Sega GENESIS FB8280C User manual

CLASSIC GAME CONSOLE
INSTRUCTION
MANUAL
MODEL NO: FB8280C
AtGames Holdings, Ltd. www.atgames.net

1
AC Adapter Specification
INPUT: 100V-240V
AC/50HZ-60HZ
OUTPUT: DC 9V/500mA
PLUG:
Power ON/OFF
Turn the game console’s power ON/OFF.
MENU
Press this button to return to the main menu.
Cartridge Slot
Slot for additional cartridges.
First Player Game Controller Jack
Game controller connected to this
jack controls games in 1-player games
and controls the first player in 2-player
games. Note that some two player games
alternate use of the first player controller.
Second Player Game Controller Jack
Game controller connected to this jack controls
the second player in 2-player games.
Video Output
Video output.
Audio Output
Audio output.
AC Adaptor Jack (DC 9V)
The power adaptor plugs into this port,
then into your AC outlet.
NOTE
• Must use the AC adapter
included as power supply to
the console.
• Do not connect the AC adapter
to the power input other than
the above specifications.
• AC adapter is not a toy.
• The socket-outlet shall be
installed near the equipment
and shall be easily accessible.
Classic Game Console Appearance and Key List
The image below shows the location of the connectors and buttons. Each
function is outlined below (the illustration is for reference only).
1
1
2
3
4
5
6
7
8
6
4
2
7
3
8
5

3
2
Input Instruction
If your TV does not have a dedicated composite input, it may support such a
connection through a shared component input. For TVs with shared compo nent
inputs, the diagram below indicates a typical setup, with the yellow composite
video connector plugging into the green component video input. Refer to your
TV's manual for additional information on available ports and how to change
inputs once connected.
What can I do if my TV can only support HDMI input?
Check out AtGames Flashback Zone for products that support HDMI
http://atgames.us/.
What are the two controller ports on the console for?
These ports are for the wired controllers. These ports are also compatible with
original Sega Genesis and compatible wired controllers.
How to connect wired controllers?
For 1 player games: Connect a wired controller to the left controller port.
For 2 player games: Connect a second wired controller to the right controller
port for player two.
Wired Game Controllers Appearance and Key List
The image below shows the appearance and key list of the wired game
controllers (the illustration is for reference only).
START
Press the button to start the game and
press it again to pause the game.
Directional Pad (D-Pad)
Directional Pad for game playing.
A Key
Games key A.
B Key
Games key B.
C Key
Games key C.
X Key
Games key X.
Y Key
Games key Y.
Z Key
Games key Z.
How to connect the console to a TV?
1. Connect the game console to TV using the enclosed AV cable.
2. Press the power button on the game console after configuring the TV
input to AV or Composite input.
NOTE
Display results will vary by TV. Consult your TV's manual to adjust Brightness, Sharpness,
Contrast, Aspect Ratio, and other features for best display results.
Do not unplug AV cable when console is on. Otherwise, please press MENU button to
return to the main menu.
1
2
3
4
5
6
7
8
3
6
4
7
8
5
2
1
ON/OFF

