SECO-LARM SLI ENFORCER SK-2612-SFSQ User manual

®
SK-2612-SFSQ
Fingerprint Reader and Keypad
Manual
Features:
•
500DPI Optical fingerprint reader
•Up to 3,000 users (up to ,000 fingerprint
users, up to 2,000 PIN users)
•User code length 4~6 digits
•Fingerprint identification time – ≤ second
•Fingerprint false acceptance rate – ≤ 0.0 %
•Fingerprint false rejection rate – ≤ 0. %
•2VDC Operation
•
Form C relay output – 2A@ 2VDC
•Tamper alarm output – 2.5A@ 2VDC
•Adjustable relay output time – 00ms~99s,
or toggle
•Weatherproof – IP66
•Illuminated fingerprint reader window
•Wiegand output
•2-Door interlock

ENFORCER Fingerprint Reader and Keypad
2SECO-LARM U.S.A., Inc.
This page is for installers looking to do a basic installation and programming of the fingerprint
reader and keypad. For more in-depth installation and programming instructions, see "Table of
Contents" on pg. 4.
Quick Wiring Diagram:
Mounting Diagram:
NOTE: For DC-powered electric strikes, connect the included diode as clo
se as possible and in parallel
with the electric strike. This absorbs possible electromagnetic interference to prevent operation
of the strike from damaging the fingerprint reader/keypad. Do not connect a diode when using
electromagnetic locks or with AC powered strikes.
Quick nstallation Guide:
Orange
–
Output (N.C.)
Blue
–
Output (N.O.)
Yellow
–
Egress Input
(N.O.)
Black
–
Ground (
–
)
Gray
–
Tamper Alarm Output (GND)
Purple
–
Output (COM)
Red
–
2VDC (+)
2VDC
Power
Supply
(+)
Egress
Button
(
–
)
(+)
(
–
)
Or
Cathode
Electric
Lock
IN4007
Output Relay
N.O. Output for Fail-secure Lock
N.C. Output for Fail-safe Lock
(+)
Alarm
(
–
)
Diode IN4007
(See note below)
Door Sensor
Brown
–
Door Sensor Input
Green
–
Data 0
White
–
Data
Wiegand
Controller
Mounting screws
Housing base
Security screw
Drill 2 mounting holes
3 /
4
" (83mm) apart
Drill at least ø
3
/
8
"
(ø9mm) wiring hole

ENFORCER Fingerprint Reader and Keypad
SECO-LARM U.S.A., Inc. 3
Quick Programming Guide:
Programming Tips:
•Master programming code (6 digits) should be programmed before any other programming.
•A steady red LED indicates that fingerprint reader/keypad is in standby mode. A flashing red
LED indicates that fingerprint reader/keypad is in base programming mode. A steady orange
LED indicates the unit is in function programming mode.
Programming nstructions:
Follow the instructions below if the following covers your needs:
•A new master programming code.
•Setting one user fingerprint and one user code.
•A door-unlocked time of 3-seconds after the output is activated.
. Enter programming mode:

NOTE:  is the factory default master programming code. A new master
programming code (6 digits) should be set the first time you enter programming mode.
There is
no master programming fingerprint.
2. Set the master programming code (6 digits):

NOTE:

is the new master programming code and must be entered twice.
3. Set a user fingerprint to operate the output (unlock the door):

NOTES:
• chooses fingerprint user ID #3 of 998 possible fingerprint users ( ~998).
(Omit  to use auto ID to assign the first available user ID.)
• is the new user fingerprint (must be presented twice to set).
4. Set a user code to operate the output (unlock the door):

NOTES:
•

chooses user code ID # 00 of 2998 possible user codes
( 00 ~2998).
•

is the new user code for user ID # 00 (4~6 digits).
5. Set the output time (skip this step if the default value of 5 seconds is acceptable):

NOTE:

sets the output delay time for 3 seconds.
6. Exit programming mode:


ENFORCER Fingerprint Reader and Keypad
4SECO-LARM U.S.A., Inc.
Operating voltage
2VDC
Current draw
Standby
45mA@ 2VDC
Active
200mA@ 2VDC (max.)
Outputs
Form C
2A@ 2VDC
Tamper alarm
2.
5A@ 2VDC
Egress input
N.O. Ground
Door sensor input
N.C
. Ground
Enclosure material
Zinc alloy
Operating temperature
-
22°~ 40° F (
-
30°~60° C)
Operating humidity
20~90%
Dimensions
2
/
4
"x5
3
/
8
"x " (58x 37x26 mm)
Weight
4.2
-
oz (400g)
Specific
ations:
Features:
Table of Contents:
Quick Installation Guide:
................................
..............
2
Mounting Diagram: ....................................................... 2
Quick Wiring Diagram: ................................................. 2
Quick Programming Guide: .......................................... 3
Table of Contents: ........................................................ 4
Features: ...................................................................... 4
Specifications: .............................................................. 4
Overview: ...................................................................... 5
Parts List: ...................................................................... 5
LED Indicators and Device Sounds: ............................ 5
Important Notes: ........................................................... 5
Installation: ................................................................... 6
Wiring Chart:................................................................. 6
Sample Application: ...................................................... 7
Getting Ready to Program:........................................ 7-9
Programming Master Add/Delete Fingerprints: ....... 9- 0
Programming Format and Default Values: ................. 0
Programming the Master Programming Code: .......... 0
Programming Super User Codes/Fingerprints: ..........
Programming User Fingerprints:
..........................
~ 3
Programming User Codes: ......................................... 4
Deleting User Fingerprints or User Codes: .......... 5~ 6
Programming Output Mode and Time: ................. 6~ 7
Programming Access Mode / Security Level: ...... 7~ 8
Programming Keypad Sounds/Notifications: ....... 8~ 9
Programming the External Alarm Output: .................. 9
Programming Door Propped-Open / Forced-Open
Detection: ............................................................. 20
Programming the Wrong-Code Lockout/Alarm: ......... 2
Wiegand Pass-Through Connection Diagram: .......... 22
Progamming Wiegand Pass-Through Operation: 22~24
Setting Up an Interlock System with
Two Keypads: ................................................. 24~25
Resetting the Fingerprint Reader/Keypad: ................. 25
Installer Notes:............................................................ 26
User Operation of the Fingerprint Reader/Keypad: ... 27
Troubleshooting: ......................................................... 28
Warranty: .................................................................... 28
• 2VDC Operation
• Up to ,000 fingerprint users ( ~ 000)
• Up to 2,000 user codes ( 00 ~3000)
• Output: Form C relay, 2A@ 2VDC max.
• Output can be programmed to activate for
up to 99 seconds or toggle
• Tamper alarm output: Transistor ground,
2.5A@ 2VDC max.
• Fingerprint reader window illuminates
when finger is present
• EEPROM Memory protects programmed
information in case of power loss
• All features programmed directly from the
fingerprint reader/keypad: No need for an
external programmer
• Egress input lets users exit the premises without
a fingerprint or keying in a code
• 500DPI Optical fingerprint reader
• Fingerprint identification time – ≤ second
• Fingerprint false acceptance rate – ≤0.0 %
• Fingerprint false rejection rate – ≤0. %
• Weatherproof – IP66
• Wiegand output
• 2-Door interlock

