Seagate ST31000322CS - Pipeline HD 1 TB Hard Drive User manual

160 GB, 250 GB, 320 GB, 500 GB and 1 TB • SATA
Key Features and Benefits
• Eco-friendlypowersavingsenablethemostenergy-efcientand
cost-effectivesystemdesigns.
• Industry-leadingreliabilityof0.55%AFRinanalways-on
environmentsupportslongevityexpectationsofconsumerand
commercialvideoapplications.
• 75°Coperatingtemperaturecapabilityforimprovedsystem
reliability
• Videostreamingoptimizedtosupportatleast10simultaneous
high-denitionvideostreamsformulti-roomDVRapplications
• SeagateSoftSonic™motortechnologyenablesyearsofultra-
quiet,worry-freeoperationwithacousticsperformanceaslow
as1.9bels.
• Upto1-TBcapacityenablingupto200hoursofHDstorageor
1000hoursofSDtelevisionrecording
• Sweet-spotcapacitiesenablepremiumtelevisionservicessuch
asvideoondemand,high-denitionstorageandmulti-room
streamingforDVRsandmediacenters.
• SeagateThinkGreen™sustainabilitygoesbeyondgreenwith
improvedreliability,lowpowerconsumption,leadingrecycling
programs,RoHScompliance,PVCfree,halogenfreeand
brominatedameretardantfree
Best-Fit Applications
• ConsumerDVRandmediacenterapplications
• EmbeddedsurveillanceDVR(SDVR)systems
• HometheaterPCs,karaokeandaudiojukeboxes
• Cable,satelliteandIPTVset-topboxes
Pipeline HD™
The industry’s leading combination of
video streaming and low-power performance
DataSheet

Pipeline HD™
The industry’s leading combination of
video streaming and low-power performance
AMERICAS Seagate Technology LLC 920 Disc Drive, Scotts Valley, California 95066, United States, 831-438-6550
ASIA/PACIFIC Seagate Technology International Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888
EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 130–136, rue de Silly, 92773, Boulogne-Billancourt Cedex, France 33 1-4186 10 00
Copyright©2009SeagateTechnologyLLC.Allrightsreserved.PrintedinUSA.Seagate,SeagateTechnologyandtheWavelogoareregisteredtrademarksofSeagateTechnologyLLCintheUnitedStatesand/orothercountries.
PipelineHD,SoftSonicandThinkGreenareeithertrademarksorregisteredtrademarksofSeagateTechnologyLLCoroneofitsafliatedcompaniesintheUnitedStatesand/orothercountries.Allothertrademarksorregistered
trademarksarethepropertyoftheirrespectiveowners.Whenreferringtoharddrivecapacity,onegigabyte,orGB,equalsonebillionbytesandoneterabyte,orTB,equalsonetrillionbytes.Yourcomputer’soperatingsystemmay
useadifferentstandardofmeasurementandreportalowercapacity.Inaddition,someofthelistedcapacityisusedforformattingandotherfunctions,andthuswillnotbeavailablefordatastorage.Quantitativeusageexamples
forvariousapplicationsareforillustrativepurposes.Actualquantitieswillvarybasedonvariousfactors,includinglesize,leformat,featuresandapplicationsoftware.Seagatereservestherighttochange,withoutnotice,product
offeringsorspecications.DS1693.1-0906US,June2009
Specifications 1 TB1500 GB1320 GB1250 GB1160 GB1
Model Number ST31000322CS2ST3500312CS2,
ST3500321CS3
ST3320311CS2,
ST3320310CS3
ST3250312CS2ST3160316CS2,
