SCHURR SCHURR cow-brush type B00 User manual

SCHURR cow-brush
2-brush-system
Type B00 / Type C12
OPERATING INSTRUCTIONS
Retain for future reference
ENGLISH

SCHURR cow-brush Type B00/C12
Feb. 2017 Page 2 www.schurr-geraetebau.de
Contents
1 Identification data..............................................................................................page 2
2 Basic safety notes..............................................................................................page 4
3 Product description............................................................................................page 8
4 Assembly and function.......................................................................................page 11
5 Commissioning..................................................................................................page 17
6 Operation...........................................................................................................page 21
7 Maintenance and repair .....................................................................................page 22
8 Disposal ............................................................................................................page 25
9 Parts list ............................................................................................................page 26
1 Identification data
Model: SCHURR cow-brush type B00 (Standard-motor)
SCHURR cow-brush type C12 (EC-motor)
Serial number: see designation plate on device
Year of manufacture: see designation plate
Manufacturer's address Ordering of spares and customer service
Schurr-Gerätebau GmbH Telephone: [phone] / 9 11 60
Langer Rain 2 Fax: [phone] / 9 11 62
88524 Uttenweiler/Dentingen Germany
www.schurr-geraetebau.de email: [email protected]
Hubert Schurr, Marianne Schurr,
Philipp Schurr
USt.Id: 230298996
Amtsgericht Ulm HRB 650446 88524 Uttenweiler/Dentingen
Document number: B00/C12
Creation date: 201
Last modified: 23.02.2017

SCHURR cow-brush Type B00/C12
Feb. 2017 Page 3 www.schurr-geraetebau.de
Purpose of document
These operating instructions are designed to make the person responsible for the SCHURR Cow-brush familiar with the
following:
mode of operation
operating
safety notes
maintenance
Operating personnel
The SCHURR Cow-brush may be operated exclusively by persons who have read and understood the operating instructions
and safety notes.
Additional requirements, qualifications and skills are detailed in each chapter.
Notation used
Keyword Notation Meaning
Safety notes Bold and cursive indicate facilities or actions that protect the user and the
environment from damage
Symbol indicates an action for the operator
(25) Round brackets indicate the numbering of a component
Notation used in conjunction with the safety notes is described in
Chapter 2 'Basic safety notes'.
Storage
The operating instructions are to be kept at or near the machine at all times, and must always be at hand.
User feedback
Dear valued customer,
These operating instructions are updated regularly by us. Your suggestions for improvement will help to produce
operating instructions that are more and more user friendly.
2017 Schurr-Gerätebau GmbH, Langer Rain 2, 88524 Uttenweiler/Dentingen, GERMANY
All rights reserved
Reprinting, also of portions of this document, only with permission of the company.

SCHURR cow-brush Type B00/C12
Feb. 2017 Page 4 www.schurr-geraetebau.de
2 Basic safety notes
2.1 Observe notes in the operating instructions
 The basic requirement for handling and operating this machine in a safe and error-free manner is the knowledge of
the basic safety notes and the safety regulations.
 These operating instructions contain the most important notes for safe operation of the machine.
 These operating instructions, in particular the safety notes, must be observed by all personnel operating this machine.
 In addition, the rules and regulations applicable to accident prevention at the place of use are to be observed.
2.2 Duties of the person responsible for the machine
The person responsible for the machine is obliged to allow operation of the machine only by those persons who
 are familiar with the basic regulations concerning work safety and accident prevention, and are trained in the
handling of the machine.
 have read and understood the safety chapter and warning notes in these operating instructions.
2.3 Duties of the operator
All persons who are to operate the machine are obliged, before commencing work,
 to observe the basic regulations concerning work safety and accident prevention
 to read and understand the safety chapter and warning notes in these operating instructions.
Schurr-Gerätebau GmbH is available for enquiries where questions remain unanswered.
2.4 Dangers when operating the machine
The machine is constructed according to state of the art technology and recognised technical
safety controls. Nevertheless, the use of the machine can lead to danger to life and limb
for the operator or a third party, or harm to the machine or other material assets.
The machine is only
to be used
 for the intended purpose
 in a state where technical safety is not compromised.
Failures that can impair safety are to be rectified immediately.
2.5 Guarantee and liability
In principle, our 'General Conditions of Business' are applicable. These are available to the person responsible for the
machine. If this is not the case, they can be requested.
Any guarantee or liability claim in the event of damage to persons or property is excluded when it can be ascribed to one
or more of the following causes:
 Use of the machine for a purpose other than its intended purpose.
 Inappropriate installation, commissioning, operation and maintenance of the machine.
 Operation of the machine in conditions where safety equipment is defective, or improperly installed or incorrectly
functioning safety and protection equipment.
 Disregarding of the notes in the operating instructions dealing with transport,
storage, installation, commissioning, operation and maintenance of the machine.
 Unauthorised structural modifications to the machine.
 Unauthorised modifications to the machine, e.g. drive ratios - output and rotation speed.
 Faulty monitoring of machine parts subject to wear and tear.

