SDL Atlas Vortex M6 User manual

Vortex M6
INSTRUCTION MANUAL
SDL Atlas USA
3934 Airway Drive,
Rock Hill, SC 29732, USA
P: +1 803.329.2110
F: +1 803.329.2133
E: info@sdlatlas.com
service-[email protected]
SDL Atlas Hong Kong
3J,Garment Centre, 576
Castle Peak Road, Kowloon,
Hong Kong
P:: +852 3443 4888
F: +852 3443 4999
E: [email protected].cn
SDL Atlas China
1B, Building B, Junxiang Da
Mansion,
No. 9 Zhongshan Yuan
Road, Nanshan,
Shenzhen, 518052, China
P: +86 (755)26711168
F: +86 (755)26711337
E: [email protected]m.cn
www.sdlatlas.com
Instrument Version 2.0
Manual Version 1.0

Vortex M6
i
MANUALSYMBOLS
WARNINGTOUSER,MANTAINENCEORINSTALLER
FAILURE TO INSTALL, MAINTAIN AND/OR
OPERATE THIS MACHINE ACCORDING TO THE
MANUFACTURER’S INSTRUCTIONS MAY
RESULT IN CONDITIONS WHICH CAN PRODUCE
BODILY INJURY AND/OR DAMAGE PROPERTY.
WARNING

___________________ Vortex M6
ii
GENERALEQUIPMENTSPECIFICATIONS
Thispageisarecordoftheequipmentspecifications.Thisinformationmaybefoundonthe
nameplateoftheinstrument.PleasefillintheblanksbelowoncetheSDLAtlasinstrument
hasbeenreceived.
Whencontactingthesalesorservicedepartmenttoorderpartsorobtaininformation,refer
tothispage.ThiswillallowSDLAtlastorespondquicklyandaccuratelytotherequest.
MODEL NO.
___________________________________________________________________
SERIAL NO.
____________________________________________________________________
________________________ ________________________ ________________________
VOLTS CYCLES PHASE
________________________ ________________________ ________________________
NUMBER REV.NO. DATE
MAIN
FUSE____________________________________________________________________
SINGLEPHASE________________AMPERES
MAINFUSE. 把
MODEL: M 6 RE
TYPE: Vortex M6

___________________ Vortex M6
iii
SAFETYINSTRUCTIONS
READTHESEINSTRUCTIONSBEFOREUSE
Duetopotentialhazardsassociatedwithanyelectricalequipment,itisimportantthatthe
user is familiar with the instructions covering the capabilities and the operation of this
instrument.Theusershouldensurethatallreasonablesafetyprecautionsarefollowedand
ifanydoubtexists,seekprofessionaladvicebeforeproceeding.
Theinstrumentisdesignedforusebysuitablytrained,competentpersonnelinacontrolled
workingenvironmentandisintendedforuseasawashtestinginstrumentonly.
Thisinstrumenthasmovingpartsandwhileallreasonablestepshavebeentakentoprotect
personnelassociatedwiththesemovingparts,incorrectorimproperuseoftheequipment
could result in injury. Consideration should be given to the nature of these moving parts
when installing and setting up the equipment. Fully trained, competent personnel should
installthisequipment.Thisinstrumentisintendedforuseinaresidential,commercial,and
lightindustrialenvironmentasdetailedinEN50081‐1.
SDLAtlascannotbeheldresponsibleforanyunauthorizedmodificationstotheVortexM6.
WARNING
Thisinstrumentcontainsmovingpartsandhazardouslivevoltages.Undernocircumstance
shouldtheusertrytopreventorrestrictthemovementofpartsorgainaccesstothe
internalcircuitry.

