ScrapBox WorkBox 3.0 User manual

We’ve been working hard to bring you a more customer friendly build in 2018
and we need your feedback. After assembling your WorkBox, please email us about
your experience at [email protected].
For this build, there is no companion video tutorial.
For help installing the shelves, please visit this link (case sensitive):
http://bit.ly/ShelfPegs
If you have questions regarding your WorkBox 3.0, please contact us.
USA/CAN [phone], M-F 9am-5pm MST (Utah)
[e-mail]
www.theoriginalscrapbox.com
You have received The WorkBox 3.0!
Thank you for your continued interest in our products.
We hope The WorkBox 3.0 will provide a place to organize and create.
- The Original Scrapbox Team
AUS #: 61-4-1-4441-8022
GER #: 49-40-57-00-39-98
Cnrtlos
UPDATED: 06/05/2018

2
All panels must be kept at a 90 (Right Angle)
All bases, lids, and shelves must be installed and kept at a right angle (90 ) with side panels.
Once all pieces are fully connected the design is very strong and will last many years!
IMPORTANT
PLEASE READ BEFORE ASSEMBLY
All panels must be installed at a right angle.
Damage may occur if not properly assembled.
o
90
o
90
o
90
o
90
o

3
TOOLS NEEDED:
Our furniture is designed to be built with two people.
Please do not try to build alone.
x16
x16
x4 x4
LEFT BOX HARDWARE: RIGHT BOX HARDWARE:
Door Knob
Bolts
x16
Bolts
Nuts
x16
Nuts
Wheels
Small Base
support pins
x4
MADE IN THE USA
UPDATED: 06/05/2018
The WorkBox 3.0: Assembly Instructions
Phillips Screw Driver Hammer
10mm wrench
(or socket wrench
with extension)
Rubber Mallet
(included)
Locking
Cams
x16 x16
Posts
1 1/2”
Screws
x4 1 1/2”
Screws
x4
14mm
Washer Screws
x8
1” Screw
(or x2 for Ergo White)
(or x1 door handle
for Ergo White)
x1 x1
x1
Angle Brackets
x2
Door Knob
Wheels
Small Base
support pins
x4
Locking
Cams
x16 x16
Posts
14mm
Washer Screws
x8
1” Screw
(or x2 for Ergo White)
(or x1 door handle
for Ergo White)
x1
Angle Brackets
x2
Allen Wrench
(included)

4
CENTER BOX HARDWARE:
LEFT SWING DOOR HARDWARE: WORK TABLE HARDWARE:
SHELVES INCLUDED:
CLEAR TOTES INCLUDED:
Small Base
Support Pins
x4
Table Legs
Metal
Shelf Holders
For Hinges
13mm Euro Screws
Hinges
Shelf Pegs
Vertical Adjustable
Shelf Hardware
13mm Euro Screws
Right Swing Door Hardware
13mm Euro Screws
Center Box Drawer Hardware
Metal
Hooks
Center Drawer
Name Plates
3/4” table
leg screws
(39) 13” x 13”
(3) 13” x 7 1/2 (Upper Center Box)
(24) 3” x 13” Shelves
(3) 11” x 13 (Under Table)
(2) Large Shelves For Under Table
(Uses Metal Shelf Pins)
(20) Shoebox w/ 2 dividers each
(26) Notions w/ 3 dividers each
(33) Large Totes (12 1/4” x 12 1/4” x 3”)
(5) Notion Tray Inserts (For Large Totes)
(13) Clear Zipper Totes (For Black Felt Panel)
(1) 13 x 13 Large
(4) 13 x 6 Medium
(8) 6 x 6 Small
12 mm
Offset Hinges
Offset Hinges
OPTIONAL:
Sash Lock
x4
Sash Lock
x1
14mm
Self-tapping
screws
x28
Posts
x8
Locking
Cams
x28 14mm
Washer Screws
x8
Angle Brackets
x2
x4
x302
Wheels
x16
Nuts
x16
Bolts
1 1/2”
Screws
for divider panels
x12
x102
x13
For Back Panel
25mm Euro Screws
x23
Metal Rods
x2
Plastic Metal
Rod Holders
x4
x6
x5
x3
x6
x30
x8
x2
Drawers
x3
x5
x30
Acrylic Guards
x7

