Scott RXI 400 WL - S User manual

RXi400WL
Wi-Fi Internet/ Ethernet/ FMPLL Radio
Instruction Manual

GB-
1
Thelightningflash
witharrowheadsymbol
withinthetriangleisa
warning signalerting
the userof angerous
voltage?insidetheunit.
ATTENTION :Toreducethe rlskof
electricshock,donotremove thecover.
Therearenouserserviceableparts
insidetheunit, Referallservicingto
qualifiedpersonnel.
Theexclamationpoint
withinthe triangleis a
warningsignalerting
the userofimportant
instructions
accompanyingthe
product.
PRECAUTIONS
Follow the advicebelowforsafeandappropriateoperations.
ONPLACEMENT
. Donotusetheunit inplaces,whichareextremelyhot,cold,dusty, or humid.
. Placetheuniton aflat and even surface.
. Donotrestrict theairflowoftheunitbyplacingitin aplacewithpoorairflow,by
coveringit withacloth, orby placingit onacarpet.
ONSAFETY
. When connectinganddisconnectingthe AC/DC adapter fromtheAC mainsoutlet,grip
theplugandnotthecorditself.Pullingthe cord may damage itandcreateahazard.
. Themainsplugmust remainreadilyoperable.
. Whenyouarenotgoingtousetheunitforalongperiod oftime,disconnectthe AC/DC
adapter fromthe ACmainsoutlet.
ONACVOLTAGE
. Beforeuse,checkthatthe voltage thatcan bebornebytheappliancematchesyour
localmainsvoltage.
ONCONDENSATION
. When thereiscondensationinsidetheunit,the unitmaynot functionnormally.
. Letitstand for1to2hoursbeforeturningthepower on, orgraduallyheatthe roomup
and drythe unitbeforeuse.
. Ensure aminimum distanceof5cmaroundthe apparatusforsufficient ventilation.
. Ensure thattheventilation isnotimpeded bycoveringtheventilation openingswith
items,suchasnewspapers, tablecloths, curtains, etc.
. Donotplacenaked flamesources, suchaslightedcandlesontheapparatus.
. Payattention tothe environmental aspects ofbattery disposal.
. Usethe apparatusonly in moderateclimates (notin tropical climates).
. Donotexposetheapparatustodripping orsplashing.
. Donotplaceobjects filledwithliquids,suchasvases,onthe apparatus.

GB-
2
TABLEOFCONTENTS
PRECAUTIO
NS
1
TABLEOFCONTENTS ..
2
BOXCONTENTS ..
2
FEATURES ....
2
LOCATIONOFCONTROLS ...
3
PREREQUISITESFORINTERNETRADIO
5
CONNECTIONS
5
INSTALLINGBATTERIES ... ...
6
BASICOPERATIONS
..
7
FMRADIOOPERATION .
9
INTERNETRADIOOPERATION ...
10
USB DEVICEAND SD/MMC
CARD OPERATION .
12
AUXINFUNCTION ..
12
RECORD FUNCTION ..
13
MAINTENANCE
13
TROUBLESHOOTINGGUIDE ..
14
TECHNICALSPECIFICATIONS
15
BOXCONTENTS
1. Mainunit4.AUXINcable
2. AC/DC adapter5. Interchangeableinlays(x3)
3. Remotecontrolwithbattery 6. Instructionmanual
FEATURES
ThisunitletyouenjoythousandsofInternetradiostationsaswell asyour
favoritelocalFMstations, withfollowingfeatures:
•Accessyour webradioevenwhen your PCisoff. vTuner liveinternetradio
serviceprovidesmore than 5000 radiosworldwide and more than 10000
regularlyupdatedpodcasts.
•ConnecttheunittoyourInternetnetworkwirelessly(Wi-Fi)orwithacable
(Ethernet).
•Fivepreset stationsfor eachwebradiostationand localFMradiostation.
•Recordwebradio,FMradioandmusic(viathe AUXINjack)on aUSB device
or SD/MMCcard forprivateusage only.
•PlayfilesonaUSB deviceor SD/MMCcardandcopyfilesfromyourUSB
devicetoyour SD/MMCcard and vice-versa.
•Usingthe AUXINjack,youcanconnectanexternalaudiodevicetoyour
radioand useit asadocking station.
•Clock and alarmfunctions(wake-upat selectablesource,snoozefunction).
•Stylish,flexibledesignwithinterchangeableinlaysindifferent colors.
•Firmwarecaneasilybe upgraded viatheInternet.
Note:Duetocontinuousimprovements,thefeaturesmaybe subjecttochange
withoutnotice.You shouldupgrade thefirmware regularlybybrowsing
through themenus:Mainmenu àSettings àSystem àUpgrade. Please
download thelatestupdateofthe instruction manual at
http://www.awox.com/scott.

