SDMO MICS Telys User manual

Instructions for use
Telys level 1
1.06 F
Réf. constructeur : Réf. GPAO : 33502012701 ind1

GB
ENGLISH
SSAAFFEETTYYSSYYMMBBOOLLSS44
CCOONNTTEENNTTSS11
10/01
3

4
10/01
SAFETY SSYMBOLS
Protective clothing required.
Eye and hearings protection necessary
Periodic maintenance required
Check battery charge
Recommended Lifting point
Fork lift stacking point
Naked flame and non protected lightining
forbidden, no smoking
Do not use water based fire extinguishers
Caution : danger
Caution : toxic substances
Caution : risk of electric shock
Caution : pressuried fluids
Caution : high temperature (risk of burning)
Caution : rotating or moving parts (risk of
entanglement)
Caution : risk of corrosion
Caution : risk of explosion
Caution, refer to the publications supplied with
the Genset
Authorised personnel only
MMAACCHHIINNEERRYYDDIIRREECCTTIIVVEE9988//3377//CCEEIINNSSTTRRUUCCTTIIOONNFFOORRGGEENNEERRAATTIINNGGSSEETTSS
- Access prohibited to unauthorized personnel
- Live installation, potencial automatic starting.
Power
Earth
Trailer : link up the earth before starting the
generator
Emergency stop
Safety symbols_________________________________________________________________________________________________________________________________________

10/01
5
_____________________________________________________________________________________________________________________________________________________

6
10/01
6
10/01
EENNGGLLIISSHH
A
AB
B
KKeeyy
PPaanneelllliigghhttiinnddiiccaattoorr
Lighting for wall mounted or free stan-
ding panel
EEmmeerrggeennccyySSttoopp
The genset shuts down immediately
and the control unit goes into STOP
mode
CCoonnttrroolluunniitt
Generating set programmable control-
ler
MMIICCSSAAMMPPGG
Device for electrical value display
PPootteennttiioommeetteerrvvoollttss
Adjusts the alternator voltage
DDuuaallffrrééqquueennccyysswwiittcchh5500//6600HHzz
to select the frequency
PPootteennttiioommeetteerrsswwiittcchh
to select the voltage
PRESENTATION
Présentation___________________________________________________________________________________________________________________________________________

USER MANUAL
Due ttooour oon-ggoing rresearch pprogram aand tthe ccontinual iimprovements ttooour pproducts, wwerreserve tthe rright ttommake aall cchanges ddeemed nnecessary wwithout pprior nnotice.
All rrights rreserved aascconcerns cchanges ttotthese mmanuals.
Reproduction oorttranslation iinwwhole oorppart sstrictly pprohibited wwithout pprior wwritten aauthorization.
Design aand pproduction: SSee ddocumentation:
Manufacturers ddocumentation bbase ffor ppower ggenerating ssets ++EElec. EEng. DDept. DDocumentation
Level 1
CONTROL UNIT

Warning
Changes to the front panel of the MICS Telys
The MICS Telys front panel has been modified.
Leaving aside the colour and design of the keys, the modifications are as follows:
nthe "I" key has been changed to the "I/P" key (output measurements)
othe "F/" key has been changed to the "F/H" key
pthe "Manu" key has been changed to the "Start" key
previous design new design
nThe output measurement function will not be available initially, as software version 1.07G
will not be marketed until October 2003. Therefore, repeatedly pressing the "I/P" key will
only display the voltages.
oThe change from the "F/" key to the "F/H" key does not affect the information displayed
on the screen.
pThe most significant change is that from
the "Manu" key to the "Start" key. When the
generating set is started up in Manu mode, the
message shown opposite appears.
Fuel Lev(%)
E.Speed(RPM)
Batt.(Volts)
MANUAL mode selected
press MANU to confirm
24.2
50
0
As the "Manu" key is no longer present, one press on the "Start" key will trigger the starter
motor or the spark plug preheating (depending on configuration).
These modifications will be introduced to the technical documentation during
the next update (software update from version 1.06 F to version 1.07 G).