5
Left Box
Left Box
Lid
Base
16 Bolts
16 Nuts
Bottom View
LEFT BOX Build on a blanket for best results
1
Left Box: Side 2
Small base support pins
2
Install small base support pins and posts into
BOTTOM of Side 2 as shown.
Install posts into TOP of Side 2 as shown.
Green dowels
Post hole
Locking
Cam hole
Unfinished edge
Pre-drilled
wheel screw
holes
Pre-drilled
angle bracket
holes
Post hole
Divider
screw
hole
Hammer (16) bolts into top of base.
Install (4) wheels onto bolts.
Tighten with (16) nuts using a
wrench or socket wrench.
Do NOT overtighten screws (wheels should spin freely)
x2
3
With finished edges of Base & Lid facing down,
match up posts with post holes on Side 2.
Use mallet to tap Base and Lid into Side 2.
IMPORTANT
All panels must be installed at a right angle.
Damage may occur if not properly assembled.
Left Box
Side 2
x4 Posts
TOP
BOTTOM

6
5
6
4
Left Box: Side 1
Small base support pins
Install small base support pins and posts into
Insert Cams into bottom
side of Base and top
side of Lid. Turn Cams
with Allen Wrench
until locked in place.
BOTTOM of Side 1 as shown.
Install posts into TOP of Side 1 as shown.
x2
LEFT BOX
Left Box
Side 1
Use mallet to carefully tap Side 1
into the post holes on Base and Lid.
Insert & use Allen Wrench to lock
2 more Cams on Base.
Repeat for Lid.
BASE LID
Locking
Cams
x4
Locking
Cams
x4
BASE LID
x4 Posts
BOTTOM
TOP

7
Be certain each post is secure.
Next, carefully turn box over so that DOOR is facing down.
Be sure that door does not slide off posts.
LEFT BOX
Left Box
Side 1
7
Insert 8 Posts HEAD DOWN
into Post Holes on the edge
of Sides 1 & 2.
8
CAREFULLY Set door over 8 posts.
*Make sure door knob hole is
over Side 1.
DO NOT FORCE onto posts.
Left Box
Side 1
Left Box
Side 1
x8 Posts
Head

8
9
10
11
Left Box
Facing Side 2
Divider
LEFT BOX
To secure door,
insert 8 Cams
along both sides of the
interior of the box and
turn with Allen Wrench until
locked in place.
Insert Shelf Pegs in
holes on Side 2.
We recommend placing
pegs as shown.
*Use rubber mallet to gently
tap into peg hole. Be sure
peg is secure.
Insert Shelf Pegs in
holes on Side 1 of Left Box Divider
to match peg placement from
step 10. *Gently tap with rubber mallet
until secure .
Locking
Cams
x8
Left Box
Side 1
Left Box
Side 1
Shelf Pegs
x24
Shelf Pegs
x24
3
7
11
15
19
23
27
31
35
39
43
47
3
7
11
15
19
23
27
31
35
39
43
47

9
12
13
Next, you will use several shelves as spacers to properly
align and install the Left Box Divider.
Take a moment to locate these shelves:
LEFT BOX
Left Box
Side 1
Left Box
Side 1
3 x 13”
Notions
Shelf
x6
13 x 13”
shelves
x2
Slide divider in and align with
pilot holes on lid and base.
Add shelves as shown.
Once divider and shelves are in place
make sure they fit tightly.
Use a Phillips screw driver to MANUALLY insert
(4) 1 1/2” screws into pilot holes to secure divider.
**Divider MUST be screwed in MANUALLY in order to avoid damaging your WorkBox.**
1 1/2”
Screws
x4

10
13mm
CAUTION: Leave the Left Box laying on its side for a future step
and until attaching the Center Box.
LEFT
Swing Door
with
shelves
Remove spacer shelves now and set aside.
LEFT BOX
13mm Euro Screws
x18
14
Turn box onto Side 2.
Install 5 offset hinges to Left Box Side 1
panel using (15) 13mm Euro Screws.
With two people, attach Left Swing Door with Shelves
to Left Box Side 1 using (15) 13mm Euro Screws.
Left Box
Side 1
Barrel faces down
so that short side of
hinge drops down
below edge of Right
Box.
SHORT SIDE Attaches to
Left Swing Door with Shelves
LONG SIDE Attaches to
Left Box Side 1
It is SAFE to use
an Electric Screw Driver
to intall hinges.

