NEVADA 3+2 DRAWER CHEST
RUSTIC OAK EFFECT
ASSEMBLY INSTRUCTIONS
54812HN
54812HN
IMPORTANT
FOR DOMESTIC USE ONLY
PLEASE READ BEFORE YOU CONTINUE FURTHER
CARE AND MAINTENANCE
After unpacking this product please keep the original packaging in case it needs to be returned for any reason.
• Please ensure all fittings and parts are present before commencing with assembly.
• Never drag or push products as this could cause damage to the joints making it inferior.
• We strongly recommend that you keep children away from your work area.
• Assemble this product as close to its final position as possible.
• Do not place this product next to a radiator or in direct sunlight.
• Do not drag or push items across your high gloss furniture as this may cause the surface to scratch.
• Wood is a natural product and may expand if subjected to damp and may shrink or crack if subjected to heat.
Therefore it is recommended that room temperature is maintained, with no sudden temperature fluctuations.
• Make sure any spillage is wiped off immediately.
• Do not place hot or chilled items directly on to the surface, use a place mat or marking will occur.
• For general cleaning use a soft cotton or micro fibre cloth, and do not use detergents of any kind.
• From time to time it may be necessary to tighten fittings, regular inspections should be carried out.
• Do not place on a wet or damp floor as staining may occur to your floor.

PAGE 2
SEC/AY/04/21/HN1
ITM/D727-
Please Note:
The below parts have all been stamped with the part number to help identify them during assembly.
PARTS LIST
1
7
2
9
10 10
12
11
13
15
10
10
14
6
88
5
5
4
16
3
Part Number Part Code Part Description Quantity Carton
01 S100-102-119-HN1-01 Left Side Panel 1 1/2
02 S100-102-119-HN1-02 Right Side Panel 1 1/2
03 S100-102-119-HN1-03 Front Baseboard 1 1/2
04 S100-102-119-HN1-04 Back Baseboard 1 1/2
05 S100-102-119-HN1-05 Crossbar 2 1/2
06 S100-102-119-HN1-06 Top Panel 1 2/2
07 S100-102-119-HN1-07 Division Panel 1 1/2
08 S100-102-119-HN1-08 Back Panel 2 1/2
09 S100-102-119-HN1-09 Small Drawer Back Panel 2 2/2
10 S100-102-119-HN1-10 Drawer Side 10 1/2
11 S100-102-119-HN1-11 Small Drawer Front 2 1/2
12 S100-102-119-HN1-12 Small Drawer Bottom 2 2/2
13 S100-102-119-HN1-13 Drawer Back Panel 3 2/2
14 S100-102-119-HN1-14 Drawer Front 3 2/2
15 S100-102-119-HN1-15 Drawer Bottom 3 2/2
16 S100-102-119-HN1-16 Drawer Bottom Support Bar 3 2/2
3X
2X
TOOLS REQUIRED

FITTINGS LIST
PAGE 3
SEC/AY/04/21/HN1
ITM/D727-
2/+
2/+
1/+
1/+
1/+
2/+
2/+
1/+ 2/+
OMPN
Washer (4x) Strap (2x)
Cam Bolt (6x)
Cam Nut O15mm (6x)
D
EG F
AB
IJK
H
Plastic Foot 16x20mm (6x)
Tack 10x10mm (48x)
Zamac handle 128mm (5x)
L
Q
Glue (3x)
Hole Plugs (8x)
Flat Head Screw
O3,5x10mm (104x)
Flat Head Screw
O3,0x16mm (44x)
Flat Head Screw
O4,0x45mm (9x)
Dowel O5x25mm (69x)
Metal support 4 holes (20x) Drawer Runners (5x)
Back Panel Strip (1x)
C
Flat Head Screw
O3,0x30mm (8x)
1/+
R
Back Panel Bracket (2x)
1/+
S
Union Screw 15mm (2x)
1/+ 1/+

PAGE 4
SEC/AY/04/21/HN1
ITM/D727-
PARTS REQUIRED
PARTS REQUIRED
HARDWARE REQUIRED
HARDWARE REQUIRED
1 - LEFT SIDE PANEL x1
2 - RIGHT SIDE PANEL x1
F 02
F 02
G 02
G 02
H 02
H 02
Q
Q
H
H
H
H
G
G
G
G
Detail 1
Detail 1
Detail 3
Detail 3
STEP 1
STEP 2
Detail 1
Detail 1
Q + F
Q + F
1
2
TOOLS REQUIRED
TOOLS REQUIRED
F
F
F
F
Detail 3
Detail 3
G
G
H
H