8
10/01
FOREWORD
CCoonnttrroolluunniittuuppggrraaddee::
The software compatibility is ensured with the old interface boards, meaning it is possible to reprogram, on site, an interface board having
a software index 1.01B with a software having an index 1.04D and 1.05E. However, a display defined for software version 1.2 and higher
is required to use a software version 1.05E.
Software upgrade 1.04D comprises the following:
- Addition of functions and parameters
- Modification of standard value of certain parameters
- Modification of utilization limits of certain parameters
- Supervision and remote management
- Control/command of engines MTU 2000 and 4000
- Control/command compatible with standards NFPA110 and CSA C282
- Control/command compatible with French standards NF S 61-940 and NF E 37-312
- Control/command for Cummins engines type QST30
- Control/command for Nevada engines
- Generating sets with "multi-voltage" option
- Generating sets with "bi-frequency/bi-voltage" option
- Option 5 module (this module is only used with applications on MTU 2000/4000 engines and CUMMINS engines QST30).
The software version 1.06F used with the CB and CB12 I/O cards extends the functionality and working range of the Telys MICS. A sum-
mary of the developments and changes incorporated into the new software is shown below. Each development is then described in detail
in the subsequent paragraphs.
Compatibility with earlier I/O cards has been provided, and it is therefore possible to reprogram I/O cards originally using software ver-
sions 1.01B, 1.04D or 1.05E with version 1.06F, without having to remove the card.
Software version 1.06F includes the following features:
- Command and control of the JDEC electronics used with the John Deere 6081HF engines using the optional module 5.
- Command and control of the EDC III electronics used with Volvo D12 engines using the optional module 5.
- Changing the number of working hours for the generator (clear or preset) by entering a single access code.
- Option 4 of module 4, allowing operation at three different voltages (480V, 208V and 240V), may be fine tuned to reflect the customer's
actual usage.
- The "low coolant level" LED of the optional module 6 comes on when either the 'low coolant level' or 'air cooling inadequate ' inputs are
enabled (only for NFPA110 applications).
- For gas-powered generators, the "low gas pressure" fault condition now has a five-second fixed timer. This timer prevents the engine
being switched off by sudden load changes. In practice, the gas pressure has a tendency to drop when the load increases sharply, before
returning to its normal value.
SSuuppeerrvviissiioonnaannddrreemmootteemmaannaaggeemmeenntt::
Supervision and remote management is possible using the "wintelys" software on a PC computer under a Windows 95, 98; NT or 2000 envi-
ronment.
A complete document describing the supervision and remote management features can
be obtained from the "products and development" department.
Supervision and remote management are operational on software version 1.01B with a
few restrictions as concerns the various data acquisition and display features. In this res-
pect, with software version 1.01B, it will not be possible to:
- Control the generator set from a remote location
- Display the status of the alarm and fault LEDs on the front panel of the display or retro-
information concerning the position of the Normal/Backup switch.
In addition, with software version 1.01B, the MICS Telys is automatically reset when the
generating set is configured from a remote location.
For optimum use of the supervision/remote management function, we recommend that
you use software version 1.04D.
MMoodduullee55::
Module 5 is simply module OPT34 configured as module 5.
This module is programmed specifically for the applications with engines using an inte-
grated control electronics (MTU and Cummins engines).
The selection parameter for this module already exists in software version 1.01B.
However, a line has been added in the INPUTS and OUTPUTS screens to display the logi-
cal state of the inputs and outputs of the module according to its programming.
Supervision
Remote management

10/01
1
_______________________________________________________________________________________________________________________________________________Contents
CONTENTS
Presentation and technicals characteristics
1. Foreword . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
1.1. Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
1.2. Power connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
1.3. Electric connections (control) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
1.4. Battery preliminary inspection and commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
1.5. Control unit first power-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
1.6. Welcome screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
1.7. " Overview " screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
2. Operating Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
2.1. Stop Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
2.2. Manu Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
2.3. Auto Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
2.4. Test Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
3. Sleep mode and automatic shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
3.1. Sleep mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
3.2. Automatic shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
3.3 Special Case . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
4. Viewing the electrical values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
4.1. Voltages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
4.2. Currents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
4.3. Frequency and hours counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5. Viewing the engine parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
6. Display LEDs and lamp test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
7. Screen contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8. Displaying the alarm and fault messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.1. Appearance of messages on screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.2. Removing messages on screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
9. Displaying the status messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
10. Accessing the level 1 display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
11. " Alarm/Flt " menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
11.1. Special features for a fault . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
11.2. Special features for an alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
11.3. Other special cases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
12. " Status " Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
13. " Inputs " Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
14. " Outputs " Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
15. " Contrast " Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
16. " Protect " Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
16.1. Differential protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
16.2. Protection via CIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
16.3. Special case . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
17. Generating set operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
17.1. Water heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
17.2. Engine preglow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
17.3. Fuel solenoid control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
17.4. Starter control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
17.5. Starter tripping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
17.6. RPM and Volts stabilisation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
17.7. Generating set output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
17.8. Engine cooling down and shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
18. Operation of GES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
19. ATS operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
19.1. In Stop mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
19.2. In automatic mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
19.3. In manual mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Appendix -software version 1.05E: "international" language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
2 Strating up the MICS TELYS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
3 Modifying display with International language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
4 Display of electrical values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
5 Display of mechanical values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
6 Others symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
7 Alarms and fault codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
8 Access to programming and language change functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

2
10/01
Presentation and technicals characteristics_____________________________________________________________________________________________________
Power on after automatic shutdown
(with LED).
Button to access the main menu (pro-
gramming/display)
Button to validate a selection.
Button to exit a selection Button to display the engine parame-
ters
Buttons to browse through menus and
adjust contrast
Button to select Auto mode (with LED).
Button to select Test mode (with LED).
Number pad
Button reset a fault.
Button to select Manu mode (with
LED).
Button to open genset breaker (with
LED).
Button to select Manu mode (with
LED).
Button to close genset breaker (with
LED).
Button to test the LEDs (except ON
button LED).
1. Oil pressure fault/shutdown (red LED on).
2. Water Tº fault/shutdown (red LED on).
3. Overcranking fault/shutdown (red LED on).
4. Overspeed fault/shutdown (red LED on).
5. Genset on load or ready to take the load (green LED on).
6. Charge alternator fault/shtdwn (red LED on).
7. General alarm/warning (yellow LED flashing).
8. General fault/shutdown (red LED flashing).
Button to display the voltages.
Button to display the currents
Button to display the frequency and
hours counter
1
2
3
4
5
6
7
8
PRESENTATION AAND TTECHNICALS CCHARACTERISTICS