11
Right Box
Right Box
Lid
Base 16 Bolts
16 Nuts
Bottom View
RIGHT BOX
Build on a blanket for best results
1
Right Box: Side 2
Small base support pins
2
Install small base support pins and posts into
BOTTOM of Side 2 as shown.
Install posts into TOP of Side 2 as shown.
Green dowel
Post hole
Locking
Cam hole
Unfinished edge
Pre-drilled
wheel screw
holes
Pre-drilled
angle bracket
holes
Post hole
Divider
screw
hole Hammer (16) bolts into top of base.
Install (4) wheels onto bolts.
Tighten with (16) nuts using a
wrench or socket wrench.
DO NOT overtighten screws (wheels should spin freely)
BOTTOM TOP
x2
3
With finished edges of Base & Lid facing down,
match up posts with post holes on Side 2.
Use mallet to tap Base and Lid into Side 2.
IMPORTANT
All panels must be installed at a right angle.
Damage may occur if not properly assembled.
Right Box
Side 2
x4 Posts

12
5
6
4
Right Box: Side 1
Small base support pins
Install small base support pins and posts into
Insert Cams into bottom
side of Base and top
side of Lid. Turn Cams
with Allen Wrench
until locked in place.
BOTTOM of Side 1 as shown.
Install posts into TOP of Side 1 as shown.
x2
RIGHT BOX
Right Box
Side 1
Use mallet to carefully tap Side 1
into the post holes on Base and Lid.
Insert & use Allen Wrench to lock
2 more Cams on Base.
Repeat for Lid.
BASE LID
Locking
Cams
x4
Locking
Cams
x4
BASE
LID
x4 Posts
BOTTOM
Left Box
Side 1
TOP

13
Be sure each post is secure.
Next, carefully turn box over so that DOOR is facing down.
Be sure that door does not slide off posts.
RIGHT BOX
7
Insert 8 Posts HEAD DOWN
into Post Holes on the edge
of Sides 1 & 2.
8
CAREFULLY Set door over 8 posts.
*Make sure door knob hole is
over Side 1
DO NOT FORCE onto posts.
Right Box
Side 1
x8 Posts
Head
Right Box
Side 1

14
9
10
11
Right Box
Facing Side 2
Divider
RIGHT BOX
To secure door,
insert 8 Cams
along both sides of the
interior of the box and
turn with Allen Wrench until
locked in place.
Insert Shelf Pegs in
holes on Side 2.
We recommend placing
pegs as shown.
*Use rubber mallet to gently
tap into peg hole. Be sure
pegs are secure.
Insert Shelf Pegs in
holes on Side 1 of Right Box Divider
to match peg placement from
step 10
Locking
Cams
x8
Right Box
Side 1
Right Box
Side 1
3
7
11
15
19
23
27
31
35
39
43
47
3
7
11
15
19
23
27
31
35
39
43
47
Shelf Pegs
x24
Shelf Pegs
x24
*Use rubber mallet to gently
tap into peg hole. Be sure
pegs are secure.

