Fritsch ANALYSETTE 28 IMAGESIZER User manual

PARTICLE SIZER
ANALYSETTE 28 IMAGESIZER
Operang instrucons
Valid starng with: 28.2000/00131
Read the instrucons prior to performing any task!
Translaon of the original operang instrucons

Version 03/2019 Index 010
Fritsch GmbH
Milling and Sizing
Industriestraße 8
D - 55743 Idar-Oberstein
Telephone: [phone]
Fax: [phone]
Email: inf[email protected]
Internet: www.fritsch-sizing.de

Cercaons and CE conformity
Fritsch GmbH has been cered by the SGS-TÜV Saar GmbH.
An audit cered that Fritsch GmbH conforms to the requirements of the
DIN EN ISO 9001:2015.
The enclosed Conformity Declaraon lists the guidelines the FRITSCH
instrument conforms to, to be able to bear the CE mark.
Cercaon
CE Conformity
Cercaons and CE conformity
- 3 -

Table of contents
1Basic structure............................................................................... 7
2 Safety informaon and use......................................................... 10
2.1 Requirements for the user................................................... 10
2.2 Scope of applicaon............................................................. 10
2.3 Obligaons of the operator.................................................. 11
2.4 Informaon on hazards and symbols used in this manual... 11
2.5 Device safety informaon.................................................... 14
2.6 Hazardous points................................................................. 15
2.7 Electrical safety.................................................................... 15
2.7.1 General informaon.......................................................... 15
3 Technical data.............................................................................. 16
3.1 Dimensions.......................................................................... 16
3.2 Weight.................................................................................. 16
3.3 Operang noise.................................................................... 16
3.4 Voltage................................................................................. 16
3.5 Current consumpon........................................................... 16
3.6 Power consumpon............................................................. 16
3.7 Electrical fuses..................................................................... 16
4Installaon................................................................................... 17
4.1 Transport and storage.......................................................... 17
4.2 Unpacking............................................................................ 17
4.3 Scope of delivery.................................................................. 18
4.3.1 Accessory case.................................................................. 19
4.3.2 Accessories case 1 - dry.................................................... 20
4.3.3 Accessory case 2 - wet dispersion unit.............................. 21
4.4 Seng up............................................................................. 21
4.4.1 Transport securing devices................................................ 22
4.5 Ambient condions.............................................................. 22
4.6 Electrical connecon............................................................ 23
4.6.1 Stability of the mains voltage............................................ 23
4.7 Preparaon of the ANALYSETTE 28 ImageSizer.................... 24
4.7.1 Connecon of the camera to the lens and inseron......... 24
4.8 Connecons for supply units................................................ 26
4.9 Preparaon of the computer............................................... 27
4.10 Checking the communicaon between the device and
the PC................................................................................. 31
4.10.1 Checking the communicaon between the camera and
the PC.............................................................................. 32
5 Using the device........................................................................... 33
5.1 Changing the lens................................................................. 33
5.1.1 Adjusng the camera angle.............................................. 34
Table of contents
- 4 -

5.2 Dry measurement................................................................ 34
5.2.1 Installing the feeder and funnel........................................ 34
5.2.2 Funnel holder 250 ml........................................................ 36
5.2.3 Adjusng the funnel height............................................... 36
5.3 Wet measurement............................................................... 36
5.3.1 Inserng the measuring cell.............................................. 36
5.3.2 Selecng the liquids.......................................................... 37
5.3.3 Filling the measuring circuit.............................................. 38
5.3.4 Sample addion................................................................ 39
5.4 Fritsch test powder F16....................................................... 40
5.5 Fritsch test powder F70....................................................... 41
6 Accessories................................................................................... 43
6.1 Lenses for dry measurement............................................... 43
6.2 Accessories for wet measurement....................................... 43
6.2.1 Immersion pump set......................................................... 43
6.3 Calibraon plate................................................................... 44
7 Cleaning........................................................................................ 45
7.1 Cleaning the device.............................................................. 45
7.1.1 Cleaning the falling chute.................................................. 45
7.2 Cleaning the lens.................................................................. 45
7.3 Cleaning the windows.......................................................... 46
7.3.1 Removing the window holder........................................... 46
7.4 Cleaning the lens of the digital camera................................ 46
7.5 Cleaning the hoses............................................................... 47
7.6 Cleaning the wet measuring cell.......................................... 47
7.6.1 Design of wet measuring cell............................................ 48
7.6.2 Preparaon....................................................................... 48
7.6.3 Emptying the system......................................................... 49
7.6.4 Removing the wet measuring cell..................................... 49
7.6.5 Cleaning the measuring cell glasses.................................. 49
7.6.6 Sealing rings...................................................................... 50
7.6.7 Mounng the wet measuring cell..................................... 51
7.6.8 Check the wet measuring cell for impermeability............ 51
8 Maintenance................................................................................ 52
8.1 Replacing hoses in wet dispersion units.............................. 53
9 Repairs......................................................................................... 54
9.1 Checklist for troubleshoong............................................... 54
10 Disposal........................................................................................ 56
11 Guarantee terms.......................................................................... 57
12 Exclusion of liability..................................................................... 59
13 Safety logbook............................................................................. 61
Table of contents
- 5 -

