INSTRUCTIONS FOR
INDUSTRIAL WORKSTATION 4 DRAWERS
MODEL NO: AP990
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using workbenches
and associated workbench drawers.
WARNING! Use the workbench on level and solid ground, preferably concrete. Avoid tarmacadam since the workbench may sink into
the surface.
9Locate the workstation in a suitable working area.
9Keep the work area clean, uncluttered and ensure there is adequate lighting.
9Keep the workstation clean and tidy in accordance with good workshop practice.
9Keep children and unauthorised persons away from the working area.
9Take care when assembling of sharp edges
8DO NOT remove a fully loaded drawer.
8DO NOT use the workstation drawer for any purpose other than that for which it is designed.
8DO NOT use the workstation out of doors.
8DO NOT get the workstation drawers wet or use in damp or wet locations or areas where there is condensation.
8DO NOT clean the workstation drawers with any solvents which may damage the painted surfaces.
Note: The assembly of this product to the will require assistance.
2. INTRODUCTION
Industrial four drawer workstation, ideal for site workers or line managers and supervisors. Lockable ball bearing slide drawers allow for
paperwork, books, stationary, valuables or even tools to be stored safely and securely. Large at work surface provides plenty of room to
carry out day to day tasks. Four large and four small pigeon holes can be used for paperwork, stationary or as in and out trays, keeping the
essentials on hand and in order. Lower shelf allows for items such as workwear to be stored and on hand. Supplied with two keys. Some
assembly required.
3. SPECIFICATION
Model No..................................................................... AP990
Overall Size (W x D x H) .......................990 x 735 x 1430mm
Large Drawer (x1) ...................................485 x 500 x 140mm
Large Drawer (x1) ...................................330 x 500 x 140mm
X-Large Drawer (x2)................................330 x 500 x 310mm
Pigeon Hole Small(x3) ................................70 x 220 x 90mm
Pigeon Hole Large(x3) ..............................300 x 220 x 90mm
Shelf (W x D).....................................................585 x 380mm
4. ASSEMBLY
AP990 | Issue 2 23/03/17
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear protective
gloves
Wear safety
footwear
g.1

PARTS LIST DESCRIPTION Qty.
A Drawer Cabinet (with
3 Drawers)
Drawers 2
Drawer 1
Pedestal 1
B Desk Top (with
one drawer)
B1 Desk Top Plate 1
B2 Drawer 1
B3 Support 2
C Panel Leg Support 1
D Desk Hood 1
E Lower Self 1
F Drawer Lock 4
G Handles 4
H Hanging folder
brackets
4
✳Nuts/Bolts 22
4.1. Take all the components out of the carton and compare to the
parts list.
4.2. Pull out the drawers until the plastic latches are exposed.
4.3. Press the plastic latches of both sides at the same time g.2,
pull out the drawer.
4.4. Place part A, part B3 (Keep the folded edge inward) and part C
as shown in g.3. Then x with bolts provided.
4.5. Place part E, part B1 and part D as shown in g.4. Align bolt holes and x with bolts provided.
AP990 | Issue 2 23/03/17
Original Language Version
© Jack Sealey Limited
g.3
g.2
g.4

NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
Environmental Protection
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
When the product becomes completely unserviceable and requires disposal, drain off any fluids (if applicable)
into approved containers and dispose of the product and the fluids according to local regulations.
Parts support is available for this product. To obtain a parts listing and/or diagram,
please log on to www.sealey.co.uk, email [e-mail] or telephone [phone].
g.5
g.6
4.6. Attach hanging bracket(H) as shown in g.5 to the
two larger draws.
4.7. Replace all four draws g.6. Press the plastic latches of both
sides at the same time g.3, and push in the drawer.