SCHURR cow-brush Type B00/C12
Feb. 2017 Page 5 www.schurr-geraetebau.de
 Repair work not properly performed.
 Loose collars on the animals.
 Tail hair (tufts) too long - these should be kept short. (not longer than 10-15cm)
 Emergencies caused by the introduction of foreign bodies and
force majeure .
Similarly, parts subject to wear and tear are excluded from warranty claims.
2.6 Machine noise
 The continuous sound pressure level produced by the machine is 70 dB(A).
2.7 Safety regulations
2.7.1 Explanation of symbols and notes
The following terms and symbols are used in the operating instructions for hazards:
Danger!
This symbol indicates an immediate threat of danger
to life and health of persons.
 Failure to observe this note will have serious
consequences injurious to health, including
life-threatening injuries or even death.
Caution!
This symbol indicates a situation that is possibly dangerous.
 Failure to observe this note can lead to injuries or damage to property.
This symbol indicates a tip for usage and particularly
useful information.
 These assist you in the optimal use of all functions of the machine and
avoiding failures in the machine and environment.
1 3 2 1 3 2

SCHURR cow-brush Type B00/C12
Feb. 2017 Page 6 www.schurr-geraetebau.de
Pos. Symbol Erklärung
1 Do not lift at the engine!
2 Before opening disconnect mains.
3 Seriel no. of the SCHURR cow-brush
2.7.2 Organisational measures
All safety facilities are to be checked regularly.
2.7.3 Protective equipment
Prior to every startup of the machine, all protective equipment must be properly installed and functional.
Protective equipment may only be removed
 after stopping the machine and
 securing it against restarting, e.g. padlock on the motor circuit breaker or removal of the fuse from the
domestic supply.
Where part components are delivered, the person responsible for the machine must ensure that the protective
equipment is properly installed.
2.7.4 Informal safety measures
The operating instructions are to be kept at or near the machine at all times, and must always be at hand. In
addition to the operating instructions, the general and local rules in force applicable to accident prevention and
environmental protection are to be made available and observed.
All safety and operating notes at the machine are to be kept in a legible state and renewed where necessary.
2.7.5 Operator training
 Only qualified and trained personnel may operate the machine.
 Responsibilities of personnel in terms of usage, resetting and maintenance are to be clearly defined.
 Personnel undergoing training may only work at the machine under supervision of an experienced person.
Persons
Activity
Persons
instructed
Persons with technical
training
Persons with
electrotechnical training
Failure determination - mechanical -- X X
Failure resolution - mechanical -- X X
Failure determination - electrical -- -- X
Failure resolution - electrical -- -- X
Maintenance X X X
Repairs -- X X
Legend: X...permitted --...not permitted