GB-
3
LOCATIONOFCONTROLS
Unit backview
Unit front view
1. Bassreflexhole
2. FMantenna
3. Timeback upbattery
cover
4. Ethernetjack
5. DC IN12Vjack
2
1
3
4
5
1
1. Speakers
2. ALARMOFF button
3. ( ) ON/STANDBY button
4. Preset P1 button
5. Preset/Previous
P2/ button
6. Preset/Play/Pause
P3/ button
7. LCD display
8. Preset/Next
P4/ button
9. Preset/Stop
P5/ button
10. VOLUME + button
11. VOLUME - button
12.Interchangeableinlay
13. SD/MMC cardslot
14.RECORD button
15. USB port
16.Repeat/Shuffle /button
17. SCROLL/SELECT/SNOOZE knob
18. BACK button
19.Headphonesjack
20. AUX IN jack
21. IR (Infra-red)remotecontrolsensor
2
1
3
4
5
6
7
8
9
10 111
21
20
19
18
17
16
15
14
13
12

GB-
4
1
2
4
5
6
3
Remotecontrol
LCDdisplay
1. The heading ofthemenu
2. Connectionstatus(Wi-FiorWired)
3. Navigation
4. Volume
5. Clocktime
6. The contentof themenu
MeaningofLCDicons
1. ( ) ON/STANDBY button
2. BACK button
3. DOWN button
4. Preset P1 button
5. Repeat/Shuffle /button
6. Preset/Previous P2/ button
7. SNOOZE button
8. ALARMOFF button
9. VOLUME +/- buttons
10. SELECT button
11.UP button
12.Preset/Play/Pause P3/ button
13.Preset/Stop P5/ button
14.Preset/Next P4/ button
15.RECORD button
Wired connection
Volume
WiFiconnection
Folder
File
Radio
Previous/NextLevel
Previous/NextItem
Favorites
ProgressBar
Play
Pause
Stop
Record
Select/Enable
Deselect/Disable
Shuffle
Repeatone
Repeatfolder
Track
Stereo
Connection (Top right)
Navigation
Items
Audio Format
Misc. Information
Action in progress
Options
Reminders
Tuning
WAV
MP3
WMA
3
4
5
7
8
9
11
1
2
6
10
12
13
14
15

