SCHUNK TANDEM KSP3-IM User instructions

Translation of Original Operating Manual
TANDEM Clamping Force Block
KSP3-IM, KSP3-LH-IM
Assembly and Operating Manual
Superior Clamping and Gripping

Imprint
2 01.00|KSP3-IM, KSP3-LH-IM |en
Imprint
Copyright:
This manual is protected by copyright. The author is SCHUNK GmbH & Co. KG. All rights
reserved.
Technical changes:
We reserve the right to make alterations for the purpose of technical improvement.
Document number: 1474090
Version: 01.00 |27/05/2021|en
Dear Customer,
thank you for trusting our products and our family-owned company, the leading
technology supplier of robots and production machines.
Our team is always available to answer any questions on this product and other solutions.
Ask us questions and challenge us. We will find a solution!
Best regards,
Your SCHUNK team
H.-D. SCHUNK GmbH & Co.
Spanntechnik KG
Lothringer Str. 23
D-88512 Mengen
Tel. [phone]
Fax [phone]
[email protected]
schunk.com
Customer Management
Tel. [phone]
Fax [phone]
[email protected]
Please read the operating manual in full and keep it close to the product.

Table of contents
01.00|KSP3-IM, KSP3-LH-
IM |en
3
Table of contents
1
General .................................................................................................................... 5
1.1
About this manual .................................................................................................... 5
1.1.1
Presentation of Warning Labels.................................................................... 5
1.1.2
Applicable documents................................................................................... 6
1.1.3
Sizes............................................................................................................... 6
1.2
Warranty................................................................................................................... 6
1.3
Scope of Delivery...................................................................................................... 6
1.4
Accessories ............................................................................................................... 7
2
Basic safety notes .................................................................................................... 8
2.1
Intended use............................................................................................................. 8
2.2
Not intended use...................................................................................................... 8
2.3
Constructional changes ............................................................................................ 9
2.4
Spare parts................................................................................................................ 9
2.5
Use of special chuck jaws ......................................................................................... 9
2.6
Environmental and operating conditions............................................................... 10
2.7
Personnel qualification........................................................................................... 10
2.8
Personal protective equipment.............................................................................. 11
2.9
Notes on safe operation......................................................................................... 12
2.10
Transport ................................................................................................................ 12
2.11
Malfunctions........................................................................................................... 13
2.12
Disposal................................................................................................................... 13
2.13
Fundamental dangers............................................................................................. 13
2.13.1
Protection during handling and assembly .................................................. 14
2.13.2
Protection during commissioning and operation ....................................... 14
2.13.3
Protection against dangerous movements................................................. 15
2.13.4
Notes on particular risks ............................................................................. 16
3
Technical data ......................................................................................................... 18
4
Tightening torques for screws.................................................................................. 21
5
Assembly................................................................................................................. 22
5.1
Assembly of the Clamping Block on the machine table......................................... 23
5.2
Mounting the clamping force block on the base plate .......................................... 24
5.3
Connecting the clamping block .............................................................................. 26
5.3.1
Supply lines ................................................................................................. 27
5.4
Monitoring of the jaw position via inductive proximity switches ......................... 28
5.4.1
Basic construction and dimensions of the inductive proximity switches with
scew-fastened connection cable ................................................................ 29

Table of contents
4 01.00|KSP3-IM, KSP3-LH-IM |en
5.4.2
Dimensions and switching function of the IN S-M8-1 ................................ 30
5.4.3
Dimensions and switching function of the IN S-M8-2 ................................ 31
5.4.4
Assembly and adjustment of the proximity switches................................. 32
5.4.5
Circuit and functional diagram for external workpiece clamping .............. 34
5.4.6
Circuit and functional diagram for internal workpiece clamping............... 36
6
Troubleshooting ...................................................................................................... 38
7
Maintenance and care ............................................................................................. 40
7.1
Notes....................................................................................................................... 40
7.2
Maintenance and lubrication intervals .................................................................. 40
7.3
Greasing areas/lubricants ...................................................................................... 41
7.3.1
Lubrication .................................................................................................. 41
7.3.2
Leak test ...................................................................................................... 48
7.3.3
Assembly device.......................................................................................... 49
8
Sealing kits, accessory packs and parts lists ............................................................. 50
8.1
Sealing kit lists ........................................................................................................ 50
8.2
Accessory packs...................................................................................................... 50
8.3
Parts lists................................................................................................................. 51
8.4
Proximity switches and supply cables for single or replacement orders .............. 53
9
Assembly drawing ................................................................................................... 54
10
Translation of the original declaration of incorporation........................................... 55
11
Appendix on Declaration of Incorporation, as per 2006/42/EC, annex II, No. 1 B ..... 56

