Overview
Verifying and calibrating HDR is one of the most difficult things in the current UHD landscape. HDR
is a key element in HDMI 2.0(a) specifications. Most manufactures have already (or have plans to)
implement HDR into their display devices in one way or another. The current landscape of HDR as
of this writing (Jan, 2016), contains various theories and concepts on proper implementation.
There are many resources I highly recommend reading on the last page of this document to help
you see exactly what it happening out there as it pertains to HDR. Even though there are differing
theories on how HDR should be “decoded” a mastering process is already in place, so the
implementation is sound.
In this document you will see how to use the Fresco SIX-G to get the “HDR Mode” response from
displays so you can examine how HDR effects greyscales, etc.
We are continuously working with our partners like SpectraCal to define a color correction process
when this mode is active as the luminance is typically “through the roof” and it uses an entirely
different Gamma curve.
There is already HDR Mastered content available from sources like VUDU, Amazon and soon
Netflix. As well at the UHD Blu-Ray on its heels, so from an integrators/calibrator standpoint you
need to understand how HDR content effects these displays and how to get it reproduced
properly.
Key Features:
“3-Ways” of operation
oFree PC Software
oFront Panel Control
oCalMan Calibration Software (Coming Soon)
HDR Metadata can “ride” on any pattern in the device
Can initiate “HDR Mode” from front panel with no need for software
Can read HDR metadata
Can input any Infoframe manually
Can store 2 separate “infoframe injections” for various configurations
Can use CalMan to measure against Gamma throughout Greyscale