GB-
5
ROUTER
MODEM
INTERNET
DATAPORT
ROUTER
MODEM
INTERNET
DATAPORT
RJ45ETHERNET
CABLE(NOT
SUPPLIED)
PREREQUISITESFORINTERNETRADIO
Firstofall,you will need abroadband Internetconnectionand awirelessaccess
point(Wi-Fi)connectedtothe broadbandInternetviaarouterandamodem
(cable/DSL).Youcanchoosebetweenawired connection (Ethernet)anda
wirelessconnection (Wi-Fi).
CONNECTIONS
Note:Inorder toavoidanymalfunctions,do notturn on theunitbefore making
anyconnections.
Wiredconnection (Ethernet)
Connecttheunittothebroadband Internetusingan
RJ45Ethernetcable(notsupplied)viathe router
andbroadbandmodem(cable/DSL) asillustrated.
Followyour router’sinstruction manualtoensurea
properInternetconnection.
Ifyoudonothavearouter,youshouldconnectthe
unit directlytothemodem.
Wi-Ficonnection
Usearouter(notsupplied)toconnectthewireless
accesspoint(Wi-Fi)tothebroadbandInternetas
illustrated.Shouldyou haveproblemswiththe
Internetconnection setup,contactyournetworking
devicesupplierand/or Internetserviceprovider.
Note:Theunitshouldworkanywhere withinarange
of atleast15metresaround the wireless accesspoint.
However,theconnectionwill dependonyourrouter
performanceand environmentalfactorssuchasthe
number/ thicknessofthe walls, doorsor windows.
Configurations
•IfyourwirelessnetworkisprotectedbyWiredEquivalentPrivacy(WEP)orWi-
FiProtectedAccess(WPA)dataencryption,you need toknowthe WEP or
WPAcodeinorder toconnecttheunittothenetwork.
•Ifyour wirelessnetworkisconfigured toaccepttrusted
stationsonly,you needtoentertheunitMACaddress into
yourwirelessaccesspoint.TheunitMACaddress canbe
locatedbybrowsingthrough themenu:Mainmenu à
Settings àSystem àConnection àStatus àConfiguration.
•Toenter theunitMACaddressintoyourwireless accesspoint,you mustread
the instructionssuppliedwiththewireless access point.
•For more detailson configurations,refertothe “INTERNETRADIO
OPERATION”section.

GB-
6
Connectingthepowersupply
Insertthe AC/DC adapter plugintoan ACmainsoutletwitha230VAC~50Hz
powersource,and theotherendtothe DC IN12V jack attheback oftheunit.
Connectinganexternal audiodevice(e.g.MP3player)
Connecttheline outorheadphonesjack onanexternalaudiodevice(suchasa
MP3player)tothe unit’s AUX IN jackwiththe AUXINcable(supplied).
Connectingheadphones
Plug theheadphones(notsupplied)intotheunit’sheadphonesjackfor private
listening.The speaker output willbeshut offautomatically.
INSTALLINGBATTERIES
Installingtheremotecontrolbattery
1.Removethebatterycompartmentcoveron thebottomoftheremotecontrol,
bypressing thelefttabtotheright whilstremoving the cover.
2.Inserta3Vlithiumbattery(CR2025or equivalent)withpolarity(+)matching
the markonthebottomoftheremotecontrol.
3.Replacethebatterycompartmentcover.
Note:The remotecontrolbatterynormallylastsforaboutone year,althoughit
dependsonhowoftenand forwhatoperationstheremotecontrolisused.
If the remotecontrolfailstoworkeven whenitisoperatednearthe unit,
replacethebattery.
Installtimebackupbatteries
Timebackup
The clocktimecanbemaintained duringapower failurebyusing 2xAAA/ LR03
batteries(notsupplied).Duringapowerinterruption,the timemaygoforwardor
backslightlyand mayrequire resetting.
Batteryinsertion
1.Removethebatterycover onthe backofthe unitbypressingonthebattery
cover catchwhilstremovingit.
2.Insert2xAAA/LR03 batteries(alkalinebatteriesarerecommended) intothe
batterycompartment,followingthecorrectpolaritiesmarkedinsidethebattery
compartment.
3. Replacethebatterycover.
Note:For optimumperformance,thebatteriesshouldbereplacedevery6
months
Precautionswhenusingbatteries
1. CAUTION: Dangerofexplosionifbatteryisincorrectlyreplaced.Replaceonly
withthe sameorequivalenttypeofbattery.
2.Ensure you followthe correctpolaritieswheninstallingthe batteries(see
marksinthebatterycompartment).Reversed batteriesmaydamagethe
remotecontrol.
3. Exhausted batteriesmust beremovedastheymayleak.
4. Disposeofbatteriesproperlyaccording toenvironmentalregulations.