ST3160310CS3
Interface SATA 3Gb/s SATA 3Gb/s SATA 3Gb/s SATA 3Gb/s SATA 3Gb/s
Performance
Cache, Multisegmented (MB) 88888
SATA Data Transfer Rate (Gb/s, max) 3.0 3.0 3.0 3.0 3.0
Simultaneous SDTV Streams Supported (Assumes 256K host buffer per stream) 10 10 10 10 10
Simultaneous HDTV Streams Supported (Assumes 2-MB host buffer per stream) 10 10 10 10 10
Power-On to Ready (typical, sec) <12 <62, <123<6 <6 <6
Standby to Ready (typical, sec) <12 <62, <123<6 <6 <6
Maximum External Transfer Rate (MB/s) 300 300 300 300 300
Voltage
Voltage Tolerance (including noise) 5V ± 5%
12V ± 10%
5V ± 5%
12V ± 10%
5V ± 5%
12V ± 10%
5V ± 5%
12V ± 10%
5V ± 5%
12V ± 10%
Environmental
Halogen Free Yes Yes2, No3Yes2, No3Yes Yes2, No3
Ambient Temperature (°C)
Operating (ambient min)
Operating (drive case max)
Nonoperating (ambient min)
Nonoperating (ambient max)
0
75
–40
70
0
75
–40
70
0
75
–40
70
0
75
–40
70
0
75
–40
70
Temperature Gradient, Operating/Nonoperating (°C per hour max) 20/30 20/30 20/30 20/30 20/30
Relative Humidity, Operating/Nonoperating (non-condensing, %) 5 to 90/5 to 95 5 to 90/5 to 95 5 to 90/5 to 95 5 to 90/5 to 95 5 to 90/5 to 95
Web Bulb Temperature, Operating/Nonoperating (°C) 37.7/40.0 37.7/40.0 37.7/40.0 37.7/40.0 37.7/40.0
Shock
Operating: 2 ms (max, Gs)
Nonoperating: 1 ms (max, Gs)
70
350
70
3502, 3003
70
350
70
350
70
350
Vibration, Operating
5-22 Hz (limited displacement) (Gs)
22-350 Hz (Gs)
350-500 Hz (Gs)
0.50
0.50
0.25
0.502, 0.253
0.50
0.25
0.50
0.50
0.25
0.50
0.50
0.25
0.502, 0.253
0.50
0.25
Vibration, Nonoperating
5-350 Hz (limited displacement) (Gs)
350-500 Hz (Gs)
5.00
1.00
5.00
1.00
5.00
1.00
5.00
1.00
5.00
1.00
Power Management
Startup Current (12 V typical, amps) 2.0 2.0 2.0 2.0 2.0
Consumer Storage Profile (W) 4.1 3.42, 5.033.42, 4.733.4 3.42, 4.73
Idle Average (W) 3.8 3.02, 4.333.0 3.0 3.0
Standby/Sleep Mode (typical, W) 0.7 0.7 0.6 0.7 0.57
Acoustics
PVR Profile (typical/max, bels) 2.1/2.4 1.9/2.02, 2.1/2.431.9/2.02, 1.9/2.131.9 /2.0 1.9/ 2.02, 1.9/2.13
Reliability
Nonrecoverable Read Errors per Bits Read 1 sector per 10E15 1 sector per 10E152,
1 sector per 10E143
1 sector per 10E152,
1 sector per 10E143
1 sector per 10E15 1 sector per 10E152,
1 sector per 10E143
Annualized Failure Rate (AFR) 0.55% 0.55%2, 0.57%30.55%2, 0.57%30.55% 0.55%2, 0.57%3
Contact Start-Stop Cycles (25°C, 50% relative humidity) 50,000 50,000 50,000 50,000 50,000
Dimensions
Height (mm/in, max) 26.1/1.028 20.0/0.7952, 26.1/1.028320.0/0.795 20.0/0.795 20.0/0.795
Width (mm/in, max) 101.85/4.010 101.85/4.010 101.85/4.010 101.85/4.010 101.85/4.010
Depth (mm/in, max) 146.99/5.787 146.99/5.787 146.99/5.787 146.99/5.787 146.99/5.787
Weight (g/lb, max) 600 /1.323 380/0.8382, 530/1.168 3415/ 0.9152, 380/0.8383380/0.838 415/0.9152, 380/0.8383
1 One gigabyte, or GB, equals one billion bytes and one terabyte, or TB, equals one trillion bytes when referring to hard drive capacity.
2 500-GB/disk model
3 320-GB/disk model