10/01
3
__________________________________________________________________________________________________________________Technicals characteristics
11- FFeeaattuurreess
Display module (DM)
Interface board available in 2 versions (CB, CB12) depending on customer optional equipment.
Option 3 module, option 4 module and option 5 module (OPT 334)
Block building system enabling multiple combinations.
Note: DM required in all combinations
22- DDiissppllaayymmoodduullee(Fig. 2)
LCD screen, 8 lines 21 characters, built-in back-light and keyboard adjustable contrast
28 momentary push buttons (two types; 10 and 13 dia.)
15 display LEDs (alarms/warnings, faults/shutdowns, status, operating modes)
UL approved polycarbonate case supplied with cable and connector for connection to the interface board
Dimensions 192x144x70
Quick installation using brackets and nuts screws
IP65 on panel face with seal (not supplied), IP20 inside
Extremely user friendly man-machine interface: multiple-message screens, diagnostic, genset status, ...
33- IInntteerrffaacceebbooaarrdd((FFiigg..11))
CB = Main board
CB12 = Main board with option 1 and option 2 built in
Electronics in a sheet steel case (base + lid)
Dimensions : 435x263x31
Voltage bus; alternator, mains and DC built into the printed circuit board (see paragraphs 7, 8, 9 and 13)
16 bit microcontroller, (Flash, RAM and EEPROM) memories, real-time clock, battery backup for time and date
Supply from 9 to 33Volts DC and from 6Volts DC, for voltage drop at start-up
All connections are built into the printed circuit board on both sides with full screen printing
44- LLooggiiccaall//aannaallooggII//OO
All inputs and outputs are allocated to a specific use
(see tables below).
Note: Alarm or Fault selection via programming
Key:
A=Alarm, F=Fault, ana.=analog, C=Control
T=Transistor, R=Relay, Ω=resistive
Fig. 11- CCB12 bboard
Fig. 22- DDisplay mmodule
* : France only
Type
Logical output description
CB
CB12
F
oil pressure
x
x
F
water temperature
x
x
A or F
day tank low fuel level
x
x
F
emergency stop
x
x
A or F
overload or short-circuit
x
x
C
water heater thermostat
x
x
C
external start-up command
x
x
F
radiator low water level
x
x
C
Mains
contactor home position
x
x
C
Stand-by
contactor home position
x
x
F
external emergency stop
x
x
F
oil temperature
x
F
low oil level
x
A or F
water heater failure
x
A or F
battery charger failure
x
A or F
differential or CIC trip
x
F
differential relay available
x
F
Constant Insulation Check available
x
F
air cooler disconnection
x
F
air cooler low water level
x
A or F
fuel pump 1 disconnection
x
A or F
retention
bund
x
C
bulk tank CF80
x
A or F
bulk tank low fuel level
x
C
EJP switch (*)
x
C
EJP start-up (*)
x
C
EJP advanced warning (*)
x
Type
Logical output description
CB
T
fuel solenoid control
x
T
starter 1 contr ol
x
T
engine
preglow control
x
T
water heater control
x
T
hooter control (general fault)
x
R
Mains
contactor control
x
R
Stand-by
contactor control
x
T
air damper control
T
starter 2 control
R
electro-flaps control
T
fuel pump 1 control
R
CIC remote contact
Type
Analogue input description
CB
Ω
oil pressure indication
x
Ω
water temperature indication
x

4
10/01
Technicals characteristics _________________________________________________________________________________________________________________________________
55- OOppttiioonn33,,44aanndd55mmoodduulleess((OOPPTT3344))
Modular case, dimensions : 160x90x58
Programming specific to each module (dip-switch)
8 allocated inputs and 10 programmable outputs on option 3 for remote volt free contacts
8 programmable inputs and 10 programmable outputs on option 4 , with 24 preprogrammed options
Specific programming of some entries
66- AAlltteerrnnaattoorrccuurrrreennttiinnppuutt
4-wire, unisolated, on current transformer with 5A secondary (not built into the electronics)
Measurements in true root mean square values
Measurement range: 60A to 5000A
77- AAlltteerrnnaattoorrvvoollttaaggeeiinnppuutt
4-wire (3ph + neutral), unisolated, with 12.5A-500Vac built in power bus in 50 and 60Hz
Measurements in true root mean square values
Frequency measurement on phase 1 for screen display and engine overspeed sensing
88- MMaaiinnssvvoollttaaggeemmaaiinnss11
4-wire (3ph + neutral), unisolated, with 15A-600Vac built in power bus in 50 and 60Hz
No voltage and frequency measurements
99- MMaaiinnssvvoollttaaggeemmaaiinnss22
2-wire (1ph + neutral), unisolated, with 10A-240Vac built in power bus in 50 and 60Hz
No voltage and frequency measurements
1100- CChhaarrggeeaalltteerrnnaattoorriinnppuutt
Charge alternator excitation and fault
Starter hardware fail safe on software failure
1111- CCoommmmuunniiccaattiioonn
RS485 serial port with J-Bus protocol (Mod bus RTD)
9-pin SUB-D connector
Monitoring possible in local mode (≤1000meters)
Remote management possible with 2 modems (>1000m)
Optional monitoring/remote management software
1122- CCAANNLLiinnkk
Link between interface board and option module(s)
Standard CAN bus version 2.0b, 9-pin SUB-D connector for CC supply to module
1 connector on CB and CB1, 2 connectors on CB12
1133- FFuusseepprrootteeccttiioonn
Fn, F1, F2, F3, 12.5A-500V fuses for alternator bus
Mains bus protected by circuit breaker in the ATS
F5, 10A fuse for the DC bus
F7, 2.5A delayed action fuse for the interface board
F6, 1A delayed action fuse for option 3 Module
F8, 1A delayed action fuse for option 4, 5 Module (CB12 only)
1144- CCoonnnneeccttiioonnss
Multi-pin (2 to 15 pins) connectors with polarizer
Number of connectors varies with interface board
Each connector has a specific use
1155- PPrrooggrraammmmiinnggooppttiioonnss
Multiple programming possibilities
Access code required to read/program

