Scion-Tech SC01.7050 User manual

SC01.7050
HDMI over CAT6
4K/60Hz, 4:4:4, HDR
User Manual
Version: 1.0
Scion-Tech Ltd
Digital Video Distribution

Thank you for purchasing this product
For optimum performance andsafety, please read these instructions carefully
before connecting, operating or adjusting thisproduct. Pleasekeep this manual
for future reference.
Surge protection device recommended
This product contains sensitive electrical componentsthat may bedamaged
by electrical spikes, surges, electric shock, lightingstrikes, etc. Use of surge
protection systems ishighly recommended in order to protect and extend the
life of your equipment.
Table of Contents
1. Introduction.……………………………………………………………………………………………………
2. Features…………………………………………………….…………………………………………………….
3. Package Contents……………………………………………………………………………………………..
4. Specifications.………………………………………………………………………………………………….
5. Panel Description………………..……………………………………………………………………………
6. Connecting Devices………………………………………………………..…………………………………
7. EDID Settings…………………………………………………………………………………………………..
8. ApplicationDrawing..…………………………………………………..…………………………………..
9. Maintenance………………………………………………………..………….…….…………………………
9.1.Servicing……………………………………………………………………………………………………
9.2.Warranty……………………….………………………………………………………………………….
9.3.Returning a Product…………………………….…………………………………………………….
10. Warranty Limitsand Exclusions……………………………………………………………………..
1
1
1
1
2
3
4
4
5
6
6
6
6
7

1. Introduction
TheSC01.7050extends the distance betweentheHDMI source anddisplay up to 50m
over asingle CAT6/6a/7 cable. Theextender deliversUltra HD 4K resolution and
returnpathinfra-redfor controlling the source device. These units support HDMI 2.0,
HDCP 2.2 and HDR making themsuitable for most system installations, including
Gaming, Blu-Ray, SkyHD and SkyQ™.
2. Features
Transmitting distancesup to 50m over single CAT6 cable
18Gbps
4K/60Hz, RGB/YCbCr 4:4:4, YCbCr 4:2:2, YUV 4:2:0, HDR
HDMI 2.0, HDCP 2.2
Uncompressedzero latency
LPCM 7.1, Dolby™ True HD, DTSHD Master Audio™
EDID copying fromsource or display
Return path infra redfor controllingsource device
Locking power supply connectors for peace on mind
3. Package Contents
1) 1 x Transmitter
2) 1 x Receiver
3) 1 x Infrared sender cable
4) 1 x Infrared emitter cable
5) 1 x DC12V/1A Power supply
5) 1 x User Manual
Page 1

4.Specifications
Transmitter Connectivity
HDMIInput: 1 x HDMI Type A, 19-Pin Female
HDMILoop: 1 x HDMI TypeA, 19-Pin Female
CAT6 Output:1 x RJ45 Data Socket
Infra Red: 1 x 3.5mm Jack Socket
Power:1 x DC Jack
Receiver Connectivity
CAT6 Input: 1 x RJ45 Data Socket
Output:1 x HDMI TypeA, 19-Pin Female
Infra Red: 1 x 3.5mm Jack Socket
Signal
Signal Input: HDMI and DVI 1.0 Compliant
Standards:HDMI 2.0, HDCP 2.2, HDR10
Bandwidth: 18Gbps
Video Resolutions:4K/60Hz, 4:4:4
Colour Space: RGB/YCbCr 4:4:4, YCbCr 4:2:2, YUV 4:2:0, HDR
Colour Depth:8/10/12-bit
Audio: LPCM, Dolby Digital™/Plus/EX, Dolby TrueHD, DTS, DTSEX, DTS-96/24,
DTS HighRes, DSD-HD Master Audio, DSD
Infra-Red:WideBandwidth,Frequency 30KHz to 56KHz (940nm)
Power
Type: ACto DCMainsAdaptor
Input: 100~240V AC50/60Hz
Output:Transmitter12V/1A, Receiver PoC (power overcable)
Consumption:6.5watts
Environment
Operating Temperature:-0° to 40°C
Storage Temperature: -20° to 60°C
Operating Humidity: 20to 90%RH(no condensation)
Transmitter Dimensions: (W) 102x (D) 70x ( H) 14
Receiver Dimension: (W) 102 x (D) 70x (H) 14
Weight: Transmitter 150g and receiver 150g
Colour:Black
ESD: HumanBody - +/-8kV, (air gapdischarge) & +/-4kV (contact discharge)
Safety and Emissions: CE, FCC, RoHS
Page 2

5.Panel Description
1. HDMI Input
2. HDMI Looped Output
3. DC 12V / 1A Power Input
4. USB Service Port
5. EDID Copy Switch Tx/Rx
6. Infra Red Output (emitter)
7. CAT6/6a/7 Output
Page 3
4 5 6 7
Service
EDID IR Out CAT Output
1 2 3
DC 12V
HDMI In HDMI Out
Transmitter
1. HDMI Output
2. USB Service Port 3. Infra Red Input (sender)
4. CAT6/6a/7 Input
4
Service IR In CAT Input
1
2 3
HDMI Out
Receiver

