Scientific SMO5000X Series User manual

Digital Oscilloscope
SMO5000X
User Manual

Scientific
SMO5000X User Manual 2/205
Copyright © Scientific All rights reserved.
This instrument contains proprietary information, no part of this manual may be
photocopied, reproduced or translated without any prior written consent.
Information in this manual supersedes all corresponding previous released material.
Scientific continues to improve products and reserves rights to amend part or all of the
specifications, procedures, equipment at any time without notice.
Ver_1.1/ 1121
Scientific Mes-Technik Pvt. Ltd
B-14 Industrial Estate, Pologround
Indore - 452015 (India)
Tel : [phone]/33
Fax: [phone]
Email : sa[email protected]
Website : www.scientificindia.com

Scientific
SMO5000X User Manual 3/205
Contents
CONTENTS .................................................................................................................... 3
1 INTRODUCTION...............................................................................................10
2 GENERAL SAFETY SUMMARY .......................................................................11
2.1 SAFETY TERMS AND SYMBOLS ...................................................................11
2.2 WORKING ENVIRONMENT..............................................................................12
2.3 COOLING REQUIREMENTS ............................................................................13
2.4 AC POWER ......................................................................................................13
2.5 POWER AND GROUND CONNECTIONS .......................................................14
2.6 CALIBRATION ..................................................................................................15
2.7 CLEANING .......................................................................................................15
2.8 ABNORMAL CONDITIONS ..............................................................................12
3 FIRST STEPS ...................................................................................................16
3.1 DELIVERY CHECKLIST....................................................................................16
4 DOCUMENT CONVENTIONS...........................................................................17
5 GETTING STARTED.........................................................................................18
5.1 POWER ON ......................................................................................................18
5.2 SHUT DOWN .................................................................................................... 18
5.3 SYSTEM STATUS ............................................................................................18
5.4 INSTALL OPTIONS........................................................................................... 18
6 PROBE .............................................................................................................19
7 QUICK START ..................................................................................................20
7.1 FRONT PANEL OVERVIEW .............................................................................20
7.2 REAR PANEL OVERVIEW ...............................................................................21
7.3 CONNECTING TO EXTERNAL DEVICES/SYSTEMS ...................................... 22
7.3.1 Power Supply ....................................................................................................22
7.3.2 LAN...................................................................................................................22
7.3.3 USB Peripherals................................................................................................22
7.3.4 External Monitor ................................................................................................22
7.3.5 Auxiliary Output.................................................................................................22
7.3.6 SAG1021I Waveform Generator........................................................................ 22
7.3.7 Probes...............................................................................................................22
7.3.8 Logic Probe.......................................................................................................23

Scientific
SMO5000X User Manual 4/205
8 TOUCH SCREEN DISPLAY..............................................................................24
8.1 OVERVIEW.......................................................................................................24
8.2 MENU BAR .......................................................................................................25
8.3 GRID AREA ......................................................................................................25
8.4 CHANNEL DESCRIPTOR BOX ........................................................................26
8.5 TIMEBASE AND TRIGGER DESCRIPTOR BOXES ......................................... 28
8.6 DIALOG BOX ....................................................................................................30
8.7 TOUCH GESTURES.........................................................................................31
8.8 MOUSE AND KEYBOARD OPERATION .......................................................... 33
8.9 CHOOSING THE LANGUAGE ..........................................................................33
9 FRONT PANEL .................................................................................................34
9.1 OVERVIEW.......................................................................................................34
9.2 VERTICAL CONTROL ......................................................................................34
9.3 HORIZONTAL CONTROL.................................................................................35
9.4 TRIGGER CONTROL........................................................................................35
9.5 RUN/STOP BUTTON ........................................................................................36
9.6 AUTO SETUP BUTTON....................................................................................36
9.7 DECODE/DIGITAL/MATH/REF CONTROL.......................................................36
9.8 NAVIGATE CONTROL...................................................................................... 37
9.9 CURSORS CONTROL......................................................................................37
9.10 UNIVERSAL KNOB...........................................................................................37
9.11 OTHER BUTTONS............................................................................................38
10 MULTIPLE APPROACHES TO RECALL FUNCTIONS..................................... 39
10.1 MENU BAR .......................................................................................................39
10.2 DESCRIPTOR BOX ..........................................................................................39
10.3 SHORTCUT BUTTON ON THE FRONT PANEL .............................................. 39
11 QUICKLY CAPTURE THE SIGNAL ..................................................................40
12 VERTICAL SETUP ...........................................................................................41
12.1 TURN ON/OFF A CHANNEL ............................................................................41
12.2 CHANNEL SETUP ...........................................................................................41
13 DIGITAL CHANNELS........................................................................................46
13.1 OVERVIEW ......................................................................................................46
13.2 ENABLE/DISABLE THE DIGITAL CHANNELS ................................................ 47
13.3 DIGITAL CHANNEL SETUP .............................................................................49

