error. Refer to the
troubleshooting guide for guidance.
• Wi-Fi LED (blue) solid: The wall charger is connected to the saved
Wi-Fi network.
• Wi-Fi LED (blue) flashing: The wall charger’s Wi-Fi connection needs
to be configured. This can be completed through the SchuPowerTM app.
• Wi-Fi LED (blue) o: The wall charger cannot connect to the saved
Wi-Fi network.
EN - English

- 17 -
TROUBLESHOOTING
LED Behavior Problem Solution
Power LED o No AC power
Check the breaker. Have a licensed
electrician connect the charging
station to AC power.
Charging Status LED
flashes red two (2)
times
Leakage
Re-power the unit by turning the circuit
breaker o and on again. If the fault
still exists, please consult a licensed
electrician for help or contact our
support service.
Charging Status LED
flashes red three (3)
times Overvoltage
Unplug the charging gun and then
reinsert it into your vehicle’s charging
port. If the fault still exists, please
consult a licensed electrician to
check the AC supply.
Charging Status LED
flashes red four (4)
times
Undervoltage
Unplug the charging gun and then
reinsert it into your vehicle’s charging
port. If the fault still exists, please
consult a licensed electrician to
check the AC supply.
Charging Status LED
flashes red five (5)
times
Overcurrent
Unplug the charging gun and then
reinsert it into your vehicle’s charging
port.
Charging Status LED
flashes red six (6)
times
Over
temperature
Unplug the charging gun and then
reinsert it into your vehicle’s charging
port. If the fault still exists, unplug
the charging gun and allow the unit
to cool down before attempting to
charge again.
Charging Status LED
flashes red seven (7)
times
Ground fault
Unplug the charging gun and then
reinsert it into your vehicle’s charging
port. If the fault still exists, please
consult a licensed electrician to
check the ground connection.
Charging Status LED
flashes red eight (8)
times
Relay fault
Unplug the charging gun and then
reinsert it into your vehicle’s charging
port. If the fault still exists, contact
our support service.
Charging Status LED
flashes red nine (9)
times
Meter chip
fault
Unplug the charging gun and then
reinsert it into your vehicle’s charging
port. If the fault still exists, contact
our support service.
EN - English

- 18 -
SPECIFICATIONS
Input Voltage ................................................................220V-240V AC ~, 50-60Hz
Output Voltage.............................................................220V-240V AC ~, 50-60Hz
Rated Current...............................................................................................................32A
SEV455 Rated Output Power ..........................................................................7.4kW
Configurable Current ...............................................................6/10/14/20/26/32A
Configurable Power ......................................................1.4/2.3/3.2/4.6/6.0/7.4kW
Operating Temperatures .................................................................. -30°C to 50°C
Charging Connector ............................................................................................Type 2
Installation Type ............................................................................... Indoor/Outdoor
IP Rating ................................................................................................ IP66 enclosure
Warranty ............................................................................................. 2-Year Warranty
MAINTENANCE INSTRUCTIONS
Occasionally cleaning the case of the wall charger with a soft cloth will
keep the finish shiny and help prevent corrosion.
EN - English
Charging Status LED
flashes red ten (10)
times
Frequency
fault
Unplug the charging gun and then
reinsert it into your vehicle’s charging
port. If the fault still exists, please
consult a licensed electrictian to
check the AC supply.

- 19 -
TWO-YEAR LIMITED WARRANTY
(Schumacher Electric Corporation Product)
THE WARRANTY APPLIES TO MANUFACTURING AND MATERIAL
FAULTS UNDER NORMAL USE AND CARE DURING A TWO-YEAR
PERIOD FROM THE DATE OF PURCHASE.
TO BENEFIT FROM THE GUARANTEE, THE PURCHASER IS REQUIRED
TO RETURN THE PRODUCT WITH PROOF OF PURCHASE TO THE
PLACE OF PURCHASE.
THE DEVICES ON WHICH WILL HAVE BEEN SEEN ANY ABUSE,
IMPROPER USE OR INSTALLATION OR IMPROPER HANDLING
OR MODIFICATIONS, AS WELL AS ENTRUSTING THE DEVICE TO
BE REPAIRED TO THIRD PARTIES OTHER THAN AUTHORIZED
REPRESENTATIVES WILL VOID THE WARRANTY.
THIS WARRANTY DOES ALSO NOT COVER ANY EXTERNAL CAUSES
SUCH AS TRANSPORTATION, ACCIDENTS, WEATHER OR NATURAL
DISASTERS.
Our dedication to providing the best technology and products is an
ongoing commitment. Engineering and design improvements are
continually being added to our product line and may change the product
appearance and/or specifications at any time.
All images displayed in this manual are unique, for illustration purposes
only, and are not intended to represent or reproduce any copyrighted
material or images.
EN - English

- 20 -
AR - Arabic - ةيبرعلا
  
  
.     .   
     .       
.          .  
.        
.   
. 
.  
.               
     (  )        .1
.                 
.       .2
.           .3
.     .              .4
       (EMF)      .5
. 
               -
. 60
               -
. 40
.         .6
.   .7
               .8
.   
.       .9
.      .10
.          .11
.  50    -30            .12
