INSTRUCTIONS FOR
INDUSTRIAL WORKSTATION 1 DRAWER
MODEL NO: AP875
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using workbenches
and associated workbench drawers.
WARNING! Use the workbench on level and solid ground, preferably concrete. Avoid tarmacadam since the workbench may sink into
the surface.
9Locate the workstation in a suitable working area.
9Keep the work area clean, uncluttered and ensure there is adequate lighting.
9Keep the workstation clean and tidy in accordance with good workshop practice.
9Keep children and unauthorised persons away from the working area.
9Take care when assembling of sharp edges
8DO NOT remove a fully loaded drawer.
8DO NOT use the workstation drawer for any purpose other than that for which it is designed.
8DO NOT use the workstation out of doors.
8DO NOT get the workstation drawers wet or use in damp or wet locations or areas where there is condensation.
8DO NOT clean the workstation drawers with any solvents which may damage the painted surfaces.
Note: The assembly of this product to the will require assistance.
2. INTRODUCTION
Industrial single drawer workstation, ideal for site workers or line managers and supervisors. Workstation features a 5° sloped surface allowing
a better angle to write on, with a raised lip on the lower edge to prevent items sliding off. A lockable ball bearing slide drawer is ideal for
keeping valuables, stationary or paperwork safe. Three pigeon holes are suitable for keeping paperwork or manuals on hand and in order, or
as in and out trays. Adjustable feet ensure the unit sits level, even if your oor is not. Lower shelf allows for items such as work wear to be
stored and on hand. Supplied with two keys. Some simple assembly required.
3. SPECIFICATION
Model No..................................................................... AP875
Overall Size (W x D x H) .......................875 x 755 x 1350mm
Drawer (W x D x H) ................................. 585 x 685 x 115mm
Pigeon Hole (x3) (W x D x H) ....................315 x 215 x 80mm
Shelf (W x D).....................................................870 x 380mm
4. OPERATION
PARTS LIST DESCRIPTION Qty.
A Desk Hood 1
B Desk Top 1
B1 Drawer 1
B2 Desk Top Assembly 1
C Leg 4
D Lower Shelf 1
E Shelf Supports 2
F Adjustable Feet 4
✳Nuts/Bolts 30
▲Drawer Lock 1
AP875 | Issue 1 30/01/17
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear protective
gloves
Wear safety
footwear
g.1

4.1. Take all the components out of the carton and compare to the
parts list.
4.2. Pull out the drawer until the plastic latches are exposed.
4.3. Press the plastic latches of both sides at the same time g.2,
pull out the drawer.
4.4. Screw in the four adjustable feet(F) to the legs(C) g.3.
4.5. Attach legs to main draw body g.4. Fix in position using screws
provided
4.6. Attach lower shelf(D) and shelf supports(E) as shown g.5
using screws provided.
4.7. Position and attach desk top(B) g.5 using screws provided.
4.8. Position and attach desk hood(A) g.5 using screws provided.
4.9. Push Draw(B1) back into Desk top assembly(B2) g.6. Press the plastic latches as per instruction 4.3 to complete assembly
4.10. Adjust feet to level workstation.
g.2
g.3
g.4
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
Environmental Protection
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
When the product becomes completely unserviceable and requires disposal, drain off any fluids (if applicable)
into approved containers and dispose of the product and the fluids according to local regulations.
Parts support is available for this product. To obtain a parts listing and/or diagram,
please log on to www.sealey.co.uk, email [e-mail] or telephone [phone].
g.5 g.6