Scientific
SMO5000X User Manual 5/205
14 HORIZONTAL AND ACQUISITION SETUP ......................................................51
14.1 TIMEBASE SETUP ..........................................................................................51
14.2 ACQUISITION SETUP ......................................................................................51
14.2.1 Overview ..........................................................................................................51
14.2.2 Acquisition ........................................................................................................53
14.2.3 Roll Mode .........................................................................................................55
14.2.4 Sequence .........................................................................................................56
14.3 HISTORY ..........................................................................................................59
14.4 ZOOM ..............................................................................................................61
15 TRIGGER .........................................................................................................63
15.1 OVERVIEW ......................................................................................................63
15.2 TRIGGER SETUP ............................................................................................. 64
15.3 TRIGGER LEVEL .............................................................................................65
15.4 TRIGGER MODE .............................................................................................66
15.5 TRIGGER TYPE ...............................................................................................67
15.5.1 Overview ..........................................................................................................67
15.5.2 Edge Trigger .....................................................................................................68
15.5.3 Slope Trigger ....................................................................................................68
15.5.4 Pulse Trigger ....................................................................................................70
15.5.5 Video Trigger ....................................................................................................71
15.5.6 Window Trigger .................................................................................................74
15.5.7 Interval Trigger .................................................................................................75
15.5.8 Dropout Trigger ................................................................................................76
15.5.9 Runt Trigger ......................................................................................................77
15.5.10 Pattern Trigger ..................................................................................................77
15.5.11 Qualified Trigger ................................................................................................78
15.6 TRIGGER SOURCE..........................................................................................80
15.7 HOLDOFF......................................................................................................... 80
15.8 TRIGGER COUPLING .....................................................................................81
15.9 NOISE REJECT ...............................................................................................82
15.10 ZONE TRIGGER ..............................................................................................83
16 SERIAL TRIGGER AND DECODE ...................................................................88
16.1 OVERVIEW ......................................................................................................88
16.2 I2C TRIGGER AND SERIAL DECODE ............................................................ 90