10/01
5
_________________________________________________________________________________________________________________________________ Technicals characteristics
1166- OOppttiioonnssccoonnnneecctteeddttootthheeiinntteerrffaaccee
(*)indication and fault/shutdown for oil temperature, low oil level, water heater failure and alarm/warning for, oil pressure, water tempera-
ture, oil temperature, air damper control, starter 2 control.
1177- SSoorrttiieessrreellaaiiss
Max switching voltage: 250Vac (277Vac for *)
Mains and Stand-by contactor control outputs: 4.9A, 1500VA breaking capacity at cosϕ=0.7
Electro-flaps outputs: 500mA & CIC remote contact:1A
MX coil control output (*): 4.9A (optional relay on baseplate)
1188- TTrraannssiissttoorroouuttppuuttss
Protected against short-circuit
Output for fuel solenoid/panel lighting: 700mA
Other outputs: 300mA
1199- HHaarrddwwaarreeccoonnffiigguurraattiioonn
C14/C15 connector, auxiliaries voltage selection
C7 dip-switch, RS485 terminator
P3 dip-switch, CAN bus terminator
Dip-switch selection for VDE option
2200- EEnnvviirroonnmmeennttaannddssttaannddaarrddss
Operating temperature: -15°C to +60°C
Storage temperature: -20°C to +70°C
Resistance to shocks: IK01, vibration: to CEI68-2-6
Salt mist resistance : 96 hours according to EN68011-2-11
Humidity : 95 % of humidity at 45°C.
EMC :
- Generic standards EN50081-2 and EN50082-2
- Emissions EN55011 Class A
- Immunity EN61000-4.2, EN6100-4.3, EN61000-4.4, EN61000-4.6, EN61000-4.8, ENV50201
CE mark, UL listed, CSA certified
Option description
CB
CB12
external start-up command
x
x
auto predisposition + external command
x
x
3ph+neutral or 1ph+N mains connection
x
x
battery charger (3 possible ratings)
x
x
water heater (3 poss. depending on supply V)
x
x
hooter
x
x
RS485 for monitoring or remote
management
x
x
option 3 module / CAN bus connection
x
x
additional engine kit (9 options) (*)
x
electro-flaps (DC or AC)
x
anti-condensation heater
x
EJP (switch, adv. warning and start -up)
x
1ph or 3ph fuel pump (control & power)
x
Air cooler (low level, disconnection)
x
differential protection and MX coil contr ol
x
CIC protection with remote contact and MX
coil control
x
bulk tank fuel pump (CF80, low level,
retention bund)
x
AMPG with optional RS485
x
option 4 module / CAN bus connection
x
three-alarm (OP,WT,OT) and module 4 kit
x
French only

6
10/01
Foreword _______________________________________________________________________________________________________________________________
1. FFOREWORD
11..11..PPrreeccaauuttiioonnss
The control unit is connected to various AC voltage sources (alternator, mains, ...).
If work inside the control panel is required, it must be performed by staff authorised to work live.
These fuses must be replaced when the generating set is in complete shutdown. For any voltage measurement on these four fuses, please
use suitable equipment.
The generating set can be equipped with a remote start-up (simple contact) or with an automatic starting system [mains failure + ATS
(Mains/Stand-by changeover switch)] .
11..22..PPoowweerrccoonnnneeccttiioonn
For power connection, make sure that flexible cables of suitable cross section are used to avoid overheating and a major in-line voltage drop.
Depending on laying method, ambient temperature and proximity of other cables, the conductor's cross section may vary.
11..33..EElleeccttrriiccccoonnnneeccttiioonnss((ccoonnttrrooll))
Generating sset wwith mmanual sstart oonly (from the control unit keyboard)
No external connection to make.
Generating sset wwith rremote ((without mmains) ooraautomatic ((with mmains) sstart-uup
For proper operation, make the connections on the user terminal block as per the diagram below.
For DC signals, we recommend the use of a 5-core (5x1.5mm²) flexible cable between the ATS and the user terminal block.
For AC signals, we recommend the use of a 12-core (12G1.5mm²) flexible cable between the ATS and the user terminal block.
(G means cable with a Green/Yellow conductor)
Note: for a remote start only, a 2x1.5mm² flexible cable is sufficient (see overleaf)
N
S
C16-UTIL
C13-UTIL
C35-UTIL
AC
DC
DC
DC
AC
AC
6
1
2
3
4
5
1
2
3
4
5
1
2
3
4
1
2
3
4
5
6
7
8
9
10
11
12
1
2
3
V/J
N
30
31
1
2
1
2
3
4
5
6
7
8
9
10
11
12
External command (mains sensing or client contact) Output C/B fault auxiliary signal contact
Mains and Stand-by contactors home position Stand-by contactor control
Mains contactor control 1 or 3 phase water heater
If the user does not connect an ATS from our range, it is imperative to observe the board relay characteristics given below and to check
that the coils power requirements are within these parameters.
Rated ccurrent=5A Rated vvoltage=250Vac
Maximum bbreaking ccapacity uunder aa00.7 ccos ϕϕ:11500VA
11..44..BBaatttteerryypprreelliimmiinnaarryyiinnssppeeccttiioonnaannddccoommmmiissssiioonniinngg
The battery must be connected for the control unit to operate and the generating set to start, hence the need to check its connection:
Red wire, positive polarity (+),
Black wire, negative polarity (-).
Some generating sets are equipped with a battery isolator enabling the electric circuit to be isolated. Check that it is in the position enabling
the operation.
Beware of possible electric shock by contact with any live part, during the generating set start up.
While the generating set is idle, any work inside the control equipment is strictly forbidden as some parts of the electric and elec-
tronic equipment stay live (mains voltage available).
When the generating set is running, the fuses marked Fn, F1, F2, F3 are at a dangerous potential which can lead to electric shock
when touched.
The cross sections above are given as a guide as they can vary depending on the current to be drawn, length, temperature and
control cable laying method.
Not observing the above characteristics will damage or even destroy the board control relays.
The battery is supplied without electrolyte. Fill the battery with electrolyte at least 20 minutes before any start-up attempt (see main-
tenance manual).