14 Index............................................................................................. 63
Table of contents
- 6 -

1 Basic structure
1 Funnel
2 Feeder
3 Rotary knob for funnel adjustment
4 Height-adjustable funnel holder
5 Funnel support column
6 Latches
7 Sample collecng vessel
8 Housing ap
Basic structure
- 7 -

9 5 MP digital camera
10 Lens holder
11 Lens
12 Lens holder end stop
13 Window holder
14 Falling chute (wet measuring cell holder)
15 Flash unit
16 Main switch
17 Mains connecon
18 Wet dispersion unit port
Basic structure
- 8 -

20 Wet dispersion unit
21 ImageSizer measuring unit
22 Sample bath
23 Measuring cell holder
24 Wet measuring cell
Basic structure
- 9 -

2 Safety informaon and use
2.1 Requirements for the user
This operang manual is intended for persons assigned with operang
and monitoring the Fritsch of the ANALYSETTE 28 ImageSizer. The oper-
ang manual and especially its safety instrucons are to be observed by
all persons working on or with this device. In addion, the applicable
rules and regulaons for accident prevenon at the installaon site are
to be observed. Always keep the operang manual at the installaon site
of the of the ANALYSETTE 28 ImageSizer.
People with health problems or under the inuence of medicaon,
drugs, alcohol or exhauson must not operate this device.
The of the ANALYSETTE 28 ImageSizer may only be operated by author-
ised persons and serviced or repaired by trained specialists. All commis-
sioning, maintenance and repair work may only be carried out by techni-
cally qualied personnel. Qualied personnel are persons who, because
of their educaon, experience and training as well as their knowledge of
relevant standards, regulaons, accident prevenon guidelines and oper-
ang condions, are authorised by those responsible for the safety of the
machine to carry out the required work and are able to recognize and
avoid possible hazards as dened for skilled workers in IEC 364.
In order to prevent hazards to users, follow the instrucons in this
manual.
Malfuncons that impair the safety of persons, the of the ANALYSETTE
28 ImageSizer or other material property must be reced immediately.
The following informaon serves both the personal safety of operang
personnel as well as the safety of the products described and any devices
connected to them: All maintenance and repair work may only be per-
formed by technically qualied personnel.
This operang manual is not a complete technical descripon. Only the
details required for operaon and maintaining usability are described.
Fritsch has prepared and reviewed this operang manual with the
greatest care. However, no guarantee is made for its completeness or
accuracy.
Subject to technical modicaons.
2.2 Scope of applicaon
The ANALYSETTE 28 ImageSizer is used for the analysis of the parcle
shape and size of powders and bulk solids. The parcle sizer has an extra-
large measuring range of 20 µm to 20 mm! It is therefore an ideal device
for uncomplicated quality control in various areas of applicaon.
The parcle sizer described here is an operaons resource for use in
industrial environments. This operaons resource possesses hazardous
live components during operaon.
Safety informaon and use
- 10 -

