Seconique CORONA EXTENDING DINING TABLE User manual

CORONA EXTENDING DINING TABLE
ASSEMBLY INSTRUCTIONS
IMPORTANT
PLEASE READ BEFORE YOU CONTINUE FURTHER
After unpacking this product please keep the original packaging in case it needs to be
returned for any reason.
• Please ensure all fittings and parts are present before commencing with assembly.
• We recommend that you lay a blanket or sheet on the floor to avoid damage to both your
floor and the product.
• We strongly recommend that you keep children away from your work area.
• Assemble this product as close to its final position as possible.
• Never drag or push products as this could cause damage to the joints making it inferior.
• Do not place this product next to a radiator or in direct sunlight.
• Wood is a natural product and may expand if subjected to damp and may shrink or crack
if subjected to heat. Therefore it is recommended that room temperature is maintained,
with no sudden temperature fluctuations.
• Make sure any spillage is wiped o ffimmediately.
• Do not place hot or chilled items directly on to the surface, use a place mat or marking
will occur.
• For general cleaning use a duster, and do not use detergents of any kind. However, the
surface will need to be retreated from time to time. This can be done by using block wax
(unperfumed) and rubbing it over the whole item.
• From time to time it may be necessary to tighten fittings, regular inspections should be
carried out.
CARE AND MAINTENANCE
Page 01
FOR DOMESTIC USE ONLY
SEC/SW/07/21/KK1

1
2
1
1
1
1
1
2
7
7
3
4
4
5
5
3
6
6
* Please check contents and read the instructions before commencing assembly.
* Assemble this product following the enclosed instructions carefully.
* Please take care to avoid damaging panels during assembly.
* Use of power tools to assemble this product will invalidate
any claim and damage this product making it unsafe !!!
* Please assemble on a clean soft surface to avoid damage.
PARTS LIST
Part Code
Part Number Part Description Quantity Carton
1
2
3
4
5
S400-403-009-KK1-01 Table Top Panel 21/2
Table Centre Panel
Table Leg (Yellow Marking)
Table Leg (Blue Marking)
Short Frame Side
S400-403-009-KK1-02
S400-403-009-KK1-03
S400-403-009-KK1-04
S400-403-009-KK1-05
1
2
2
2
1/2
2/2
2/2
2/2
Page 02
SEC/SW/07/21/KK1
6
7
Long Frame Side
Table Crossbar Support
S400-403-009-KK1-06
S400-403-009-KK1-07
2
2
2/2
2/2

08
12
08
01
I
J
D
E
Ø7 x 50mm
Ø1/4" x 120mm
Ø8 x 20mm
Ø10 x 40mm
Ø3,5 x 16mm
4mm
1/4"
FITTINGS
TOOLS REQUIRED
Page 03
SEC/SW/07/21/KK1
14
04
08
02
32
04
F
G
H
A
B
C
GLUE

C
C
5
x2
D
D
7
x2
Ø8 x 20mm
Ø10 x 40mm
GLUE
BLUE
YELLOW
A
A
J
J
6
4
3
x2
ADD GLUE
Ø1/4" x 120mm
STEP 1
STEP 2
SEC/SW/07/21/KK1
Page 04
PARTS REQUIRED
TOOLS REQUIRED
HARDWARE REQUIRED
3 - x2
TABLE LEG(YELLOW MARKING)
PARTS REQUIRED
TOOLS REQUIRED
HARDWARE REQUIRED
A04
Please assemble on
a clean soft surface
to avoid damage.
Please assemble on
a clean soft surface
to avoid damage.
C+D
Glue must be added to
the dowel holes on
parts 5,6 and 7.
4 - x2
TABLE LEG(BLUE MARKING)
6 - x2
LONG FRAME SIDE
H01
J04
1/4"
GLUE
Glue must be added to
the dowel holes on
parts 3 and 4.
7 - x2
TABLE CROSSBAR SUPPORT
5 - x2
SHORT FRAME SIDE
6 - x2
LONG FRAME SIDE
C08
D08
H01
ADD GLUE
C
C
D
6
x2
Ø7 x 50mm
Ø1/4" x 120mm

