Sealey CP2812V User manual

CORDLESS MINI SANDER/POLISHER KIT 12V
LITHIUM-ION
MODEL NO: CP2812V
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. ELECTRICAL SAFETY
WARNING! It is the user’s responsibility to check the following:
Check all electrical equipment and appliances to ensure that they are safe before using. Inspect power supply leads, plugs and
all electrical connections for wear and damage. Sealey recommend that an RCD (Residual Current Device) is used with all electrical
products. You may obtain an RCD by contacting your local Sealey stockist.
If the polisher is used in the course of business duties, it must be maintained in a safe condition and routinely PAT (Portable
Appliance Test) tested.
Electrical safety information. It is important that the following information is read and understood.
1.1.1. Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
1.1.2. Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that they are secure.
1.1.3. Important:Ensurethatthevoltageratingontheappliancesuitsthepowersupplytobeusedandthattheplugisttedwiththe 
correct fuse - see fuse rating in these instructions.
8DO NOT pull or carry the appliance by the power cable.
8DO NOTpulltheplugfromthesocketbythecable.Removetheplugfromthesocketbymaintainingarmgripontheplug.
8DO NOT use worn or damaged cables, plugs or connectors. Ensure that any faulty item is repaired or replaced immediately by a
 qualiedelectrician.
1.1.4. ThisproductisttedwithaBS1363/A13Amp3pinplug.
1.1.5. If the cable or plug is damaged during use, switch the electricity supply and remove from use.
1.1.6. ReplaceadamagedplugwithaBS1363/A13Amp3pinplug.Ifindoubtcontactaqualiedelectrician.
1.1.7. Class II products are wired with live (brown) and neutral (blue) only are marked with the Class II symbol;
 A)ConnecttheBROWNlivewiretotheliveterminal‘L’.
 B)ConnecttheBLUEneutralwiretotheneutralterminal‘N’.
C) After wiring, check that there are no bare wires and ensure that all wires have been correctly connected.
Ensure that the cable outer sheath extends inside the cable restraint and that the restraint is tight.
8DO NOT connect either wire to the earth terminal.
 Sealeyrecommendthatrepairsarecarriedoutbyaqualiedelectrician.
1.2. BATTERY SAFETY
9Chargebatterypriortorstuse.Thebatterypackwillhavebeenshippedinalowchargestate.
9 Useonlythechargerprovidedtochargethepolisherbattery.
8DO NOT charge battery when room temperature is below 50°F (10°C) or above 104°F (40°C).
8DO NOT attempt recharging the battery by means of a generator or a DC power source.
8DO NOT short-circuit the battery by linking both terminals with conductive materials.
8DO NOT store the battery (or wrench) in locations where the temperature may exceed 104°F (40°C).
▲DANGER! DO NOT attempt to dismantle the battery pack. For safety and environmental reasons DO NOT discard in domestic
waste or by burning. ONLY discard or recycle according to local authority regulations.
WARNING! DO NOT allow a leaking battery to contact your person. If you come into contact with battery liquid take the following
immediate action:
 a)Skincontact:Washimmediatelywithsoapandwater,thenwasheshineitherlemonjuiceorvinegar.
 b)Eyecontact:Washwithastrongsolutionofboricacid,andseekimmediatemedicalattention.
1.3. BATTERY CHARGER SAFETY INSTRUCTIONS
WARNING: DO NOT use the charger to charge any battery other than that supplied for the polisher. Other types of batteries may
explode.
1.3.1. All mains electrical supply safety features must be followed as described in 1.1. above.
1.3.2. Disconnect the charger from the mains power supply when not in use.
Important: Check that the voltage marked on the charger is the same as the power supply to be used.
8DO NOT pull or carry the charger by the power lead, or pull the plug from the mains socket by the power lead.
8DO NOT use any other type of charger.
8DO NOT try to open or dismantle the charger.
