Schwinn 202 Recumbent Bike User manual

202 Schwinn® Recumbent Exercise Bike
Parts List
Full Size Hardware Chart
Product Illustration
Assembly Instructions
202 Recumbent Exercise
Bike

IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of serious injury, please read the following
precautions before using the Schwinn 202.
1. It is the responsibility of the owner to ensure that all users of this equipment
are adequately informed of all precautions.
2. Read all instructions in this manual and in the accompanying literature and
follow them carefully before using the equipment.
3. If you feel pain or dizziness at any time while exercising, stop immediately and
consult your physician.
4. Use this equipment only on a solid level surface. Cover the floor or carpet
beneath this equipment for protection.
5. Inspect and tighten all parts often. Replace any worn parts immediately.
6. Keep small children and pets away from this equipment at all times.
7. Always wear athletic shoes for foot protection. Do not wear loose or dangling
clothing while using exercise bicycle.
8. Care should be taken when mounting or dismounting the exercise bicycle.
9. Read all warnings posted on the exercise bicycle.
10. User weight limit on the Schwinn 202 is 300 lbs.
This Schwinn 202 is intended for home use only. Do not use this equipment in
any non-residential environment.
WARNING: Before beginning this or any exercise program, consult your
physician. This is especially important for persons over the age of 35 or persons
with pre-existing health problems. Read all instructions before using. We
assume no responsibility for personal injury or property damage sustained by or
through the use of this product.

202 Schwinn Recumbent Bike Parts List,
Hardware Chart, and Assembly Instructions
Assembly of the 202 Recumbent Bike is divided into 5 easy stages; each
comprised of only a few setup steps. Before proceeding with the assembly,
please read over the easy to follow instructions to familiarize yourself with the
process.
• A flat area of 5’ x 7’ is suggested to assemble the 202 exercise bike.
• You will need the following tools to complete the assembly:
5mm Allen wrench (supplied)
Open wrench 13mm, 14mm, 15mm (supplied)
Phillips screwdriver (supplied)
Also, to ensure quick and easy set up of the 202 Recumbent Bike, please verify
the size and quantity of each of the enclosed assembly hardware. Included is a
handy full size hardware chart and parts list of each of the required assembly
hardware. Simply match up the corresponding hardware to each full size
drawing.

Parts List
Check Quantity Description Reference #
__ 8 Allen Bolt M8 x P1.25 x 45mm 1
__ 15 Flat Washer 2
__ 1 Seat Pin Adjustment Knob 3
__ 1 Seat 4
__ 1 Seat Back 5
__ 1 Handlebar Assembly 6
__ 8 Flat Washer ф8*ф16*2T 7
__ 1 Seat Frame Assembly 8
__ 1 Seat Rail 9
__ 1 Rear Stabilizer Tube 10
__ 1 End Cap (for #9) 11
__ 1 Buffer 12
__ 1 Buffer Plate 13
__ 2 Flat Washer for 12/13 14
__ 2 Screw for 12/13 15
__ 2 Carriage Bolt M8 x P1.25 x 75mm 16
__ 1 Front Stabilizer Tube (w/wheels) 17
__ 1pr Pedal Strap (Left & Right) 18
__ 8 Curved Washer 19
__ 4 Acorn Nut 20
__ 1pr Pedals (Left & Right) 21
__ 19 Allen Bolt M8 x P1.25 x 16mm 22
__ 2 Bolt Cover 23
__ 2 Carriage Bolt M8 x P1.25 x 90mm 24
__ 1 Computer Cable (Lower) 25
__ 1 HR Cable (Lower) 26
__ 1 Console Mast Cover 27
__ 1 Computer Cable (Upper) 28
__ 1 HR Cable (Upper) 29
__ 1 Console Mast 30
__ 1 Main Unit 31
__ 1 Lower Base Frame 32
__ 4 Computer Mounting Screws 33
__ 1 Computer 34
__ 1 HR Cable (Seat Rail) 47
__ 2 Water Bottle Cage Mounting Screws 56
__ 1 Water Bottle Cage 57
__ 1 AC Adapter 50