General
01.00|KSP3-IM, KSP3-LH-
IM |en
5
General
About this manual
This manual contains important information for a safe and
appropriate use of the product.
This manual is an integral part of the product and must be kept
accessible for the personnel at all times.
Before starting work, the personnel must have read and
understood this operating manual. Prerequisite for safe working is
the observance of all safety instructions in this manual.
Illustrations in this manual are provided for basic understanding
and may differ from the actual product design.
In addition to these instructions, the documents listed under
(1.1.2, Page 6) are applicable.
Presentation of Warning Labels
To make risks clear, the following signal words and symbols are
used for safety notes.
DANGER
Danger for persons!
Non-observance will inevitably cause irreversible injury or death.
WARNING
Dangers for persons!
Non-observance can lead to irreversible injury and even death.
CAUTION
Dangers for persons!
Non-observance can cause minor injuries.
CAUTION
Material damage!
Information about avoiding material damage.
1
1.1
1.1.1

General
6 01.00|KSP3-IM, KSP3-LH-IM |en
Applicable documents
• General terms of business *
• Catalog data sheet of the purchased product *
The documents marked with an asterisk (*) can be downloaded on
our homepage schunk.com
Sizes
This operating manual applies to the following sizes:
• KSP3 IM 100, 140, 160, 250
• KSP3-LH IM 100, 140, 160, 250
Warranty
The warranty period is 24 months after delivery date from factory
or 500 000 cycles*, if it is used as intended, under the following
conditions:
• Observe the applicable documents,
(1.1.2, Page 6)
• Observe the ambient conditions and operating conditions,
(2.6, Page 10)
• Observance of the specified care and maintenance instructions
(7, Page 40)
Parts touching the workpiece and wear parts are not included in
the warranty.
* A cycle consists of a complete clamping process ("Open" and
"Close").
Scope of Delivery
Clamping force block
KSP3 IM, KSP3-LH IM
including inductive proximity switch
(without top jaws)
ACCESSORY KIT:
(for contents, see sealing kit list and parts list) (8.1, Page 50)
1.1.2
1.1.3
1.2
1.3

General
01.00|KSP3-IM, KSP3-LH-
IM |en
7
Accessories
(see catalog or data sheets when ordering separately)
Top jaw blanks, type: STR, KTR
Supporting jaws, type: TBA-G
TANDEM Base plates
Valves, pneumatic screws
Extension cable for INW inductive proximity switch
1.4

Basic safety notes
8 01.00|KSP3-IM, KSP3-LH-IM |en
Basic safety notes
Intended use
• This product is intended for clamping and holding workpieces
on machine tools and other suitable technical devices.
• It is designed to be set up on a machine table or machine
pallets.
• The product may only be used within the scope of its technical
data, (3, Page 18).
• The product is intended for industrial and industry-oriented
use.
• Appropriate use of the product includes compliance with all
instructions in this manual.
Not intended use
• The product is not being used as intended if, for example:
• It is used as lifting equipment, as a press, as a punching tool, as
a lathe chuck, as a drill or as a cutting tool.
• It is used in working environments that are not permissible.
• Workpieces are not properly clamped.
• Safety regulations are disregarded and persons are working at
this product (for example, to machine clamped workpieces)
without additional protective equipment.
• The technical data specified by the manufacturer are exceeded
during usage.
• It is used with machines/systems or workpieces that are not
designed to be used with it.
2
2.1
2.2