GB-
7
BASICOPERATIONS
ON/STANDBY mode
Afterconnecting thepower supply(refertoprevioussection - CONNECTIONS),
pressthe( ) ON/STANDBY buttontoturnonthe unit orgotostandbymode.
Navigation andnumber/characterentry
Using thebuttonsontheunit
Turn the SCROLL/SELECT/SNOOZE knob toscrollthrough
the menu andpressittoenter thehighlighteditem.You can
pressthe BACK buttontoreturntopreviousmenu.Pressand
holdthe BACK button toreturntothemainmenu. When
entering numbers,e.g.atime,turn the SCROLL/SELECT/SNOOZE knobto
adjustandpress ittoconfirm.When enteringcharacters,such
asaWEP/WPAkeyduring theWi-Ficonnectionset-up,turn
the SCROLL/SELECT/SNOOZE knobtoadjustthenumber/
characterandpressittoconfirm.Usethe P2/ , P4/ buttons
tomovetothe previousor nextnumber/character.Press and
holddownthe SCROLL/SELECT/SNOOZE knob (or pressthe button) to
completeandconfirmthe entry.
Using theremote control
Thisissimilar tousingthe unitexceptthatyouwillneed tousetheUP or
DOWN buttontoscrollthrough the menu and adjusttheitem.Tocomplete
andconfirmthe entry,pressthe button asthe “pressand hold”button
operation doesnot workontheremotecontrol.
Inthemainmenu,youcan choose: “FMRadio”, “InternetRadio”, “USB/SD/MMC”,
“AuxIn”and “Settings”.
Settings”menu:
Settings
Descriptions
Display
Time Set thehour and minuteoftheclock time.
Alarm
“disable”:
Disablethealarmfunction.
“set/
enable”:
Setthealarmtimeandenablealarm
function.
“select
source”:
Selectthe alarmsource: “FM
preset”, “FMtune”, “Internetradio”,
“USB/ SD/MMC”or “buzzer”.
System
“Connection”
Setup theconfigurationtoconnect
theWi-FiorEthernet, orcheckthe
connection status.
“Upgrade”:
UpgradethefirmwareviatheInternet.
“Language”:
Select theon-screen-displaylanguage.
“Reset”:
Resetall settingstodefaultvalues.

GB-
8
TIMEset
Set theclock
1. Select Settings àTime.Theclock timeisdisplayed.
2.Turnthe SCROLL/SELECT/SNOOZE knob toadjustthe
hourandpress it toconfirm.
3. Repeatthestep(2)toadjustthe minutes.
Set thealarm time
1. Select Settings àAlarm àset/enable. The alarmtimewillbedisplayed.
2. Followthe steps(2) to(3)in “Settheclock”tosetthealarmtime.
Theunitallowsyoutochoosethe sound towhichyou wouldliketowakeup.
1.Toenablethealarm function,select “Settings”à”Alarm”à
“set/enable”and ifnecessary,setthealarmtime.Pressthe
SELECT buttontoconfirm.
2. Toselectthealarmsource,choose “selectsource”: “FM
preset”, “FMtune”(manualtuning toalocalFMradiostation), “Internetradio”,
“USB/SD/MMC”and “buzzer”.
3.Whenthepresetalarmtimeisreached,theunitwillswitchon withthe selected
alarmsource.
4.Press the button tostopthealarmand itwillsound againthe nextdayat
the sametime.
5. Todisablethe alarmcompletely,select “Settings”à”Alarm”à“disable”.
Note:Thedefaultalarmsourceisthe buzzer.Whenanothersourceisselected
butisnotavailableatthealarmtime,itwillautomaticallyswitchtothe
buzzer alarm.
The buzzervolumelevelisfixed.Howeverthesoundlevelcan beadjusted
forthe other sourcesusing the VOL+/- button.
SNOOZEfunction
Whenthe alarmsounds,pressthe SCROLL/SELECT/SNOOZE knobtostopthe
alarmanditwillsound againafter 8minutes.Thisalarmcyclewillrepeatfor up
toonehour.Tocancel SNOOZE function and repeatthealarmthe nextday,
pressthe button.