Hardware Chart
Allen Bolt M8xP1.25x16mm
Stage#2
Allen Bolt M8xP1.25x mm
Note: Please verify you have all correct parts and quantities before assembling
unit.
If you are missing items, are short quantities, or have damaged components,
please call 1-800-4-MY-HOME for assistance.
Flat Washer for ф8*ф16*2T
Flat Washerф8*ф19*2T
Allen Bolt M8xP1.25x16mm
Flat Washerф8*ф19*2T Flat Washer
Carriage Bolt M8xP1.25x75mm Curved Washer
Stage#3
Acorn Nut M8
Stage#1
Flat Washerф8*ф19*2T
Flat Washer ф8*ф16*2T
Allen Bolt M8xP1.25x16mm
Stage#4
Curved Washer
Acorn Nut M8
Carriage Bolt M8xP1.25x mm
Allen Bolt M8xP1.25x16mm
Curved Washer
Stage#5
Allen Key
Screwdriver

202 Assembly Drawing with Reference
Numbers
30
2
22
23
22
20
19
32
31
20
19
18
16
17
28
21
22 26
19 25
29
27
11
24
10
22
2
8
47
9
56
57
33
34
58
3
15
14
13
12

Replacement Parts List
Reference # Description
3 Seat Pin Adjustment Knob
4 Seat
5 Seat Back
6 Handlebar Assembly
9 Seat Rail
10 Rear Stabilizer Tube
11 Seat Rail End Cap
12 Buffer
13 Buffer Plate
14 Flat Washer
15 Screws
16 Carriage Bolt M8 x P1.25 x 75mm
17 Front Stabilizer Tube (w/wheels)
20 Acorn Nut
21 Pedals(Left & Right)
22 Allen Bolt M8 x P1.25 x 16mm
23 Bolt Cover
24 Carriage Bolt M8 x P1.25 x 90mm
25 Computer Cable (Lower)
26 HR Cable (Lower)
27 Console Mast Cover
28 Computer Cable (Upper)
29 HR Cable (Upper)
33 Computer Mounting Screws
ottle Cage Mounting Screw
30 Console Mast
32 Lower Base Frame
34 Computer
56 Water B
57 WaterBottleCage

Instructions
IMPORTANT!: To ensure ease of assembly please verify the size and
quantity of all the required assembly hardware and parts with the enclosed
parts list and full size hardware chart.
b ken d wn inEach step of the assembly process has been ro o to s o5 ea y-to-f llow
e.
Assembly Stage #1
Assemble Seat and Handle Bar
Assembly hardware required: (8) M8 Allen Bolts 45 mm long (item #1)
(8) Flat Washers Ø8*Ø19*2T (item #2)
(4) M8 Allen Bolts 16 mm long (item #22)
(4)Flat Washer Ø8* Ø 16*2T(item #7)
Step 1: Attach HANDLEBAR ASSEMBLY (#6) to SEAT FRAME (#8) with the 4
ALLEN BOLTS (#22) and 4 FLAT WASHERS (#7). Tighten bolts with the
provided Allen wrench.
Step 2: Attach SEAT (#4) to SEAT FRAME (#8) with 4 ALLEN BOLTS (#1) and 4
WASHERS (#2). Tighten Bolts.
stages. Please take just a few moments to read over these instructions to
familiarize yourself with the process to make assembly quick and trouble-fre

TSStep 3: Attach SEAT BAC ) with 4 ALLEN BOL
(#1) and 4 WASHERS (#2). Tighten Bolts.
Note: Finished seat should look like picture below:
K (#5) to SEAT FRAME (#8

l to Seat Assembly
.
Assembly hardware required: (4) M8 Allen Bolts 16mm (item #22)
(4) Flat Washers Ø8 * Ø19 * 2T(item#2)
Step 4: Attach SEAT RAIL (#9) to REAR STABILIZER TUBE (#10) with 4 FLAT
WASHERS (#2) and 4 ALLEN BOLTS (#22). Tighten bolts.
Step 5: Place END CAP (#11) on the end of the SEAT RAIL (#9). Make sure the
HR CABLE (#47) is strung through the exit slot on the SEAT RAIL before end cap is
secured.
Step 6: Insert SEAT PIN ADJUSTMENT KNOB (#3) into SEAT FRAME (#8).
Slide the seat assembly from stage 1 onto the SEAT RAIL (#9). Tighten seat
assembly to the rail with the SEAT PIN ADJUSTMENT KNOB (#3). Insert HR
CABLE (#47) into HR input on the back of the seat assembly.
Step 7: Attach BUFFER (#12), BUFFER PLATE (#13), FLAT WASHER (#14) and
SCREWS (#15) to the bottom of the seat rail as illustrated above.
Assembly Stage #2
Attach Rear Stabilizer and Seat Rai