ENFORCER Fingerprint Reader and Keypad
SECO-LARM U.S.A., Inc. 5
Status Sounds LED
In standby mode -- Red steady
In base programming mode Beep Red flashing
In function programming mode Beep Orange steady
Exit programming mode Beep Red steady
Successful operation Beep Green steady
Unsuccessful operation 3 Fast beeps
Notification output Rapid beeping* Red flashing rapidly
LED ndicators and Device Sounds:
*De
-
activate the notification or alarm by presenting a valid user fingerprint or by entering a valid user code.
mportant Notes:
.
Always disconnect power before servicing the fingerprint read
er/keypad. Do not apply power
until all connection wiring is completed.
2. The fingerprint reader/keypad must be properly grounded. Use a minimum 22AWG wire
connected to the common ground wire. Failure to do so may damage the unit.
3. All wiring and programming should be done by a professional installer to reduce the risk of
improper installation.
4. The user's operating guide for this fingerprint reader/keypad is located on pg. 27 of this
manual. Be sure to store this manual in a safe place for future reference.
Parts List:
x Fingerprint reader and keypad x Security wrench x Diode
2x Mounting screws 2x Mounting screw anchors x Manual
Overview:
"
(26mm)
F US NG THE F NGERPR NT READER/KEYPAD W TH A
MECHAN CALLY OPERATED DOOR OR GATE, MOUNT THE UN T AT
LEAST 15' (5m) FROM THE DOOR OR GATE TO PREVENT USERS
FROM BE NG CRUSHED OR P NNED. FA LURE TO DO SO MAY
RESULT N SER OUS NJURY OR DEATH.
!
!
5
3
/
8
"
(
37m
m)
2
/
4
"
(
58m
m)
33
7
/
6
"
(
850m
m
)

ENFORCER Fingerprint Reader and Keypad
6SECO-LARM U.S.A., Inc.
.
Find a suitable location to mount the fingerprint
reader/keypad. Install it at a height at which most users
will be able to easily operate the unit.
2. Using the included security wrench, unscrew the
security screws located on the bottom of the fingerprint
reader/keypad (Fig. ).
3. Carefully remove the fingerprint reader/keypad from
the housing base, sliding the keypad slightly upwards.
4. Using the housing base as a template, mark the holes
needed for the wiring and mounting screws and drill
needed holes. Ensure that the wiring hole is large
enough to allow the wiring to be pushed in without
crimping.
5.
Run wiring through the wall to the wiring hole cut in the
wall
6. Thread the wiring through the center of the fingerprint
reader/keypad's base.
7. Install the base using the included mounting screws
and mounting screw anchors (if necessary). Ensure the
correct orientation as shown in Fig. 2.
8. Connect the wires to the fingerprint reader/keypad
according to "Wiring Chart" below.
9. Finish assembly by reattaching the fingerprint
reader/keypad to the base and securing with the
security screw.
Wiring Chart:
Connection Wires
Color Function Description
Red Power (+) Connect to + 2VDC power supply
Black Ground (-) Connect to Ground
Yellow Egress Input N.O. Pushbutton contact to ground. Press button to
activate the output
Brown Door Sensor Connect to a magnetic contact or door sensor
Blue Output N.O.
NO/NC/COM, relay output, max. 2A@ 2VDC Purple Output COM
Orange Output N.C.
Gray Alarm Output Transistor ground output, max. 2.5A@ 2VDC. Switches to
ground (-) when tamper switch activated.
Green Data 0 Wiegand controller
White Data Wiegand controller
nstallation:
Fig. 2
Fig.
Drill 2 mounting holes
3 /
4
" (83mm) apart
Drill at least ø
3
/
8
"
(ø9mm) wiring hole
NOTE: For weatherproof installation, add a
bead of silicone sealant around the
base where it meets the wall.