Scientific
SMO5000X User Manual 6/205
16.2.1 I2C Signal Settings ...........................................................................................90
16.2.2 I2C Trigger .......................................................................................................91
16.2.3 I2C Serial Decode ............................................................................................94
16.3 SPI TRIGGER AND SERIAL DECODE .............................................................96
16.3.1 SPI Signal Settings ...........................................................................................96
16.3.2 SPI Trigger .......................................................................................................97
16.3.3 SPI Serial Decode ............................................................................................97
16.4 UART TRIGGER AND SERIAL DECODE ........................................................98
16.4.1 UART Signal Settings........................................................................................ 98
16.4.2 UART Trigger ...................................................................................................99
16.4.3 UART Serial Decode ........................................................................................99
16.5 CAN TRIGGER AND SERIAL DECODE ...........................................................99
16.5.1 CAN Signal Settings .........................................................................................100
16.5.2 CAN Trigger .....................................................................................................100
16.5.3 CAN Serial Decode ..........................................................................................101
16.6 LIN TRIGGER AND SERIAL DECODE ............................................................ 102
16.6.1 LIN Signal Settings............................................................................................102
16.6.2 LIN Trigger ........................................................................................................102
16.6.3 LIN Serial Decode ............................................................................................103
16.7 FLEXRAY TRIGGER AND SERIAL DECODE................................................... 104
16.7.1 FlexRay Signal Settings ...................................................................................104
16.7.2 FlexRay Trigger ................................................................................................104
16.7.3 FlexRay Serial Decode .....................................................................................105
16.8 CAN FD TRIGGER AND SERIAL DECODE .....................................................106
16.8.1 CAN FD Signal Settings ...................................................................................106
16.8.2 CAN FD Trigger ................................................................................................106
16.8.3 CAN FD Serial Decode .....................................................................................107
16.9 I2S TRIGGER AND SERIAL DECODE ............................................................108
16.9.1 I2S Signal Settings ........................................................................................... 108
16.9.2 I2S Trigger ........................................................................................................109
16.9.3 I2S Serial Decode .............................................................................................110
16.10 MIL-STD-1553B TRIGGER AND SERIAL DECODE ........................................111
16.10.1 MIL-STD-1553B Signal Settings........................................................................111
16.10.2 MIL-STD-1553B Serial Decode ........................................................................111

Scientific
SMO5000X User Manual 7/205
17 CURSORS ........................................................................................................113
17.1 OVERVIEW ......................................................................................................113
17.2 SELECT AND MOVE CURSORS......................................................................119
18 MEASUREMENT .............................................................................................121
18.1 OVERVIEW ......................................................................................................121
18.2 SET PARAMETERS .........................................................................................122
18.3 TYPE OF MEASUREMENT .............................................................................124
18.3.1 Vertical Measurement .......................................................................................124
18.3.2 Horizontal Measurement ..................................................................................126
18.3.3 Delay Measurement .........................................................................................127
18.4 MEASUREMENT STATISTICS ........................................................................128
18.5 STATISTICS HISTOGRAM ..............................................................................129
18.6 ALL MEASUREMENT ......................................................................................130
18.7 GATE ...............................................................................................................130
19 MATH ...............................................................................................................132
19.1 OVERVIEW ......................................................................................................132
19.2 F(X) ..................................................................................................................134
19.2.1 Addition/Subtraction/Multiplication/Division .......................................................134
19.2.2 Differential ........................................................................................................134
19.2.3 Integral .............................................................................................................135
19.2.4 Square Root .....................................................................................................136
19.2.5 FFT ...................................................................................................................137
19.3 G[F(X)] .............................................................................................................142
20 REFERENCE ...................................................................................................144
21 SEARCH ..........................................................................................................146
22 NAVIGATE .......................................................................................................149
23 MASK TEST .....................................................................................................154
23.1 OVERVIEW ......................................................................................................154
23.2 MASK SETUP ..................................................................................................155
23.2.1 Create Mask......................................................................................................156
23.2.2 Mask Editor ......................................................................................................157
23.3 PASS/FAIL RULE .............................................................................................159
23.4 OPERATION ....................................................................................................159
24 DVM .................................................................................................................160

Scientific
SMO5000X User Manual 8/205
24.1 OVERVIEW ......................................................................................................160
24.2 MODE ...............................................................................................................161
24.3 DIAGRAMS ......................................................................................................162
25 HISTOGRAM ...................................................................................................165
25.1 OVERVIEW ......................................................................................................165
25.2 REGION SETTING............................................................................................167
26 DISPLAY ..........................................................................................................169
27 ARBITRARY WAVEFORM GENERATOR.........................................................175
27.1 OVERVIEW ......................................................................................................175
27.2 OUTPUT ...........................................................................................................177
27.3 WAVE TYPE ....................................................................................................177
27.4 OTHER SETTING ............................................................................................178
27.5 SYSTEM ..........................................................................................................179
28 SAVE/RECALL .................................................................................................181
28.1 SAVE TYPE ......................................................................................................181
28.2 INTERNAL SAVE AND RECALL ......................................................................183
28.3 EXTERNAL SAVE AND RECALL......................................................................184
28.3.1 File manager ....................................................................................................184
28.3.2 External Save and Recall Instance.................................................................... 186
29 SYSTEM SETTING ..........................................................................................189
29.1 SYSTEM STATUS ...........................................................................................189
29.2 SOUND .............................................................................................................189
29.3 UPGRADE SOFTWARE ..................................................................................189
29.4 LANGUAGE .....................................................................................................191
29.5 SCREEN SAVER .............................................................................................191
29.6 I/O SETTING ....................................................................................................192
29.6.1 LAN ..................................................................................................................192
29.6.2 Clock Source.....................................................................................................192
29.6.3 VNC Port ..........................................................................................................193
29.7 DATE/TIME ......................................................................................................193
29.8 INSTALL OPTIONS ..........................................................................................193
29.9 REFERENCE POSITION SETTING .................................................................194
29.10 PERFORM SELF TEST ...................................................................................196
29.11 DO SELF CAL ..................................................................................................199