PAGE 5
SEC/AY/04/21/HN1
ITM/D727-
Please note:
Pre-Drilled
Holes
D
D
J
PARTS REQUIRED
PARTS REQUIRED
HARDWARE REQUIRED
HARDWARE REQUIRED
1 - LEFT SIDE PANEL x1
2 - RIGHT SIDE PANEL x1
D 12
D 12
J 04
J 04
D
D
D
D
D
D
D
D
D
D
D
D
D
DD
D
D
D
D
DD
D
D
D
J
J
J
J
J
J
J
J
2
1
STEP 3
STEP 4
D
D
J
Please note:
Pre-Drilled
Holes
Detail 2
Detail 2
J
J
TOOLS REQUIRED
TOOLS REQUIRED
Right
Detail 2
Detail 2
Detail 2
Detail 2
Detail 2
Detail 2
Detail 2
Detail 2
Left
FIRST HOLE (LINE UP WITH PRE-DRILLED HOLE)
SECOND HOLEPRE-DRILLED HOLE
SECOND HOLE
FIRST HOLE (LINE UP WITH PRE-DRILLED HOLE)
PRE-DRILLED HOLE

PAGE 6
SEC/AY/04/21/HN1
ITM/D727-
STEP 5
STEP 6
3
7
7
4
5
HARDWARE REQUIRED
PARTS REQUIRED Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 3
Detail 3
Detail 17
Detail 1
Detail 1
Detail 1
F
F
F
F
F
F
F
F
F
F
F
H
G
G
H
F
F
F
J
J
S
S
S
S
F
Detail 1
Detail 1
Q + F
Q + F
Detail 3
G
H
F 16
G 02
H 02
Q
TOOLS REQUIRED
3 - FRONT BASEBOARD x1
4 - BACK BASEBOARD x1
5 - CROSSBAR x2
PARTS REQUIRED
TOOLS REQUIRED
HARDWARE REQUIRED
7 - DIVISION PANEL x1
F 03
J 01
S 02
J 01
Q
J
J
S
S
Detail 17
J
LAST FOURTH HOLE SECOND HOLE (LINE UP WITH PRE-DRILLED HOLE)
Right
Left
2x

PAGE 7
SEC/AY/04/21/HN1
ITM/D727-
STEP 8
STEP 7
1
2
3
4
5
5
3 - FRONT BASEBOARD x1
4 - BACK BASEBOARD x1
Detail 6
Detail 6
Detail 6
Detail 6
A
AA
A
Detail 10
Detail 10
Q
Q
PARTS REQUIRED
2 - RIGHT SIDE PANEL x1
HARDWARE REQUIRED
HARDWARE REQUIRED
A 04
A 04
Q
Q
TOOLS REQUIRED
TOOLS REQUIRED
Detail 6
Detail 6
A
A
Detail 10
Detail 10
Detail 10
PARTS REQUIRED
1 - LEFT SIDE PANEL x1
5 - CROSSBAR x2
A
A
A
A
Detail 6
Detail 6
Detail 6
Detail 6
Detail 10
Detail 10
Detail 10

PAGE 8
SEC/AY/04/21/HN1
ITM/D727-
MQ
Cam bolt head needs to be in centre
Detail 10 Detail 4
Q
Detail 5
Detail 5
Detail 5
Detail 5
Detail 5
Detail 5
Detail 4
Detail 4
Detail 10
Detail 10
STEP 9
STEP 10
6
6
7
L
L
L
M
M
L
L
L
Detail 5
L
PARTS REQUIRED
TOOLS REQUIRED
HARDWARE REQUIRED
6 - TOP PANEL x1
L 06
23
PARTS REQUIRED
TOOLS REQUIRED
6 - TOP PANEL x1
HARDWARE REQUIRED
M x2
7 - DIVISION PANEL x1

PAGE 9
SEC/AY/04/21/HN1
ITM/D727-
M
M
M
Detail 4
Detail 4
M 04
MQ
STEP 11
STEP 12
HARDWARE REQUIRED
TOOLS REQUIRED
PARTS REQUIRED
8 - BACK PANEL x2
Cam bolt head needs to be in centre
Detail 10 Detail 4
GGGG
G
G
G
R
R
GG
G
G
G
G
G
G
G
G
G
G
G
G
G
G
P
G
G
G
G
G
G
G
G
G
* For your future reference
Order Number should be here
xxxxx
xxxxx
8
8
TOOLS REQUIRED
HARDWARE REQUIRED
Detail 7
Detail 7
Detail 14
G
G
G
G
Detail 7
Detail 7
Q
Detail 10
Detail 10
Detail 10
Detail 10
A 01
A
Detail 18
Detail 18
A
G 32
P 01
R 02
Detail 14
G
R
8
8