10/01
7
_______________________________________________________________________________________________________________________________Foreword
11..55..CCoonnttrroolluunniittffiirrssttppoowweerr-uupp
If the battery is connected and the electrolyte level correct, control unit powers up automatically and the initialisation screen below appears.
This screen is visible for eight seconds. All LEDs are lit and will go out after 3 seconds except the ON
button LED. When initialisation is complete, the Stop button LED comes on again.
If other LEDs are lit or flashing, refer to paragraph 6.
Note 1: The 0button LED can also be lit (see paragraph 18).
Note 2: During initialisation, the display module software version appears on screen.
11..66..WWeellccoommeessccrreeeennss
Screen 11
After the initialisation phase, the screen below appears. The operator is then able to choose in which language he wants the messages to be
displayed on the control unit screen. Four languages are available: French, English, Spanish and Portuguese.
The language selection screen is then displayed. The cursor flashes by default on "international". If no
action is taken while the four squares are displayed in the small overlaid window, the MICS Telys is auto-
matically positioned on the international language. You then have around 6 seconds to change the lan-
guage by pressing the button then the Vor Esc button (*).
(*) By pressing the Vbutton, you store the selected language in memory meaning that the next time you
power up the unit, the cursor will automatically go to the previously selected language. In addition,
when you press the Vbutton, the system goes to the next screen for modification of the date and time.
LANGUAGE SELECTION
V:
Valid
Esc: Exit
o International
o English
o
Spanish
o
Portugues
o French
(*) If you press the Esc button, the selected language is not stored in memory. The next time the unit is powered up, the cursor will automa-
tically be positioned on the international language.
By pressing or , the operator places the cursor over the required language. Note : Depending on the cursor position, the text of the
two upper lines changes to enable the operator to know where he is.
Press Esc to go directly to the " overview " screen (see paragraph 1.7).
There, the language used will be the one where the cursor was positioned.
Example : Cursor positioned over English. Pressing Esc configures the control unit in English. Any messages will appear be in English.
If neither Vnor Esc is pressed, the " overview " screen (see paragraph 1.7) appears automatically after three minutes. There, the language used
will be the one where the cursor was positioned.
Not until the appearance of the " overview " screen will it be possible to start the generating set, however all inputs stay active (example:
appearance of a fault).
Press Vto go to the second welcome screen, in the language where the cursor was before pressing V.
Note: If the "international" language is selected, refer to the "international language" appendix.
Screen 22
Screen 2 will allow the date and time to be modified. This is only required when the clocks change because the internal clock is kept active
by a lithium battery while control unit is powered off.
The cursor flashes over the osign of the first line.
Press to move the cursor to the next line, except if it flashes next to Minute.
Press to move the cursor to the previous line, except if it flashes next to Day.
By pressing or , the operator places the cursor on the line to be changed.
DATE / TIME
V: Valid Esc: Exit
o Day : 12
o Month : 01
o Year : 2000
o Hour : 16
o Minute : 30
By following the instructions below, it is possible to change, line after line, the day, month, year, hours and minutes.
Press Vto take the cursor to the first digit after the : sign. By pressing one of the ten buttons 0to 9, the first digit is modified and the cur-
sor is automatically moved to the second digit.
The cursor can be moved to the second digit by pressing instead of one of the ten digits 0to 9. Afterwards, it can be moved back to
the first digit by pressing .
Note: the year has four digits.
Press Vagain to take the cursor back to oand to validate the entry made.
When the cursor is positioned over one of the digits, press Esc to bring it back to o, without saving the entry made or without changing the
previous value if there was no entry.
Press Esc without any entry to go to the " overview " screen (see paragraph 1.7). There, the date and time taken into account will be the
ones appearing on the screen before Esc was pressed.
Press Esc after changing one of more parameters (hour, minute,...) to go to the " overview " screen (see paragraph 1.7). There, the time
and date taken into account will be those which were modified on screen before Esc was pressed.
When the clocks change, if you press Esc without changing the date and time, the generating set alarms, faults and status will not
be correctly date and time stamped.
Version 1.2

