SCHUNK IFT User manual

Original Betriebsanleitung
SCHUNK IFT Clamping force measuring device
Montage- und Betriebsanleitung
Superior Clamping and Gripping

Imprint
2
02.00|SCHUNK IFT Spannkraftmessgerät |en
Imprint
Copyright:
This manual is protected by copyright. The author is SCHUNK GmbH & Co. KG. All rights
reserved. Any reproduction, processing, distribution (making available to third parties),
translation or other usage - even excerpts - of the manual is especially prohibited and
requires our written approval.
Technical changes:
We reserve the right to make alterations for the purpose of technical improvement.
Document number: 1425312
Version: 02.00 |03/04/2020|en
© H.-D. SCHUNK GmbH & Co.
All rights reserved.
Dear Customer,
thank you for trusting our products and our family-owned company, the leading
technology supplier of robots and production machines.
Our team is always available to answer any questions on this product and other solutions.
Ask us questions and challenge us. We will find a solution!
Best regards,
Your SCHUNK team
H.-D. SCHUNK GmbH & Co.
Spanntechnik KG
Lothringer Str. 23
D-88512 Mengen
Tel. [phone]
Fax [phone]
[email protected]
schunk.com

Table of contents
02.00|SCHUNK IFT Spannkraftmessgerät |en
3
Table of contents
1
General instructions ................................................................................................. 4
1.1
Information about this manual ................................................................................ 4
1.1.1
Presentation of Warning Labels.................................................................... 4
1.1.2
Applicable documents................................................................................... 5
1.2
Warranty................................................................................................................... 5
1.3
Scope of delivery ...................................................................................................... 5
2
Basic safety notes..................................................................................................... 6
2.1
Intended use............................................................................................................. 6
2.2
Not intended use ...................................................................................................... 6
2.3
Structural changes.................................................................................................... 7
2.4
Spare parts................................................................................................................ 7
2.5
Ambient conditions and operating conditions......................................................... 7
2.6
Personnel qualification............................................................................................. 8
2.7
Personal protective equipment................................................................................ 9
2.8
Instructions for safe operation................................................................................. 9
2.8.1
Constructional changes, attachments, or modifications............................ 10
2.9
Transport ................................................................................................................ 10
2.10
Malfunctions........................................................................................................... 10
2.11
Disposal................................................................................................................... 10
2.12
Fundamental dangers............................................................................................. 11
2.12.1
Notes on particular risks ............................................................................. 11
3
Technical Data......................................................................................................... 12
3.1
Tablet technical data: ............................................................................................. 12
3.2
Measuring head technical data .............................................................................. 12
4
Functional description and operation ...................................................................... 13
4.1
Overview................................................................................................................. 13
4.2
Measuring head...................................................................................................... 13
4.2.1
General........................................................................................................ 13
4.2.2
Charging process / state of charge ............................................................. 14
4.2.3
Changing the clamping inserts .................................................................... 15
4.3
Tablet and APP ....................................................................................................... 17
4.3.1
Functional description of the tablet ........................................................... 17
4.3.2
Operating the APP....................................................................................... 18
4.3.3
Main screen................................................................................................. 19
4.3.4
Measuring procedure.................................................................................. 24
5
Calibration and recalibration ................................................................................... 26
6
Charging adapter..................................................................................................... 27
7
EU Declaration of Conformity .................................................................................. 29

General instructions
4
02.00|SCHUNK IFT Spannkraftmessgerät |en
General instructions
Information about this manual
This manual contains important information for the safe, correct
use of the product.
The manual is an integral part of the product and must be kept
accessible for personnel at all times.
Personnel must have read and understood this manual before
beginning any work. The observance of all safety notes in this
manual is the precondition for safe working. The illustrations in
this manual are intended to provide a basic understanding and
may deviate from the actual version.
Besides this manual, other documents which apply are those listed
under (1.1, Page 5)
Presentation of Warning Labels
To make risks clear, the following signal words and symbols are
used for safety notes.
DANGER
Danger for persons!
Non-observance will inevitably cause irreversible injury or death.
WARNING
Dangers for persons!
Non-observance can lead to irreversible injury and even death.
CAUTION
Dangers for persons!
Non-observance can cause minor injuries.
CAUTION
Material damage!
Information about avoiding material damage.
1
1.1
1.1.1

