Sealey AK1998.V3 User manual

80-1000V NON-CONTACT VOLTAGE DETECTOR
MODEL NO:AK1998.V3
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURYAND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instruction
manual
Wear protective
clothing
AK1998.V3 Issue:5 24/05/23
Original Language Version
© Jack Sealey Limited
Wear protective
gloves
1. SAFETY
WARNING! Ensure Health and Safety, local authority and general workshop practice regulations are adhered to when using tools.
NOTE: FOR USE BY COMPETENT PERSONSAnyone using this instrument should be knowledgeable and trained about the risks involved
with measuring voltage, especially in an industrial setting, and the importance of taking safety precautions and of testing the instrument before
and after using it to ensure that it is in good working condition.
9Read and understand all of the instructions and safety information in this manual before operating or servicing this tool.
8DO NOT use the unit if it is wet or damaged.
8DO NOT operate with the case open.
9Only use the tester as specified, or the protection supplied by the voltage detector can be compromised.
8DO NOT rely on the voltage detector to detect the presence or absence of voltage on a conductor for safety purposes. A single pole non-
contact voltage detector such as this product is not suitable to determine if a circuit is hazardous. A volt meter or 2-pole voltage detector
is necessary to confirm the absence of hazardous voltage prior to commencing work.
8DO NOT use if the light/buzzer fails to operate.
8DO NOT expose the unit to extremes in temperature or high humidity. Refer to ‘Specifications’ as failure to observe these precautions
may result in severe injury and can damage the tester.
9Test on a known voltage first to make sure that the voltage tester operates correctly. This should be done both before and after each
repair.
NOTE: When using the voltage detector if tip does not glow, voltage could still be present. The detector indicates active voltage in the presence
of electric fields of sufficient strength generated from the source mains voltage. If the field strength is low, the detector may not provide indication
of live voltages. Lack of an indication occurs if the detector is unable to sense the presence of voltage, which may be influenced by
several factors such as shielded wire and cables, thickness and type of insulation, distance from the voltage source, condition of the detector
and batteries.
9Hold the tester behind the tactile barrier.
9Always have detected faults to be rectified by a qualified electrician.
CAUTION with voltages above 30V AC as a shock hazard may exist.
WARNING! The AK1998.V3 will not detect voltages in cables connected to a centre tapped earth supply e.g. 110V transformer
or generator.
2. INTRODUCTION
Non-contact voltage detector with LED/audible indication. Designed for quickly identifying wire and cable breaks as well as detecting voltage in fuses,
cables, switches, outlets, lighting fixtures and many more. Features two selectable sensitive settings low gear (L) and high gear (H) detecting voltage
ranges from 80V – 1000V. Requires 2 xAAAbatteries (not included).
3. SPECIFICATION
Model No:......................................................AK1998.V3
Altitude:.......................................................up to 2000m
Dimensions:.........................................26 x 22 x 160mm
Display:.............................................................Red LED
Frequency:.........................................................50-60Hz
Overvoltage Category:..........................................CATIII
Operating Temperature: .........0°C to +40°C at RH <80%
Voltage Range: ................................................80-1000V
Indoor use only

Original Language Version
© Jack Sealey Limited
4. BATTERY REPLACEMENT
 Batteryremovalseeg.1.
NOTE: The direction of how the batteries are to be installed is embossed on the side of the voltage detector.
5. OPERATION
5.1. With the batteries installed (see section 4), turn the unit on by rotating the switch to choose high or low voltage sensitivity.
The green LED will flash once and the audible output will beep once when “High V” or “Low V” is selected. This indicates the batteries are
functioning correctly.
5.2. Bring the probe (fig.2) in close proximity to the conductor, the red LED and audio output will indicate the presence of an AC supply voltage
within the range stated in the specifications. To determine magnitude and or frequency an appropriate metering device is required.
5.3. Insulated cores may be checked for continuity breaks (fig.3).
NOTE: Each core must be individually connected to a detectable voltage.
5.4. Electrical sockets (80V - 220V) can be checked by placing the probe tip into socket terminal aperture.
5.5. NOTE: Wait until the LED and the audible output finishes before proceeding with the next operation. Using this device near equipment
that generates electromagnetic interference may result in inaccurate indications.
6. MAINTENANCE
6.1. Periodically wipe the casing with a damp cloth DO NOT use abrasives or solvents.
fig.2 fig.3
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 [e-mail] www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste.All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
REGISTER YOUR
PURCHASE HERE
fig.1
AK1998.V3 Issue:5 24/05/23