ENFORCER Fingerprint Reader and Keypad
SECO-LARM U.S.A., Inc. 7
NOTE: For DC-powered electric strikes, c
onnect the included diode as close as possible and in parallel
with the electric strike. This absorbs possible electromagnetic interference to prevent operation
of the strike from damaging the fingerprint reader/keypad. Do not connect a diode when using
electromagnetic locks or with AC powered strikes.
The fingerprint
reader/keypad can be set to be activated by users
using
either a keypad user code
or a fingerprint. All fingerprints and user codes must have a unique User ID (between and 3000).
User IDs may be specifically selected or, for fingerprints, may be either specifically selected or
automatically assigned. It is important to record all User IDs for future management tasks
Keypad code:
There are three types of keypad codes:
•Master programming code – Used only for entering programming mode. The initial master
programming code is disabled after setting the new master programming code. The master
programming code is 6 digits in length and there can be only one master programming code
per keypad.
•Super user code – 2 Super user codes (user IDs 2999 and 3000) can be assigned to toggle
between allowing and disallowing user access. When user access is disallowed, the doors will
remain locked and not respond to other users' fingerprints or user codes.
•User codes – Up to 998 user codes (user IDs 00 ~2998) can be assigned. User codes are
used to activate the relay.
Both types of user codes may be 4~6 digits in length, but the master code must be 6 digits.
Getting Ready to Program:
Sample Application:
Orange
–
Output (N.C.)
Blue
–
Output (N.O.)
Yellow
–
Egress Input (N.O.)
Black
–
Ground (
–
)
Gray
–
Tamper Alarm Output (GND)
Purple
–
Output (COM)
Red
–
2VDC (+)
2VDC
Power
Supply
(+)
Egress
Button
(
–
)
(+)
(
–
)
Or
Cathode
Electric
Lock
IN4007
Output
Relay
N.O. Output for Fail-secure Lock
N.C. Output for Fail-safe Lock
(+)
Alarm
(
–
)
Diode IN4007
(included)
Door Sensor
Brown
–
Door Sensor Input
Green
–
Data 0
White
–
Data
Wiegand
Controller

ENFORCER Fingerprint Reader and Keypad
8SECO-LARM U.S.A., Inc.
Getting Ready to Program (Continued):
Fingerprints:
There are three types of fingerprint entries:
•Master add/delete fingerprints – 2 Master fingerprints can be assigned as master fingerprints
which are only used for conveniently adding/deleting user fingerprints. The first master
fingerprint programmed is for adding user fingerprints and the second is for deleting user
fingerprints (see "Programming the Master Add/Delete Fingerprints," pgs. 9~ 0). Master
add/delete fingerprints are not used to enter programming mode.
•Super user fingerprints –
2 Super user fingerprints (user IDs 999 and 000) can be assigned to
toggle between allowing and disallowing user access. When user access is disallowed, the
doors will remain locked and not respond to other users' fingerprints or user codes.
•User fingerprints – Up to 998 fingerprints (user IDs ~998) can be assigned as user
fingerprints. User fingerprints are used to activate the relay.
Security Levels:
There are four possible security levels (see "Programming the Access Mode / Security Level,"
pgs. 7~ 8):
•User code only – A user must use a user code for access (see "Programming User Codes,"
pg. 4).
•Fingerprint only – A user must use a fingerprint for access (see "Programming User
Fingerprints," pgs. ~ 3).
•Either user code or fingerprint – A user may use either a user code or a fingerprint for access
(see pgs. ~ 4).
•Multiple user codes or fingerprints – Multiple (2~9) user codes/fingerprints are required for
access. Any combination of user codes or fingerprints in any order up to the set number must
be used with no more than 5 seconds between each code/fingerprint. No particular user
code/fingerprint can be repeated. This could be used for extremely secure areas requiring
authentication by more than one person or requiring one person to either use both a user code
and a fingerprint or multiple fingerprints/user codes (by assigning more than one user ID to that
person, see pgs. ~ 4).
NOTES for Multiple User Codes or Fingerprints:
•If the same user fingerprint/code is repeated, the device will return to standby without
triggering the output.
•In multiple user code/fingerprint mode, the interval between each user code/fingerprint
must not exceed 5 seconds, otherwise, the device will return to standby.