5
4
Warning
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
NOTE
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
Repair and Exchange Service
If the unit is damaged due to its improper use or simply wear and tear, and if
the place where the product was originally purchased can't do an exchange of
this product, a standard repair and exchange program may help. Please visit
http://www.atgames.us/Repair_c2.htm for more details about the repair and
exchange program.
Safety Notice
How do I start playing?
1. Press the button to turn on the game console.
2. Use the player 1 (P1) wired controller that is connected to the left controller
port to browse menu.
3. Press the button on the controller to select and begin the game.
How do I play two-player games?
1. Follow the steps in section “How do I start playing”.
2. Press or on to select a two player game.
3. Press the button of the P1 controller to start playing the game.
How do I play a cartridge game?
1. Make sure you turn off the console.
2. Insert the cartridge into slot on the console.
3. Press the button to turn on the console. It will automatically start the
cartridge game.
NOTE: Console may not be compatible with all Genesis/Mega Drive cartridges.
How do I go back to game menu while playing the game?
Press the button on the console and the screen will go back to the game
menu page.
What do I do when the controller is not working?
1. If you only have a controller plugged into the P2 socket, turn off your
console and connect the controller to the P1 (left) controller port. Then, turn
on the console and try again.
2. If you have a controller plugged into the P1 socket, press MENU button to
reload the console and try it again.
What do I do when the power supply is not working?
You might be using the wrong AC adapter. Please use the one included in the
package, which is rated for 9V/500mA.
MENU
With certain TV models, e.g., Vizio VOJ320F1A, SONY KDL-32BX310, SONY KDL-32EX308,
SONY KDL-46HX729, SONY KDL-50R550A, LG 47LA6900, LG 55UB8500, Samsung
UN40C7000WF and Panasonic TC-58AX800U0, this console may be incompatible and
cause undesired effects, like display shifting, which results in the picture not being centered
on the screen. Or horizontal display noise, it might move up and down on the screen. If this
happens, try the console on a different display or return the console to the point of purchase.

7
6
Game title: Altered Beast
MENU TITLE: ALTERED BEAST
In a time of legend, warriors and supernatural foes, Zeus,
God of Thunder, summons you from the dead as his
champion in the fight of good versus evil. Athena, daughter
of Zeus, has been imprisoned by the evil Neff, God of
the Underworld, and it is your charge to free her from his
clutches. To do so, you must battle Neff’s henchmen until
you reach the ultimate challenge. Zeus has given you one
advantage: the ability to capture spirit balls which you can
use to transmute into various beast forms. If you succeed,
Zeus will be your ally for all time. If you fail, only Neff knows
what pain will be your fate!
Control the direction.
Start game. Pause and un-pause game.
Punch
Kick.
Jump.
No function.
No function.
No function.
Jump higher.
Game title: Arrow Flash
MENU TITLE: ARROW FLASH
Things are grim. An evil dragon from another galaxy is
rapidly approaching Earth and as a space pilot you realize
that it is up to you to stop this threat cold. If you fail, your
home will be burnt to a cinder. Your ship provides two
distinct modes, each known as an Arrow Flash. Using blast
weapons and defensive shield capabilities, your challenge is
formidable. Hit the thrusters; you have a date with a dragon
in outer space!
Control the direction.
Start game. Pause and un-pause game.
Switch between Plane or Robot mode.
Shoot.
Attack enemies with laser while in Plane Mode.
Attack enemies with speeding bump while in Robot Mode.
No function.
No function.
No function.
Game title: Alex Kidd in the Enchanted Castle
MENU TITLE: ALEX KIDD
Alex Kidd’s father’s life is in danger! Fortunately, facing
danger is what Alex does best! To save his father, he must
win round after exciting round of “Paper, Rock and Scissors”.
Winning rounds not only moves Alex that much closer to his
father, but winning also provides gifts that Alex can utilize for
special powers. These will be necessary as the opponents
get harder and harder and the danger increases! If Alex
can win the ultimate level, he can save his father and win
amazing prizes as well! There is not time to lose!
Control the direction.
Start game. Select the tool in tool menu.
Jump up and kick.
Punch.
Jump up and kick.
No function.
No function.
No function.
Game title: Alien Storm
MENU TITLE: ALIEN STORM
Strange and deadly aliens have invaded the Earth and it is
up to you to stop them! Your battle will take you through
numerous environments as you fight your way to the mother-
ship to face off with the “mother of all aliens”. Each character
has unique attacks and special abilities that will add strategic
variety to your game play. Additionally, mission objectives
provide opportunities for exciting power-ups. It will take all
your skills to save the Earth!
Control the direction.
Start game. Pause and un-pause game.
Powerful attack in wide area which takes a lot of energy.
Attack in medium power. Press to attack while in sprint status.
Toss forward. Press to jump while in sprint status.
No function.
No function.
No function.
Press twice to make hero run.
Game Description