2.3 Obligaons of the operator
Before using the of the ANALYSETTE 28 ImageSizer, this manual is to be
carefully read and understood. The use of the of the ANALYSETTE 28
ImageSizer requires technical knowledge; only commercial use is per-
mied.
The operang personnel must be familiar with the content of the oper-
ang manual. For this reason, it is very important that these persons
actually receive the present operang manual. Ensure that the operang
manual is always near the device.
The of the ANALYSETTE 28 ImageSizer may exclusively be used within the
scope of applicaons set down in this manual and within the framework
of guidelines put forth in this manual. In case of non-compliance or
improper use, the customer assumes full liability for the funconal capa-
bility of the ANALYSETTE 28 ImageSizer and for any damage or injury
arising from failure to full this obligaon.
By using the of the ANALYSETTE 28 ImageSizer the customer agrees with
this and recognizes that defects, malfuncons or errors cannot be com-
pletely excluded. To prevent risk of damage to persons or property or of
other direct or indirect damage, resulng from this or other causes, the
customer must implement sucient and comprehensive safety measures
for working with the of the ANALYSETTE 28 ImageSizer.
Neither compliance with this manual nor the condions and methods
used during installaon, operaon, use and maintenance of the of the
ANALYSETTE 28 ImageSizer can be monitored by Fritsch GmbH. Improper
execuon of the installaon can result in property damage and thus
endanger persons. Therefore, we assume absolutely no responsibility or
liability for loss, damage or costs that result from errors at installaon,
improper operaon or improper use or improper maintenance or are in
any way connected to these.
The applicable accident prevenon guidelines must be complied with.
Generally applicable legal and other obligatory regulaons regarding
environmental protecon must be observed.
2.4 Informaon on hazards and symbols used in this manual
Safety informaon in this manual is designated by symbols. Safety infor-
maon is introduced by keywords that express the extent of the hazard.
DANGER!
This symbol and keyword combinaon points out a
directly hazardous situaon that can result in death or
serious injury if not avoided.
Safety informaon
Safety informaon and use
- 11 -

WARNING!
This symbol and keyword combinaon points out a pos-
sibly hazardous situaon that can result in death or
serious injury if not avoided.
CAUTION!
This symbol and keyword combinaon points out a pos-
sibly hazardous situaon that can result in slight or
minor injury if not avoided.
NOTICE!
This symbol and keyword combinaon points out a pos-
sibly hazardous situaon that can result in property
damage if not avoided.
To call aenon to specic hazards, the following symbols are used in the
safety informaon:
DANGER!
This symbol and keyword combinaon points out a
directly hazardous situaon due to electrical current.
Ignoring informaon with this designaon will result in
serious or fatal injury.
DANGER!
This symbol and keyword combinaon designates con-
tents and instrucons for proper use of the machine in
explosive areas or with explosive substances. Ignoring
informaon with this designaon will result in serious
or fatal injury.
DANGER!
This symbol and keyword combinaon designates con-
tents and instrucons for proper use of the machine
with combusble substances. Ignoring informaon with
this designaon will result in serious or fatal injury.
WARNING!
This symbol and keyword combinaon points out a
directly hazardous situaon due to movable parts.
Ignoring informaon with this designaon can result in
hand injuries.
Special safety informaon
Safety informaon and use
- 12 -

WARNING!
This symbol and keyword combinaon points out a
directly hazardous situaon due to hot surfaces.
Ignoring informaon with this designaon can result in
serious burn injuries due to skin contact with hot sur-
faces.
Safety informaon can refer to specic, individual procedure instrucons.
Such safety informaon is embedded in the procedure instrucons so
that the text can be read without interrupon as the procedure is being
carried out. The keywords described above are used.
Example:
1. Loosen screw.
2.
CAUTION!
Risk of entrapment at the lid.
Close the lid carefully.
3. Tighten screw.
This symbol emphasises useful ps and recommenda‐
ons as wells as informaon for ecient operaon
without malfuncon.
To emphasise procedure instrucons, results, lists, references and other
elements, the following designaons are used in this manual:
Designaon Explanaon
1., 2., 3. ...
Step-by-step procedure instrucons
ðResults of steps in the procedure
References to secons in this manual and rele-
vant documentaon
Lists without a specic order
Safety informaon in the procedure
instrucons
Tips and recommendaons
Further designaons
Safety informaon and use
- 13 -

Designaon Explanaon
[Buon] Operang elements (e.g. push buon, switch),
display elements (e.g. signal lamps)
‘Display’ Screen elements (e.g. buons, funcon key
assignment)
2.5 Device safety informaon
nThe parcle sizer has been designed from the viewpoint of safety to
users; nevertheless, residual hazards cannot be ruled out.
nThe device may only be used for the purpose described under
Ä Chapter 2.2 ‘Scope of applicaon’ on page 10.
nOnly use original accessories and original spare parts. Failure to
observe this instrucon can compromise the safety of the machine.
nSafe conduct must be strictly observed during all work with the
device.
nAll currently applicable naonal and internaonal accident preven-
on guidelines must be complied with.
nDo not remove the informaon signs.
DANGER!
Explosion hazard!
– The device is not explosion-protected!
– The device must not be used in electrically conduc-
ve, dusty or damp environments.
DANGER!
Mains voltage
– Do not allow any liquids to run inside the device.
WARNING!
The maximum accepted concentraon (MAC) levels of
the valid safety regulaons must be observed. If neces-
sary, venlaon must be provided or the machine must
be operated under an extractor hood.
NOTICE!
Immediately replace damaged or illegible informaon
signs.
Safety informaon and use
- 14 -