6.Connecting Devices
1. Connect the source to the transmitter usinga premium quality HDMI cable no
longer than 3 metersin length.
2. Connect the looped HDMI output to your local display using a similar HDMI
cable.
3. Connect the remote display to thereceivers HDMI output using a premium
quality HDMI cable no longer that 5 meters in length.
4. Usinga CAT6/6a/7 patch lead connect the transmitter and receiver to the wall
outlets.
5. Set theEDID switch (see section 7).
6. Power thetransmitter which will also send power to thereceiver over the CAT
cable. The greenLED’s located inthe RJ45 will illuminateto confirmbothunits
are powered. The amber LED’s with illuminate when the transmitter and
receiver have connected.
7. EDID (Extended Display Identification Data)
Copy EDID fromTx
When the switch position is set to “TX” the transmitter will copy theEDID data from
the display connectedto thelopped HDMI outputandsend the datato thesource
device. Thesource device will thensend the datato all outputs.
Copy EDID fromRx
When the switch position is set to “RX” the Receiver will copy the EDID data from the
farend display connectedto thereceiversHDMI output and send thedatato the source
device. Thesource device will thensend the datato all outputs.
Page 4

8.Application Drawing
Page5
4K/60HzDisplay
4:4:4
DC 12V
HDMI In HDMI Out
Transmitter
Service
EDID IR Out CAT Output
HDMI Out
Receiver
Service IR In CAT Input
4K/60HzDisplay
4:4:4

9.Maintenance
Clean this unit with a soft, dry cloth. Never use alcohol, pint thinner of benzine to clean these
devices.
9.1 Servicing
Damage requiring service: This product should be serviced by a qualified service engineer if:
The DC power cord or AC adaptor has been damaged.
Objects or liquids have entered the housings.
The product has been exposed to rain.
The product has stopped workingor shows signs of significant change in operating
performance or function.
The unit has been dropped or severely damaged externally.
Servicing personnel: Do not attempt to service the product beyond that described in these
instructions. Refer all other servicing to authorised serving personnel.
Replacement parts: When parts need replacingensure the service engineeruses parts specified by
the manufacture or parts that have the same characteristics as the original parts. Unauthorised
substitutes may result in fire, electric shock or other hazards.
Safety check: After a repair or service, ask the engineer to perform safety checks to confirm the
product is in proper working condition.
9.2 Warranty
If your product does not work properly because of a defect in materials or workmanship, our
Company (referred to as "the warrantor" ) will , for the length of the period indicated as below,
(Parts and labour 2 years) which starts with the date of original purchase ("Limited
Warranty period"), at its option either (a) repair your product with new or refurbished parts, or
(b) replace it with a new of a refurbished product. The decision to repair or replace will be made
by the warrantor.
During the "Labour" Limited Warranty period there will be no charge for labour.
During the "Parts" warranty period, there will be no charge for parts. You must mail-in your
product during the warranty period. This Limited Warranty is extended only to the original
purchaser and only covers product purchased as new. A purchase receipt or other proof of
original purchase date is required for Limited Warranty service.
9.3 Returning a Product
When shipping the unit carefully pack and send it prepaid, adequately insured and preferably in
the original carton. Include a letter detailing the complaint and provide a day time phone number
and/or email address where you can be reached.
Page6

10. Limited warranty limits and exclusions
ThisLimited Warranty ONLY COVERSfailuresdueto defects inmaterialsor
workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The
Limited Warranty ALSO DOES NOT COVER damages which occurredinshipment, or
failures which arecaused by productsnotsuppliedby warrantor, or failureswhich
result fromaccidents, misuse, abuse, neglect, mishandling, misapplication, alteration,
faulty installation, set-upadjustments, maladjustment of consumer controls, improper
maintenance, powerline surge, lightningdamage, modification, or service by anyone
other than a Factory Service centre or other authorizedservice engineer, or damage
that isattributableto acts of God.
THERE ARE NO EXPRESSWARRANTIESEXCEPT AS LISTED UNDER "LIMITED
WARRANTY COVERAGE".THE WARRANTORISNOT LIABLE FORINCIDENTALOR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR
ARISINGOUT OF ANY BREACH OF THIS WARRANTY. (As examples, thisexcludes
damagesfor lost time, cost of havingsomeone remove or re-install aninstalledunit if
applicable, travel to and fromthe service, loss of or damage to media or images, data or
other recorded content. Theitemslistedare not exclusive, but are for illustration
only).
PARTS AND SERVICE, WHICHARE NOT COVERED BY THISLIMITED WARRANTY,
ARE YOUR RESPONSIBILITY.
This returns policy does not affect your legal rights. Details of your legal rights are
available fromTrading Standards or Citizens Advice Consumer Service.
Scion-Tech Limited
Thatcham, Berkshire
United Kingdom
Tel:+44 (0) 1635 862484
Email: sales@scion-tech.co.uk
Www.scion-tech.co.uk
Page 7