9
8
Game title: Columns III
MENU TITLE: COLUMNS III
Columns III is the final game in the series of fast-moving puzzle
classics. As in the other games in the series, match colors
of dropping objects in order to remove them from the play
field; if they rise too high, the game is over. Columns III adds
multiple versions for strategic additions to keep the game
fresh and exciting. This is the puzzle game that started it all!
Control the direction.
Start game. Pause and un-pause game.
“Crush" left whichever jewels are currently falling from the
opponent's board and add a row of bricks to the bottom of his field.
Cycle the jewels.
“Crush" right whichever jewels are currently falling from the
opponent's board and add a row of bricks to the bottom of his field.
No function.
No function.
No function.
Game title: Comix Zone
MENU TITLE: COMIX ZONE
In this action thriller you play the part of Sketch Turner, a
highly respected comic book artist, who, by a strange twist of
fate, gets sucked into his own comic book creation. Stuck in
a familiar world, you must become the hero, fighting against
the very villains of your own imagination! If Sketch can first
stop one of his evil characters from taking over the world,
surely he will be able to find a way out to the real world!
Control the direction.
Start game. Pause and un-pause game.
Attack.
Jump.
Defense.
Use the tool in the left icon above.
Use the tool in the middle icon above.
Use the tool in the right icon above.
Game title: Bonanza Bros.
MENU TITLE: BONANZA BROS.
Mobo and Robo Bonanza are enjoying their favorite television
show when the picture crackles and a shadowy figure of a
mysterious stranger appears on screen. This figure asks them
to collect certain items that he has placed inside various
buildings to test his security force. If they return the items
successfully, Mobo and Robo will be rewarded. The two of
them state that they will get the job done in just three minutes.
However, little do they know that each building is packed with
security guards who will raise the alarm if they are caught
red-handed. Fortunately both Mobo and Robo are equipped
with bullets that can knock the guards unconscious for a few
seconds. A huge reward will be given out if Mobo and Robo
are apprehended. Help the infamous Bonanza Bros. infiltrate a
number of different locations ranging from banks to mansions
to casinos and don't get caught!
Control the direction.
Start game. Pause and un-pause game.
Jump.
Shoot.
Jump.
No function.
No function.
No function.
Game title: Columns
MENU TITLE: COLUMNS
Addictive and ancient, Columns is the game of a bygone era,
originating with Phoenician merchants. Align puzzle pieces
to build columns and bring them down. Easy to play, yet
challenging to master, this is a game to keep you amused for
hours on end. You will quickly understand why this simple
puzzler has stood the test of time. Prepare to lose yourself in
this game of the ancients.
Control the direction.
Start game. Pause and un-pause game.
Arrange the item.
Arrange the item.
Arrange the item.
No function.
No function.
No function.