___________________ Vortex M6
iv
PROVISIONFORLIFTINGANDCARRYING
Whenunpackingormovingthisinstrument,extremecareisrequiredowingtoitsphysical
constructionandweight.
It is recommended that accepted lifting and carrying procedures are employed and that
personnelweartheappropriateprotectiveequipmente.g.safetyshoes.Iftheinstrumentis
to be moved an appreciable distance/height, it is recommended that it is moved via a
suitablevehiclee.g.aforklifttruck.
EQUIPMENTWARRANTY
SDLAtlaswarrantsfortwelve(12)monthsfromfirstuseorfifteen(15)monthsfromdateof
shipment,whicheveroccursfirst,thatthisSDLAtlasinstrumenthas passedourinspection
andtests;thatitisfreefromdefectsinmaterialsandworkmanship;andthatitwillperform
according to the applicable published SDL Atlas specifications if installed and operated
according to our instructions. This warranty isin lieu of any other warranty expressed or
implied.InnoeventwillSDLAtlasbeliableforspecialorconsequentialdamagesduetoof
anyallegedbreachofthiswarrantyprovision.
TheliabilityofSDLAtlashereundershallbelimitedtorepairingorexchanging,atitsoption,
any defective part FOB, the nearest SDL Atlas manufacturing facility. Equipment or parts
that have been subjected to abuse, misuse, alteration, neglect, unauthorized repair, or
installationarenotcoveredbywarranty.SDLAtlasshallhavethe right of final
determinationastotheexistenceandcauseofthedefect.
Whenpartsarerepairedorexchanged,thewarrantyonsaidpartshallcontinueineffectfor
theremainderoftheoriginalequipmentwarrantyperiodorforsix(6)monthsfollowingthe
dateofshipmentbySDLAtlas,whicheverperiodislonger.
SDL Atlas reserves the right to make changes and improvements in its products without
obligationtoinstallthesechangesinproductstheretoforemanufactured.

___________________ Vortex M6
v
PARTSWARRANTY
PartsandmaterialsuppliedbySDLAtlasareinspectedandtestedtoensurethattheyare
free from defects and will operate properly when correctly installed and operated in
equipment produced by SDL Atlas. Parts (excluding consumable components such as light
sources, optical components, crock cloth, etc.) are under warranty for a period of six (6)
monthsfromdateofshipment.Thiswarrantyisinlieuofanyotherwarrantyexpressedor
implied. In no event will SDL Atlas be liable for special or alleged breach of this warranty
provision.
TheliabilityofSDLAtlashereundershallbelimitedtorepairingorexchanging,atitsoption,
any defective part FOB, the nearest SDL Atlas manufacturing facility. Equipment or parts
that have been subjected to abuse, misuse, alteration, neglect, unauthorized repair, or
installationarenotcoveredbywarranty.SDLAtlasshallhavethe right of final
determinationastotheexistenceandcauseofthedefect.
SDL Atlas reserves the right to make changes and improvements in its products without
obligationtoinstallthesechangesinproductstheretoforemanufactured.

__________________ Vortex M6
CONTENTS
1.0 INTRODUCTION.......................................................................1
2.0 SPECIFICATION........................................................................2
3.0 INSTALLATION.........................................................................4
3.1UncratingtheInstrument..................................................4
3.2StandardAccessories.........................................................4
3.3OptionalAccessories..........................................................4
3.4Setup.................................................................................5
4.0 OPERATION............................................................................15
4.1 RunningaPre‐programmedCycle..................................15
4.2 ProgrammingaCycle.....................................................20
4.3 ManualMode................................................................23
5.0 SETTINGS.................................................................................24
6.0 MAINTENANCEandCALIBRATION...........................................30
6.0 ERRORSandFAULTS................................................................33

__________________ Vortex M6
1
1.0Introduction
For decades, AATCC standards for wash shrinkage testing and other sample preparation
procedureshavecalledfortheuseofdomesticwashingmachines.Duringthistime,there
have been many changes to the accepted operating parameters ofa top loading washing
machine.Temperaturesettings,agitationspeedandstyle,spin speed, and wash and spin
timeshaveallseenchangesovertheyears.Whilesomechangesseemlesssignificantthan
others,thenetresulthasbeenamovingtargetwhentryingtosettleonwhatresultsare
correctfromoneinstrumenttothenext.
TheVortexM6hasbeendesignedtospecificallymeettableLP1:Table1,andIIAandIIBof
the 2013 AATCC Monograph and tables IIC and IID of the 2016 AATCC Monograph. The
instrument is a commercial grade instrument that has been modifiedwithacontroller,
heavy duty variable speed motor, and custom water temperature and flow controls. This
constructionallowstheVortexM6tonotonlyperformwashsequencesintightcompliance
oftheMonograph,butalsogiveuserstheabilitytoprogramcustomwasheswithdurations
runningupto5000minutes.
This Instruction Manual contains operational and safety precautions for proper operation.
Pleasereadthemanual carefullybeforeinstallingor operatingyourinstrument.Operators
andmaintenancetechniciansshould read the manual before runningatestorperforming
maintenanceprocedures.SDLAtlasstronglyrecommendsreadingthismanualandcannotbe
heldresponsiblefordamagecausedbyimproperoperationoftheVortexM6.