PAGE 10
SEC/AY/04/21/HN1
ITM/D727-
STEP 13
STEP 14
16
PARTS REQUIRED
PARTS REQUIRED
TOOLS REQUIRED
HARDWARE REQUIRED
10 - DRAWER SIDE x10
10 - DRAWER SIDE x4
D 40
F 46
I 20
Q
Detail 8
I
DD
Detail 1
Q + F
D
D
D
DF
F
F
F
F
F
I
I
Detail 8
Detail 8
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
16-DRAWER BOTTOM SUPPORT BAR x3
1°
2x
10
9 - SMALL DRAWER BACK PANEL x2
HARDWARE REQUIRED
D 08
Q
TOOLS REQUIRED
10x
3x
Detail 9 Detail 10
I
D
Q
D
D
D
9
Detail 9
10
10
Detail 10
Detail 10

PAGE 11
SEC/AY/04/21/HN1
ITM/D727-
STEP 16
STEP 15
PARTS REQUIRED
HARDWARE REQUIRED
D 08
Q
2°
2x
11 - SMALL DRAWER FRONT x2
TOOLS REQUIRED
E 06
G 04
PARTS REQUIRED
HARDWARE REQUIRED
12 - SMALL DRAWER BOTTOM x2
E
E
E
G
G
12
3°
2x Detail 11
Detail 11
Detail 15
3
2
3
6 6
2
10 2
100mm
60mm
6mm
Detail 11
Detail 15
G
E
TOOLS REQUIRED
Detail 9 Detail 10
I
D
Q
D
D
D
Detail 9
11
Detail 10
Detail 10

PAGE 12
SEC/AY/04/21/HN1
ITM/D727-
STEP 18
E
E
E
E
J
J
4°
2x
Detail 12
Detail 12
USE THE E SMALLEST HOLE
J
K
K
K
Detail 13
K
K
K
Detail 13
5°
2x
STEP 17
Detail 12
EE
J
E 08
TOOLS REQUIRED
TOOLS REQUIRED
HARDWARE REQUIRED
HARDWARE REQUIRED
K x2
J 02
J 02
Left
Right

PAGE 13
SEC/AY/04/21/HN1
ITM/D727-
Detail 9
Detail 10
Detail 10
Detail 9
D
D
STEP 20
STEP 19
PARTS REQUIRED
10 - DRAWER SIDE x6
13 - DRAWER BACK PANEL x3
HARDWARE REQUIRED
D 12
Q
TOOLS REQUIRED
1°
3x
Detail 9 Detail 10
I
D
Q
D
13
10
10
2°
3x
Detail 9 Detail 10
I
D
Q
D
PARTS REQUIRED
14 - DRAWER FRONT x3
HARDWARE REQUIRED
D 12
Q
TOOLS REQUIRED
Detail 9
Detail 10
Detail 10
Detail 9
D
D
14

PAGE 14
SEC/AY/04/21/HN1
ITM/D727-
E 18
G 06
TOOLS REQUIRED
HARDWARE REQUIRED
15 - DRAWER BOTTOM x3
3
2
3
6 6
2
10 2
100mm
60mm
6mm
Detail 15
Detail 11
Detail 15
STEP 22
STEP 21
PARTS REQUIRED
3°
3x
G
E
G
G
E
E
E
E
E
E
15
Detail 11
Detail 11
HARDWARE REQUIRED
Q
Detail 10
Q
16
Detail 10
4°
3x
PARTS REQUIRED
16-DRAWER BOTTOM SUPPORT BAR x3

PAGE 15
SEC/AY/04/21/HN1
ITM/D727-
E 12
C 06
TOOLS REQUIRED
HARDWARE REQUIRED
STEP 24
STEP 23 5°
3x
J
J
E
E
E
E
CC
Detail 12
Detail 12
Detail 12
EE
J
USE THE E SMALLEST HOLE
J
K
K
K
6°
3x Detail 13
Detail 13
K
K
K
HARDWARE REQUIRED
K 03
TOOLS REQUIRED
J 03
J 03
Left
Right

PAGE 16
SEC/AY/04/21/HN1
ITM/D727-
STEP 25
HARDWARE REQUIRED
B 08
Detail 16
B
If desired, after assembly, use
an alcohol cleaner to erase part
of the numbers.
xx

PAGE 17
SEC/AY/04/21/HN1
ITM/D727-
WARNING
Serious or fatal injuries can occur from furniture tipping
over. To prevent the furniture from tipping over we
recommend that it is permanently fixed to the wall.
Wall fixings are not supplied with this product as different wall
materials require different types of fixing devices.
Please make sure you use fixing suitable for the walls in your home.
C
N
O
Washer (X4)
Strap (X2)
Flat Head Screw
O3,0x30mm (X2)
N
N
O
O