11
10
Game title: Dr. Robotnik’s Mean Bean Machine
MENU TITLE: DR. ROBOTNIK
The evil Dr. Robotnik has always loved to turn people
and other objects into robots. In this Columns-style game
he is menacing the unsuspecting citizens of Beanville
and threatening to make them his next victims of robot
transformation! Create matching color groups to save the
Beans, but watch out for the robots. They will try to stop
you dead in your tracks. If you fail to make the match, into
the Mean Bean Machine you go and Beanville will surely
become robot central!
Control the direction.
Start game. Pause and un-pause game.
Arrange the item to right side.
Arrange the item to left side.
Arrange the item to right side.
No function.
No function.
No function.
Game title: ESWAT: City Under Siege
MENU TITLE: ESWAT
Liberty is a dark, crime ridden metropolis, teaming with
criminals who are looking to take advantage of the innocent
and the weak. ESWAT places you in the game as a member
of the Cyber Police force where it is your job to protect the
citizens and stop the criminals. As you advance through this
action-shooter, you will gain rank which will open up new
weapons and defensive capabilities. If you can arrest the
criminal masterminds behind the city’s trouble, Liberty may
even promote you to chief of the famed ESWAT squad! Look
out criminals, ESWAT is on patrol!
Control the direction.
Start game. Pause and un-pause game.
Jump.
Shoot.
Jump.
No function.
No function.
No function.
Game title: Crack Down
MENU TITLE: CRACK DOWN
When many bombs are discovered throughout a large
laboratory, Ben and Andy are called in to dismantle them
before the building explodes all around them! Racing from
spot to spot, each bomb must be neutralized with smaller
charges before time runs out. Defenses have been placed
to make it more dangerous, but Ben and Andy have an array
of weapons to help them achieve their goals. Better call the
bomb squad! Time is short!
Control the direction.
Start game. Pause and un-pause game.
Change bullets.
Shoot. Attack with fist if bullets run out.
Bomb.
No function.
No function.
No function.
Game title: Decap Attack
MENU TITLE: DECAP ATTACK
In an odd and colorful world, anything can happen. Max D.
Cap, an evil boss, has taken control of this unusual planet
and must be stopped. Chuck D. Head, a headless mummy,
rises up as the best hope of this strange world and he will
stop at nothing to defeat Max and free the planet. Brightly
colored lands, unusual foes and powerful and exotic
weapons await you as you guide Chuck in his heroic battle in
this side scrolling spectacular!
Control the direction.
Start game. Pause and un-pause game.
Open items menu.
Attack.
Jump.
No function.
No function.
No function.

13
12
Game title: Flicky
MENU TITLE: FLICKY
When the babies wander off, there is only one thing to do: lead
them back to the safety of their nest. Flicky the mother blue jay
has just such a task. It won’t be easy to get the baby chicks back
though! Hungry cats are on the prowl and many surprising
hazards are waiting to be found. Puzzle your way through level
after level of cat fighting fun in this family favorite!
Control the direction.
Start game. Pause and un-pause game.
Jump.
Jump.
Jump.
No function.
No function.
No function.
Game title: Gain Ground
MENU TITLE: GAIN GROUND
Gain Ground is a game of arcade style action and game
changing strategy at its finest. Your mission is to save
captives and get them to safety. As the leader of a group of
mercenaries, it is up to you to decide which ones to use in
each challenge. Every fighter possesses unique abilities that
could be the difference between life and death. You might
even pick up a new fighter along the way, adding to the
strategic possibilities and fun!
Control the direction.
Start game. Pause and un-pause game.
Attack.
Attack.
Attack.
No function.
No function.
No function.
Game title: Eternal Champions
MENU TITLE: ETERNAL CHAMPIONS
The Eternal Champions are a league of long undead
fighters who exist in a nether world of neither life nor
death. In this strange place, they exist for only one thing:
combat. Success in the arena can lead to another chance at
life. Upon your earthly death, the Eternal Champions have
selected you to enter their realm and fight for the right to
regain you earthly life.
Control the direction.
Start the game. Pause and un-pause game.
Light Kick.
Medium Kick.
Strong Kick.
Light Punch.
Medium Punch.
Strong Punch.
Game title: Fatal Labyrinth
MENU TITLE: FATAL LABYRINTH
Many hours of danger and excitement await you in this dungeon
crawling favorite! When the Holy Goblet is stolen and taken to
Dragonia, the castle of doom, it appears that all hope is lost for
the world. As Trykaar, you represent the last hope for mankind
against Dragonia’s evil inhabitants. Your quest is to search
Dragonia’s randomly generated levels, battle its minions and
retrieve the Holy Goblet. With success comes the eradication
of this threat as you acquire the Holy Goblet and return it to its
rightful place. Dragonia’s victory spells the end of all that is good
and holy. You cannot let Dragonia’s minions succeed!
Control the direction.
Start game. Pause and un-pause game.
Pick up an item while on top of it.
Leave the inventory screen.
Open up your inventory screen. Confirm a selection and leave the screen.
No function.
No function.
No function.
NOTE: To fight a monster, simply run into it.

