Sealey AP12600.V4 User manual

WORKSTATION 1.2M WITH DRAWERS
MODEL NO: AP12600.V4
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this bench.
9Locate bench in a suitable work area.
9Keep the work area clean, uncluttered and ensure there is adequate lighting.
WARNING! Use bench on level and solid ground, preferably concrete.
9Keep the bench clean and tidy in accordance with good workshop practice.
9Keep children and unauthorised persons away from the work area.
8DO NOT use the bench for any purpose other than that for which it is designed.
8DO NOT undertake work on the bench without the workpiece being adequately secured. Use clamps or a vice (not included) to secure
the workpiece - available from your Sealey Stockist.
8DO NOT use the bench outdoors .
8DO NOT get the bench wet or use in damp or wet locations or areas where there is condensation.
8DO NOT exceed the maximum load for the work surfaces, worktop and bottom shelf - 100kg each, top shelf - 20kg. Avoid heavy
impacts when placing objects onto the surfaces.
8DO NOT clean the bench with any solvents which may damage the surface or the protective coating on the worktop.
2. INTRODUCTION
Boltless designed frame makes the unit easy to assemble, with minimal tools being required. Pegboard rear panel with hooks for convenient
tool storage. Two half drawers, with ball bearing slides, full size shelf below MDF worktop and 230mm shelf above pegboard.
3. SPECIFICATION
Model No: .................................................................................... AP12600
Nett Weight: ..................................................................................... 33.9kg
Size (W x D x H [Overall/Worktop]): .....................1215 x 610 x 1500/900mm
Worktop: ................................................................................. 1205 x 600mm
AP12600.V4 Issue 2 06/02/19
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear protective
gloves

4. CONTENTS
Unpack the product and check the contents against the list below. Should any items be missing or damaged contact your Sealey Stockist.
ITEM PART NO. DESCRIPTION QTY
AAP12600.V3-A LEFT (RIGHT) FRONT POST (900MM) 2
B(L) AP12600.V3-BL LEFT REAR POST (966MM) 1
B(R) AP12600.V3-BR RIGHT REAR POST (966MM) 1
CAP12600.V3-C FEET 4
DAP12600.V3-D SIDE BEAMS (592MM) 4
EAP12600.V3-E BOTTOM BEAMS (1200MM) 2
E1 AP12600.V3-E1 BOTTOM TOP (1197MM) 2
FAP12600.V3-F FRONT & REAR SHELF BEAM (1200MM) 2
GAP12600.V3-G DRAW MOUNTS FRONT/REAR (135MM) 2
H(L) AP12600.V3-HL DRAW MOUNTS, LEFT (605MM) 1
H(R) AP12600.V3-HR DRAW MOUNTS, RIGHT (605MM) 1
I(L) AP12600.V3-IL DRAW MOUNTS, CENTRE LEFT (586MM) 1
I(R) AP12600.V3-IR DRAW MOUNTS, CENTRE RIGHT (586MM) 1
JAP12600.V3-J FRONT PANEL FOR DRAW (530MM) 2
KAP12600.V3-K REAR PANEL FOR DRAW (510MM) 2
L(L) AP12600.V3-LL LEFT SIDE PANEL FOR DRAW (455MM) 2
L(R) AP12600.V3-LR RIGHT SIDE PANEL FOR DRAW (455MM) 2
N(L) AP12600.V3-NL LEFT EXTENSION POST (610MM) 1
N(R) AP12600.V3-NR RIGHT EXTENSION POST (610MM) 1
O(L) AP12600.V3-OL LEFT TOP SHELF BEAMS (230MM) 1
O(R) AP12600.V3-OR RIGHT TOP SHELF BEAMS (230MM) 1
PAP12600.V3-P BOTTOM SHELF (1210 x 605 x 15MM) 1
QAP12600.V3-Q WORKTOP (1210 x 603 x 15MM) 1
RAP12600.V3-R PEGBOARD (1210 x 580 x 4.5MM) 1
SAP12600.V3-S TOP SHELF (1205 x 228 x 6.0MM) 1
TAP12600.V3-T DRAW BOTTOM (512 x 450 x 6MM) 2
UAP12600.V3-U DRAW HANDLE 2
VAP12600.V3-V M4 x 10MM - Draw handle bolts (8pcs), nuts
(8pcs), washers (8pcs)
24
WAP12600.V3-W M6 x 15MM - Fixing kit bolts (8pcs), nuts
(8pcs), washers (12pcs)
28
XAP12600.V3-XH Toolhook 20
YAP12600.V4-Y M6 x 10MM - Draw bolts (16pcs), nuts (16pcs),
washers (16pcs)
48
5. ASSEMBLY
5.1 Study each diagram and identify the components required with reference to the contents table on above.
5.2 Build up the basic frame as shown in diagrams 1,2,3 & 4.
5.3 Attach the drawer supports to the basic frame as shown in diagrams 5 & 6.
5.4 Bolt together the two drawers with reference to diagram 7 and fit them onto the drawer runners as shown in diagram 8.
Structural members have
flat headed, waisted
rivets attached which
pass through keyholes in
the uprights and are
pushed down to secure
them.
12
AP12600.V4 Issue 2 06/02/19
Original Language Version
© Jack Sealey Limited

34
56
78
AP12600.V4 Issue 2 06/02/19
Original Language Version
© Jack Sealey Limited

10
5.5 Attach the extension posts to the back two uprights and assemble and mount the top shelf frame as shown in diagram 9.
5.6 Attach the peg board and position the top shelf, work top and bottom shelf as indicated in diagram 10.
5.7 Attach tool hooks to peg board as required. See diagram 10.
9
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