GB-
9
FM RADIOOPERATION
Thismodeallowsyou tolisten tolocalFMradiostations.
ListentoFMradio
1. Press the ON/STANDBY ()button toturn on theunit.
2. Select FMRadio àTune.
3.Tosearchautomatically,turn the SCROLL/SELECT
/SNOOZE knobonthe unit(or the UP or DOWN
button on the remotecontrol)and releasetotunetoa
station.
4.Tosearchmanually,pressthe SCROLL/SELECT/SNOOZE knoboncetogo
tomanualsearchmodeandthen turnittosearchfor astation. Pressitagain
toreturn tothe autosearchmode.
Achieveoptimumreception
Whenlistening toaFMradiostation,extendand positiontheFMantennato
achieveoptimumreception.
Preset FMradiostations
Youcanstore uptofivepresetstationsfor FMradio.
1.Tunethe radiotoadesiredstation,thenpressandhold
downthepresetbuttons P1 to P5 ontheunit tostore the
station.
2. Repeat step (1)tostoreanyother desiredstations.
Note:Thepressandholdbuttonoperation doesnotworkontheremotecontrol.
ListentoapresetFM station
Directentry
InFMradiomode,pressoneofthe presetbuttons P1 to P5 tolistentothe preset
station.
ViatheFavorites”menu
Thepresetstationsare storedwiththe favoritestationsinthe
“Favorites”menu.Selectthefollowingmenus: “FMRadio”à
“Favorites”and selectthedesiredpresetstation.Press the
SELECT buttontoconfirm.

GB-
10
INTERNETRADIO OPERATION
Yourunitcanbeconnected toawirelessnetwork(Wi-Fi)oran Ethernet.This
allowsyoutoenjoythevTuner liveInternetradioservice.
Note: Beforeoperatingthismode,makesure that you havereadand understood
the instructionsin PREREQUISITESFORINTERNETRADIO”and
CONNECTIONS”.
Configurationssetup
Wiredconnection (Ethernet)
1.ConnecttheunittothebroadbandInternetusing an RJ45
Ethernetcable(notsupplied).Refer to “CONNECTIONS”
formore details.
2.Select “Settings”à“System”à“Connection”à“Ethernet”
à“DHCP”or “STATICIP”.
Dependingon yourInternetconnection type,select “DHCP”or “STATICIP”to
enabletheunittoconnecttothe Internet.In “DHCP”mode,anIPaddressis
automaticallyassigned tothe unit.In “STATICIP”mode,you mustcheckwith
yourserviceprovider toobtainthecorrectIPdataasfollows:
“IP address”à“IP mask”à“IP gateway”à“DNS”
Wi-Ficonnection
1. Usearouter(notsupplied) toconnectthe wireless accesspoint (Wi-Fi)tothe
broadbandInternet,referingtothe “CONNECTIONS”
section.
2.Select “Settings”à“System”à“Connection”à“Wi-Fi”.The
unitwill scan forallavailablewireless networksanddisplay
the networknames(SSID).
3. Select thenetworkandpressthe SELECT button toconfirm.
4. Select thecorrectencryptionsecuritysystem:Open network,
WEP keyor WPA.
5. Open network:Select “DHCP”or “STATICIP”.
WEP key:EntertheWEPcode.
WPAkey:EntertheWPAcode.
Note:Afterenteringthe WEPorWPAkey,youneedtoselect DHCP”or
STATICIP”.
Turnthe SCROLL/SELECT/SNOOZE knob toadjustthe number/
characterand press ittoconfirm.Thenusethe P2/ and P4/ buttonto
movetothepreviousor nextnumber/character.Pressand holddownthe
SCROLL/SELECT/SNOOZE knob(orpressthe buttonon theremote
control)tocompleteandconfirmtheentry.
For boththewired(Ethernet)and Wi-Ficonnection,themessage “Connection
successful”willbe displayed toconfirmthatthe internetisconnected.If thisisnot
the case, “Connectionfailed”willbedisplayed.Youshouldtryabovestepsagain
toentercorrectIP data,WEPor WPA keyandalsomakesure thatthewiredor
wirelessnetworksare availableandworking.