Basic safety notes
01.00|KSP3-IM, KSP3-LH-
IM |en
9
Constructional changes
Implementation of structural changes
By conversions, changes, and reworking, e.g. additional threads,
holes, or safety devices can impair the functioning or safety of the
product or damage it.
• Structural changes should only be made with the written
approval of SCHUNK.
Spare parts
Use of unauthorized spare parts
Using unauthorized spare parts can endanger personnel and
damage the product or cause it to malfunction.
• Use only original spare parts or spares authorized by SCHUNK.
Use of special chuck jaws
Requirements of the chuck jaws
When using special chuck jaws, please observe the following rules:
• The chuck jaws should be designed to be as low as possible.
The clamping point must be as close as possible to the housing.
(clamping points at a greater distance cause higher surface
pressures in the jaw guidance and can significantly reduce the
clamping force.)
• Do not use welded jaws.
• Reduce operating pressure for higher clamping points.
2.3
2.4
2.5

Basic safety notes
10 01.00|KSP3-IM, KSP3-LH-IM |en
Environmental and operating conditions
Required ambient conditions and operating conditions
Incorrect ambient and operating conditions can make the product
unsafe, leading to the risk of serious injuries, considerable material
damage and/or a significant reduction to the product's life span.
• Make sure that the product is used only in the context of its
defined application parameters, (3, Page 18).
• Make sure that the product is a sufficient size for the
application.
• Ensure that maintenance and lubrication intervals are
observed, (7, Page 40).
• Ensure that the environment is free from ferromagnetic
particles or chips.
Personnel qualification
Inadequate qualifications of the personnel
If the personnel working with the product is not sufficiently
qualified, the result may be serious injuries and significant
property damage.
• All work may only be performed by qualified personnel.
• Before working with the product, the personnel must have read
and understood the complete assembly and operating manual.
• Observe the national safety regulations and rules and general
safety instructions.
The following personal qualifications are necessary for the various
activities related to the product:
Due to their technical training, knowledge and experience, trained
electricians are able to work on electrical systems, recognize and
avoid possible dangers and know the relevant standards and
regulations.
Due to its technical training, knowledge and experience, qualified
personnel is able to perform the delegated tasks, recognize and
avoid possible dangers and knows the relevant standards and
regulations.
2.6
2.7
Trained electrician
Qualified personnel

Basic safety notes
01.00|KSP3-IM, KSP3-LH-
IM |en
11
Instructed persons were instructed by the operator about the
delegated tasks and possible dangers due to improper behaviour.
Due to its technical training, knowledge and experience, service
personnel of the manufacturer is able to perform the delegated
tasks and to recognize and avoid possible dangers.
Personal protective equipment
Use of personal protective equipment
Personal protective equipment serves to protect staff against
danger which may interfere with their health or safety at work.
• When working on and with the product, observe the
occupational health and safety regulations and wear the
required personal protective equipment.
• Observe the valid safety and accident prevention regulations.
• Wear protective gloves to guard against sharp edges and
corners or rough surfaces.
• Wear heat-resistant protective gloves when handling hot
surfaces.
• Wear protective gloves and safety goggles when handling
hazardous substances.
• Wear close-fitting protective clothing and also wear long hair in
a hairnet when dealing with moving components.
Instructed person
Service personne
l of
the manufacturer
2.8

Basic safety notes
12 01.00|KSP3-IM, KSP3-LH-IM |en
Notes on safe operation
Incorrect handling of the personnel
Incorrect handling and assembly may impair the product's safety
and cause serious injuries and considerable material damage.
• Avoid any manner of working that may interfere with the
function and operational safety of the product.
• Use the product as intended.
• Observe the safety notes and assembly instructions.
• Do not expose the product to any corrosive media. This does
not apply to products that are designed for special
environments.
• Eliminate any malfunction immediately.
• Observe the care and maintenance instructions.
• Observe the current safety, accident prevention and
environmental protection regulations regarding the product's
application field.
IMPORTANT!
Following a longer shutdown period (more than approx. 6 hours),
always re-tension the clamping device in order to compensate for
the setting properties of the clamping situation or possible
pressure losses and the resulting loss of clamping force.
Transport
Handling during transport
Incorrect handling during transport may impair the product's
safety and cause serious injuries and considerable material
damage.
• When handling heavy weights, use lifting equipment to lift the
product and transport it by appropriate means.
• Secure the product against falling during transportation and
handling.
• Stand clear of suspended loads.
2.9
2.10