8DO NOT get the charger wet, or use in wet, damp conditions (for indoor use only).
8DO NOT operate the charger if it or the battery is damaged.
Refer to
Instruction
Manual
Wear
Eye
Protection
Wear
Ear
Protection
Wear
Protective
Gloves
Charger:
Indoor
UseOnly
Weara
mask
Recommended fuse rating
3 Amp
CP2812V|Issue:4(3)12/09/18
Original Language Version
© Jack Sealey Limited

8DO NOTinsertforeignobjectsormaterialintotheholereservedforthebattery.
8DO NOTforcethebatteryintothecharger.Thebatterywillonlytonewaytoensurecorrectpolarityalignment.
8DO NOT charge a second battery immediately. Consecutive charging will overheat the charger. Allow the unit to cool for 15 minutes
before charging the next battery.
9Store the charger in the same manner as the battery, see section 1.2.
1.4. GENERAL SAFETY.
9Maintain the polisher and battery in good condition. Check moving parts alignment on a regular basis.
9 Replaceorrepairdamagedparts.Useanauthorisedserviceagentandrecommendedpartsonly.Unauthorisedpartsmaybe 
dangerous and will invalidate the warranty.
9Ensure the polisher is switched off before installing the battery pack.
9Keep the polisher and charger clean for best and safest performance.
9 Removeillttingclothing.Removeties,watches,ringsandotherloosejewelleryandcontainlonghair. 
9Ensure battery pack is correctly inserted into the polisher handle and latched in place before attempting to switch on polisher.
9Secure loose work pieces with a clamp, vice or other adequate holding device.
9Avoid unintentional starting.
9 Wearapprovedsafetyeyeprotection(standardspectaclesarenotadequate).
9 Maintaincorrectbalanceandfooting.Ensuretheoorisnotslipperyandwearnon-slipshoes.
9Keep children and unauthorised persons away from the working area.
8DO NOTusethepolisherwherethereareammableliquids,solidsorgases,suchaspaintsolvents,etc.
8DO NOT allow children to operate the polisher.
8DO NOToperatethepolisherifanypartsaremissingasthismaycausefailureand/orpersonalinjury.
8DO NOT hold unsecured work piece in your hand.
8DO NOT leave the polisher operating unattended.
8DO NOTcarrythepolisherwithyourngeronthepowerswitch.
8DO NOT use the polisher for a task it is not designed to perform.
8DO NOToperatethepolisherwhenyouaretiredorundertheinuenceofalcohol,drugsorintoxicatingmedication.
8DO NOT get the polisher or battery charger wet or use in damp or wet locations.
2. INTRODUCTION
Features variable speed control giving a range suitable for sanding and polishing up to 3000rpm. Soft grip handle for comfort and control.
Lockingswiveladjustmentfrompistoltostraighttype.Includesbatteryconditionindicator.Suppliedincanvasbagwith12VLithium-ionbattery
pack, battery charger and a range of polishing and sanding heads.
3. SPECIFICATION
Model no: ................................................................CP2812V
Battery: ........................................................12V 1.5Ah Li-ion
No load speed:......................................................... 3000rpm
Pad size: ................................................................... Ø75mm
Thread size: ............................................................. 1/4”UNC
Replacement battery pack:................................. CP2812VBP
4. CONTENTS
13”sandingpad
2 battery indicator
3 side handle
4 variable speed switch
5 anti slip soft grip
6batterypackrelease
button
7 battery pack
8 handle rotation button
9wavesponge
10 charger
11 spindle lock
12 cone sponge
13atsponge
14 sanding disc
15 lambswool pad
Fig.1
Noise power: ..................................................................81dB
Noise pressure:..............................................................70dB
Vibration(m/s²): .............................................................. 1.43
Uncertainty (K): ................................................................. 1.5
CP2812V|Issue:4(3)12/09/18
Original Language Version
© Jack Sealey Limited

Fig.2 Fig.3
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
arecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproductbecomescompletely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
WEEE REGULATIONS
DisposeofthisproductattheendofitsworkinglifeincompliancewiththeEUDirectiveonWasteElectricalandElectronicEquipment
(WEEE).Whentheproductisnolongerrequired,itmustbedisposedofinanenvironmentallyprotectiveway.Contactyourlocalsolid
waste authority for recycling information.
