Sealey AP1372B User manual

INSTRUCTIONS FOR
WORKSTATION WITH 3 DRAWERS & CUPBOARD
MODEL NO: AP1372B
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this bench.
9Locate bench in a suitable working area.
9Keep the work area clean, uncluttered and ensure there is adequate lighting.
WARNING! Use bench on level and solid ground, preferably concrete. Avoid tarmacadam since the bench may sink into the surface.
9Keep the bench clean and tidy in accordance with good workshop practice.
9Keep children and unauthorised persons away from the working area.
8DO NOT use the bench for any purpose other than that for which it is designed.
8DO NOT exceed maximum capacity of workbench.
8DO NOT undertake work on the bench without the work piece being adequately secured. Use clamps or a vice (not included) to secure the
work piece. Available from your Sealey dealer.
8DO NOT use the bench out of doors.
8DO NOT get the bench wet or use in damp or wet locations or areas where there is condensation.
8DO NOT clean the bench with any solvents which may damage the paint surface or the protective coating on the wooden top.
2. iINTRODUCTION
Heavy duty powder coated metal frame with a 40mm MDF work surface. Two congurations available with a combination of lockable drawers
and cupboards. Features adjustable feet to help stability when placing on an uneven surface. Supplied at packed with two keys.
3. SPECIFICATION
Model no: ................................................................ AP1372B
Size (W x D x H):...................................1200 x 600 x 865mm
Drawer (x3): ............................................415 x 160 x 415mm
Capacity:...................................................................... 300kg
4. CONTENTS
4.1. Panels etc.
AP1372B | Issue 1 07/04/16
Original Language Version
© Jack Sealey Limited
Refer to
Instructions
Part Description Quantity
A Top 1
B1 Left side 1
B2 Right side 1
C Bottom 1
D Support 1
E Drawer 3
F1 Door 1
G Shelf 1
H Back 2
I Leg leveller assy. 4
J1 Left slide 3
J2 Right slide 3

4.2. Hardware contents
4.3. Before assembly check contents against the contents lists.
5. ASSEMBLY
Part Description Quantity
a Bolts ST4. 8x10mm 10+2
b Plastic rivet 16+4
c Plastic pin 4
Step 1 Step 2
Step 3
Step 4
AP1372B | Issue 1 07/04/16
Original Language Version
© Jack Sealey Limited

Step 5 Step 6
Step 7
AP1372B | Issue 1 07/04/16
Original Language Version
© Jack Sealey Limited

NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
Sole UK Distributor, Sealey Group.
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk.
IP32 7AR
www.sealey.co.uk
[e-mail]
01284 757500
01284 703534
Web
AP1372B | Issue 1 07/04/16
Original Language Version
© Jack Sealey Limited
Environmental Protection
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
When the product becomes completely unserviceable and requires disposal, drain off any fluids (if applicable)
into approved containers and dispose of the product and the fluids according to local regulations.