8
10/01
Foreword_______________________________________________________________________________________________________________________________________________
If neither Vnor Esc is pressed, the " overview " screen appears after three minutes. There, the time and date will be those of the previous
screen (before going automatically to the " overview " screen).
Note : Not until the appearance of the " overview " screen will it be possible to start the generating set, however all engine protection shut-
downs stay active (example: appearance of a fault).
11..77..""OOvveerrvviieeww""ssccrreeeenn
The " overview " screen is the screen which appears systematically by default.
Using the four buttons: U/V, I, F/, Engine, you can access all " overview " type screens (see paragraphs 4 and 5) which give details on:
- Electrical values and engine parameters
- Generating set alarms and faults
- Status of the generating set and its auxiliaries, date and time
Normal ooperation
Following the language selection screen and/or possible date and time modification screen, the " overview " screen below appears during
normal operating conditions.
The first line indicates the fuel level, in %, in the day tank.
The second line indicates the engine speed in RPM.
The third line indicates the battery voltage in Volts.
The fourth and fifth lines indicate the generating set status, the time, date and various other messages
(see paragraph 9).
Fuel Lev(%)
E.Speed(RPM)
Batt. (Volts)
ext command=0 16:45
gen stopped 12/01/00
24
.
2
50
0
If the cabling of the fuel level analogue input is faulty or if the sensor itself is faulty, there will be no digital indication on screen. However,
the wording Fuel LLev(%) will appear (see also paragraph 5). This particular display is used to perform a quick diagnostic on the physical
status of the input (sensor and cabling).
If the fuel level analogue sensor is not available on the day tank, there will be no display on screen (see paragraph 5). This is the case for
the Pacific range generating sets where the fuel level is read directly from a mechanical gauge.
Nota 1 : Press successively one of the four buttons previously mentioned to modify the screen above (see paragraphs 4 and 5).
Nota 2 : the date is given in day/month/year
Abnormal ooperation
During abnormal operating conditions (presence of an alarm or fault, several alarms or faults or a mixture of both), the previous screen is
replaced by the following one:
Two extra lines are inserted to display the malfunctions (alarms and/or faults).
Engine parameters and electric values appear on screen in a shortened form.
The two lower lines stay unchanged.
Fuel Lev(%) 10
E.Speed(RPM) 0
Batt. (Volts) 24.2
Alarm Low fuel level
ext command=0 17:25
gen stopped 12/01/00
The display of the generating set alarms and faults is detailed in paragraph 8.
2. OOPERATING MMODES
The control unit has four operating modes which can be accessed via the four blue coloured buttons on the display module:
Mode Stop
Mode Manu
Mode Auto
Mode Test
22..11..SSttooppMMooddee
After powering up (initialization, language selection and/or possible time and date update), the control unit automatically goes into Stop
mode. The red LED associated with the button comes on and the "overview screen" appears.
Auto
Stop
Test
Manu
Example of " overview " screen in Stop mode.
Fuel Lev(%)
E.Speed(RPM)
Batt. (Volts)
ext command=0 16:45
gen stopped 12/01/00
24
.
2
50
0

10/01
9
________________________________________________________________________________________________________________________________________Operating Modes
In this operating mode, any event appearance (alarm, fault, external command, ...) is signalled on screen. However, the generating set is
stopped and automatic start-up is not possible.
When the generating set is running and whatever the current mode (Auto, TTest, MManu), press the Stop
button to stop it instantly without any cooling down. A message appears on screen for two seconds
to signal that the button has been taken into account (see screen opposite).
Note: if the engine is equipped with a water heater, the latter is not powered in Stop mode.
Ph./ph. U12
voltages U23
(Volts) U31
STOP mode selected
395
396
390
22..22..MMaannuuMMooddee
The Local mode provides local control from the keyboard, ie, the operator is wholly in control of the start procedure.
-This mode may be accessed from the Stop or AUTO modes. Two alternative programmed solutions are available :
- 1 press on the key
- 2 presses on thse key
a) SSingle kkey ppress ::
The generator starts in Local mode after a single press on the Local key. Using this function:
- The red LED usually associated with the Local key does not flash,
- The message confirming the selection of Local mode does not appear.
b) DDual kkey ppresses ::
Pressing the Local key once, briefly, selects the mode and displays the screen below. The key's associated red LED also flashes.
Pressing the Local key, briefly, a second time confirms the mode selection. The red LED comes on permanently and the generator set then
enters its automatic start procedure phase (see paragraph 17).
Whilst the red LED is flashing (awaiting confirmation), the mode may still be changed by selecting
either Stop or Auto mode.
If the first pressure on the Local key is not confirmed within two minutes, one of two things may hap-
pen s:
- Stop mode will be selected automatically if this was the previous mode, or,
- Auto mode will be selected automatically if that were the previous mode.
In Local mode, switching between Normal and Emergency is enabled by pressing the 0 or 1 keys, but only if the green LED is ON (see
paragraph 18). The operator still has control over the Normal/EmergencyY switch and the generator set.
If an external Start command appears on the screen, the control unit remains in Local mode. The operator then has to change from the
Local to AUTO mode.
Fuel Lev(%)
E.Speed(RPM)
Batt. (Volts)
MANU mode selected
press MANU to confirm
24
.
2
50
0
Fuel Lev(%)
E.Speed(RPM)
Batt. (Volts)
AUTO mode selected
24
.
2
50
0
Fuel
Lev(%)
E.Speed(RPM)
Batt. (Volts)
ext command=0 16:50
gen stand-by
12/01/00
24
.
2
50
0
From the waiting screen, the generating set start-up is conditioned by:
Logical status change of the 'external command' input
Logical status change of the 'EJP advance warning' or 'EJP start-up' inputs (France only)
Activation of the clock mode built into (if the mode is programmed).
Example: the right-hand side screen above informs of the logical status of the external start-up command (abbreviation ext command=0 or
ext command=1):
- External command = 0, no start-up
- External command = 1, imminent start-up possible
When one of the three start-up conditions changes from 0 to 1 (for and ) or from inactive to active (for ), a new message informs
the operator, then the generating set enters into an automatic start-up phase (see paragraph 17).
When one of the three start-up conditions changes from 1 to 0 (for and ) or from active to inactive (for ), a new message informs
the operator, then the generating set enters into an automatic shutdown phase (see paragraph 17).
In Auto mode, the ATS toggle is completely automatic (see paragraph 18).
22..44..TTeessttMMooddee
Test mode can only be accessed from Auto mode. If one of the inputs ; external command, EJP advance warning, EJP start-up, is in logical
status 1 or if the clock is active, Test mode cannot be selected.
If the inputs; external command, EJP advance warning, EJP start-up, are in logical status 0 or if the clock is inactive, press Test button to
select the mode and to bring up the screen below. The red LED associated with the button flashes.
22..33..AAuuttooMMooddee
Auto mode can be accessed from Stop, Manu or Test mode. Press the Auto button to select the mode and to display the left-hand side screen
below for two seconds. The red LED associated with the button comes on, then the right-hand screen appears. This screen corresponds to
the standby state of the generating set.