15
12
13
Next, as in the Left Box, you will use shelves as spacers to properly
align and install the Right Box Divider.
Take a moment to locate these shelves:
RIGHT BOX
Right Box
Side 1
3 x 13”
Notions
Shelf
x6
13 x 13”
shelves
x2
Slide divider in and align with
pilot holes on lid and base.
Add shelves as shown
Once divider and shelves are in place
make sure they fit tightly.
Use a Phillips screw driver to
MANUALLY insert (4) 1 1/2” screws
into pilot holes to secure divider.
Right Box
Side 1
**Divider MUST be screwed in MANUALLY in order to avoid damaging your WorkBox.**
1 1/2”
Screws
x4

16
SHORT SIDE Attaches to
Right Swing Door with Felt Panel
LONG SIDE Attaches to
Right Box Side 1
CAUTION: Leave the Right Box laying on its side for a future step
and until attaching the Center Box.
RIGHT
Swing Door
with
Felt Panel
Remove spacer shelves now and set aside.
RIGHT BOX
13mm Euro Screws
x18
14
Turn box onto Side 2.
Install 5 offset hinges to Right Box Side 1
panel using (15) 13mm Euro Screws.
With two people, attach Right Swing Door with Felt Panel
to Right Box Side 1 using (15) 13mm Euro Screws.
Right Box
Side 1
13mm
Barrel faces down
so that short side of
hinge drops down
below edge of Right
Box.
It is SAFE to use
an Electric Screw Driver
to intall hinges.

17
1
3
Center Box
Base Top View
Bottom View
CENTER BOX Build on a blanket for best results
Green dowel
Post hole
Pre-drilled
wheel screw
holes
Post
hole Post hole
x4
Wheels
x16
Nuts
x16
Bolts
Hammer (16) bolts into top of base.
Install (4) wheels onto bolts.
Tighten with (16) nuts using a
wrench or socket wrench.
Do NOT overtighten screws (wheels should spin freely)
Fit Divider 1 onto posts with finished
edges facing up. Tap with Mallet to secure.
Insert (2) Cams at bottom of Divider 1 and
tighten with Allen Wrench until secure.
First, assemble the lower section of the Center Box.
2
Insert (2) Posts into post holes on
top side of Center Box Base.
Center Box
Base
Center Box
Base
Top Side
Center Box
Base
x2 Posts
Center Box
Divider 1
Locking
Cams
x2
Finished Edge
Finished Edge

18
CENTER BOX
5
Fit Shelf 1 into post holes on Divider 1
with finished edge facing up.
Next, Insert (2) Cams at top of Divider 1.
Tighten with Allen Wrench until secure.
Next, assemble the upper section of the center box.
You will come back to the lower section later.
4
Insert (2) Posts into post holes on
top side of Center Box Shelf 1.
x2 Posts
Center Box
Base
Center Box
Shelf 1
Bottom Side
Center Box
Shelf 1
Top Side
Center Box
Divider 1
Locking
Cams
x2
Finished Edge

19
CENTER BOX
Use Phillips Screw Driver to MANUALLY
insert (4) 1 1/2” screws into pre-drilled
screw holes on top side of Center Box Lid
to secure Dividers 3.
**Dividers must be screwed in MANUALLY
to avoid damaging your WorkBox.
8
Center Box
Lid
Bottom Side
1 1/2”
Screws
for divider panels
x4
Center Box
Shelf 3
Top Side
Align & insert green dowels
into corresponding dowel holes
on top side of Shelf 3.
Use Rubber Mallet to carefully tap
Shelf 3 until secure.
7
6
Align green dowels on dividers with
dowel holes on lid.
Use Rubber Mallet to carefully tap
Dividers into place until secure.
Center Box
Divider 3
Center Box
Divider 3
Finished Edge
Center Box
Divider 3
Center Box
Divider 3
Center Box
Lid
Top Side
Center Box
Lid
Top Side

20
CENTER BOX
9
10
Center Box
Lid
Bottom
Side
Center Box
Shelf 3
Bottom Side
Use Phillips Screw Driver to MANUALLY
insert (4) 1 1/2” screws into pre-drilled
screw holes on bottom side of Shelf 3
to secure Dividers 3.
1 1/2”
Screws
for divider panels
x4
Center Box
Divider 3
Left Side
Center Box
Divider 3
Right Side
Insert (4) Posts into post holes on
bottom side of Shelf 3.
x4 Posts
**Shelf must be screwed into dividers MANUALLY to avoid damaging your WorkBox.
