  9. Scott Fetzer meriam M2004 User manual

Scott Fetzer meriam M2004 User manual

Page  of 
© Meriam 2018
R-IR
Quick Start Guide
M2004 Calibrator & Sensors
10920 Madison Ave.
Cleveland Ohio 44102 USA
+ 1 216 281 1100
Meriam.com
(800) 817-7849
A trusted leader in measurement
and calibration solutions.
First things first
General purpose use only
DANGER
!
M2004 Calibrator
MST Sensors
These are not intended for hazardous locations.
Steps to get started
Make a connection
▪Attach the pressure fittings to the internal
pressure sensor module.
▫The threads should be coated with a pipe
sealant compound before installation.
▫Tighten to finger tight plus 1.5 turns to 3
turns using a 19 mm ( in.) wrench on the
manifold.
NOTICE
Use only a wrench on the fitting
and the manifold.
▪Optional: Attach the pressure fittings to the
external pressure sensor module.
▪Optional: Attach the RTD cable and probe to an
RTD module.
Carefully equalize the pressure
To avoid damaging dierential sensors:
1. Make sure you are connecting to the correct
pressure port on DN or DI dierential pressure
modules.
1. P1 port is high pressure.
2. P2 port is low pressure.
2. Apply pressure to both dierential ports (P1 and
P2) at the same time.
Know your batteries
The calibrator is powered by four 1.5 volt AA size
batteries.
▪Never mix batteries—not by manufacturer or by
size, by capacity, or by chemistry.
▪Never mix old and new batteries.
▪Remove all four batteries in the calibrator at the
same time.
▪Replace all four batteries with batteries from the
same package or with the same expiration date.
Install the batteries
1. Turn over the calibrator so the display faces
down.
2. Remove the two screws on the battery cover
with the Phillips head screwdriver by turning
them counterclockwise.
3. Insert four AA batteries.
Note: Pay attention to the positive (+) and
negative (−) battery polarity markings at the
bottom of the compartment.
4. Replace the battery cover. To secure the cover,
torque the screws clockwise 2 in. lbs. maximum.
Learn the function keys
Meriam Tethered Sensors (MTS)
Optional Meriam Tethered Sensors
▪Pressure (Absolute, Compound, Dierential).
▪Temperature (RTD PT100).
Make an electrical connection
▪Align the red dot on the calibrator with the red
dot on the Tether cable and push in.
▪Align the red dot on the MTS with the red dot
on the Tether cable and push in.
USB cable & meriSuite CG
For use only in non-hazardous locations
WARNING
!
Connect the USB cable to the calibrator and to your
computer to configure the calibrator and sensors
using the meriSuite CG application.
Install USB Drivers & meriSuite CG
You must install USB Drivers first then install the
meriSuite CG application.
For installation instructions:
https://www.meriam.com/resources/download/
Open meriSuite CG
Use meriSuite CG application to:
▪Sync PC Time to Gauge for data logging and
display.
▪Select or deselect the Display functions on
each calibrator or Measurement Units that you
need on each sensor.
▪Select the timeout for the Backlight and for the
Auto O.
Close meriSuite CG
NOTICE
▪Do not turn o the power on the calibrator
while it is communicating with meriSuite CG.
▪Close meriSuite CG first, disconnect the USB,
and turn o the calibrator.
1. Backward
2. Home
3. Forward
4. Units
5. Start
6. Stop
7. Up arrow
8. Left arrow
9. Zero or Tare
10. Right arrow
11. Down arrow
12. Cancel or Esc
or ×
13. Accept or 
14. Power
15. Information
16. Backlight
The keys from
left to right
Page  of 
© Meriam 2018
R-IR
Frequently Asked Questions
FAQs
How often is a new pressure
measurement displayed?
The calibrator display updates with a new pressure
measurement five times per second.
What are the dierent Display functions
on the calibrator?
The calibrator ships with five functions turned on.
They are listed in bold below. Turn functions on or
o using meriSuite CG.
. Home (default) . AVG (Average)
. MIN (Minimum) . RATE
. MAX (Maximum) . DATA LOG
. RELIEF (VALVE
TEST)
. Temperature & Time
. Accuracy (+or -). LEAK TEST
. T.OFF, T.ON ( Tare) . LEAK TEST SETUP
What does it mean when the red
backlight flashes?
▪The flashing red backlight indicates an error
condition.
▪Possible error conditions are:
▫Pressure has exceeded the stated upper
limit of the sensor(s).
▫Pressure has fallen below the stated lower
limit of the sensor(s).
▪The red backlight overrides the white backlight.
FAQs
What does the Zero (Ø) key do?
Home
▪If the sensor is within a tolerance band around
zero, press and hold the Zero key to zero the
pressure measurement and to reset the Min
and Max measurements.
▪Note: The tolerance band is approximately ± 1
% of the Full Scale pressure value of the sensor.
▪Absolute sensors have additional functionality.
In Min or Max mode
▪Press and hold the Zero key to reset the Min
and Max measurement. However, this does not
zero the pressure measurement.
In Tare mode
▪When the Tare is o (T.OFF), press and hold
the Zero key to turn on Tare (T.ON) and to
set the Tare value at the current p ressure
measurement.
▪Likewise, when the Tare is on (T.ON), press and
hold the Zero key to turn o the Tare mode.
In Average mode
▪Press and hold the Zero key to restart the
rolling average.
Holding the Zero key
▪The key must be held to perform the Zero or
Tare mode. The displayed value(s) dashes out
during the zero or tare process.
Why are the available units dierent
between a 15 psi and 3 000 psi sensor?
If a given measurement unit cannot display
the correct number of digits, the calibrator
automatically advances to the next displayable unit.
FAQs
Which version of Data Log is on my
calibrator?
1. Turn on the calibrator.
2. Press the Display button until DATA LOG
appears.
3. Press the Information button. The version
appears: Vers. Pro or Vers. Lite.
How long does the white backlight stay
on after the Backlight key is pressed?
▪The white backlight has an automatic timeout.
If no keys have been pressed, the backlight
automatically turns o after 1 minute.
▪Note: You can configure the backlight timeout
with meriSuite CG.
What does the bar graph at the top of the
display indicate?
▪The bar graph displays a live indication of the
current pressure applied to the sensor as a % of
Full Scale.
▪However, when the battery percentage is
displayed, the bar graph follows the large digit
display in indicating the remaining state of
charge for the batteries.
What does low battery indicator mean?
▪Be prepared to change batteries when you
see the outline of the battery icon or when the
outline of the icon flashes.
FAQs
How long will the calibrator remain on if
I leave it unattended?
▪The default setting is Always On.
▪You can configure the timeout for Auto O with
meriSuite CG.
How to contact us
Contact Sales
If you have any issues, questions, or suggestions,
please contact us using one of the following
methods.
[email protected]
Meriam®
 Madison Ave
Cleveland Ohio  USA
+    
www.meriam.com
() -