Basic safety notes
01.00|KSP3-IM, KSP3-LH-
IM |en
13
Malfunctions
Behavior in case of malfunctions
• Immediately remove the product from operation and report
the malfunction to the responsible departments/persons.
• Order appropriately trained personnel to rectify the
malfunction.
• Do not recommission the product until the malfunction has
been rectified.
• Test the product after a malfunction to establish whether it still
functions properly and no increased risks have arisen.
Disposal
Handling of disposal
The incorrect handling of disposal may impair the product's safety
and cause serious injuries as well as considerable material and
environmental harm.
• Follow local regulations on dispatching product components for
recycling or proper disposal.
Fundamental dangers
General
• Observe safety distances.
• Never deactivate safety installations.
• Before commissioning the product, take suitable protective
measures to secure the danger zone.
• Disconnect power sources before installation, modification,
maintenance, or calibration. Ensure that no residual energy
remains in the system.
• Do not reach into the open mechanism or movement area of
the product during operation.
2.11
2.12
2.13

Basic safety notes
14 01.00|KSP3-IM, KSP3-LH-IM |en
Protection during handling and assembly
Incorrect handling and assembly
Incorrect handling and assembly may impair the product's safety
and cause serious injuries and considerable material damage.
• Have all work carried out by appropriately qualified personnel.
• For all work, secure the product against accidental operation.
• Observe the relevant accident prevention rules.
• Use suitable assembly and transport equipment and take
precautions to prevent jamming and crushing.
Incorrect lifting of loads
Falling loads may cause serious injuries and even death.
• Stand clear of suspended loads and do not step into their
swiveling range.
• Never move loads without supervision.
• Do not leave suspended loads unattended.
Protection during commissioning and operation
Falling or violently ejected components
Falling and violently ejected components can cause serious injuries
and even death.
• Take appropriate protective measures to secure the danger
zone.
• Never step into the danger zone during operation.
2.13.1
2.13.2

Basic safety notes
01.00|KSP3-IM, KSP3-LH-
IM |en
15
Protection against dangerous movements
Unexpected movements
Residual energy in the system may cause serious injuries while
working with the product.
• Switch off the energy supply, ensure that no residual energy
remains and secure against inadvertent reactivation.
• Never rely solely on the response of the monitoring function to
avert danger. Until the installed monitors become effective, it
must be assumed that the drive movement is faulty, with its
action being dependent on the control unit and the current
operating condition of the drive. Perform maintenance work,
modifications, and attachments outside the danger zone
defined by the movement range.
• To avoid accidents and/or material damage, human access to
the movement range of the machine must be restricted.
Limit/prevent accidental access for people in this area due
through technical safety measures. The protective cover and
protective fence must be rigid enough to withstand the
maximum possible movement energy. EMERGENCY STOP
switches must be easily and quickly accessible. Before starting
up the machine or automated system, check that the
EMERGENCY STOP system is working. Prevent operation of the
machine if this protective equipment does not function
correctly.
2.13.3

Basic safety notes
16 01.00|KSP3-IM, KSP3-LH-IM |en
Notes on particular risks
WARNING
Risk of injury in the event of workpiece loss due to failure or
reduction of the compressed air.
• Provide pressure maintenance valves
• Ensure stable compressed air supply
WARNING
Risk of injury in the event of workpiece loss due to component
failure on the product as a result of exceeding the technical
data.
• The product may only be used within the scope of its technical
data
WARNING
Risk of injury due to immediate closing of the product with high
spring force in the event of pneumatic pressure failure (AS
variant).
• Ensure stable compressed air supply
• Use pressure maintenance valves
WARNING
Risk of injury from falling parts during transport, assembly and
disassembly of the product and its accessories.
• Use suitable load handling equipment for transport
• Do not remain in the danger zone
• Wear protective equipment (protective shoes)
WARNING
Danger of crushing due to the chuck jaws approaching the
workpiece during the clamping procedure when loading and
unloading manually.
• Prioritize automated loading
• Do not reach between the workpiece and the chuck jaw
during the clamping procedure
2.13.4