15
14
Game title: Golden Axe III
MENU TITLE: GOLDEN AXE III
After a stinging defeat in Golden Axe II, the evil lord
Dark Guld has regrouped and has come for revenge!
Stealing the powerful Golden Axe, a symbol of peace and
prosperity, the Dark Guld wants to see the world revert
to chaos. Once again, three warriors, including a fierce
barbarian, a ferocious Amazon, and a fearless dwarf are
willing to risk their lives to put a stop to the terror. It's time
to start the long journey through enemy-infested territory.
Fight onward until you reach the final showdown, a battle
with Dark Guld himself!
Control the direction.
Start game. Pause and un-pause game.
Use magic.
Attack.
Jump.
No function.
No function.
No function.
Game title: Jewel Master
MENU TITLE: JEWEL MASTER
The peaceful kingdom of Mythgard seemed blessed for all
time. Then the Demon King, Jardine the Mad, came to power
and it seemed that all good was gone forever. Jewel Master,
weaver of the Elements, was summoned to possess magical
rings of great power and to use these rings to conjure spells
with which to defeat the legions of Evil. As the Jewel Master,
you must seek out the remaining rings, reclaim the Elemental
Blade, and strike down Jardine the Mad. Only by wielding the
Elemental Blade can Mythgard be restored to its former glory!
Control the direction.
Start game. Pause and un-pause game.
Empty your hands in Pause menu. Reset the ring.
Attack using your Left hand.
Attack using your Right hand.
Jump. Select the ring in the Pause menu.
No function.
No function.
No function.
Long press for attack upward.
Game title: Golden Axe
MENU TITLE: GOLDEN AXE
It is a dark time in the Land of Yuria as the evil Death Adder
has invaded, kidnapped the princess and seized the Golden
Axe. Devastation alone lays in his wake. Three powerful
heroes, each with distinct fighting styles, have emerged in a
desperate bid to bring justice to Yuria and free the princess.
It will take all of the brawn and magic they can muster just to
stand a chance of defeating Death Adder! They vow to save
the princess or die trying! The rest is up to you.
Control the direction.
Start game. Pause and un-pause game.
Use magic.
Attack.
Jump.
No function.
No function.
No function.
Game title: Golden Axe II
MENU TITLE: GOLDEN AXE II
Vanquished in Golden Axe I, the Death Adder has been
defeated by our heroes. Unfortunately, another evil force,
known as the ‘Dark Guild’, has risen to take his place. With
the Golden Axe now in the Dark Guild’s possession, our
three heroes are once again called in to action to retrieve the
Golden Axe for mankind. To meet this new challenge, they
must use all of their unique fighting skills and spells to save
the land from chaos. Fighting has never been so much fun!
Control the direction.
Start game. Pause and un-pause game.
Use magic.
Attack.
Jump.
No function.
No function.
No function.