Scientific
SMO5000X User Manual 9/205
29.12 DEFAULT.......................................................................................................... 200
29.13 POWER ON LINE ............................................................................................200
29.14 DEBUG ............................................................................................................200
30 REMOTE CONTROL ........................................................................................201
30.1 WEB BROWSER ..............................................................................................201
30.2 OTHER CONNECTIVITY .................................................................................202
31 TROUBLESHOOTING .....................................................................................203
32 SERVICE AND SUPPORT................................................................................205

Scientific
SMO5000X User Manual 10/205
1 Introduction
This user manual includes important safety and installation information related
to the SMO5000X series oscilloscopes and includes simple tutorials for basic
operation of the oscilloscope.

Scientific
SMO5000X User Manual 11/205
2 General Safety Summary
This chapter contains information and warnings that must be followed to keep
the instrument operating under the appropriate safety conditions. In addition to
the safety precautions specified in this section, you must also follow
recognized safety procedures.
2.1 Safety Terms and Symbols
When the following symbols or terms appear on the front or rear panel of the
instrument or in this manual, they indicate special care in terms of safety.
This symbol is used where caution is required. Refer to the
accompanying information or documents in order to protect against
personal injury or damage to the instrument.
This symbol warns of a potential risk of shock hazard.
This symbol is used to denote the measurement ground connection.
This symbol is used to denote a safety ground connection.
This symbol shows that the switch is an On/Standby switch. When it
is pressed, the scope’s state switches between Operation and
Standby. This switch does not disconnect the device's power supply.
To completely power off the scope, the power cord must be
unplugged from the AC socket after the oscilloscope is in the
standby state.
This symbol is used to represent alternating current, or "AC".
CAUTION
The "CAUTION" symbol indicates a potential hazard. It calls
attention to a procedure, practice or condition which may be
dangerous if not followed. Do not proceed until its conditions are fully
understood and met.
WARNING
The "WARNING" symbol indicates a potential hazard. It calls
attention to a procedure, practice or condition which, if not followed,
could possibly cause bodily injury or death. If a WARNING is
indicated, do not proceed until the safety conditions are fully
understood and met.

Scientific
SMO5000X User Manual 12/205
2.2 Working Environment
This instrument is intended for indoor use and should be operated in a clean,
dry environment with an ambient temperature range of 0 °C -50 °C.
Note: Direct sunlight, radiators, and other heat sources should be taken into
account when assessing the ambient temperature.
WARNING: Do not operate the oscilloscope in an explosive
atmosphere or wet and damp conditions.
The design of the instrument has been verified to conform to EN 61010-1
safety standard per the following limits:
•Installation (overvoltage) Category: II (Mains Supply Connector) & I
(Measuring Terminals)
•Degree of Pollution: II
•Degree of Protection: I
Note:
Installation (Overvoltage) Category II refers to the local distribution level, which is
applicable to equipment connected to the mains supply (AC power source).
Installation (Overvoltage) Category I refers to signal level, which is applicable to
equipment measuring terminals that are connected to source circuits in which
measures are taken to limit transient voltages to an appropriately low level.
Degree of Pollution II refers to a working environment which is dry and
nonconductive
pollution occurs. Occasional temporary conductivity caused by
condensation is expected.
Degree of Protection I refers to grounded equipment, in which protection
against electric shock is achieved by basic insulation and by means of a
connection to the protective ground conductor in the building wiring.