Basic safety notes
01.00|KSP3-IM, KSP3-LH-
IM |en
17
WARNING
Risk of injury due to accidental actuation when working on the
product
• Disconnect the power supply when working on the product
CAUTION
Ergonomic risk to the musculoskeletal system when lifting and
transporting the product using manual force.
• Use load handling equipment for lifting and transporting
CAUTION
Allergic reactions or irritation due to skin or eye contact with
lubricants on the product.
• In case of foreseeable contact with lubricants on the product
(e.g. when lubricating or cleaning), wear protective equipment
(protective gloves, protective goggles)
CAUTION
Risk of injury due to damaged connection cable on parts
carrying current
• Check the connection cables of the inductive proximity
switches for damage before starting work.

Technical data
18 01.00|KSP3-IM, KSP3-LH-IM |en
Technical data
Installation position
any
Operating temperature
+5°C to +60°C
Noise emission [dB(A)]
≤70
Pressure medium
Compressed air, compressed air quality according to
ISO 8573-1:7 4 4
Max. speed of rotation
100 RPM
Designation
KSP3 IM
100
140
160
250
Stroke per jaw [mm]
2
3
3
5
Clamping force* at max.
pressure
Standard/AS variant [kN]
18/22
30/36
45/54
55/70
Max. pressure standard/
AS variant [bar]
9***/9***
9/9
9***/9***
6/6
Min. opening pressure
AS variant [bar]
3
3
3
3
Repeat accuracy** [mm]
0.01
0.01
0.01
0.02
Max. jaw stroke [mm]
60
60
60
150
Weight [kg]
4
7.5
11
32
Designation
KSP3-LH IM
100
140
160
250
Stroke per jaw [mm]
6
7
8
15
Clamping force* at max.
pressure
Standard/AS variant [kN]
8/10
15/18.5
20/24
20/25
Max. pressure standard/
AS variant [kN]
9***/9***
9/9
9***/9***
6/6
Min. opening pressure
AS variant [bar]
3
3
3
3
Repeat accuracy** [mm]
0.01
0.01
0.01
0.02
Max. jaw stroke [mm]
150
120
200
500
Weight [kg]
4
7.5
11
32
*
Clamping force is the arithmetic sum of the individual forces occurring at the chuck
jaws at a distance of "H" (see catalog (

1.1.2, Page 6)).
**
End position spread after 100 consecutive strokes.
***
Sizes 100, 160: When using an ABP-A base plate, the maximum pressure must be
limited to 7 bar.
3

Technical data
01.00|KSP3-IM, KSP3-LH-
IM |en
19
Dimension
KSP3 IM/KSP3-LH IM
100
140
160
250
A
90
126
146
230
B
64
92
106
154
Ø C
6H7 x 12
8H7 x 14
8H7 x 14
10H7 x 20
D
80
110
125
200
E
29.5
44
50
75
F
32
45.5
40
64
G
34.5
51.8
59.7
92.6
H
55
74
82
139.6
I
64
91
104
170
J
69.2
72.7
82.2
98.2
K
36
38
42
82
L
10
13.5
15
20
M
59
88
100
150
N
M8
M8
M10
M12
O
15
15.5
18
20
P
4
3.5
4
5
Ø Q
10f7
10f7
12f7
14f7
Ø R
11
11
13
16
S
4.5
5.5
6
6
T
54
76
84
140
U
18.7
26
29
54
V
40
58.5
67
104
W
65.8
81.8
81.8
134.8
X
82.1
93
99.5
124.5
Y
63.5
65
73
87.2
Z
14...20
18.5...26.5
18.5...26.5
27.5...42.5

Technical data
20 01.00|KSP3-IM, KSP3-LH-IM |en
1
Optional Z variant ±0.01 mm to clamping center
2
Clamping sleeve ±0.04 mm to clamping center
3
Clamping sleeve fitting screw ±0.02 mm to clamping center
