SECO-LARM EV-2660-NKBAQ User manual

Manual
High Resolution Indoor
Dome Cameras
Features
EV-2660-NKBQ
EV-2660-NKBAQ
EV-2661-NKBQ
550 TV Lines



3-Axis Gimbal Bracket



2.8~10.5mm Varifocal Lens



Dual Voltage


True Day & Night


36 IR LEDs

EV-2660-NKBQ
EV-2660-NKBAQ
EV-2661-NKBQ
Note: Model numbers that end with “Q” or that have a round green “Q” sticker signify RoHS-compliant products.

SECO-LARM High Resolution Indoor Dome Cameras
2SECO-LARM U.S.A., Inc.
Specifications
EV-2660-NKBQ
EV-2660-NKBAQ
EV-2661-NKBQ
Type
Indoor Dome Camera
CCD
1/3” Sony Super HAD Color
Resolution
Color: 520 TV Lines
Color: 520 TV Lines
B/W: 550 TV Lines
Pickup elements
768x494 pixels
Video ouput format
NTSC
Video output
1.0Vp-p composite video, 75Ω
Lens
2.8~10.5mm, F1.2 Tarmon lens
Minimum illumination
Color: 0.3-lux
Color: 0.3-lux
B/W: 0.002-lux
S/N ratio
>48dB
Sync
Internal
White balance
Automatic
#IR LEDs
N/A
36
IR wavelength
N/A
860nm
IR range
N/A
118’ (36m)
Power source
12VDC
12/24 VAC/VDC
Current draw
LEDs off
DC: 180mA
DC: 180mA
AC: 4.3W
LEDs on
N/A
DC: 480mA
AC:12W
Operating temperature
14°~122° F (-10°~50° C)
Dimensions
51/8”x4” (130x105 mm)
Weight
15-oz (420g)
Dimensions
EV-2661-NKBQ shown. Dimensions are the
same for all three models.
51/8”
(130mm)
4”
(102mm)
Using the 3-Axis Gimbal
1. To adjust the horizontal pan, turn the camera ball
by hand up to 360°.
2. To adjust the vertical tilt, tilt the camera ball
by hand.
3. To adjust the angle of the third axis, loosen the
screw and twist by hand. Tighten the screw
when finished.
Parts List
1 x Screwdriver
1 x Manual
1 x Service monitor adapter
1 x DC plug with terminal block
EV-2660-NKBQ or EV-2660-NKBAQ shown. Gimbal
adjustment is the same for all three models.
1 x Camera
2 x Mounting screws
1
2
3
Third axis
screw

SECO-LARM High Resolution Indoor Dome Cameras
SECO-LARM U.S.A., Inc. 3
1. Remove the dome by twisting counterclockwise. Be
careful not to scratch the dome. Do not touch any of
the components inside the dome.
2. Temporarily connect the camera to the video monitor via
the video cable. If a service monitor is available, use the
included service monitor adapter.
3. Temporarily connect the camera to a 12VDC
power source. (24VAC may be connected for
EV-2660-NKBAQ and EV-2661-NKBQ).
4. Hold the base of the dome camera with your hand against
the ceiling, and try various locations and angles while
watching the video monitor to find the location which
offers the best protection. Mark that location
with a pencil.
5. Run a hidden, permanent video cable from the monitor to
the mounting location.
Before Starting
Installation
1. This product was designed for indoor use only. Do not
mount the CCTV camera where it is exposed to rain or
other moisture, or in humid or dusty places.
2. Do not point the CCTV camera at the sun. Heat could
damage the camera, even when not in use.
3. Do not mount the CCTV camera in areas exposed to
radiation, strong magnetic fields, or strong electrical
signals.*
4. Do not open or disassemble the camera. There are no
user serviceable parts inside.
5. Do not drop the camera or subject it to strong vibrations.
Note: Many video monitors produce strong
electromagnetic fields close to the display CRT,
especially when the monitor is turned on or during de-
Gaussing, which occurs automatically with many
monitors when the monitor is turned on.
Installation
6. Run a hidden cable from the power supply to the
mounting location.
7. Connect the two cables to the dome camera. Do not
cut any wires, as warranty will be voided. If needed,
use the included DC plug with terminal block.
8. Mount the base to the ceiling at the selected location.
9. Use the 3-axis gimbal to adjust the angle of the camera.
(See opposite page for further instructions.)
10. Make any necessary adjustments to the Zoom and
Focus by pulling the respective levers out and turning
them clockwise or counterclockwise.
11. Replace the dome, taking care not to touch the camera
or scratch the dome.
12. Test the camera again under the exact lighting
conditions under which it is expected to be used.
DC plug with terminal block
Mounting screw
Focus
Zoom
Dome
Base
EV-2660-NKBQ or EV-2660-NKBAQ shown. Installation is the same for all three models.
DC Jack
(connect to power)
Female BNC connector
(connect to video device)
Service monitor adapter
Connect to service monitor
at the installation site
Important: Do not cut DC jack or BNC connector as
warranty will be voided.
Service Monitor Port
Connects to Service
Monitor Port
Mounting surface

SECO-LARM High Resolution Indoor Dome Cameras
4SECO-LARM U.S.A., Inc.
MiEV-266x-NKB_1008.docx
PIKPR1
IMPORTANT
Users and installers of this product are responsible for ensuring this product complies with all national, state, and local laws and
statutes related to monitoring and recording audio and video signals. SECO-LARM will not be held responsible for the use of this
product in violation of any current laws or statutes.
WARNING
Stop using the camera if you see a malfunction such as smoke or unusual heat, as it could cause fire or electric shock. Do not open
the case of this device, as there are no field-serviceable components inside.
FCC COMPLIANCE STATEMENT
Information to the user: This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to
part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at his or her own expense.
WARRANTY: This SECO-LARM product is warranted against defects in material and workmanship while used in normal service for
a period of one (1) year from the date of sale to the original consumer customer. SECO-LARM’s obligation is limited to the repair or
replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM.
This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect, repair or
alteration, improper or abnormal usage, or faulty installation, or if for any other reason SECO-LARM determines that such equipment
is not operating properly as a result of causes other than defects in material and workmanship.
The sole obligation of SECO-LARM, and the purchaser’s exclusive remedy, shall be limited to replacement or repair only, at
SECO-LARM’s option. In no event shall SECO-LARM be liable for any special, collateral, incidental, or consequential personal or
property damages of any kind to the purchaser or anyone else.
NOTICE
The information and specifications printed in this manual are current at the time of publication. However, the SECO-LARM policy is
one of continual development and improvement. For this reason, SECO-LARM reserves the right to change specifications without
notice. SECO-LARM is also not responsible for misprints or typographical errors.
Copyright © 2010 SECO-LARM U.S.A., Inc. All rights reserved. This material may not be reproduced or copied, in whole or in part,
without the written permission of SECO-LARM.
SECO-LARM U.S.A., Inc.
16842 Millikan Avenue, Irvine, CA 92606
Tel: [phone]
Website: www.seco-larm.com
The screen is blank.
The screen image is dim
The screen image has poor contrast.
The screen image flickers.
The screen image is distorted.
The camera case is hot.
IR LEDs do not turn on.
Check that the camera is powered up.
Check that the power supply’s polarity is correct.
Check that the monitor is powered up.
Check that the video cable connecting the camera to the
monitor is connected properly.
Clean the lens using a soft, clean cloth.
Check that the light source is adequate.
Change the position of the camera.
Change the position of the camera.
Change the position of the camera.
Check that the correct power supply is in use.
Check that the correct power supply is in use.
Troubleshooting:
E-mail: [email protected]
