Secabo TC5 Smart User manual




OPERATINGINSTRUCTIONS

forthequickchangesystemfor

SecaboTC5,TC7,TPD7andTS7
















CongratulationsonpurchasingaSecaboproduct!
Pleasereadtheseoperatinginstructionscarefullybeforeusingtheproduct.
Anyreproductionoftheseoperatinginstructionsinanyformrequiresthewrittenapprovalof
SecaboGmbH.Wereservetherighttoamendtechnicaldataandproductcharacteristicswithout
priornotice.
SecaboGmbHassumesnoliabilityfordirectorindirectdamageorinjuryresultingfromtheuseof
thisproduct.

Version1.1(11.05.2015)


SecaboGmbH|Hochstatt68|85283Wolnzach|Germany|[email protected]|www.secabo.com

1

Safetyprecautions

Pleasereadtheseinstructionsandsafetyprecautionscarefullybeforeusingyourpressforthefirst
time!

● Neverreachintotheheatpresswithyourhandswhenitisconnectedtothepowersupply,
particularlywhenitisswitchedonandheatedup–dangerofsevereburns!
● Neveropenthehousingorattempttomodifythemachineyourself.
● Ensurethatliquidsandmetalobjectsdonotgetintotheinsideoftheheatpress.
● Disconnectmachinefrompoweroutletwhennotinuse!
● Neveroperatetheheatpresswithinthereachofchildrenandneverleavethemachine
unsupervisedwhenswitchedon.
● Ensurethatthemachineisusedonlyindryrooms.

 
SecaboGmbH|Hochstatt68|85283Wolnzach|Germany|[email protected]|www.secabo.com

2

Scopeofdelivery

Beforestartingwork,pleasecheckwhetherthefollowingitemsareallpresent:

Item
Quantity
Quickchangesystembase
1
Mountingpanel(onlyTC5andTC7)
1
Adapterplate(onlyTPD7)
1
Screwsforquickchangesystem
M8x123pieces(onlyTC5andTC7)
M8x202pieces(onlyTPD7)
M8x204Stück(onlyTS7)
M8washer4pieces(onlyTS7)
M8nut4pieces(onlyTS7)
BeamAdapter
1
ScrewsforBeamAdapter
M6x124pieces(TC5)
M8x164pieces(TC7,TPD7,TS7)



 
SecaboGmbH|Hochstatt68|85283Wolnzach|Germany|[email protected]|www.secabo.com

3

Mountingsteps
AssemblyTC5andTC7
● ReleasethebaseplatefromtheTC5orTC7bylooseningtheblackhandscrewsbelowthe
frameoftheheatpress.Theoriginalbaseplatecannowbetakenoffbyliftingupwards.
● Putthelowermountingpanelwiththecorrespondingscrewsbelowtheframeuntilthe
screwspointupwardsthroughtheholes.





● Placethequickchangesystembaseontheframeoftheheatpressallblackhandscrews
arepointingforwardsandthehooksfortakinguptheexchangeablebaseplatesare
pointingupwards.

SecaboGmbH|Hochstatt68|85283Wolnzach|Germany|[email protected]|www.secabo.com

4


● Nowtightenthethreescrewsfrombelow.Watchoutforthecorrectalignmentofthe
quickchangesystem.
● Thequickchangesystemisnowreadyfuruse.

AssemblyTPD7
● TipthemachinebackgentlyandreleasethebaseplatefromtheTPD7bylooseningthe4
screwsfromthebottomplate.Pleaseensurethatthepressissecuredintiltedposition.The
originalbaseplatecannowbetakenoffbyliftingupwards.
● Placetheadapterplateontothecorrespondingpositionandinsertthesuitablescrews
throughtheholes.


● Placethequickchangesystembaseontheframeoftheheatpressallblackhandscrews
arepointingforwardsandthehooksfortakinguptheexchangeablebaseplatesare
pointingupwards.

SecaboGmbH|Hochstatt68|85283Wolnzach|Germany|[email protected]|www.secabo.com

5



● IncaseyouhavetwoquickchangesystemsforyourTPD7,repeattheassemblyinthe
samewayontheotherside.
● PlacetheTPD7heatpressbackonthefourrubberfeetnowthepressisreadyforthe
nexttransfers.

AssemblyTS7
● ReleasethebaseplatefromtheTS7bylooseningtheblackhandscrewsbelowthebase
plateoftheheatpress.Theoriginalbaseplatecannowbetakenoffbyliftingupwards.





● Loosenthethreadedboltsattheadjustmentringbelowthebaseplate.

SecaboGmbH|Hochstatt68|85283Wolnzach|Germany|[email protected]|www.secabo.com

6




● Placethequickchangesystembaseatthecorrespondingpositionandstickthe
appropriatescrewsfromupwardsthroughtheholes.Tightenthescrewsandwashers.






AssemblyoftheBeamAdapter
● Loosenthescrewsonthetwoaluminiumblocksunderneaththebaseplate(onlyTC5).
● MountontheBeamAdapterbyusingtheincludedM6x12(TC5)orM8x16(TC7)screws.

SecaboGmbH|Hochstatt68|85283Wolnzach|Germany|[email protected]|www.secabo.com

7

 
 

UseoftheSecaboquickchangesystem

● InsertthebaseplatewiththeBeamAdapterontotherailinthemiddleofyour
quickchangesystem.
● Smallerexchangeablebaseplatescanalternativelybeinsertedonallthreerails.
● Platescanbeinsertedbyscrewingthefronthandwheeluntilthesmallrailontheupper
sidemovesbackwards.Nowplaceanexchangeablebaseplateinbetweenandtightenthe
screwuntiltheplateisstuck.
● Whenusingasinglesmallplatealwaysmountitontotherailinthemiddle,toassurethat
theheatingplateisloadedevenly.
SecaboGmbH|Hochstatt68|85283Wolnzach|Germany|[email protected]|www.secabo.com

8
