scope R4C User manual

FRONT
WHEEL
1
SCOPE CYCLING
MAINTENANCE MANUAL

TABLE OF
CONTENTS
General Introduction
Maintenance Intervals
Required Tools
FRONT WHEEL
Hub Parts R3C / R4C / R5C
Hub Parts R3D / R4D / R5D
REMOVING THE BEARINGS
REPLACING THE BEARINGS
REAR WHEEL
HUB PARTS R3C / R4C / R5C
REMOVING THE BEARINGS
REPLACING THE BEARINGS
3
4
5
7
8
9
10
13
14
17

3
GENERAL INTRODUCTION
Congratulations on the purchase of
your new Scope Cycling wheelset.
This maintenance manual applies for
all Scope wheels from 2017 onwards
and provides you with all the infor-
mation you need to take care of your
MAINTENANCE
MANUAL
Scope hubs and to enjoy riding.
We advise you to keep this instruction
manual. For any further information,
check our website:
www.scopecycling.com.

4
MAINTENANCE
ACTION
Replace bearing grease
Replace bearings
Check hub for damage
Cleaning hub outside
RIDING
CONDITIONS
Normal
Extreme
(snow, rain, mud, sand)
Normal
Extreme
(snow, rain, mud, sand)
-
-
INTERVAL
Half year
Quarterly
Every year
Half year
Before every ride
After each ride
HUB
MAINTENANCE
MAINTENANCE INTERVALS
To guarantee a hassle-free performance of your Scope wheels and hubs,
we recommend you to maintain them on a regular basis. For the hubs we
recommend the following maintenance intervals.

5
HUB
MAINTENANCE
REQUIRED TOOLS
All Scope wheels come with high-quality bearings from either SKF or CeramicSpeed,
depending on your chosen model. For a proper installation and deinstallation of
the bearings we advise you to use the Scope Bearing Press set, which included the
following parts:
PART NO.
T1 & T3
T2
T4
T5
T6
T7
T8
T9
PART NAME
Handles
Spindle
Long Presshead 1524/1528
Short Presshead 1524/1528
Plastic Presshead
Large Plastic Spacer (White)
Small Plastic Spacer (Black)
15mm Guide
T1
T4
T2
T5
T3
T6
T9
T7 T8

FRONT
WHEEL
6
R3C / R4C / R5C & R3D / R4D / R5D
The maintenance procedure for the R3d, R4d, and R5d front wheel hubs is
the same as for the R3c, R4c, and R5c front wheel hubs.

7
FRONT
WHEEL
HUB PARTS R3C / R4C / R5C
PART NO.
1 & 6
2 & 5
3
4
PART NAME
End Cap
Bearing
Hub Shell
Axle
1
2
3
4
5
6

8
FRONT
WHEEL
PART NO.
1 & 6
2 & 5
3
4
PART NAME
End Cap
Bearing
Hub Shell
Axle
1
2
3
4
5
6
HUB PARTS R3D / R4D / R5D

9
FRONT
WHEEL
REMOVING THE BEARINGS
To remove the bearings you’ll need the following tools:
• BearingInstallationTool(T1/T2/T3)
• 2xPlasticPresshead(T6)
Remove the end caps by inserting the bearing
installationtoolspindle(T1&T2)intoonesideof
the hub and gently tap out the end-caps on
bothsides(1&8).
Place the two small threaded plastic pressheads
(T6)onabearingasshownintheimageand
insertthebearingremovaltool(T1&T2).
Placethesmallspacer(T8)ontheoppositeside
ofthehubandstarttoscrewonthehandle(T3)
of the bearing removal tool
Gently increase the pressure until the
bearing is released.
Leavetheaxle(5)inplaceandrepeatsteps2-4
on the opposite side.
1
2
3
4
5

10
FRONT
WHEEL
REPLACING THE BEARINGS
To replace the bearings you’ll need the following tools:
• BearingInstallationTool(T1/T2/T3)
• LongBearingPresshead(T4)
• ShortBearingPresshead(T5)
• 15mmGuide(T9)
Apply a small amount of grease on both
bearing seats of the hub.
Carefullyplaceonebearing(2)inthebearing
seat without applying pressure.
Placethelong1524/1528(T5)pressheadand
15mmguide(T9)onthebearingremovaltool
(T1&T2)withthe1524sidefacingthehub.
Slide the tool into the hub and place the short
1524/1528(T5)pressheadontheoppositeside,
thenscrewonthehandle(T3).
1
2
3
4

