Scientific SMO502ED User manual

User Manual
Digital Storage Oscilloscope
SMO502ED, SMO1002ED

Scientific
SMO502ED,SMO1002ED Manual 2/69
Copyright © Scientific ll rights reserved.
This instrument contains proprietary information, no part of this manual may
be photocopied, reproduced or translated without any prior written consent.
Information in this manual supersede all corresponding previous released
material.
Scientific continues to improve products and reserves rights to amend part or
all of the specifications, procedures, equipment at any time without notice.
Ver1.0/0822
Scientific Mes-Technik Pvt. Ltd.,
B-14 Industrial Estate, Pologround,
Indore- 452015 (India)
Tel : [phone]/33
Fax : [phone],561641
Email : [e-mail]
Website: www.scientificindia.com

Scientific
SMO502ED,SMO1002ED Manual 3/69
Contents
Chapter 1 General Safety Requirements .................................................. 5
Chapter 2 Safety Terms and Symbols ...................................................... 6
Chapter 3 Quick Start ........................................................................... 8
3.1 Introduction .......................................................................... 8
3.1.1 Front Panel ...................................................................... 8
3.1.2 Rear Panel ....................................................................... 9
3.1.3 Control rea ...................................................................10
3.2 Display Interface ..................................................................11
3.3 General Inspection ................................................................13
3.4 Function Inspection ...............................................................14
3.5 Probe Compensation .............................................................15
3.6 Probe ttenuation Coefficient..................................................16
3.7 To use Probe Safely ...............................................................17
3.8 Self-calibration .....................................................................18
3.9 Introduction to Vertical System ...............................................18
3.10 Introduction to Horizontal System ...........................................19
3.11 Introduction to Trigger System ...............................................20
Chapter 4 dvanced User Guidebook ......................................................22
4.1 How to set the Vertical System ...............................................23
4.2 How to use Mathematical Function ..........................................25
4.2.1 The Waveform Calculation ................................................25
4.2.2 FFT function ...................................................................26
4.3 Use Vertical Position and Scale Knobs ......................................29
4.4 How to Set the Horizontal System ...........................................30
4.4.1 Zoom the Waveform ........................................................31
4.5 How to Set the Trigger System ...............................................31
4.5.1 Single Trigger .................................................................32
4.5.2 lternate Trigger .............................................................34
4.6 How to Operate the Function Menu ..........................................34
4.6.1 How to Set the Sampling/Display .......................................35
4.6.2 How to Save and Recall a Waveform ..................................37
4.6.3 How to Implement the uxiliary System Function Setting ......41
4.6.4 How to Update your Instrument Firmware .........................43
4.6.5 How to Measure utomatically ..........................................44
4.6.6 How to Measure with Cursors ............................................49
4.6.7 How to Use Executive Buttons ...........................................53
Chapter 5 Communication with PC .........................................................55
Chapter 6 Demonstration .....................................................................57
Example 1: Measurement a Simple Signal ...............................57
Example 2: Gain of a mplifier in a Metering Circuit ...................58
Example 3: Capturing a Single Signal ......................................59
Example 4: nalyze the Details of a Signal .............................. 61

Scientific
SMO502ED,SMO1002ED Manual 4/69
Example 5: pplication of X-Y Function ...................................63
Example 6: Video Signal Trigger..............................................65
Chapter 7 Troubleshooting ....................................................................66
Chapter 8 Maintenance and Service .......................................................68
Chapter 9 E-Waste Management & Warranty ...........................................69

Scientific
SMO502ED,SMO1002ED Manual 5/69
Chapter 1 General Safety Requirements
Before use, please read the following safety precautions to avoid any possible
bodily injury and to prevent this product or any other connected products from
damage. To avoid any contingent danger, ensure this product is only used within
the ranges specified.
Only a qualified person should perform internal maintenance.
To avoid Fire or Personal Injury:
• Use Proper Power Cord. Use only the power cord supplied with the product
and certified to use in your country.
• Connect or Disconnect Correctly. When the probe or test lead is connected
to a voltage source, please do not connect and disconnect the probe or test
lead.
• Product Grounded. This instrument is grounded through the power cord
grounding conductor. To avoid electric shock, the grounding conductor
must be grounded. The product must be grounded properly before any
connection with its input or output terminals.
When the instrument is powered by C, do not measure C power sources
directly otherwise it will cause a short circuit. This is because the testing
ground and power cord ground conductor are connected.
• Check all Terminal Ratings. To avoid fire or shock hazard, check all ratings
and markings on this product. Refer to the user manual for more
information about ratings before connecting to the instrument.
• Do not operate without covers. Do not operate the instrument with covers
or panels removed.
• Use the Proper Fuse. Use only the specified type and rating fuse for this
instrument.
• void exposed circuit. Be careful when working on exposed circuitry to
avoid risk of electric shock or other injury.
• Do not operate if any damage. If you suspect damage to the instrument,
have it inspected by qualified service personnel before further use.
• Use your Oscilloscope in a well-ventilated area. Make sure the instrument
installed with proper ventilation.
• Do not operate in damp conditions.
• Do not operate in an explosive atmosphere.
• Keep product surfaces clean and dry.