GB-
11
Listening toawebradiostation
Aftersuccessfullyconnectingtothe Internet,you canenjoythe
vTuner liveinternet radioservicebyselecting “Internet Radio”.
Thefollowing optionsare available:
Options
Descriptions
Country
The u
nitcanautomaticallydetectthe countryinwhichtheunit
islocatedanddisplaythewebradiostationsinthat country.
Favorites
The “Favorites”option allowsyoutofindyourfavoritestations.
Location
Thisoptionallowsyoutoselectacountryand
then selecta
web radiostation inthiscountry.
Format
Thisoption allowsyou tochooseacategory: “News”,
“Comedy”, “Dance”and “Sports”. etc.
NewStations
Select thenew stations thathavebeenaddedsincethe last update.
MostPopular
Stations Selectthemostpopularstationsbasedonweb siteusage.
Podcasts By
Genre
Selectyour favoritetypeofpodcastsuchas “Arts”,
“Entertainment”, “Lifestyle”, “Music”, “Talk”, “TV”and “Variety”.
Podcasts By
Location Selectyour favoritetype ofpodcasttypebythelocation.
Preset web radiostations
Youcanstore uptofivepresetstationsfor webradio.Theprocedurefor storing
webstation isthesameas “PresetFMradiostations”using thepresetbuttons
P1 to P5.
Listentoapreset webstation
Theprocedure isthesameastheonedescribed in “Listentoapreset FM
station”.Youcan listentoapresetwebstation directlyusing thebuttons P1 to
P5 or bybrowsing through the “Favorites”menuinInternetRadiomode.
Listof favoritestations
Youcanbookmarkthecurrentweb radiostationinalistof “Favorites”.Thislistis
stored inthe “Favorites”menu.
1.When youwishtostoreawebradiostation,press andhold
downthe SELECT buttonontheunit tobookmarkit inthe
“Favorites”menu.
Note:The pressand holdbuttonoperation doesnotworkon
the remotecontrol.
2.Tofind astationstoredinthe “Favorites”menu,browsethroughthefollowing
menus: “InternetRadio”à“Favorites”andselectthedesired station.
3. Press the SELECT button toconfirm.
4.Toremovethe bookmarkforastation,press the /button.Exitthe
“Favorites”and re-enter it tocheck that thestationisnot inthe “Favorites”list.
Notes:Somewebradiostationsdonotbroadcast24hoursperday,andsomeare
notalways on-line.
Unlikethe FMantenna,theWi-Fiantenna isbuiltintotheunit.Toachieve
optimum reception ofthe wirelessconnection,placethe unitclosetothe
wireless access point.Receptiondependson yourrouterperformanceand
environmentalfactors.

GB-
12
USB DEVICE ANDSD/MMCCARD OPERATION
Thisunitallowsyou tolisten tofilesonaUSB deviceor SD/MMCcard.Youcan
alsocopyfilesfromyourUSB devicetoyourSD/MMCcardand vice-versa.You
canalsorecord web radioand FMradiotoaUSB deviceor SD/MMCcard.
Playback
1.InsertaUSBdiskintotheUSBport or/and an SD/MMC
cardintothe SD/MMC card slotonthefrontoftheunit.
2. Select “USB/SD/MMC”à”Playing”à”USB”or “SD/MMC”.
3.Turn the SELECT buttontoselectafolder andpressittoconfirmtheselection.
Thenturn the SELECT buttontoselect afileand pressittostartplayback.
4. Toskiptothenext/previousfile,pressthe P2/ , P4/ button.
5.Topauseplayback,pressthe P3/ button. Pressit againtoresumeplayback.
6. Tostopplayback, press the P5/ button.
REPEATandRANDOMplayback
Pressthe /button repeatedlytoselectoneofthefollowing playback
modes:Repeat one ,Repeat folder ,Random or Repeat/ Randomoff.
Copyfiles
1. InsertbothaUSB diskandanSD/MMCcard intothe unit.
2. Select “USB/SD/MMC”à”Copy”à”USB”or “SD/MMC”.
3. Select thefiletoyouwishtocopyand pressthe SELECT
button toconfirm.
4. Select thedestinationfolderand press the buttonto
confirm. Note:Ifthedestination deviceisfull, copying willfail.
Note:Ensure thatthedevicecontainsatleastone folderinwhichtoplacethe
copied file.
Someexternalharddisks maynotbesupported.Hard disksthathavea
built-inpower supplyshouldbefavored.
Duetodifferent formats,somemodelsofUSB,SD/MMCstoragedevicesor
MP3playersmaytakelonger timetoberead or evenmaynotberead.
AUX INFUNCTION
An AUXIN jack isprovidedwiththecabletoconnectyourexternalaudiodevice,
suchasaMP3player, inorder tolistentothe musicthroughthisunit.
1.PlugtheAUXINcable(supplied)intothe AUXINjack.Refer
tothe “CONNECTIONS”section.
2. Inthe mainmenu,select “AuxIN”.
3. Operateyour externalaudiodeviceasusualtoselectandplaythemusic.
4.Adjustthevolumecontrolsonbothyour externalaudiodeviceand thisunitto
the desired volumelevel.
Note:InAUXINmode,thisunitdisplaycannotshowanymusicinformation (e.g.
track no.)for your externalaudiodevice.