nUnauthorised alteraons will void Fritsch's declaraon of conformity
to European direcves and void the guarantee.
nIf aer reading the operang manual you sll have quesons or
problems, please do not hesitate to contact our technical specialists.
2.6 Hazardous points
DANGER!
There is a risk of fatal injuries from power surges when
cleaning the device. Disconnect the mains plug before
cleaning the device.
CAUTION!
Crushing hazard!
When
– Moving the funnel
– Closing the device
–Inserng the holders with the "measuring win-
dows" 13 + 14
–Inserng the lenses
–Mounng the camera
–Inserng the sample collecon container
NOTICE!
Do not leave any oxidizing parts on the channel or in
the funnel - risk of corrosion.
2.7 Electrical safety
2.7.1 General informaon
nThe main switch separates the device from the mains on two poles.
nSwitch o the main switch if the ANALYSETTE 28 ImageSizer is to
stand idle for a longer duraon (e.g. overnight).
In the switched-on state, the switch is illuminated red and the control
lamp on the front side blue.
Safety informaon and use
- 15 -

3 Technical data
3.1 Dimensions
ImageSizer:
84 x 20 x 28 cm (width x depth x height without funnel and feed channel)
Wet dispersion unit:
32 x 65 x 44 cm (W x D x H)
3.2 Weight
ImageSizer:
43.8 kg net
Wet dispersion unit:
30.8 kg
3.3 Operang noise
The noise level is up to approx. 78 dB(A).
3.4 Voltage
The voltage range is from 100 - 240 V.
3.5 Current consumpon
The maximum current consumpon is 0.2 A (230 V), 0.6 A (115 V) .
3.6 Power consumpon
The maximum power consumpon is 50 W.
3.7 Electrical fuses
Micro-fuse 5 x 20 mm 2A slow-blow, 2 pieces The fuses are located inside
the mains power socket (19).
Technical data
- 16 -

4 Installaon
4.1 Transport and storage
DANGER!
Do not step under the transport pallet during transport.
The ANALYSETTE 28 is delivered in a wooden crate on a pallet. Do not lt
or stack this crate. The ImageSizer must be transported and stored in its
packaging and protected from weather and outside inuences.
Transport over larger distances only in the original Fritsch packaging.
We recommend using a forkli or pallet truck for transporng the packed
device.
WARNING!
Improper liing can lead to personal injury or property
damage. The machine is only to be lied with suitable
equipment and by qualied personnel.
The guarantee excludes all claims for damage due to improper transport.
4.2 Unpacking
Remove the transport packaging as shown in the following illustraons.
1. Cut open the straps of the package using side cuers.
2. Remove the staples using an appropriate tool.
3. Li the lid o.
The accessories case becomes visible.
Installaon
- 17 -

4. Remove the surrounding packaging.
5. Remove the accessories case.
6. Remove the foam trays and li the ImageSizer from the transport
cradle using two people.
NOTICE!
Do not use the funnel support column to li the
ANALYSETTE 28 from the transport cradle.
For liing, reach under the base plate.
If you have ordered the ANALYSETTE 28 ImageSizer with two
lenses, you will nd the second lens stored vercally next to the
ImageSizer in a lens case (a).
4.3 Scope of delivery
Please check the delivery against your order! If the delivery is incomplete
or damaged, inform the shipping agent immediately and inform Fritsch
GmbH within 24 hours. Any claims received later cannot be considered.
Installaon
- 18 -

4.3.1 Accessory case
1 USB cable and USB interface cable
2 Data sck with soware, operang instrucons and
manual
3Mulple socket outlet with mains switch
4 Round jar with small parts
5 Spirit level
6Connecon cable
7 Digital camera
Country-specic adapter
Installaon
- 19 -

4.3.2 Accessories case 1 - dry
7 Standard test powder F 70 and/or F 16
8 Lens
9 Funnel
10 Lens brush
11 Sha cover
12 Spoon spatula
13 Feeder
14 Flat brush
15 Anstac cloth
16 Opcs ssue
17 Bellows
Installaon
- 20 -