SCHURR cow-brush Type B00/C12
Feb. 2017 Page 7 www.schurr-geraetebau.de
2.7.6 Safety measures in normal operation
The machine is to be operated only when all safety facilities are fully functional.
Before switching the machine on, ensure that no-one could be placed in danger by the machine starting up.
Check the machine at least once per day for externally recognisable damage and for the functionality of the safety
facilities. See Chapters 6 and 7
2.7.7 Hazards caused by electricity
Only qualified electricians are permitted to work on the power supply.
The electrical configuration of the machine should be checked regularly.
Loose connections and heat-damaged cables must be rectified immediately.
The terminal box must be kept closed at all times. Only authorised personnel with a key or tool are permitted
access.
2.7.8 Cleaning of the machine and disposal
Substances and materials used must be properly handled and disposed of, in particular
- when working with transmission oil
2.7.9 Maintenance and service, failure correction
 The prescribed adjustment, maintenance and inspection activities must be performed according to schedule.
 The power supply to the machine must be switched off during all maintenance, inspection and repair work.
The main switch must be secured against unexpected reconnection, e.g. via a padlock on the motor circuit
breaker or the removal of the fuse from the domestic supply.
 Check that screw connections are firmly seated.
 Check the safety facilities for functionality after completion of the maintenance activities.
2.7.10 Structural modifications to the machine
 No modifications, extensions or reconstructions of the machine may be made without the manufacturer's
permission. This also applies to the welding on the load-bearing parts.
 All measures taken to extend the machine require the written permission of the manufacturer.
 Machine parts that are not in perfect condition must be replaced immediately.
 Use only original replacements for parts, including those subject to wear and tear.
No guarantee can be given that parts sourced from elsewhere are designed and constructed according to required
standards and levels of safety.

SCHURR cow-brush Type B00/C12
Feb. 2017 Page 8 www.schurr-geraetebau.de
3 Product description
3.1 Use according to design
The machine is intended solely for the dry cleaning of cattle/milking cows. Alternative or additional use is considered to be
not according to design and constitutes misuse of the system.
Use according to design also includes:
 that animals' collars are tight enough, ensuring that animals are not snared by the device.
 that tail hair (tufts) is kept short.
  compliance with all notes in the operating instructions.
 adherence to inspection and maintenance activities.
The manufacturer is not liable for damages arising herefrom.
Precautionary measures
Use for other purposes, as indicated above, is prohibited. Danger may occur where use is contrary to intended purpose.
Foreseeable misuse or use contrary to intended purpose is for example:
 cleaning of persons or
 cleaning of clothing/shoes
 combing of hair in the case of humans
3.2 Danger areas
Danger areas are:
 The electric terminal box
 The brushes.
In these areas, dangers are constantly present or can occur unexpectedly. Special safety regulations must be applied.
3.3 Conformity
The machine conforms to machine guideline 2006/42/EG including supplements, EMV.
3.4 Designation of the machine
The designation plate and the CE identification are attached to the wall support frame, below electronic box:

SCHURR cow-brush Type B00/C12
Feb. 2017 Page 9 www.schurr-geraetebau.de
3.5 Technical data
General data
Overall machine B x D x H 310 x 1150 x 1250 mm
Weight approx. 135 kg
Rotation speed 60/min
Brushes 410 mm/310 mm
Length of brushes 650 mm/550 mm
Bristle material Nylon, 1.2 mm
Rotation speed Motor: 1360 rpm Gearbox: 60/min
Power supply
Electricity Standard-Version
Voltage 220V/230 V , single phase, 50Hz/60Hz
Motor output 0,37 kW
Protection type IP 55
Rated current 2,5 A
Safety fuse in power line Dependent on domestic supply
Environmental requirements Transport and storage Operation
Temperature -25° C to +55° C -15° C to +40° C
Humidity Protected from dew, under
roof if possible
Installation site Observe the transport notes on the packaging. Do
not tip, keep free from oscillation where possible
Vertical, fixed wall, support or
similar

SCHURR cow-brush Type B00/C12
Feb. 2017 Page 10 www.schurr-geraetebau.de
3.6 Electrical connection
 An electrical cable complying with the data specified in Chapter 3.5 must be provided at the installation site for the
SCHURR Cow-brush.
 Installation of the SCHURR cow-brush to power supply may only be performed by a qualified electrician.
3.7 Configuration of the machine
Normal equipment is:
Operating instructions
List of spare parts (see Chapter 9)
Check the tools and auxiliary materials for completeness.
Quantity Tools, auxiliary materials
4 Heavy-duty plugs 12 mm
3.8 Status on delivery
 The machine is attached via a wall bracket to prevent toppling over - see
fig. 2.0.
Fig. 2.0 Attachment to a palette
 Heavy-duty plugs are included (for concrete-wall only).
screws

