Seafloor TriDrone Programming manual

- TriDrone USV
- TriDrone Carry Case
- TriDrone Hardware Kit
- Data Collector Cable
- Accessory Pouch
-Spektrum Remote
Control with case
-USB Drive
-Mast
IMPORTANT
THANK YOU FOR PURCHASING SEAFLOOR SYSTEMS' PRODUCTS FOR YOUR SURVEYING NEEDS.
Please read through all of these Instructions and tips before proceeding with the operation. We do our best
to provide a simple setup process for all applications however please contact your nearest authorized
dealer if you encounter issues.
Always disconnect any power sources connected to your vessel before servicing vessel or accessories.
PRODUCT INCLUDES:
STEP: 1
Remove the vessel from the
case. Remove the remote case
from the top of the lid. Remove all
accessories from accessory pouch
located at the bottom of the case.
QUICKSTART INSTRUCTIONS
TriDrone Portable Remote Surveying Vessel

QUICKSTART INSTRUCTIONS
STEP: 2
Attach the thruster to the rear bracket of the vessel and secure by tightening
retaining screw.
STEP: 3
Insert fully charged 4S battery
and connect to power
distribution cable.
STEP: 4
Open bow hatch lid with provided hatch wrench,
and remove lid.
STEP: 5
Run the data collector cable through the inside of the hull through to the
hull hatch lid.

QUICKSTART INSTRUCTIONS
STEP: 6
Connect data collector cable to
transducer.
STEP: 8
Connect the thruster cable to the bulkhead
located at the stern of the vessel.
STEP: 7
Attach antenna to the mounting screw located at the front of the frame.

QUICKSTART INSTRUCTIONS
Operation: Be sure to observe and follow all local water safety regulations and procedures. Always
operate vessel within line of sight, and immediately stop operation if hazards or safety risks arise.
Your setup is now complete.
Welcome to the Seafloor Squad!
WARRANTY INFORMATION
For warranty information, visit https://www.seafloorsystems.com/terms-and-conditions 4415 Commodity Way, Shingle
Springs, CA, 95682 • 530-677-1019 https://www.seafloorsystems.com/
STEP: 9
Switch power to the "On" position.
STEP: 10
Connect the remote by holding the power button for
approximately 2 seconds. The remote will beep when
activated. You are now ready to survey.