A
A
B
B
7 - x2
TABLE CROSSBAR SUPPORT
Ø7 x 50mm
Please assemble on
a clean soft surface
to avoid damage.
Ø7 x 50mm
TOOLS REQUIRED
HARDWARE REQUIRED
B02
Ø1/4" x 120
A02
H01
J02
1/4"
GLUE
SEC/SW/07/21/KK1
Ø7 x 50mm
Ø1/4" x 120mm
STEP 3
STEP 4
Page 05
5 - x2
SHORT FRAME SIDE
PARTS REQUIRED
TOOLS REQUIRED
HARDWARE REQUIRED
PARTS REQUIRED
Please assemble on
a clean soft surface
to avoid damage.
Glue must be added to
the dowel holes on
parts 3,4 and 6.
ADD GLUE
J
J
BLUE
YELLOW
YELLOW
5
5
7
7
ADD GLUE
B02
Ø1/4" x 120
A02
H01
J02
1/4"
GLUE
YELLOW
A
A
B
B
J
J
BLUE
YELLOW
YELLOW
Ø7 x 50mm
Ø1/4" x 120mm
Glue must be added to
the dowel holes on
parts 3,4 and 6.

C
C
C
C
C
C
D
D
D
D
1
2
GLUE
C
Please assemble on
a clean soft surface
to avoid damage.
2 - x1
TABLE CENTRE PANEL
1
Please assemble on
a clean soft surface
to avoid damage.
SEC/SW/07/21/KK1
STEP 5
STEP 6
Page 06
1 - x1
TABLE TOP PANEL
PARTS REQUIRED
PARTS REQUIRED
TOOLS REQUIRED
HARDWARE REQUIRED
GLUE
C
GLUE
D
Please be sure to only add
glue into the dowel holes
as shown above.
Ø8 x 20mm
Ø10 x 40mm
GLUE
TOOLS REQUIRED
HARDWARE REQUIRED
C06
D04
H01
XXXX
XXXXX
2
1
2 - x1
TABLE CENTRE PANEL
1 - x2
TABLE TOP PANEL

Please assemble on
a clean soft surface
to avoid damage.
STEP 7
STEP 8
SEC/SW/07/21/KK1
Page 07
PARTS REQUIRED
PARTS REQUIRED
TOOLS REQUIRED
HARDWARE REQUIRED
E08
G16
Please assemble on
a clean soft surface
to avoid damage.
Xxfaturamentoapembaagn
XXXX
XXXX
XXXX
XXXX
G
E
x8
When fitting the table guides (E)
carefully line up the screw (G)
with the pre-marked holes on the
table top panel, this will ensure
the table will open correctly when
the table requires extending.
Ø3,5 x 16mm
XXXX
Xxfaturamentoapembaagn
XXXX
XXXX
XXXX
XXXX
TOOLS REQUIRED
HARDWARE REQUIRED
F04
G16
Ø3,5 x 16mm
G
F
Xxfaturamentoapembaagn
XXXX
XXXX
XXXX
XXXX

ASSEMBLY INSTRUCTIONS
IMPORTANT
PLEASE READ BEFORE YOU CONTINUE FURTHER
After unpacking this product please keep the original packaging in case it needs to be
returned for any reason.
• Please ensure all fittings and parts are present before commencing with assembly.
• We recommend that you lay a blanket or sheet on the floor to avoid damage to both your
floor and the product.
• We strongly recommend that you keep children away from your work area.
• Assemble this product as close to its final position as possible.
• Never drag or push products as this could cause damage to the joints making it inferior.
• Do not place this product next to a radiator or in direct sunlight.
• Wood is a natural product and may expand if subjected to damp and may shrink or crack
if subjected to heat. Therefore it is recommended that room temperature is maintained,
with no sudden temperature fluctuations.
• Make sure any spillage is wiped o ffimmediately.
• Do not place hot or chilled items directly on to the surface, use a place mat or marking
will occur.
• For general cleaning use a duster, and do not use detergents of any kind. However, the
surface will need to be retreated from time to time. This can be done by using block wax
(unperfumed) and rubbing it over the whole item.
• From time to time it may be necessary to tighten fittings, regular inspections should be
carried out.
CARE AND MAINTENANCE
Page 01
CORONA DINING CHAIR
FOR DOMESTIC USE ONLY
SEC/SH/07/21/KK1