SCHURR cow-brush Type B00/C12
Feb. 2017 Page 11 www.schurr-geraetebau.de
4 Assembly and function
4.1 Mechanical assembly
Fig. 3.0View of the brush/gearbox component
No. Designation No. Designation
1 Upper brush 550mm long 8 Lower clamping flange 65/25mm
2 Upper shaft 40mm 10 Lower shaft 25mm
4 Upper clamping flange 80/40mm 11 Lower brush 650mm long
5 Gearbox block 12 Allen screw M10 x 20
6 Type B00: standard motor (green)
Type C12: EC-Motor (silver/green) 13 End plate
7 Terminal housing
1
2
4
5
6
8
10
11
12
13 7

SCHURR cow-brush Type B00/C12
Feb. 2017 Page 12 www.schurr-geraetebau.de
Fig. 3.1View of the support frame component
No. Designation No. Designation
14 Plug 16 x 275mm – (lower) plug 255mm
With hexagonal screw M 6 x 20 19 Bearing support bracket with hexagonal screws
M 12 x 30 and square taper washers
15 8 hexagonal screws M 12 x 25 20 Stop rubber
16 Support frame for brushes 21 Sheet metal strips with 8 hexagonal screws M 6x25
17 Bearing support with hexagonal screw M 10 x 30 22 Rubber protective strips
18 Plastic bearing with hexagonal screw M 8 x 25
18
17
14
16
14
15
22
21
20
19

SCHURR cow-brush Type B00/C12
Feb. 2017 Page 13 www.schurr-geraetebau.de
Fig. 3.2View of wall mounting component
23
35
34
33
27
24
25 28
26
24
30
31
32

SCHURR cow-brush Type B00/C12
Feb. 2017 Page 14 www.schurr-geraetebau.de
No. Designation No. Designation
23 Electric box with 2m cable+plug 30 Lower vertical arm with lubricating nipple
24 16x215mm plug with Allen screw M 5x35 31 Hexagonal screw M20x100 with nuts, square taper
washers and lubricating nipple
25 Upper vertical arm with lubricating nipples 32 Lower side arm
26 Upper side arm 33 Tension spring
with eye bolt M 10 x 60
27 Stop rubber 34 FL strap 30mmx5mmx60mm
28 Hexagonal screw M20x110 with 2 half nuts and
lubricating nipple 35 Wall mounting
29 (Before: Magnetic switch)
SCHURR cow-brush typ B00

SCHURR cow-brush Type B00/C12
Feb. 2017 Page 15 www.schurr-geraetebau.de
Meaning of the LED‘s (SCHURR cow-brush type B00)
WORK = If this LED lights up the motor is working, cow-brush will turn all the time
ERROR = „protection mode“
After 10x reversing the cow-brush switches off, at this time the light is flashing red. If this LED lights up
permanently, the plug (power supply) has to be removed and reinserted (RESET)
DEFECT = Fault => lights up constantly, board must be replaced

SCHURR cow-brush Type B00/C12
Feb. 2017 Page 16 www.schurr-geraetebau.de
SCHURR cow-brush typ C12
4.2 Functional description
When an animal is in the SCHURR Cow-brush, and the brushes are turned just a little bit, they begin to rotate autmatically.
The animals are cleaned by the rotating brushes, for as long as the brushes are turning. When the animal exits the
SCHURR Cow-brush, the brushes are switched off after a set time by means of time relay control.
4.3 Safety and monitoring facilities
1 2
No. Part Description
1 Cable ca. 2m with plug for
power supply
On/Off
2 Fuse 5 x 20 mm 5A Overvoltage protection – on the electronic card (only type B00)