17
16
Game title: Phantasy Star II
MENU TITLE: PHANTASY STAR II
Set in a futuristic world, the people of the planet Mota
engage in experiments to make biomechanical creatures.
While most of the experiments resulted in useful creatures
that serve the people, one was made that posed a great
danger to Mota. As this disaster struck, the signal for help
came from the experimental labs, summoning you to action.
With the aid of a few fellow fighters you begin an adventure
that starts with a simple mission but you soon discover that
the fate of the entire planet is at stake!
Control the direction.
Start game. Pause and un-pause game.
Use magic.
Cancel the selected item.
Enter the menu. Confirm the selected item.
No function.
No function.
No function.
Game title: Ristar
MENU TITLE: RISTAR
Greedy, an evil tyrant, has one goal in mind: control all the
planets of the solar system. With only one planet left, Greedy
believes he is near the end of his quest. The only holdout
from Greedy’s relentless onslaught was guarded by a mighty
hero. When Greedy managed to capture this protector,
Greedy thought his work was done. That was when Ristar, the
son of the hero, emerged to stop Greedy, rescue his father
and save the solar system. Action and puzzles await in this
inter-stellar adventure!
Control the direction.
Start game. Pause and un-pause game.
Jump.
Grab. Attack.
Jump.
No function.
No function.
No function.
Long press for attack upward.
Game title: Kid Chameleon
MENU TITLE: KID CHAMELEON
When his friends get sucked into a virtual reality game and
can’t escape, it is up to Kid Chameleon to enter the game
himself and save the day! Using his ability to change his
shape into various other forms, Kid Chameleon must do
battle against his foes. Each form adds a special ability which
must be used to pass each of the game's stages. With over
100 levels of gameplay, you will find plenty of challenges on
your quest. Your friends are depending on you, so it’s time to
get in the game!
Control the direction.
Start game. Pause and un-pause game.
Run.
Jump.
Use weapon if available.
No function.
No function.
No function.
Game title: Phantasy Star III: Generations of Doom
MENU TITLE: PHANTASY STAR III
After an ancient battle between the people of Orakio and Laya,
peace reigned for a thousand years across the entire planet.
The victorious Orakians were ruled by the young prince Rhys.
Upon the day of his wedding, the prince’s enemies emerged
from the shadows and kidnapped his bride. Devastated, Rhys
began his epic quest to learn the identity of the kidnappers
and find his beloved Maya. Deep down, Rhys knows that
only the Layans would attempt such a crime. Rhys must be
victorious in battle against his newfound enemies and reclaim
his bride or global war will begin once more!
Control the direction.
Start game. Pause and un-pause game.
Use magic.
Cancel the selected item.
Enter the menu. Confirm the selected item.
No function.
No function.
No function.

19
18
Game title: Sonic & Knuckles
MENU TITLE: SONIC AND KNUCKLES
Dr. Robtnik is back and he is after the Master Emerald. If he
can get his hands on it, he knows that he can fuel his ultimate
weapon, the Death Egg, forever. With this power, Dr. Robtnik
can destroy the floating island and with it his enemies, Sonic
and Knuckles. In order to save the island and themselves,
Sonic and Knuckles must find the Master Emerald before
Robotnik and his henchmen.
Control the direction.
Start game. Pause and un-pause game.
Jump. Hold direction control down to start spinning, then tap
the button repeatedly to rev up your spin. Release the direction
control to dash away like a road rocket. As Knuckles, press button
twice quickly to get some air and start gliding. When close to
a wall, press button twice quickly, then move with the direction
control. Press button to jump off.
No function.
No function.
No function.
Game title: Sonic Spinball
MENU TITLE: SONIC SPINBALL
Dr. Eggman (AKA Dr.Robotnik) has taken over Mt. Mobius and
turned it into a mechanical base. He is using energy from the
magma flowing under the volcano to power his Veg-O-Fortress.
He has the power to transform helpless animals into robot slaves.
Sonic the Hedgehog and Tails must take down this fortress to
free the enslaved animals. The only way to make that happen is
to trigger an eruption in the volcano it's built on. Sonic knows
this can be done by removing the Chaos Emeralds that keep the
volcano stable. Dr. Eggman, however, is also aware of the fragile
relationship that exists between the Emeralds and the mountain,
and he's set up an elaborate Pinball Defense System to make
sure the precious jewels don't go anywhere.
Control the direction.
Start game. Pause and un-pause game.
Left Flipper.
Right Flipper.
Both Flippers.
No function.
No function.
No function.
Game title: Shadow Dancer: The Secret of Shinobi
MENU TITLE: SHADOW DANCER
Union Lizard, a vast crime empire, has taken over New York.
As Shadow Dancer, a master of martial arts, you must do
battle in the name of justice. Using all of your kung-fu skills
and the help of your faithful dog, it is up to you to stop the
evil Ninjas of Union Lizard once and for all and regain the
honor of a slain friend. Once New York is safe, you must fight
the mighty Lizard King himself to achieve ultimate victory!
Control the direction.
Start game. Pause and un-pause game.
Use the master skill.
Attack. Long press to send dog fighting with Shadow Dancer.
Jump.
No function.
No function.
No function.
Game title: Shinobi III: Return of the Ninja Master
MENU TITLE: SHINOBI III
After their utter annihilation in Shinobi II, the Neo Zeed
leaders are secretly rebuilding their evil organization.
Shinobi senses their powers growing and he knows that it is
up to him to stop them again. Neo Zeed’s minions have been
ordered to stop Shinobi at all costs. The stakes are high,
and as Joe Musashi – Shinobi – you know that unless you
succeed, the world will fall into the clutches of Neo Zeed!
You must not fail!
Control the direction.
Start game. Pause and un-pause game.
Use the master skill.
Attack.
Jump.
No function.
No function.
No function.
A B C