BATTERY REMOVAL
UndertheWasteBatteriesandAccumulatorsRegulations2009,JackSealeyLtdarerequiredtoinformpotentialpurchasersofproducts
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
SealeyLtd’sBatteriesProducerRegistrationNumber(BPRN)isBPRN00705.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
5. OPERATION
5.1. Variablespeedswitch:adjustspeedbyholdingdownthevariablespeedswitchg.1.4.
5.2. Rotationofthehandle:pressthebuttong.1.8whilstturningtothepreferredorientation.
5.3. Installing the sanding pad: press the spindle lock button and wind the sanding pad on
 (clockwise)thentightenit,g.2.
5.4. Fitsidehandle:screwintobodyinaclockwisedirection,canbettedtoeitherside,g.3.
5.5. Approximate run time remaining.
5.6. Installing/removingbatterypack:removebydepressingbatterypackreleasebutton,g.1.6andpullthebatterypackout.
 Installbypushingthebatterypack,g.1.7backontothetooluntilitlocksintoplace.
5.7. Batterychargeroperation:
Power on - green light
Charging - red light
Charged - green light
5.8. Accessories: only use Sealey recommended accessories and consumables.:
6. MAINTENANCE
WARNING! unplug charger from the mains supply before cleaning it.
6.1. Regularly clean the charger using a soft brush or a dry cloth. DO NOT use any abrasive or solvent based cleaners.
6.2. Store in a dry, clean childproof place.
CP2812V|Issue:4(3)12/09/18
Original Language Version
© Jack Sealey Limited

WARNING! – Risk of Hand Arm Vibration Injury.
This tool may cause Hand Arm Vibration Syndrome if its use is not managed adequately.
ThistoolissubjecttothevibrationtestingsectionoftheMachineryDirective2006/42/EC.
This tool is to be operated in accordance with these instructions.
Measured vibration emission value (a): 1.43 m/s²
Uncertainty value (k): 1.5 m/s²
Please note that the application of the tool to a sole specialist task may produce a different average vibration emission. We recommend that a
specific evaluation of the vibration emission is conducted prior to commencing with a specialist task.
A health and safety assessment by the user (or employer) will need to be carried out to determine the suitable duration of use for each tool.
NB: Stated Vibration Emission values are type-test values and are intended to be typical.
Whilst in use, the actual value will vary considerably from and depend on many factors.
Such factors include; the operator, the task and the inserted tool or consumable.
NB: ensure that the length of leader hoses is sufficient to allow unrestricted use, as this also helps to reduce vibration.
The state of maintenance of the tool itself is also an important factor, a poorly maintained tool will also increase the risk of Hand Arm Vibration
Syndrome.
Health surveillance.
Werecommendaprogrammeofhealthsurveillancetodetectearlysymptomsofvibrationinjurysothatmanagementprocedurescanbemodified
accordingly.
Personal protective equipment.
Wearenotawareofanypersonalprotectiveequipment(PPE)thatprovidesprotectionagainstvibrationinjurythatmayresultfromthe
uncontrolleduseofthistool.Werecommendasufficientsupplyofclothing(includinggloves)toenabletheoperatortoremainwarmanddryand
maintaingoodbloodcirculationinfingersetc.Pleasenotethatthemosteffectiveprotectionisprevention,pleaserefertotheCorrectUseand
Maintenance section in these instructions. Guidance relating to the management of hand arm vibration can be found on the HSC website
www.hse.gov.uk-Hand-ArmVibrationatWork.
