Scotsman SW 12 USPH-S User manual

Pagina 1 Pagina 1
SCOTSMAN EUROPE - FRIMONT SPA
Via Puccini, 22 - 20010 Pogliano M.se - Milano - Italy
Tel. [phone] (Aut. Sel.)- Telefax [phone]
Direct Line to Service & Parts:
Phone [phone] - Fax [phone]
Website: www.scotsman-ice.com
E-Mail: [email protected]
ISO 9001 - Cert. n. 0080
SERVICE MANUAL
SW 12
USPH-S
S
Water Cooler
REV. 05/2012

Pagina 2 Pagina 2
CONFORMANCE STATEMENT
SW12hasbeenmanufacturedwith
suitable materials for drinking
water.The unit conform to L.D. 108
dated 25.01.1992. The appliance
and approved by the WRAS
(WATERREGULATIONADVISORY
SCHEME)
Water cooler is:
• EC approved
• RespectsECrequirementssafety
objectives of the “Low Voltage”
2006/95/CEE;
•Approvedforprotectionrequisites
of "EMC" 2004/108/CEE.
1 INTRODUCTION
Thismanualprovidesspecificationsandstepby
step procedures for unpacking installation,
operation and maintenance.
• Keep this book for further use.
• When unpacking the unit check about any
transport damage. Anything occured must be
reported to your carrier within 24 hours.
Iftheunithasbeenshippedlayorupside
down, wait approx 8 hours before start
up. This is for cooling system safety.
• Make sure thatinstallation and electrical wiring
are carried out by a qualified technician
according to the manufacturer’s instructions
and to the local norms in force. The electrical
system must be equipped with an effective
earth according to the law (46/90)
Before carrying out any maintenance
orcleaningoperation,disconnectunit
from power.
Thedataandcharacteristicsindicatedinthis
manual do not bind the manufacturer, who
reserves the right for modifications.
Failuretocomplywithanyofthesesafety
regulations could cause fires, electric
shocks or damage the machine
PLACE OF INSTALATION
• Do not place the machine near inflammable
solvents such as alcohol or diluents.
• Donotinstallthemachine inexcessivelydamp
and dusty places, exposed to direct sunlight,
outdoors or near to heat sources.
Installationin theseplacescould causefiresor
electric shocks.
• The appliance is not suitable for use in open
places.
•Duringconnectionoftheappliancetothemains
watersupply,allpreexistingtubes,gasketsand
joints placed between the appliance and the
water mains connection must be replaced with
new material to avoid contamination.
ELECTRIC POWER SUPPLY
• Donot connectordisconnect themachinefrom
the socket with wet hands.
• Do not damage, modify, stretch, bend or twist
the power cable.
Donotplaceheavyobjectsonthe powercable.
•Donotconnectthemachinetoasockettogether
with other equipment (extensions, 2 or 3 plug
adaptors, etc.)
•Donotusethemachineifthepowercableistied
or knotted.
• If smoke, unusual smells or strange noises are
found coming from the machine, disconnect it
immediately from the socket and contact the
local retailer or technical service assistance.
Use of the machine in these conditions could
cause fires or electric shocks.
• Do not spray water on the device; this could
cause electric shocks or fires.
• The appliance must not be installed where
water jets can be generated.
• Use a damp cloth to clean the machine. Do not
use inflammable solvents such as alcohol,
benzeneordiluents.Ifinflammablesubstances
come in contact with the electrical components
inside the machine, they can cause fires or
electric shocks.
• Before cleaning the machine, switch it off and
disconnect it from power. Whether unit is
electrically connected during cleaning could
cause injuries to persons or damages to the
machine.
000100 0102
MANUFACTURER
Mod. ..................
..........V ..........Hz ..........W ..........A
Freon R134a kg............. ClasseT
MADE IN ITALY
WATER COOLERS
1
5
4
2
3
7
6
8
1 Model
2 Power supply
3 Ref. charge
4 Class
5 Watts
6 Cycles
7 Serial number
8 Manufacturing year-month