11
FRONT
WHEEL
Gently tighten the bearing removal tool and
assure its correct position on the bearing.
Tighten the bearing removal tool until the
bearing is fully seated.
Check the alignment to make sure the bearing
runs smoothly.
Inserttheaxleintothehub(5).
Repeat steps 3-7 but do not use the 15mm
guide (T9).
5
6
7
8
9

12
REAR
WHEEL
R3C / R4C / R5C & R3D / R4D / R5D
The maintenance procedure for the R3C, R4C, and R5C rear wheel hubs is
the same as for the R3D, R4D, and R5D rear wheel hubs.

13
REAR
WHEEL
HUB PARTS R3C / R4C / R5C
PART NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
PART NAME
End Cap (DS)
Freehub Bearing (DS)
Freehub Spacer (DS)
Lock Ring
Freehub Body
Freehub Bearing (NDS)
Freehub Spacer (NDS)
Pawls and Springs
Hub Bearing (DS)
Hub Shell
Axle
Hub Bearing (NDS)
End Cap (NDS)
1
234
567
89
10
11
12 13

14
REAR
WHEEL
HUB PARTS R3D / R4D / R5D
PART NO.
1
2
3
4
5
6
7
8
9
10
12
14
15
PART NAME
End Cap (DS)
Freehub Bearing (DS)
Freehub Spacer (DS)
Lock Ring
Freehub Body
Freehub Bearing (NDS)
Freehub Spacer (NDS)
Pawls and Springs
Hub Bearing (DS)
Hub Shell
Axle
Hub Bearing (NDS)
End Cap (NDS)
1
234
567
89
10
11
12 13

15
REAR
WHEEL
REMOVING THE BEARINGS
To remove the bearings you’ll need the following tools:
• BearingRemovalTool(T1/T2/T3)
• 1xPlasticPresshead(T6)
• LargeSpacer(T9)
• SmallSpacer(T8)
Remove the freehub and hub cap from the
hubbypullingitofftheaxle.
Removethefreehubspacerfromtheaxle.
Pull off the non-drive side hub cap by hand.
Placeasmallthreadedplasticpresshead(T6)
onthebearingremovaltool(T1&T2)andinsert
thetoolintotheaxlefromthedrivesideofthe
hub.
Placethesmallspacer(T8)onoppositeside
of the hub and screw on the bearing removal
toolhandle(T3).
Gently tighten until the bearing is released.
Takethehubaxle(11)turnitaroundandplace
it into the non-drive side of the hub.
1
2
3
4
5
6
7

16
REAR
WHEEL
Placethelargespacer(T7)ontheopposite
side of the hub and screw on the bearing
removaltoolhandle(T3).
Gently tighten the tool until the bearing is
released.
Place a small threaded plastic presshead
(T6)onthebearingremovaltool(T1&T2)
andinsertitintotheaxleonthenon-drive
side of the hub.
8
9
10

17
REAR
WHEEL
REPLACING THE BEARINGS
To replace the bearings you’ll need the following tools:
• Bearingremovaltool(T1/T2/T3)
• Longpresshead1524/1528(T4)
• Shortpresshead(1524/1528(T5)
• 15mmguide(T9)
Apply a small amount of grease onto both
bearing seats of the hub.
Carefullyplaceonebearing(2)onthebearing
seat on the drive-side without applying pressure.
Placethelong1524/1528(T5)pressheadand
the15mmguide(T9)onthebearingremoval
tool(T1&T2)withthe1524sidefacingthehub.
Slide the tool into the hub and place the short
1524/1528(T5)pressheadontheoppositeside,
thenscrewonthehandle(T3).
1
2
3
4

18
REAR
WHEEL
Inserttheaxleintothehub(11).
Carefullyplacetheotherbearing(13)inthe
bearing seat on the non-drive side without
applying pressure.
Gently tighten the bearing removal tool and
assure its correct position on the bearing.
Tighten the bearing removal tool until the
bearing is fully seated.
Check the alignment to make sure the bearings
run smoothly.
Repeat steps 3-7 but do not use the 15mm
guide(T9).
Placethefreehubspacer(7)onaxledriveside.
Placethelong1524/1528(T5)pressheadand
the15mmguide(T9)onthebearingremoval
tool(T1&T2)withthe1524sidefacingthehub.
8
9
5
6
7
10
11
12