SCHURR cow-brush Type B00/C12
Feb. 2017 Page 17 www.schurr-geraetebau.de
5 Commissioning
5.1 Safety regulations
Danger!
Electric voltage or current
Can lead to serious injury or death.
Ensure that work with live parts and the electrical connection is performed by a qualified and
authorised electrician only.
Danger!
Transport the device manually or by means of a transport device.
In the event of the device overturning or falling down injury to fingers/hands or feet/legs may occur.
Worst case scenario is that the device may fall on top of you. In this case there is also a danger of
injury.
The device should always be carried by at least 2 persons, or
an auxiliary apparatus, e.g. front loader should be used.
Ensure that fingers/hands and legs/feet are kept away from the danger area.
5.2 Operating personnel requirements
 The electrical connection must be performed by a qualified electrician.
 Technical skill is required for installation. Technical training would be most suited, e.g. blacksmith, locksmith, farm
machine mechanic.
5.3 Setup
5.3.1 Prerequisites
 A 230 V connection, including error current protection switch is required (FI switch). If the power supply
system does not already contain an F1 switch, it should be installed
by a qualified electrician.
 The installation wall for the SCHURR Cow-brush should be made of concrete. Where other wall material such
as tiles or wood for example is used, please note differing installation instructions (see 4.3.4).
5.3.2 Transport
Never lift the device by the motor!
Ideally, the SCHURR Cow-brush should be transported by means of an auxiliary apparatus, e.g. front loader or
trolley.
Ensure that the speed is kept low, as the device might otherwise fall off.
Do not drive on downward sloping paths or ramps.
Where an auxiliary apparatus cannot be used, the SCHURR Cow-brush should be carried by at least 2 persons.

SCHURR cow-brush Type B00/C12
Feb. 2017 Page 18 www.schurr-geraetebau.de
5.3.3 Securing for transport
 The device is bolted onto the wall mounting or
 strapped down.
Release the transport securing before installation, and be aware of the possible danger of tipping over. Injury
may also occur as a result.
5.3.4 Securing
 The device is mounted on a wall or on a support within the barn or yard.
 The device should be protected from rain and snow by a roof, if installed in the open.
 Sufficient free space must be available in front of the device so that other animals may pass freely while an
animal is being brushed.
 Do not install the device directly in front of or behind the milking parlour, to ensure that animal congestion
does not occur.
 The device must be attached to a concrete wall using the 4 heavy-duty plugs supplied.
 In the case of other wall materials such as tiles or wood, through bolts must be used. This type of material
does not have the required carrying capacity/stability for heavy-duty plugs.
 In the case where the device is attached to a pillar, support or plank wall, please consult Schurr Gerätebau
GmbH for information on the dimensions necessary for suitable fastening.

SCHURR cow-brush Type B00/C12
Feb. 2017 Page 19 www.schurr-geraetebau.de
Sequence of actions
Mark the drilling template according to fig. 4.0.
Drill the 4 12 mm holes
Hammer the heavy-duty plugs into the wall,
or push the through bolts through the holes.
At least 2 persons should assist in hanging the device on the heavy-duty plugs.
Tighten the nuts. Use self-securing nuts or a safety glue such as 'Loctite blue', for example.
Fig. 4.0 Securing of SCHURR Cow-brush
For example: fixing height from bottom to the upper screws
holsteins – ca. 1530 mm-1570 mm brown – ca. 1520 mm-1550 mm
Note:
No guarantee or liability claims will be entertained where the SCHURR Cow-brush is not secured properly!
See below:
recommended height for
installation

SCHURR cow-brush Type B00/C12
Feb. 2017 Page 20 www.schurr-geraetebau.de
5.3.5 Power supply
Danger!
Electric voltage or current.
Can lead to serious injury or death.
Ensure that work with live parts and electrical connection is performed by a qualified and
authorised electrician only.
 A qualified electrician should connect the power supply with the connecting terminal/ground clamp.
 Protection max. 16A. It has to be a residual current circuit-breaker installed.
The qualified electrician have to connect the protective conductor (green/yellow)
5.4 First time use
5.4.1 Measures prior to first time use
A qualified electrician should
Set the potentiometer in the control housing to the required time (preset to approx. 18 sec.).
5.4.2 Trial run
When the device has been connected to the power supply, the functionality may be tested.
Sequence of actions
Typ C12/B00: Turn the brush to start the motor accordingly. It’s not necessary to push the support frame
upwards!
