CS0415 – 50 lb Cube Ice Machine
CS0415 – 50 lb Cube Ice Machine
Scotsman Ice Systems
775 Corporate Woods Parkway
Vernon Hills, IL 60061
1-800-SCOTSMAN
Fax: [phone]
E-mail: [e-mail]
www.scotsman-ice.com
Features
Self-Contained Under Counter Cuber with Storage
Designed with a
unique inside door
flap to prevent spillage
and maximize storage.
Warranty
• 1 years parts and labor on all components.
Warranty valid in North, South & Central America.
Contact factory for warranty in other regions.
24 Hour Volume Production
Cube Ice
Produces up to 49 lb of small cube ice in 24 hours and stores up to 26 lb of ice.
Compact design allows for placement in tight locations.
15” cabinet width.
Ideal for any under counter bar application.
Unique door flap prevents spillage and maximizes storage.
Produces clear, cube shape ice which is ideal for
mixed drinks and carbonated beverages.
Air Cooled
70˚F/21˚C
50˚F/10˚C
lb/kg
Air
Water
ARI
90˚F/32˚C
70˚F/21˚C
lb/kg
49/22 44/20
Small Cube
¾” x ¾” x ⁄”
(2 x 2 x .95 cm)
Common ice
form, ideal for
mixed drinks.
PRELIMINARY

CS0415 – 50 lb Cube Ice Machine
Scotsman Ice Systems
775 Corporate Woods Parkway
Vernon Hills, IL 60061
1-800-SCOTSMAN
Fax: [phone]
E-mail: [e-mail]
www.scotsman-ice.com
© 2007 Scotsman Ice Systems.
The Smart Choice in Ice.
TM
TM
SIS-SS-CU-CS0415 7-07
Specifications
Operating Requirements
All Models
Dimensions (W x D x H):
Unit:
14.9” x 21.9” x 34”
(37.8 x 55.6 x 86.4 cm)
Shipping Carton:
17.375” x 28.5” x 36.375”
(44.1 x 72.4 x 92.4 cm)
Shipping Weight:
CS0415A-1A 101 lb / 46 kg
CS0415PA-1A 107 lb / 49 kg
BTUs per hour:
N/A
Accessories
* Scotsman recommends all ice machines have water filtration. See Scotsman Sanitation Matrix for details.
Model Number
Condenser
Unit
Storage
Capacity
lb/kg
Basic Electrical
Volts/Hz/
Phase
Max. Fuse Size
or HACR Circuit
Breaker (amps)
Circuit
Wires
Min. Circuit
Ampacity
Energy Consumption
kWh/100 lb (45.4 kg)
90˚F(32˚C)/70˚F(21˚C)
Potable
90˚F(32˚C)/
70˚F(21˚C)
Condenser
90˚F(32˚C)/
70˚F(21˚C)
CS0415A-1A Air 25/11 115/60/1 15 2 Cord 16.7 48/12.7 -
CS0415PA-1A Air 25/11 115/60/1 15 2 Cord 16.7 48/12.7 -
Water Usage
Gallons/100 lb (liters/45.4 kg)
Model Number Description
KCSWFILL Filler kit for installing icemaker in 18” opening.
KCSWTRIM Trim kit for putting wood cabinet front on icemaker door.
Minimum Maximum
Air Temperatures 50°F (10°C) 100°F (38°C)
Water Temperatures 40°F (4.4°C) 100°F (38°C)
Remote Cond. Temps -20°F (-29°C) 120°F (49°C)
Water Pressures 20 PSIG (1.4 bar) 80 PSIG (5.5 bar)
Electrical Voltage -10% +10%
Finish: White, high gloss baked enamel steel.
CS0415PA-1A comes with a pump drain instead of a gravity drain. Maximum vertical pumping height 10’.
Refrigerant - R134a.
Installation Note: Allow 6”space at back for utility connections.
