ScrapBox DreamCart User manual

DreamCart Assembly Instructions
(Proprietary patented product and instructions. Do not copy or distribute)
UPDATED: AUGUST 2019
oh happy day
YOU’VE RECEIVED THE DREAMCART!
It’s already time for your first project. Let’s get to work!
To make the process simple and easy to follow, we’ve broken down the Storage
Cart assembly instructions into simple steps. All of the hardware you will need can
be found in one bag.
If you have questions at any point of the assembly process, don’t hesitate to reach
out to our customer service team. They are the friendliest bunch of furniture ex-
perts and will be happy to help you.
[e-mail]
www.theoriginalscrapbox.com
U.S.A./Canada: 801-226-2686 M-F 9am-5pm MST
We are excited for you to enjoy your inspiring new workspace and can’t wait to see
pictures! Share your photos on Facebook and Instagram and don’t forget to tag @
theoriginalscrapbox. Happy crafting!
The Original ScrapBox Team

Our furniture is
designed to be built
with two people.
Please do not try to
build alone.
A Friend
(not included)
Hardware you’ll need:
Tools you’ll need:
Phillips
Screw Driver
x12
Connecting
Bolts
x5
Hinges
x30
13mm
Euro Screws
x4
Table Leg
Screws
x16
Wheel
Screws
x4
Locking
Wheels
x7
Left Shelf Supports
x7
Inner Shelf Supports
Shelves:
x7
Adjustable Shelves
x1
Sash Lock Catch
(screws included)
x1
Barrel lock
reciever
(screws included)
x2
Left & Right Side
guide sticker
FRONT
LEFT
SIDE
OUTSIDE EDGE
FRONT
RIGHT
SIDE
OUTSIDE EDGE
Hardware for DreamBox Attachment:
x1
Sash Lock
(screws included)
Additional Hardware for
Second Table:
x5
Hinges
x30
13mm
Euro Screws
x4
Table Leg
Screws
x1
Double
Connecting
Bolt
x7
Right Shelf Supports

1
With Lid lying face down, install (6)
connecting bolts with phillips head
screwdriver.
Lid
Lid
2
Install Divider onto center of Lid. Line up
pre-installed cams in Divider with con-
necting bolts making sure that extra hole
on the Divider is toward the back.
Divider
x6
Connecting
Bolts

3
Tighten (2) cams by inserting a phillips
head screwdriver at a slight angle and
turning clockwise.
4
Separate the double connecting bolt and
install into Divider by connecting the two
halves through the pilot hole. Turn to
tighten
Lid
Divider
Lid
Divider
x1
Double
Connecting Bolts

Lid
Divider
Back 1
5
Slide Back 1 onto (3) connecting bolts in
Lid and Divider. Tighten (3) cams.
6
Slide Back 2 onto (3) connecting bolts.
Tighten (3) cams. Back 1
Back 2
Back View

7
Install (6) connecting bolts into Base
piece
Base
8
Carefully flip Base and place onto Back 1,
Back 2 and Divider
Working from the inside out, tighten (4)
cams on the right side and (2) cams on
the left
Lid
Divider Back 1
Back 2
Base
x6
Connecting
Bolts

Back 2
Base
Back 1
9
Install (5) hinges onto Lid using
(15) 13mm euro screws
Back 2
Base
Back 1
10
Attach (5) hinges onto Table using
(15) 13mm euro screws
For DreamBox owners:
Install (1) sash lock and (1) barrel lock
receiver into the pilot holes as shown.
For WorkBox 3.0 owners:
Install (1) sash lock and (1) barrel lock
receiver into the pilot holes.
Table
Electric drill may be used to install hinges.
If you want to attach
DreamCart table to the left
side of your DreamBox table,
install the sash lock and
barrel lock receiver on the
right side (as shown here).
For the right side, install on
the left.
Back View
x5
Hinges
x15
13mm
Euro Screws
x5
Hinges
x15
13mm
Euro Screws
x1
Barrel
Lock Receiver WorkBox 3.0
DreamBox
x1
Sash Lock
(screws included)

Back 2
Base
Back 1
11
Install table leg using (4) Table Leg
Screws
Table
12
To install second Table, install (5) more
hinges onto Lid using (15) more 13mm
euro screws
Base
Back 1
Lid
Divider Table
If you ordered the 1-table option, you can skip to step 15 to complete assembly.
x4
Table Leg Screws
x5
Hinges
x15
13mm
Euro Screws

13
Table
Attach second Table to hinges using
another (15) 13mm euro screws
Stick two rubber bumpers to the corners
of Table
14
Table
Install table leg using (4) table
leg screws
Table
Base
Back 1
Lid
Table
Base
Back 1
Lid
Divider
Divider
x15
13mm
Euro Screws
x4
Table Leg Screws

15
Table
Install (4) wheels using (16) wheel
Screws Table
Base
Back 1
Lid
Divider
With a helper, lock all 4 wheels, and
carefully fold table(s) in. Flip the table
right-side-up.
x16
Table Leg Screws

Install (1) Right Shelf Support, (1) Left Shelf Support, and
(1) Inner Shelf Support per shelf as shown
Slide shelf into all three supports.
For maximum storage capacity, see the
suggested shelf placement on the next
page.
Back 1 Divider
x7
Install shelves using shelf support system
shown below:
2
1
outer edge
x7
Back 1 Divider
inner shelf support holes
Outer Shelf SupportsLeft Shelf Supports
x7
Right Shelf Supports
Left Shelf Support
Right Shelf
Support
Left Shelf
Support
Inner Shelf
Support
Inner Shelf Support

Lid
Base
Suggested shelf placement (for maximum storage capacity)
13
8
3
9
5
1
13
To attach the DreamCart to the DreamBox go to the next two pages. To Attach
the DreamCart to the WorkBox 3.0, see last page.

Proprietary, patented product and instructions. Do not copy or distribute.
LH
FRONT
EGDEEDISTUO
Apply the Left and /or Right Side Guide Sticker to Left/Right
Corner of the DreamBox table. Be sure sticker is up against
the front outside edge of the table.
Use the provided screws to
attach (1) Sash Lock Catch
(per side) with the hook near
the edge of the table using
the sticker as a guide.

LH
You can attach the DreamCart to the DreamBox
using the Sash Lock and Barrel Lock.
You can also install the table on the right side by
changing the position of the barrel and sash lock
Underside view

CENTER BOX
RIGHT BOX
LEFT BOX
Underside view
You can attach the DreamCart to the WorkBox 3.0
using the Sash Lock and Barrel Lock.
You can also install the table on the right side by
changing the position of the barrel and sash lock
Install the sash lock and barrel lock on to
the bottom of the WorkBox 3.0 table by
engaging the locks with the receiving ends.
There are no pre-drilled holes, you will need
to self-tap.
WorkBox Table
DreamCart Table

2Proprietary, patented product and assembly instructions. Do not copy or distribute.
Proprietary, patented product and instructions. Do not copy or distribute.
yipee!
You’ve done it. Now sit back and enjoy your newly expanded workspace, with
three times as much room to dream and create.
Remember to share pictures of your crafts and craft space with us on
Facebook @ScrapBoxFamily