__________________ Vortex M6
2
2.0Specifications
VORTEXM6
AATCCMonographInstrument
LoadType TopNonLocking
Agitator PlasticFlexVanePost
FrameMaterial GalvanizedSteel
WashTub StainlessSteel
OuterTub PorcelaincoatedStainlessSteel
ExternalDimensions 25.625 "Wide 65.09 cmWide
28 "Deep 71.12 cmDeep
43 "High 109.22 cmHigh
36 "WorkSurface 91.44 cmWorkSurface
DrumDimensions 3.3 ft3 93.45 L
MachineWeight 195 Lbs 88.45 Kg
PackingWeight 300 Lbs 136.1 Kg
Voltage 220Volt±10%,50/60Hertz,AC
BreakerSize 15amp
WaterInputs Hot/Cold
TemperatureControl AvailableIncomingTemps+/‐4C**
DrainRequirements 36"(91.44cm)tallreceptaclerecommended
Agitation 20to120+/‐2spm
AgitationRotation 210degrees
MaxAgitationCycle 5000minutes(83hours)
MaxWaterCapacity 22+/‐1 Gallons 83.6 L
MaxExtractionspecs 770+/‐20RPM
PreprogrammedCycles
Normal,PermanentPress,Delicate,AATCCMonograph6TableIIC&IID**‐2016
Normal,PermanentPressTable1AATCCLP1‐2018.
#ofOpenprograms 99
ProgrammableFunctions FillLevel,Agitationspeed*,ExtractionSpeed,RinseLevel,Temperature***,Soak
Time,WashTime,SpinTime
BypassableErrors Temperature
* ProgrammableAgitationspeedscannotsurpassMax/MinAgitationSpeed
** IIA–2013andIID2016donothaveaPermanentPressOption
***
Temperaturesettingsaredependentonuserssupply.Systemcannotcoolorheat
internally

__________________ Vortex M6
3

__________________ Vortex M6
4
3.0Installation
3.1UncratingtheInstrument
When you receive your Vortex M6, inspect the crate for damage thatmay have occurred
during shipping. Carefully unpack the instrument and thoroughly inspect the instrument
componentsforanydamageorshortages.Reportanyinstrumentdamage to the carrier
and/orshortagestoSDLAtlasCustomerService.
3.2ListofMaterials(StandardAccessories)
204356 VortexM6(1)
Hoses(2–1hot,1cold)
FilterScreens(2)
RubberHoseGaskets(2)
RubberCupsforFeet(4)
3.3OptionalAccessoriesandTestMaterials
201902 AATCCStandardReferenceDetergentwithOpticalBrightener
201858 AATCCStandardReferenceDetergentwithoutOpticalBrightener
201113 CottonWashingBallast
201112 50/50Cotton/PolyWashingBallast
202139 AATCCShrinkageScale
303255 BlackIndelibleMarkers
303257 YellowIndelibleMarkers

__________________ Vortex M6
5
3.4Setup
EquipmentRequiredforInstallation
NOTE:IftheVortexM6isdeliveredonacoldday(belowfreezing), or is stored in an
unheated room or area during the cold months, do not attempt to operate it until the
VortexM6hashadachancetowarmup.
Theproperorderofstepsmustbefollowedtoensurecorrectinstallation.Refertothelist
belowwheninstallingyourinstrument.
3.4.1Removetheshippingbraceandshippingplug.
3.4.1.1 Removetheshippingbracefromunderthelid.
3.4.1.2 The shipping plug will be released from the base of the
instrumentwhenremovingthecardboardbase.

