Seagate ST31500341AS - Barracuda 1.5 TB Hard Drive User manual

1.5 TB, 1 TB, 750 GB, 640 GB, 500 GB, 320 GB, 160 GB •
7200 RPM •SATA 3Gb/s with NCQ
Key Advantages
•Delivers the industry’s highest capacity—up to 1.5 TB of storage
(also 1 TB and 750, 640, 500, 320 and 160 GB)
•Ships with the industry’s most reliable and proven perpendicular
magnetic recording (PMR) technology
•Delivers high performance
– up to 120-MB/s sustained data rate
– 32-, 16- and 8-MB cache buffer
•Environmentally friendly
– Consumes up to 43 percent less power during idle than previous
products, enabling customers to build low-power systems
– Meets strict RoHS requirements
•Leverages best combination of technology (areal density, PMR)
and proven components for volume availability
Best-Fit Applications
•Workstations
•Desktop RAID
•Gamer PCs
•High-end PCs
•Mainstream PCs
•USB/FireWire/eSATA personal external storage
Barracuda®7200.11
Up to 1.5 TB of high-performing, eco-friendly
desktop storage—so right for so many
different applications
Data Sheet

Barracuda®7200.11
Up to 1.5 TB of high-performing, eco-friendly
desktop storage—so right for so many
different applications
AMERICAS Seagate Technology LLC 920 Disc Drive, Scotts Valley, California 95066, United States, 831-438-6550
ASIA/PACIFIC Seagate Technology International Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888
EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 130–136, rue de Silly, 92773, Boulogne-Billancourt Cedex, France 33 1-4186 10 00
Copyright © 2008 Seagate Technology LLC. All rights reserved. Printed in USA. Seagate, Seagate Technology and the Wave logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries.
Barracuda is either a trademark or registered trademark of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. All other trademarks or registered trademarks are the property of their
respective owners. When referring to hard drive capacity, one gigabyte, or GB, equals one billion bytes and one terabyte, or TB, equals one trillion bytes. Your computer’s operating system may use a different standard of measurement
and report a lower capacity. In addition, some of the listed capacity is used for formatting and other functions, and thus will not be available for data storage. Seagate reserves the right to change, without notice, product offerings or
specifications. DS1629.5-0812US, December 2008
Specifications 1.5 TB11 TB1750 GB1640 GB1500 GB1320 GB1160 GB1
Model Number ST31500341AS ST31000333AS
ST31000340AS
ST3750330AS ST3640323AS ST3500320AS ST3320613AS ST3160813AS
Interface Options SATA 3Gb/s NCQ SATA 3Gb/s NCQ SATA 3Gb/s NCQ SATA 3Gb/s NCQ SATA 3Gb/s NCQ SATA 3Gb/s NCQ SATA 3Gb/s NCQ
Performance
Transfer Rate, Max Ext (MB/s) 300 300 300 300 300 300 300
Sustained Data Rate OD (MB/s) 120 115, 1052105 115 105 115 115
Cache (MB) 32 32 32, 16332 32, 16316 8
Spindle Speed (RPM) 7200 7200 7200 7200 7200 7200 7200
Reliability/Data Integrity
Contact Start-Stops 50,000 50,000 50,000 50,000 50,000 50,000 50,000
Annualized Failure Rate 0.34% 0.34% 0.34% 0.34% 0.34% 0.34% 0.34%
Mean Time Between Failures (hours) 750,000 750,000 750,000 750,000 750,000 750,000 750,000
Physical
Height (in/mm) 1.0 2 /26.11 1.0 2 /26.11 1.0 2 /26.11 1.0 2 /26.11 1.0 2 /26.11 0.787/20.00 0.787/20.00
Width (in/mm) 4.00/101.6 4.00/101.6 4.00/101.6 4.00/101.6 4.00/101.6 4.00/101.6 4.00/101.6
Depth (in/mm) 5.78/146.99 5.78/146.99 5.78/146.99 5.78/146.99 5.78/146.99 5.787/146.99 5.787/146.99
Weight (lb/kg) 1.4/0.64 1.4/0.64 1.4/0.64 0.838/0.380 1.2/0.54 0.838/0.380 0.805/0.365
This Barracuda Generation Brings
a Whopping 1.5 TB
This is a drive for the ages, and it will take ages to fill it up. In
one bold move, Seagate provides the largest single capacity
jump in the history of hard drives—a half-terabyte increase
from the previous high of 1 TB—thanks to the capacity-
boosting power of perpendicular magnetic recording
technology.
The Eco-Friendly Choice
The Barracuda 7200.11 drive delivers up to 43 percent power
savings over the previous Seagate desktop generation
without sacrificing performance, giving customers the
ability to manufacture eco-friendly PC systems and external
storage systems that meet energy-savings requirements.
Like all other Seagate®drives, the Barracuda 7200.11
product family complies with the Restriction of Hazardous
Substance (RoHS) directive that limits the use of hazardous
materials in electronic goods.
www.seagate.com
1-800-SEAGATE (1-800-732-4283)
1 One gigabyte, or GB, equals one billion bytes and one terabyte, or TB, equals one trillion bytes when referring to hard drive capacity.
2 Sustained Data Rate OD for model number ST31000333AS is 115 MB/s, and for ST31000340AS is 105 MB/s.
3 Not available through distribution
With the Barracuda 7200.11 drive, our customers can have
the best of both worlds—top hard-drive performance and a
high-capacity drive with a very small eco-footprint.
Seagate is committed to minimizing the impact of our
products and operations on the environment. We have
implemented production efficiency measures, such as
replacing or renovating less-efficient equipment, resulting
in a 20 percent increase in production efficiency on a per-
hard-drive basis. In just six months this delivered a savings
of 158.93 million kWh, or enough energy to power nearly
15,000 U.S. homes for one year. Seagate also has deployed
aggressive waste minimization and recycling programs in
facilities worldwide.