ENFORCER Fingerprint Reader and Keypad
SECO-LARM U.S.A., Inc. 9
Two
master
add/delete
fingerprints are used only
to
c
onveniently add or delete user fingerprints
.
The first master fingerprint added will be the master add fingerprint, used for adding a new
fingerprint user, and the second will be the master delete fingerprint, used for deleting a fingerprint
user. The master add/delete fingerprints are not used to enter programming mode and do not
serve as user fingerprints activating the output. To program the master add/delete fingerprints:
. Power the reader/keypad off.
2. While holding down the egress button, power the keypad on. When you hear two beeps,
release the egress button. The LED should change to orange. You must complete the process
within 30 seconds of this point.
3. Program the master add fingerprint by pressing a finger against the reader and repeat.
4. Program the master delete fingerprint by pressing a different finger against the reader and
repeat.
5. After 30 seconds, the keypad/reader will exit programming mode and the LED will return to
steady red, or you can press the  key to exit immediately.
Getting Ready to Program (Continued):
Programming Master Add/Delete Fingerprints:
Enter and
Exit
Base
Programming Mode:
All programming of the fingerprint reader/keypad is done from base programming mode.
. Enter base programming mode using the master programming code:

One beep will sound, the LED will flash red to indicate the unit is in base programming mode.
From there you may press a function code to enter function programming mode (the LED will
change to steady orange).
NOTE:  is the master programming code.  is the default
master programming code (see "Programming the Master Programming Code,"
pg. 0). The LED will flash red to indicate the keypad is in base programming mode.
2. Exit programming mode:
Press the  key or wait 25 seconds to exit automatically.
NOTES:
•DO NOT D SCONNECT THE F NGERPR NT READER/KEYPAD FROM POWER WH LE N
PROGRAMM NG MODE. Disconnecting the unit while in programming mode may cause a
memory error.
•The flashing red LED indicates that the unit is in base programming mode and will turn to
steady orange when you press one of the programming function codes. If you are unsure
which function you are in, press the  key to return to base programming mode (flashing red
LED) and then press the number of the function to proceed (steady orange LED).
•Except for adding or deleting users with the master add/delete
fingerprints, for all programming
functions, the fingerprint reader/keypad must first be in base programming mode.

ENFORCER Fingerprint Reader and Keypad
10 SECO-LARM U.S.A., Inc.
Programming the Master Add/Delete Fingerprints (Continued):
Programming the Master Programming Code:
In this manual, the format used for programming the keypad is as follows:
•A single-digit () FUNCTION CODE to tell the keypad what is being programmed.
•A varying number of digits () to represent the parameters of that FUNCTION.
•The  key to confirm programming of the FUNCTION and exit to base programming mode.
•The  key to exit programming mode and return to standby mode.
The following is a list of the different programming functions:
Function
Code* Parameters Default Functions and Values Page #
0
Master programing code
Default 23456, code length 6 digits
0
Add user codes/fingerprints
No
default, must be programmed
~ 4
2
Delete user codes/fingerprints
No default, must be programmed
5~ 6
3
Output mode/time
Momentary 5 seconds
6~ 7
4
Access mode / security level
Either user code or fingerprints
7~ 8
5
Wrong
-
code lockout / external
alarm
Lockout disabled, alarm enabled minute
9, 2
6
Keypad sounds / interlock system / door
propped-open/forced-open notification
Sounds enabled, interlock disabled, door
open notification disabled
8~20,
24~25
7
Set device ID for Wiegand controller
0
22~23
8
Set Wiegand output bits/format
Output bits 26, output bits 4
23~24
*Press the function code only to enter the programming mode for that function. It should not be
repeated between each parameter.
Programming Format and Default Values:
The
master programming code is used to enter programming mode. The master programming
code does not serve as a user code to activate the keypad output.
. Make sure the keypad is in base programming mode (see "Enter and Exit Base Programming
Mode , " pg. 9).
2. Enter the new master programming code (6 digits):

(where "X" is the new master programming
code)
3. Exit programming mode:
Press the  key or wait 25 seconds to exit automatically.
NOTE:
Programming the master add/delete fingerprints also resets the keypad to factory default.
Though all user information is retained, the master code will return to the default 23456,
and other settings will return to the default. Because of this, if you desire to use the master
add/delete fingerprints, it is best to program them before programming any other settings.