General instructions
02.00|SCHUNK IFT Spannkraftmessgerät |en
5
Applicable documents
•General terms of business *
•Catalog data sheet of the purchased product *
The documents marked with an asterisk (*) can be downloaded on
our homepage schunk.com
Warranty
If the product is used as intended, the warranty is valid for 24
months from the ex-works delivery date under the following
conditions:
•Observe the applicable documents,
(1.1, Page 5)
•Observe the ambient conditions and operating conditions
(5 2.1, Page 7)
•Observance of the specified calibration intervals.
(5, Page 26)
Parts touching the workpiece and wearing parts are not part of the
warranty.
Scope of delivery
1
Tablet incl. APP
1
Measuring head
6
Spacers for Ø72
6
Spacers for Ø96
6
Spacers for Ø136
1
Insertion aid
1
Stand for speed measurement
1
Charging adapter for tablet and measuring head
1
USB charging cable
1
Torx wrench
8
Screws for spacer
1.1.2
1.2
1.3

Basic safety notes
6
02.00|SCHUNK IFT Spannkraftmessgerät |en
Basic safety notes
Risks to persons and property may arise from incorrect handling of
this product if these instructions are disregarded.
Report any damage and defects immediately and repair without
delay to keep the extent of the damage to a minimum and avoid
compromising the safety of the product.
Only original SCHUNK spare parts may be used!
Intended use
The product is used for measuring clamping force on clamping
devices in a machine tool. The measurement can be static
(clamping force without speed of rotation) and dynamic (clamping
force with speed of rotation).
•For dynamic measurement, the axis of rotation of the
measuring head must always lie on the axis of rotation of the
machine spindle.
•The product may only be used within the scope of its technical
data.
•The product is intended for industrial and industry-oriented
use.
•Appropriate use of the product includes compliance with all
instructions in this manual.
Not intended use
The product is used inappropriately if, for example:
•the product is used with machines or clamping devices that are
not designed to be used with it.
•the specified technical data for use of the product are
exceeded.
•the product is used in working environments that are not
permissible.
•the product is operated without protective equipment (only
with dynamic measurement).
•system changes or external influence of the tablet by the
operator.
2
2.1
2.2

Basic safety notes
02.00|SCHUNK IFT Spannkraftmessgerät |en
7
Structural changes
Implementation of structural changes
Modifications, changes or reworking, e.g. additional threads,
holes, or safety devices, can damage the product or impair its
functionality or safety.
•Structural changes should only be made with the written
approval of SCHUNK.
Spare parts
Use of unauthorized spare parts
Using unauthorized spare parts can endanger personnel and
damage the product or cause it to malfunction.
•Use only original spare parts and spares authorized by SCHUNK.
Ambient conditions and operating conditions
Requirements for ambient and operating conditions
Incorrect ambient and operating conditions can make the product
unsafe, leading to the risk of serious injuries, considerable material
damage and/or a significant reduction to the product's life span.
•Make sure that the product is only used within its defined
application parameters.
•The measuring head must have reached room temperature
before measurement.
2.3
2.4
2.5

Basic safety notes
8
02.00|SCHUNK IFT Spannkraftmessgerät |en
Personnel qualification
Inadequate qualification of personnel
Work on and with the product by inadequately qualified personnel
can lead to serious injuries and considerable material damage.
•Order all work to be performed only by appropriately qualified
personnel.
•Personnel must have read and understood the complete
operating manual before beginning any work on the product.
•Observe national accident prevention regulations and the
general safety notes.
The following personnel qualifications are required for the various
types of work on the product:
Specialist personnel:
Specialist personnel have the specialized training, knowledge, and
experience to perform the tasks entrusted to them, to recognize
and avoid potential dangers, and know the relevant standards and
regulations.
Instructed personnel:
Instructed persons have been instructed by the user regarding the
tasks entrusted to them and the potential dangers of
inappropriate behavior.
Manufacturer service personnel:
The manufacturer's service personnel have the specialized
training, knowledge, and experience to perform the work
entrusted to them and to recognize and avoid potential dangers.
2.6