GB-
13
RECORDFUNCTION
Youcanrecord awebradioorFMradiobroadcast on aUSBdeviceorSD/MMC
cardforprivateusageonly, orrecord an audiofilereadbyan appliance
connectedviatheAUXINjack.
Recordingweb andFMradiostationbroadcasts
1) InsertaUSB deviceand/or SD/MMCcardintotheunitand
listentothe desired weborFMradiostation.
2) Pressthe buttonandifbothdevicesare inserted,
selectthedestination device(USBorSD/MMC).Pressthe
SELECT buttontoconfirm.
3) You can namethe fileyouareabout tocreate. Inorder todo
so,usethe SCROLL/SELECT/SNOOZE knob tochoosea
character,usethe BACK button todeleteacharacterand
the P4 button toskiptothenextcharacter.Thenpressthe
or SELECT button tostart recording.
4) Tostoprecording,press the button.Thefileissaved.
Instantrecordfunction
Youcan alsopressand holddownthe buttonon the unit tostartrecording
immediatelyontheUSB devicewiththedefaultfilename.Howeveryoucannot
createyourownfilename.Ifno USB deviceisinserted,therecordingwill be
recordedtothe SD/MMCcard.
Note:Thepressandholdbuttonoperation doesnotworkontheremotecontrol.
Recordingwiththe AUXINfunction
1.Refer to “AUXINFUNCTION”toplaythe
musiconanexternalappliance.
2.Followsteps(2) to(4) inthe “Record web
andFMradio”section torecordthe musicfromawebor FMstation
broadcast.
Note:If thespaceavailableon thedeviceisnot sufficient, recording willfail.
Playingrecorded files
Refer to “USBDEVICEAND SD/MMCCARD OPERATION”toplaytherecorded
files.
MAINTENANCE
Careand maintenance
Tocleanthecasing,unplugthe unit and wipe offdustandstainswithasoftcloth
moistenedwithamildsoapand water solutiononly.Donotusebenzene,thinner
or similarchemicals.
If atanytimein thefutureyou shouldneed todisposeofthisproduct, please
notethatwasteelectricalproducts shouldnotbedisposed ofwithhousehold
waste.Pleaserecyclewhere facilities exist. Check withyourlocalauthorityor
retailerforrecyclingadvice.(WasteElectricalandElectronicEquipment
Directive)