Pagina 3 Pagina 3
• CutstrapsAandremovecartonB,polystyrene
D and external plastic bag C.
• Remove the base E.
• Place the appliance in its installation site
(pitc 5).
2.1 ADVICE ON HOW TO PROTECT THE
ENVIRONMENT
Packaging
Packaging material is 100% recyclable.
For its disposal follow your local regulations.
Thepackagingmaterial(plasticbags,polystyrene
partsetc.)mustbekeptoutofchildren’sreachas
it could be dangerous.
Information
ThisappliancedoesnotcontainCFCs(thecooling
circuit contains a gas that is not harmful to the
ozone layer).
For further details, please refer to the serial data
plate on the appliance.
Produkt
This appliance is marked according to the
European directive 2002/96/EC on Waste
ElectricalandElectronicEquipment(WEEE).By
ensuring this product is disposed of correctly,
you will help prevent potential negative conse-
quences for the environment and human health,
whichcouldotherwisebecausedbyinappropriate
waste handling of this product.
The symbol on the product, or on the
documents accompanying the product,
indicates that this appliance may not be
treated as household waste. Instead it
shall be handed over to the applicable
collectionpointfortherecyclingofelectrical
and electronic equipment.
2 REMOVAL OF PACKAGING Disposal must be carried out in accordance with
local environmental regulations for waste
disposal.For more detailed information about
treatment,recoveryandrecyclingofthisproduct,
please contact your local city office, your
household waste disposal service or the shop
where you purchased the product.
3 DESCRIPTION OF THEAPPLIANCE
These water coolers are designed to offer
maximum hygiene and easy maintenance.
They are manufactured with a high level perfor-
mance.
The direct water cooling system guarantees an
optimalhygieneforfactories,offices,communities
and public places.
Can be used free standing or wall tight to avoid
unsightly connections.
Exclusive Projector Design: 2-stream mound-
buildingprojectorandautomaticstreamregulator.
PlumbingConnections:enterdirectlyintocabinet.
Waste 24 mm (1”) IPS.
Supply 8 mm (3/7”) IPS.
Finish: stainless steel.
1 Front panel
2 Dispensing water plate
3 Front panel screws
4 Water stream projector
5 Aeration grill (do not cover)
6 Push button actuator
7 Water INLET connection 8 mm (3/7”) with No Return
valve optional
8 Electrical box
9 Thermostat box
10 Water temperature
11 Unit nameplate adjusting screw

Pagina 4 Pagina 4
4 TECHNICAL CHARACTERISTICS
l/h gal/h
Water production 50 13,2
°C°F
Water outlet temperature
8 - 12 46 - 53
Compressor HP 1/4
Rated input W 250
Supply Volt/Hz 230/50-60
Kg Lbs
Net weight 33 73
Kg Lbs
Gross weight 36 79
goz
Freon 134a charge 160 5,6
Conditions of surroundings
Dimensions

Pagina 5 Pagina 5
5 INSTALLATION
Warning! The installation should be
carried out by a qualified operator.
• Remove screws and front panel (pitc 4).
• Forwallmountingbecarefullwhiledrillingfitting
holes and use anchor bolts (pitc 5).
• Locateasuitablewaterdrain baseposition and
drill a hole for hose passing through (pitc 6).
•Predispose holesforthewatersupply pipeand
water supply cable (pitc 11).
• Connect the water supply pipe 8 mm (3/7”) to
the inlet fitting (pitc10).
The No return valve is an optional.
Install a water tap on water inlet line.
• Connect the power supply cable inside the
electrical box (pitc 9).
The supply socket must be equipped
with an efficient earth plate and it
must be sized for the load of the
appliance (see technical characteristics).
Make sure that the mains voltage
correspondswithwhatisspecifiedon
the data plate.
Make sure that there is an omnipolar
switch above the socket with a
minimumcontactbreakof3mm(0.12”)
protected by fuses of suitable
amperage for the absorption of the
appliance itself (see technical
characteristics and data plate).
• Open the water tap G (pitc 11) and adjust the
water flow using a screwdriver on the central
button tap (pitc 8).

5
4
7 8
9
10
11
5 6
F
H
G