Basic safety notes
02.00|SCHUNK IFT Spannkraftmessgerät |en
9
Personal protective equipment
Use of personal protective equipment
Personal protective equipment serves to protect staff in the event
of a danger that may interfere with their health or safety at work.
•When working on and with the product, observe the
occupational health and safety regulations and wear the
required personal protective equipment.
•Observe the valid safety and accident prevention regulations.
•Wear protective gloves to guard against sharp edges and
corners or rough surfaces.
•Wear close-fitting protective clothing and place a hairnet over
long hair when dealing with moving components.
Instructions for safe operation
Working in an incorrect manner
An incorrect manner of working can make the product unsafe and
risk the danger of serious injuries and considerable material
damages.
•Avoid any manner of working that may interfere with the
function and operational safety of the product.
•Use the product as intended.
•Observe the safety notes and assembly instructions.
•Do not expose the product to any corrosive media. Products for
special ambient conditions are excluded.
•Rectify malfunctions as soon as they occur.
•Observe the calibration intervals.
•Observe the current safety, accident prevention, and
environmental protection regulations for the application field
of the product.
2.7
2.8

Basic safety notes
10
02.00|SCHUNK IFT Spannkraftmessgerät |en
Constructional changes, attachments, or modifications
Additional threads, bore holes or attachments which are not
supplied as accessories by SCHUNK may affect safety. They may
only be applied after obtaining the prior consent of SCHUNK.
Transport
The transport is performed exclusively in the original, specially
adapted transport case.
Malfunctions
Behavior in case of malfunctions
•Immediately remove the product from operation and report
the malfunction to the responsible departments/persons.
•Have appropriately trained personnel rectify the malfunction.
•Do not recommission the product until the malfunction has
been rectified.
•Test the product after a malfunction to establish whether it still
functions properly and no increased risks have arisen.
Disposal
Conduct during disposal
Incorrect handling during disposal can make the product unsafe
and risks serious injuries and considerable material and
environmental harm.
•Follow local regulations on dispatching product components for
recycling or proper disposal.
•Batteries and rechargeable batteries are subject to hazardous
waste treatment and may only be disposed of by authorized
specialist companies.
2.8.1
2.9
2.10
2.11

Basic safety notes
02.00|SCHUNK IFT Spannkraftmessgerät |en
11
Fundamental dangers
General:
•Do not reach into the open mechanism or movement area of
the product during operation.
•Never deactivate safety installations.
•Before commissioning the product, take appropriate protective
measures to secure the danger zone.
•Technical data of the machine or the clamping device must not
exceed the maximum permissible data of the measuring head.
Notes on particular risks
WARNING
Crushing!
•Do not reach between moving parts (measuring head and
jaw).
•Use an insertion aid for protection!
WARNING
Rotating parts!
When measuring during speed of rotation, the insertion aid must
be removed before switching on the machine!
WARNING
Rotating parts!
When measuring during speed of rotation, the measuring head
must be clamped firmly and plane-parallel to the axis of rotation.
2.12
2.12.1

Technical Data
12
02.00|SCHUNK IFT Spannkraftmessgerät |en
Technical Data
Tablet technical data:
Designation
Handset/tablet/APP
Display size
8"
Operating system
Android
Charger connection
USB micro
Operating temperature
[°C]
0...40
Protection class
IP67
Transmitting/receiving
frequency
[GHz]
2.4
Data exchange
MicroSD; USB micro
Measuring head technical data
Designation
Measuring head
Voltage supply
Internal energy accumulator
Energy accumulator
capacity
approx. 1.5 h @ 100% d.c
Charging process
< 3 minutes
Charger connection
USB mini
Number of jaws
2, 3 or 6 jaws can be set
Force range of
measurement
[kN]
0...180 kN (2-jaws)
0...270 kN (3-jaws)
0...540 kN (6-jaws)
Force measurement
accuracy
< 3% fsr
Speed of rotation
measurement
[min-1]
approx. 200...6000
Speed of rotation
measurement accuracy
< 1% fsr
Clamping range
[mm]
Ø72, Ø96, Ø136
Measured value
transmission rate
500 ms
Dimensions
[mm]
Ø68 / 58 x 63
Weight
[g]
700 (without extensions)
Operating temperature
[°C]
0...40
Protection class
IP67
Transmission frequency
[GHz]
2.4
Handset/measuring head
distance
< 10 m (depending on ambient
conditions)
3
3.1
3.2

Functional description and operation
02.00|SCHUNK IFT Spannkraftmessgerät |en
13
Functional description and operation
Overview
The operating principle of the measuring head is based on several
internal strain gauges. The applied clamping force is converted
into an electrical signal and evaluated by the electronics. A
wireless data link transmits the data from the measuring head to
the tablet and visualizes the measured values in the APP.
Measuring head
General
The measuring head consists of the base body with integrated
sensor system and electronic processor, as well as the respective
intermediate pieces for the clamping diameters Ø72 mm, Ø96 mm
and Ø136 mm. The arrow on the cover and also on the bottom of
the measuring head symbolizes the measuring jaw, which must
always rest on a jaw of the clamping device to be measured.
1 measuring jaw with indicator arrows
CAUTION
Measuring jaw always in force flow!
Otherwise the measured values are not meaningful.
4
4.1
4.2
4.2.1