GB-
14
TROUBLESHOOTING GUIDE
Problems
Recommendations
FMRadio
1.
Noiseordistorted
sound
1.1
ExtendandpositiontheFMantennatoachievethe best reception.
Internet R
adio
2.
Doesnotconnect
totheInternet
2.1
Ensurethatyou haveconfigured yourhomenetworkcorrectlyby
connectingtothe Internet fromaPCusingthesamenetwork.
2.2Forawiredconnection(Ethernet), check thatthe Ethernet cableis
properlyplugged in.
2.3EnsurethataDHCPserverisavailableorthatyouhave
configured astaticIPaddress.ToconfiguretheDHCP, you must
read the instructionssuppliedwiththewirelessaccesspoint.
2.4Ensurethatyourwirelessaccess pointdoesnotrestrict
connectionstoparticularMACaddresses.The unitMACaddress
canbelocatedbybrowsingthrough themenus: “Settings”
à”System”à”Connection”à”Status”à”Configuration”.
2.5If youhaveanencryptednetwork,ensurethatthecorrectWEPor
WPAcodeshavebeen entered correctly.
3.
T
heInternet
connection is
successfulbut
cannotplaya
particularstation
3.1
Thestationdoesnotbroadcast24hoursperday.
3.2Thestationhasreachedthemaximumallowednumberofon-line
listeners.
3.3Thestationdoesnotbroadcastanymore.
3.4Thelinkon the unit isout ofdate.
3.5TheInternetconnectionbetween youand theserver(oftenlocated
inadifferentcountry)isslow.
USBdevice,SD/MMCcard
4.
USB device
orSD/MMCcard
cannotbe inserted
4.1
Insert ittheotherwayround.
5.
USB deviceor,
SD/MMCcardis
not read
5.1
Someexternalharddisks maynotbe supported.Hard
disks that
haveabuilt-inpowersupplyshouldbefavored.
5.2NTFSformatisnotsupported. CheckwiththeUSBdevicefile
systemandformatit withFATorFAT32.
5.3Duetodifferenttechnicalspecifications,somemodelsofUSB
devices,SD/MMCcardsorMP3playersmaynotbe read.
General
6.
Systemhangsup
orabnormal
displayindication
6.1PresstheON/STANDBY(
)buttontogotoStandbymode and
pressitagaintoturnontheunit.
6.2ResetbyunpluggingtheAC/DCadapterforfewsecondsand
plugging it backin.
7.
Nosound
7.1
Adjustthevolume.
7.2Disconnect theheadphones.
8.
Theremote
controldoesnot
work
8.1
Movecloserto
theunitand pointtowardtheIRremotecontrol
sensor.
8.2Insertthebatterywiththe polarity(+)matchingthemarkonthe
bottomofthe remotecontrol.
8.3Replacethebattery.
8.4Thepressandholdbuttonoperationworksonthe unitonly.
Note:Shouldthe problempersist,pleasedownloadthe firmwarefor thisInternet
radiofrom http://www.awox.com/scott andplaceitonaUSB device. Unplug
the AC/DC adapter and inserttheUSB deviceintotheunit.Plugthe AC/DC
adapterbackinand itwill automaticallyupgrade the system.

GB-
15
TECHNICALSPECIFICATIONS
Amplifier
Output power
.
6W(2x3W)
Speakers.
3
”
4
Ohm
FMRadio
Tuningrange
..
87.5
–
108 MHz
Numberofstations
that canbestored...
5
FMantenna
.......
T
elescopic
type,externa
l
InternetRadio
Wiredconnection
..
Network10/100 RJ45 Ethernetjack
Wireless(Wi
-
Fi)connection
802.11b/gwithWEP/WPAencryption
vTuner live
internet
radioservice
Ø
5000 stations+ 10000podcasts
Numberofstations
that canbe
stored...
5
Wi
-
Fiantenna
.
Built
in
to
the unit
USB
device
/Card
Compatiblefiles
.
MP3, WMA
, WAV
USB porttype
.
2.0
USB maximumhandlingcapacity
...
320
GB
Card type
SD/MMC
Card maximumhandlingcapa
city
..
2.0
GB
MP3samplingrate
32,44,48kHz
WMAsampling rate
..
44,48kHz
Otherconnections
AUXINjack
3.5mm
stereojack
Headphonesjack
..
3.5mm stereo
jack
General
Powerconsumption
..
1
2
W
AC/DC adapter
..
AC
100
–
240V
~ 50Hz
DC Output ..
DC IN12V
/1200mA
Remotecontrolbattery
.
3Vlithiumbattery(CR2025
)
Timeback
-
upbattery
2xAAA/LR03(Notsupplied)
Dimension
...
138
(H) x
253
(W)
x
131
(D) mm
Weight(withoutAC/DC adapter)
........
1.5
Kg
Note: Duetocontinuingimprovements, thetechnicalspecificationsare subject to
changewithout notice.