Scientific
SMO5000X User Manual 13/205
CAUTION: Protect the display touch screen of the scope from
excessive impact.
CAUTION: Do not exceed the maximum specified front panel
terminal (CH1, CH2, CH3, CH4, EXT) voltage levels. Refer to
Specifications for more details.
CAUTION: Do not connect or disconnect probes or test leads while
they are connected to a voltage source.
2.3 Cooling Requirements
This instrument relies on the forced air cooling with internal fans and ventilation
openings. Care must be taken to avoid restricting the airflow around the apertures
(fan holes) at each side of the scope. To ensure adequate ventilation it is required
to leave a 15 cm (6 inch) minimum gap around the sides of the instrument.
CAUTION: Do not block the ventilation holes located on both sides of
the scope
CAUTION: Do not allow any foreign matter to enter the scope through
the ventilation holes, etc.
2.4 AC Power
The instrument operates with a single-phase, 100 to 240 Vrms (+/-10%) AC power
at 50/60 Hz (+/-5%), or single-phase 100 - 120 Vrms (+/-10%) AC power at 400Hz
(+/-5%).
No manual voltage selection is required because the instrument automatically
adapts to line voltage.
Depending on the type and number of options and accessories (probes, PC port
plug-in, etc.), the instrument can consume up to 100 W of power.

Scientific
SMO5000X User Manual 14/205
Note: The instrument automatically adapts to the AC line input within the
following ranges:
Voltage Range: 90 - 264 Vrms 90 - 132 Vrms
Frequency Range: 47 - 63 Hz 380 - 420 Hz
2.5 Power and ground connections
The instrument includes a grounded cord set containing a molded three terminal
polarized plug and a standard IEC320 (Type C13) connector for making line
voltage and safety ground connection. The AC inlet ground terminal is connected
directly to the frame of the instrument. For adequate protection against electrical
shock hazard, the power cord plug must be inserted into a mating AC outlet
containing a safety ground contact. Use only the power cord specified for this
instrument and certified for the country of use.
WARNING: Electrical Shock Hazard!
Any interruption of the protective conductor inside or outside of the
scope, or disconnection of the safety ground terminal creates a
hazardous situation.
Intentional interruption is prohibited.
The position of the oscilloscope should allow easy access to the socket. To make
the oscilloscope completely power off, unplug the instrument power cord from AC
socket.
The power cord should be unplugged from the AC outlet if the scope is not to
be used for an extended period of time.
CAUTION: The outer shells of the front panel terminals (CH1, CH2,
CH3, CH4, EXT) are connected to the instrument’s chassis and
therefore to the safety ground.
2.6 Calibration
The recommended calibration interval is one year. Calibration should be only
performed by qualified personnel.

Scientific
SMO5000X User Manual 15/205
2.7 Cleaning
Clean only the exterior of the instrument, using a damp, soft cloth. Do not use
chemicals or abrasive elements. Under no circumstances allow moisture to
penetrate the instrument. To avoid electrical shock, unplug the power cord from
the AC outlet before cleaning.
WARNING: Electrical Shock Hazard!
No operator serviceable parts inside. Do not remove covers.
Refer servicing to qualified personnel
2.8 Abnormal Conditions
Only operate the instrument for the purposes specified by the manufacturer.
Do not operate the scope if there is any visible sign of damage or has been
subjected to severe transport stresses.
If you suspect the scope’s protection has been impaired, disconnect the power
cord and secure the instrument against any unintended operation.
Proper use of the instrument depends on careful reading of all instruction and
labels.
WARNING: Any use of the scope in a manner not specified by the
manufacturer may impair the instrument’s safety protection. This
instrument should not be directly connected to human subjects or
used for patient monitoring.