__________________ Vortex M6
6
NOTE:Theshippingbraceand
plugshouldbesavedandmust
be reinstalled whenever the
VortexM6ismovedor
transportedtoanewlocation.
This will prevent damage to
the Vortex M6 components.
Do not tilt the instrument to
frontorsideswhenmoving.
RefertotheUser'sGuidefor
instructions on reinstalling the
shippingmaterials
3.4.2WipeOutInsideofWashtub
3.4.2.1 Priortofirsttest,useanall‐purposecleaneroradetergentand
watersolutionandadampclothtoremoveshippingdustfrom
insideofwashtub
3.4.3 Connectthefillhoses.

__________________ Vortex M6
7
NOTE: Water supply faucets must fit standard 3/4 inch [19 mm] femalegardenhose
couplings.DONOTUSESLIP‐ONORCLAMP‐ONCONNECTIONS.
NOTE:Watersupplyfaucetsshouldbereadilyaccessibletopermitturningthemoffwhen
theVortexM6isnotbeingused.
NOTE:Waterpressuremustbeaminimumof20toamaximumof120poundspersquare
inch[minimumof138toamaximumof827kPa]staticpressuremeasuredatthefaucet.
NOTE:Waterpressureunder20poundspersquareinch[138kPa]willcauseanextended
filltimeintheVortexM6
3.4.3.1 Turn on the water supply faucets and flush the lines for
approximately two minutes to remove any foreign materials
that could clog the screens in the water mixing valve. This is
especiallyimportantwheninstallingyourVortexM6inanewly
constructedorrenovatedbuilding.Build‐upmayhaveoccurred
duringconstruction.
3.4.3.2 Removethetwoplainrubberwashersandtwofilterscreens
fromtheaccessoriesbag.
3.4.3.3 Install them into each end of the fill hoses as shown. The
screenmustbefacingoutward.
3.4.3.4Screw hose couplings with the filter screens onto the water
faucetsuntiltheyarefinger‐tight.Usetheredcolor‐coded
hose for the hot water connection and the blue color‐coded
hoseforthecoldwaterconnection.
3.4.3.5Then,usingapliers,screwapproximately1/4turn.
3.4.3.6Screwhosecouplingsfromotherendofhosesontothewater
mixing valve until they are finger‐tight. Make sure the red
color‐codedhosefromthehotwaterfaucetgoestothewater
mixingvalvemarked“H”andtheblue color‐coded hose from
thecoldfaucetgoestothevalvemarked“C”.
3.4.3.7Then,usingapliers,screwapproximately1/4turn.

__________________ Vortex M6
8
IMPORTANT:DONOTcrossthreadorovertightencouplings.Thiswillcausethemtoleak.
3.4.3.8 Turnwateronandcheckforleaks.
3.4.3.9Ifleaksarefound,turnoffthewater,unscrewhosesand
reinstallthemuntiltherearenoleaks.
IMPORTANT:Turnoffwatersupplywhenevertherewillbeanextendedperiodofnon‐use

__________________ Vortex M6
9
IMPORTANT:
Hosesandothernaturalrubberpartsdeteriorateafterextendeduse.Hosesmaydevelop
cracks,blistersormaterialwearfromthetemperatureandconstanthighpressuretheyare
subjectedto.Allhosesshouldbecheckedonamonthlybasisforanyvisiblesignsof
deterioration.Anyhoseshowingthesignsofdeteriorationlistedaboveshouldbereplaced
immediately.Allhosesshouldbereplacedeveryfiveyears.
3.4.4 Connectthedrainhosetothedrainreceptacle.
3.4.4.1 Removethedrainhosefromitsshippingpositionontherearof
the instrument by unhooking the hose from the retainer
clamp.
3.4.4.2Installthedrainhoseintothedrainreceptacle(standpipe,wall
orlaundrytub)followingtheinstructionsbelow.
NOTE: Drain receptacle must be capable of handling a minimum of1‐1/4inch[32cm]
outsidediameterdrainhose.
StandpipeInstallation
1. Checkstandpipeheight.Therecommendedheightforthestandpipeis36inches
[914mm].Standpipeshigherthan4feet[1220mm]arenotrecommended.
2. Placetheadapterintothestandpipe.
IMPORTANT: To prevent siphoning,
do not place any ribbed portion of
thedrainhoseintothestandpipe.
3. Remove the beaded strap
fromaccessoriesbagand
place around standpipe
and drain hose,
approximately 12 inches
[300mm]downfromthe
topofpipe.
4. Tighten strap to hold hose
to standpipe. This will
prevent the drain hose
fromdislodgingfromdrain
receptacleduringuse.