10
10/01
Operating Modes________________________________________________________________________________________________________________________________________
Press Test button again to confirm the mode, the associated red LED comes on continuously and the
generating set then enters into an automatic start-up phase (see paragraph 17).
When the red LED flashes (waiting for confirmation), the mode can be changed by selecting Stop
mode or Auto mode.
Fuel Lev(%)
E.Speed(RPM)
Batt. (Volts)
TEST mode selected
press TEST to confirm
24
.
2
50
0
If you do not press Test to confirm, Auto mode is automatically selected after two minutes.
In Test mode, the ATS cannot be toggled, this is a no-load operation. The generating set operating time is indicated on screen by a time
displayed in minutes and seconds which counts down automatically. When the delay elapses, the generating set shuts down without cooling
and automatically goes into Auto mode.
Example of " overview " screen in Test mode
There are two minutes and thirty seconds of operation left before the generating set stops and the
control unit goes into Auto mode.
Fuel Level(%)
E.Speed(RPM)
Batt. (Volts)
TEST mode
eng. stops in: 02’ 30’’
24
.
2
50
0
During operation, if one of the inputs ; external command, EJP advance warning, EJP start-up, changes logical status (from 0 to 1) or if
internal clock is activated, a screen message is displayed to indicate the status change or the clock activation. The Test mode timer is bypas-
sed, automatically goes into Auto mode, the ATS toggles and you are then back in normal Auto mode operation.
3. SSLEEP MMODE AAND AAUTOMATIC SSHUTDOWN
Is equipped with a sleep mode and an automatic shutdown.
33..11..SSlleeeeppmmooddee
Sleep mode is possible when is in Stop mode or Auto mode with the generating set on stand-by (*). The sleep mode starts automatically
after an adjustable time if there is no status change on one of the system logical inputs, no communication with a PC or no keystroke.
In this case, the back-light switches off and goes into a minimum consumption mode.
Example of a " overview " screen in sleep mode, the various indications stay visible on screen.
(*) Genset stopped with no external command, no EJP start-up and no clock activation.
If one the system logical inputs changes status (alarm, fault, thermostat, external command, ...), the
messages appear and the back-light switches back on.
On the appearance of an alarm or a fault not generated by the change of state of an entry, the back-
lighting does not come on again.
Note : if a low/high battery voltage alarm or fault or a CAN bus fault appears, the back-light will not
switch itself back on.
Fuel Lev(%)
E.Speed(RPM)
Batt. (Volts)
ext command=0 16:48
gen stopped 12/01/00
24
.
2
50
0
33..22..AAuuttoommaattiiccsshhuuttddoowwnn
Automatic shutdown is only possible when is in Stop mode. In Stop mode, even if the back-light is switched off, the battery discharges slowly
(electronics consumption) in cases where the generating set is not equipped with a battery charger.
To avoid the battery from discharging and thus the generating set from not being able to start, will shut down automatically after a delay.
After shutdown, the internal clock stays active. The generating set alarm, fault and status event log is kept unchanged.
After powering up via the ON button, automatically goes into Stop mode and brings up the " overview " screen (see paragraph 1.7) in the
language used before the automatic shutdown. This way, the operator does not need to reselect the language and press Esc to return to the
" overview " screen.
Following an automatic shutdown, can be powered up again by simply pressing the ON button. Initialisation is carried out in the
same conditions as with a first power-up.
33..33..SSppeecciiaallccaassee
- On the appearance of any fault condition whatsoever, the Telys MICS automatically sets itself into the STOP mode but, at the end of the
'auto cut-off' timer (setting 108 in the Timer menu), the Telys MICS remains switched on. This function is particularly useful for those appli-
cations fitted with :
- An OPT34 module, programmed for Option 3
- An optional module 6
- The Wintelys supervision and remote management software.
This feature ensures that the signals provided by these modules (free potential contact, remote module 6 control) and the monitoring soft-
ware will remain available for remote operating.