Scientific
SMO5000X User Manual 16/205
3 First steps
3.1 Delivery Checklist
First, verify that all items listed on the packing list have been delivered. If you note
any omissions or damage, please contact your nearest SCIENTIFIC customer
service center or distributor as soon as possible. If you fail to contact us
immediately in case of omission or damage, we will not be responsible for
replacement.

Scientific
SMO5000X User Manual 17/205
4 Document Conventions
For convenience, text surrounded by a box border is used to represent the button
of the front panel. For example, Print represents the "Print" button on the front
panel. Italic sized text with shading is used to represent the touchable or clickable
menu/button/region on the touch screen. For example, DISPLAY represents the
"DISPLAY" menu on the screen:
For the operations that contain multiple steps, the description is in the form of
"Step 1 > Step 2 >...".As an example, follow each step in the sequence to
enter the upgrade interface:
Utility＞System Setting＞Upgrade
Press the Utility button on the front panel as step 1, click the System Setting
option on the screen as step 2, and click the Update option on the screen as
step 3 to enter the upgrade interface.

Scientific
SMO5000X User Manual 18/205
5 Getting Started
5.1 Power on
SMO5000X provides two ways for power on, which are:
Power on Line
When the “Power on Line” option is enabled, once the oscilloscope is connected
to the AC power supply through the power cord, the oscilloscope boots
automatically. This is useful in automated or remote applications where physical
access to the instrument is difficult/impossible.
Steps for enabling the "Power on Line" function:
Utility＞Power On Line
Power on by Manual
When the "Power on Line" option is disabled, the power button on the front panel
is the only control for the power state of the oscilloscope.
5.2 Shut down
Long press the power button for two seconds to turn off the oscilloscope.
Note:
The Power button does not disconnect the oscilloscope from the AC power
supply. The only way to fully power down the instrument is to unplug the AC
power cord from the outlet. The power cord should be unplugged from the AC
outlet if the scope is not to be used for an extended period of time.
5.3 System Status
Follow the steps below to examine the software and hardware versions of the
oscilloscope.
Utility＞System Setting＞System Status
See the section "System Status" for details.
5.4 Install Options
A license is necessary to unlock a software option. See the section "Install
Option" for details.

Scientific
SMO5000X User Manual 19/205
6 Probe
The SMO5000X series oscilloscope package includes passive probes as standard
accessories. Please contact us for technical data.
Probe Compensation
When a probe is used for the first time, you should compensate it to match the
input channel of the oscilloscope. Non-compensated or poorly compensated probe
may increase measurement inaccuracy or error. The probe compensation
procedures are as follows:
1. Connect the coaxial cable interface (BNC connector) of passive probe to any
channel of the oscilloscope.
2. Connect the probe to the “Compensation Signal Output Terminal” (Cal) on the
front of the oscilloscope. Connect the ground alligator clip of the probe to the
“Ground Terminal” under the compensation signal output terminal.
3. Press the Auto Setup button.
4. Check the waveform displayed and compare it with the following.
Under Perfectly Over
Compensated Compensated Compensated
5. Use a non-metallic driver to adjust the low-frequency compensation
adjustment hole on the probe until the waveform displayed is as the “Perfectly
compensated” in the figure above.

Scientific
SMO5000X User Manual 20/205
7 Quick Start
7.1 Front Panel Overview
A. Touch Screen Display: The display and major functions area. See "Touch
Screen Display" chapter for more details.
B. Front Panel: Includes knobs and buttons. See "Front Panel" chapter for
more details.
C. Probe Compensation/ Ground Terminal: Supplies a 0-3 V 1 kHz square
wave for compensating the probes.
D. USB Host Ports: Connect the USB host ports to USB storage devices for
data transfer, or USB mouse / keyboard for control.
E. Digital Input Connector: Receives digital signals from the SPL2016 digital
probe.
F. Analog Input Connectors
G. Power Switch
H. Supporting Legs: Adjust the supporting legs properly to use them as stands
to tilt the oscilloscope for stable positioning of the oscilloscope.