Functional description and operation
14
02.00|SCHUNK IFT Spannkraftmessgerät |en
Charging process / state of charge
A USB mini jack is located in the lid of the measuring head. This is
used in conjunction with the USB mini cable supplied and charging
adapter to charge the measuring head.
1 USB-mini measuring head charging socket
CAUTION
Danger of confusion!
Charging the tablet: USB micro
Charging the measuring head: USB mini
WARNING
Damage by liquid!
The charging socket must be dry and free of dirt during the
charging process.
The charging status is indicated by the LED integrated in the lid
and within the APP. If the charge level is less than 15%, the LED on
the measuring head flashes.
4.2.2

Functional description and operation
02.00|SCHUNK IFT Spannkraftmessgerät |en
15
Changing the clamping inserts
The clamping inserts can be changed with the assembly key
supplied. The clamping inserts for the clamping diameters Ø72
mm, Ø96 mm and Ø136 mm are supplied.
1
Measuring head
2
Clamping insert
3
Fastening screw
4
Torx assembly key
WARNING
Imbalance!
Only clamping inserts of the same length may be installed on the
clamping force meter.
The clamping inserts must be arranged symmetrically.
(2 pieces at 180°; 3 pieces at 120°; 6 pieces at 60°)
4.2.3

Functional description and operation
16
02.00|SCHUNK IFT Spannkraftmessgerät |en
1
Extension for Ø72
2
Extension for Ø96
3
Extension for Ø136

Functional description and operation
02.00|SCHUNK IFT Spannkraftmessgerät |en
17
Tablet and APP
WARNING
Lithium-ion battery!
The product is equipped with a lithium-ion battery.
•Do not disassemble.
•Keep away from heat sources.
•Do not use in areas of increased radiation.
Functional description of the tablet
The supplied tablet is connected to the measuring head via the
internal Bluetooth interface. The evaluation of the measured
values is done with the pre-installed APP.
The tablet is charged using the charging adapter and the USB
micro cable supplied.
CAUTION
Danger of confusion!
Charging the tablet: USB micro.
Charging the measuring head: USB mini.
WARNING
Damage by liquid!
The charging socket must be dry and free of dirt during the
charging process.
4.3
4.3.1

Functional description and operation
18
02.00|SCHUNK IFT Spannkraftmessgerät |en
1
USB-mini jack (charging)
2
ON key
3
External memory card slot
Operating the APP
The pre-installed APP is used to visualize the values of the
measuring head.
Starting the APP
The APP for the clamping force meter is started via the APP-ICON
on the start page.
4.3.2
4.3.2.1

Functional description and operation
02.00|SCHUNK IFT Spannkraftmessgerät |en
19
Main screen
All relevant data can be visualized and edited on the main screen.
You can change the display based on the respective situation by
clicking on Change display. The display with a diagram of the
clamping force data points, showing all data points sent by the
sensor head over time is defined as the standard.
1
Current value of the clamping force
2
Current speed of rotation of the sensor head
3
Temperature at sensor head
4
Characteristics of sensor head (designation/charge status/connection
status)
5
Updating the display
6
Start/stop measurement
7
Save data (in history)
8
Export data
9
Change display
10
Diagram (clamping force data points/clamping force speed of rotation)
11
Advanced menu (Settings/History/Parameters/Tare/ Connect other
sensor)
4.3.3

Functional description and operation
20
02.00|SCHUNK IFT Spannkraftmessgerät |en
Connecting to the measuring head
The sensor head has a unique serial number on the bottom. This is
also the designation in the radio network. The sensor head can be
selected and connected via
Advanced menu →Connect other sensor. As soon as the sensor
head is connected, it is displayed on the main screen.
Settings
Via the settings, the APP can be customized.
1
Selection of the clamping method (2/3/6-jaws)
2
Selection of the unit system (metric (kN / °C) / American (Ibs / °F))
3
Language
CAUTION
Ensure correct clamping method!
Correct entry of the clamping method must be checked.
Incorrect input leads to incorrect display values of the force
value.
4.3.3.1
4.3.3.2
