Sealey Auto Service Series User manual

 WARNING! Ensure Health and Safety, local authority and general workshop practice regulations are
adhered to when using tools.
DO NOT use tools if damaged.
 Maintain tools in good and clean condition for best and safest performance.
 Ensure that a vehicle which has been jacked up is adequately supported with axle stands.
 Wear approved eye protection. A full range of personal safety equipment is available from your
Sealey dealer.
 Wear suitable clothing to avoid snagging.
DO NOT wear jewellery and tie back long hair.
 Account for all tools and parts being used and do not leave any in or near the engine.
1. SAFETY INSTRUCTIONS
2. INTRODUCTION & SPECIFICATION
INSTRUCTIONS FOR:
BRAKE CALLIPER THREAD
REPAIR KIT
MODEL No: VS0462
2.1. Introduction. Time and money
saving kit for replacing damaged
brake calliper threads with a new
threaded insert. Features three
alignment plates for correct
alignment of the insert. Kit includes
7mm hex key, stepped drill, M9 tap
and ten inserts in storage case.
2.2. Specification.
Calliper Insert Thread Size:
M9x1.25mm
Replacement Inserts:
VS0462R (Pack of 10)
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS, AND
CAUTIONS. USE THIS PRODUCT CORRECTLY, AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO
MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY.
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions
and properly maintained, give you years of trouble free performance.
Ref. Description Part No.
1Alignment Plate - VAG (Volkwagon Audi Group) VS0462.01
2 Alignment Plate - Vauxhall / Opel VS0462.02
3 Alignment Plate - Ford VS0462.03
4 Drill Bit VS0462.07
5 7mm Hex Key VS0462.04
6 Tap M9 x 1.25mm VS0462.06
7 Threaded Inserts (Replacemnt Inserts - pack of 10) VS0462R
Original Language Version VS0462 Issue: 1 - 14/06/11

3. INSTRUCTIONS
3.1. Remove the road wheel, brake disc and brake calliper from the car. Next remove the calliper mounting
bracket, in some vehicles the calliper mounting bracket is a cast part of the hub.
3.2. Clean up the calliper mounting bracket and insert it in a vice.
3.3 One Thread Stripped.
3.3.1 Clean the thread that is still intact using the M9 tap. Grease the tap for lubrication.
3.3.2 Re-fit a pin into the good thread then slide the correct alignment plate for your vehicle over the pin.
3.3.3 Use the other hole on the alignment plate as a guide, drill out the damaged thread using the stepped
drill bit. Continue drilling all the way through, using the larger diameter on the drill bit to enlarge the pin
hole so a threaded insert can be used.
3.3.4 Take a threaded insert with copper washer and insert into drilled out hole. Ensure it is pushed in the
opposite end that the pin is inserted.
Note: Use some thread lock on the threaded insert.
3.3.5 Re-insert the calliper pins and tighten using the Hex key, this will seat the insert fully home.
3.3.6 Remove the pins and reassemble the brakes, refer to a proprietary manual for correct procedure.
3.4 Both Threads Stripped.
3.4.1 When both threads are damaged use the stepped drill bit to centre on the first hole.
3.4.2 Follow from 3.3.4 inserting a threaded insert.
3.4.3 Then follow from section 3.3.2 for the second hole.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
01284 757500
01284 703534
[e-mail]
Sole UK Distributor, Sealey Group,
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk,
IP32 7AR
www.sealey.co.uk
Web
email
Original Language Version VS0462 Issue: 1 - 14/06/11