10/01
11
_______________________________________________________________________________________________________________________________Viewing the electrical values
4. VVIEWING TTHE EELECTRICAL VVALUES
44..11..VVoollttaaggeess
You can view the various AC voltages by pressing the U/V button successively. Their values are expressed in true root mean square Volts.
Depending on the client's needs (type of electrical installation), several screens are possible:
3 phase with neutral (3ph+N)
3 phase without neutral (3ph)
2 phase (2ph+N)
1 phase (1ph+N)
Note: one of the four choices above has been factory programmed as per the client's specification.
3pphase wwith nneutral ((3ph+N)
Press U/V to get the three phase-to-phase voltages:
U12 = voltage across phase 1 and phase 2
U23 = voltage across phase 2 and phase 3
U31 = voltage across phase 3 and phase 1
Ph./ph. U12
voltages U23
(Volts) U31
ext command=1 17:05
gen running 12/01/00
398
399
400
Press U/V again to get the three phase-to-neutral voltages:
V1 = voltage across phase 1 and neutral
V2 = voltage across phase 2 and neutral
V3 = voltage across phase 3 and neutral
Press U/V again to bring up the first screen and so on...
Ph./neutr. V1
voltages V2
(Volts) V3
ext command=1 17:05
gen running 12/01/00
230
230
230
3pphase wwithout nneutral ((3ph)
Press U/V to get the three phase-to-phase voltages:
U12 = voltage across phase 1 and phase 2
U23 = voltage across phase 2 and phase 3
U31 = voltage across phase 3 and phase 1
If you press U/V nothing changes.
Ph./ph. U12
voltages U23
(Volts) U31
ext command=1 17:05
gen running 12/01/00
398
399
400
Press U/V to get the two half voltages:
U1n = voltage across phase 1 and neutral
U2n = voltage across phase 2 and neutral
Half U1n
voltage U2n
(Volts)
ext command=1 17:05
gen running 12/01/00
120
122
2pphase ((2ph+N)
Press U/V again to get the voltage across the two phases:
U12 = voltage across phase 1 and phase 2
Press U/V again to bring up the first screen and so on ...
Phase U12
voltage
(Volts)
ext command=1 17:05
gen running 12/01/00
242
1pphase ((1ph+N)
Press U/V button to get the voltage across phase and neutral:
V1 = voltage across phase 1 and neutral
If you press U/V again, nothing changes.
Ph./neutr. V1
voltage
(Volts)
ext command=1 17:05
gen running 12/01/00
230

12
10/01
Viewing the electrical values_______________________________________________________________________________________________________________________________
44..22..CCuurrrreennttss
To view the various AC currents, press the Ibutton successively. The values are expressed in true root mean square Amps. Depending on the
client's needs (type of electrical installation), several screens are possible:
3 phase with neutral (3ph+N)
3 phase without neutral (3ph)
2 phase (2ph+N)
1 phase (1ph+N)
Note: one of the four choices above has been factory programmed as per the client's specification.
3pphase wwith nneutral ((3ph+N)
Press Ito get the three phase currents:
I1 = current in phase 1
I2 = current in phase 2
I3 = current in phase 3
Phase I1
current I2
(Amps) I3
ext command=1 17:10
gen running 12/01/00
536
542
543
Press Iagain to get the neutral current:
In = current in the neutral
Note : the neutral current is calculated by vector summation of the three phase currents..
Press Iagain to bring up the first screen and so on ...
Neutral
current In
(Amps)
ext command=1 17:10
gen running 12/01/00
23
3pphase wwithout nneutral ((3ph)
Press Ito get the three phase currents:
I1 = current in phase 1
I2 = current in phase 2
I3 = current in phase 3
If you press Iagain, nothing changes.
Phase I1
current I2
(Amps) I3
ext command=1 17:10
gen running 12/01/00
536
542
543
Press Ito get the two phase currents:
I1 = current in phase 1
I2 = current in phase 2
If you press Iagain, nothing changes.
Phase I1
current I2
(Amps)
ext command=1 17:10
gen running 12/01/00
246
238
2pphase ((2ph+N)
1pphase ((1ph+N)
Press Ito get the 1 phase current :
I1 = 1 phase current
If you press Iagain, nothing changes.
Phase I1
current
(Amps)
ext command=1 17:10
gen running 12/01/00
95
44..33..FFrreeqquueennccyyaannddhhoouurrssccoouunntteerr
To view the generating set frequency and number of running hours, press the F/button. Values are expressed in Hertz (Hz) and in hours res-
pectively.
The minutes are counted from 0 to 59 minutes; on the 60th minute, the number of hours is incremen-
ted and the number of minutes goes to 0.
Example of "overview" screen showing frequency and number of generator running hours and minutes.
Note: a maximum of 32767 running hours can be displayed. The display is in whole hours.
Frequency (Hz)
No hours
ext command=1 17:10
gen running 12/01/00
5500
.
2
664433
4455
No minutes
Table of contents