__________________ Vortex M6
10
WallInstallation
Forinstallationsofthistype,thedrainhoseMUSTbesecuredtooneofthefillhosesusing
thebeadedstrapfromaccessoriesbag.
NOTE:Endofdrainhosemustnotbebelowheightofcabinettop
LaundryTubInstallation
Forthistypeofinstallation,thedrainhoseMUSTbesecuredtothestationarytubtoprevent
hose from dislodging during use. Use the beaded strap (supplied in accessories bag) to
securehose.Werecommendleavingthestandpipeadapteronthedrainhoseforthistype
ofinstallation

__________________ Vortex M6
11
3.4.5 PositionandleveltheVortexM6.
3.4.5.1Positiontheinstrumentsoit
has sufficient clearance for
installationandservicing.
3.4.5.2Place the instrument in
positiononaclean,dry,and
reasonably firm floor.
Installing the Vortex M6 on
anytypeofcarpetingisnot
recommended.
3.4.5.3Foreasieraccesstoleveling
legs,propuptheinstrument
withawoodenblock
3.4.5.4Placerubbercups(fromaccessoriesbag)onallfourlevelinglegs.
3.4.5.5Place a level on the
cabinet top and check if
theVortexM6islevel
fromsidetosideandfront
toback.
3.4.5.6If the instrument is not
level, tilt it back to access
the front leveling legs.
Loosenthelocknutsand
adjust legs by screwing
intooroutofthebase.
3.4.5.7Once adjusted, tilt the
instrument forward on
front legs and lower back
down into position to set
therearself‐levelinglegs.
3.4.5.8TheVortexM6mustnotrock.Whentheinstrumentislevelanddoes
notrock,tightenlocknutssecurelyagainstbottomofitsbase.Ifthese
locknuts are not tight, the instrument will not remain stationary
duringoperation.

__________________ Vortex M6
12
NOTE:Improperinstallationorflexingofweakfloorwillcauseexcessivevibration.Donot
slide the Vortex M6 across floor once the leveling legs have beenextended,aslegsand
basecouldbecomedamaged.
3.4.5.9 Verifythattheinstrumentdoesnotrock.
3.4.6 PlugintheInstrument
ElectricalRequirements
220Volt±10%,50/60HertzwithEarth/GroundPlug
WhenpluggingintheVortexM6:
•DONOToverloadcircuits.
•DONOTuseanextensioncord.
•DONOTuseanadapter.
•DONOToperateotherappliancesonthesamecircuit.Useseparately fused 15 Amp
circuits.
The Vortex M6 is designed to be operated on a separate branch, polarized, three‐wire,
effectiveearth/ground,220Volt,50/60Hertz,AC(alternatingcurrent),circuitprotectedbya
15amperefuse,equivalentfuseorcircuitbreaker.
Thepowercordshouldbepluggeddirectlyintoaneffectiveearth/groundreceptaclerated
220VoltsAC(alternatingcurrent)15Amps.

__________________ Vortex M6
13
Earth/GroundInstructions
This instrument must be properly connected to protective earth/ground. In the event of
malfunction or breakdown, the earth/ground will reduce the riskofelectricshockby
providingapathofleastresistanceforelectriccurrent.
TheVortexM6mustbepluggedintoanappropriateoutletthatisproperlyinstalled
and connected to a protective earth/ground in accordance with all local codes and
ordinances.
•DONOTmodifytheplugprovidedwiththeinstrument–ifitwillnotfittheoutlet,havea
properoutletinstalledbyaqualifiedelectrician.
Table of contents
Other SDL Atlas Laboratory Equipment manuals
Popular Laboratory Equipment manuals by other brands

Analytik Jena
Analytik Jena Biometra TAdvanced Series operating manual

Endress+Hauser
Endress+Hauser analytikjena CyBio QuadPrint HQ Assembly instructions

IKA
IKA A10 basic operating instructions

Thermo
Thermo Luminoskan Ascent user manual

AMX
AMX PS-POE-AT-TC quick start guide

Hologic
Hologic ThinPrep 5000 Operator's manual