* Please check contents and read the instructions before commencing assembly.
* Assemble this product following the enclosed instructions carefully.
* Please take care to avoid damaging panels during assembly.
* Use of power tools to assemble this product will invalidate
any claim and damage this product making it unsafe !!!
* Please assemble on a clean soft surface to avoid damage.
PARTS LIST
Part Code
Part Number Part Description Quantity Carton
1
2
3
4
5
6
S400-402-015-KK1-01 Le Chair Side 11/4
Right Chair Side
Chair Seat
Back Rail
Back Seat Rail (Bigger)
Front Seat Rail (Smaller)
S400-402-015-KK1-02
S400-402-015-KK1-03
S400-402-015-KK1-04
S400-402-015-KK1-05
S400-402-015-KK1-06
1
1
3
1
1
3/4
2/4
2/4
1/4
2/4
Page 02
SEC/SH/07/21/KK1
FOR YOUR FUTURE
REFERENCE
ORDER NUMBER
SHOULD BE HERE
1
2
3
5
4
6

Ø 7 x 90
FITTINGS
TOOLS REQUIRED
Page 03
SEC/SH/07/21/KK1
12
16
04
01
02
08
D
E
F
A
B
C
Ø 7 x 60
GLUE
8,0 x 30
4,0 x 35

Ø7 x 60
STEP 1
STEP 2
SEC/SH/07/21/KK1
Page 04
4 - x3
BACK RAIL
PARTS REQUIRED
TOOLS REQUIRED
HARDWARE REQUIRED
C06
1 - x1
LEFT CHAIR SIDE
PARTS REQUIRED
TOOLS REQUIRED
HARDWARE REQUIRED
B04
Please assemble on
a clean soft surface
to avoid damage.
Please assemble on
a clean soft surface
to avoid damage.
C
Glue must be added to
the dowel holes on
parts 4.
C
C
4x3
4 - x3
BACK RAIL
Ø 7 x 60
Ø 7 x 90
5 - x1
BACK SEAT RAIL (BIGGER)
B
B
B
F
B
1
5
4
8,0 x 30
E01
GLUE
E C

Ø7 x 60
B04
STEP 3
STEP 4
SEC/SH/07/21/KK1
Page 05
6 - x1
FRONT SEAT RAIL (SMALLER)
PARTS REQUIRED
TOOLS REQUIRED
HARDWARE REQUIRED
2 - x1
RIGHT CHAIR SIDE
PARTS REQUIRED
TOOLS REQUIRED
HARDWARE REQUIRED
Please assemble on
a clean soft surface
to avoid damage.
Please assemble on
a clean soft surface
to avoid damage.
Ø 7 x 60
Ø 7 x 90
A
F
Ø 7 x 60
Ø 7 x 90
6
A01
Ø 7 x 90
B
2
B
B
B
F

D04
STEP 5
STEP 6
SEC/SH/07/21/KK1
Page 06
PARTS REQUIRED
TOOLS REQUIRED
HARDWARE REQUIRED
3 - x1
CHAIR SEAT
PARTS REQUIRED
TOOLS REQUIRED
HARDWARE REQUIRED
Please assemble on
a clean soft surface
to avoid damage.
Please assemble on
a clean soft surface
to avoid damage.
Ø 7 x 60
Ø 7 x 90
A01
Ø 7 x 90
A
F
D
D
CENTRALIZE
3
4,0 x 35
D
D
