SECO-LARM Enforcer EVP-124M6-P16 User manual

®
Potentiometer
to Adjust DC
Voltage range
Main
Switches
AC Terminal
Block
VAC OUTPUT PCB
VDC OUTPUT PCB
Green
Power
LEDs
To BNC
(From DC
Camera)
(EVA-F5521-3)
(3-ft. wire length)
AC_DC_PowerSupply.pmd
* Maxtotalcontinuousoutputcurrent.(1.5Afor24VDC) Outputis1.1Ampmaxperoutputchannel.
EVP-124M6-P16
8 Outputs, 3 Amps @ 12VDC*, and
8 Outputs, 3 Amps @ 24VAC*.
*Max total continuous output current,
each channel output is fused at 1.1 Amp.
CONNECTIONS:
TheEVP-124M6-P16Dual-OutputPowerSupply
providesboth12VDC and 24VACoutputsin
oneunitwhere a combinationofboth AC &DCoutputs
areneeded.Itwillsimultaneously provide 3 Ampsto
eight12VDCoutputsand3Ampstoeight24VACoutputs.
24VAC
Number of Outputs
Total Output Current
Main Fuse Rating
Output Fuse Rating
12 VDC
88
3 Amps* 3 Amps*
5.0 Amps @ 250VAC
1.1 Amps @ 250VAC
FEATURES:
DCOutputvoltageadjustablewithpotentiometerto
compensateforvoltagedrop(12.0~15.1VDC).
Eachoutputindividuallyfused(PTC**-typefuses).
Outputfusesrated1.1Amps @ 250VAC.
Individualredstatusindicator LEDforeachoutput.
Mainpowerswitches toturnon/offpower to outputs.
POWER: 120VACor220VAC.60Hz.
UL-approvedpowertransformer.
Maxtotalcontinuousoutputcurrent:
3.0Amps@12VDC
3.0Amps@24VAC
Mainfuserated5.0Amps @ 250VAC.
Sparefuseincluded.
6-footpowercordincluded.
ENCLOSURE:
Heavy-duty steel casetoprotectthepower connections.
Removablesteelcover for easyaccess to powerconnections.
Ventilationholes topreventheatbuild-up.
Dimensions- 12"x 12" x3
1
/
2
".
Knock-outonthe cover foroptionalcam lock.
AC terminal block for easy connection from transformer
to6-foot power cord.
**PositiveTemperatureCoefficient
OUTSTANDING FEATURES:
AC/DC Power Supply for CCTV Cameras
EVA-F5521-3 -- Optionalpowercord. For easy
connectionofdome orbulletcamera to powersupply.
SECO-LARM®U.S.A., Inc., 16842Millikan Avenue, Irvine,CA 92606 Tel: [phone](Domestic U.S. & Canada)
Tel: [phone] (California& International) Fax: [phone] Email: [email protected] Website: www.seco-larm.com
SPECIFICATIONS:
ENFORCER
TheSECO-LARM policy is one of continual development. For that reason, SECO-LARM reserves the right to change prices and specificationswithoutnotice. SECO-LARM is not responsible for misprints.
ENFORCER
AC Camera
DC
Camera