21
20
Game title: The Ooze
MENU TITLE: THE OOZE
As a scientist you deal with chemicals all day long, but one
day, the worst sort of thing happens: your boss creates a
compound that turns you into a puddle of thick green goop
and you get flushed down the drain! Thankfully you have
some newfound abilities that come with your transformation
which will help you make your way back to the lab so that
you can be restored to humanity. Solve puzzles and fight
enemies along the way to prevent your boss from taking
over the world!
Control the direction.
Start game. Pause and un-pause game.
Attack with your body.
Attack with green balls.
No function.
No function.
No function.
No function.
Game title: Vectorman
MENU TITLE: VECTORMAN
In the distant future, all of man's chores are done by
thankless robots. When the leader of the robots accidentally
has his head replaced with a bomb, he decides that now is
the time for the robots to rise up and take control! All the
robots are ordered to stop their work and immediately start
making weapons for the take-over. The only robot unaffected
is the barge pilot Vectorman who was out of range during
the switch. Now this pilot is the sole hope of humanity and
he sets out to destroy the evil leader known as Warhead! The
fate of the planet is at stake!
Control the direction.
Start game. Pause and un-pause game.
Attack.
Attack.
Jump.
No function.
No function.
No function.
Game title: Sonic the Hedgehog
MENU TITLE: SONIC THE HEDGEHOG
Sonic the Hedgehog is a side scrolling race to save Sonic’s
animal friends, who have been captured by the evil Dr.
Robotnik. Using great speed and a spin attack, Sonic brings
plenty of attitude, looping, jumping, and super-speed
fun. Sonic the Hedgehog is one of the fastest and most
entertaining games you can find! Save Sonic’s friends, with
special 3-D levels providing an amazing bonus!
Control the direction.
Start game. Pause and un-pause game.
Jump.
Jump.
Jump.
No function.
No function.
No function.
Game title: Sonic the Hedgehog 2
MENU TITLE: SONIC THE HEDGEHOG 2
Sonic is back and once again he must face the evil Dr.
Robotnik and stop his attempt to conquer the world. In order
to achieve his goal, Dr. Robotnik captures all of the animals
he can find and transforms them into robots to do his
bidding. Sonic must defeat Dr. Robotnik and save his friends.
The action has never been more fast or furious than this!
Control the direction.
Start game. Pause and un-pause game.
Jump.
Jump.
Jump.
No function.
No function.
No function.

23
22
Game title: Shining Force II: The Ancient Seal
MENU TITLE: SHINING FORCE II
As a student of Astral the wizard, you and your friends study
all the usual subjects: reading, writing, and sword fighting.
As your time at school draws to an end, dark events are
taking place on the island of Grana. The two jewels that
seal the Door to Darkness have been stolen, allowing a
creature of awesome power to be unleashed. Finding where
the Jewels were taken, and why, is a task only the bravest
adventurers can undertake.
Control the direction.
Start game.
Confirm. Menu.
Cancel.
Confirm. Talk. Inspect.
No function.
No function.
No function.
Game title: Super Thunder Blade
MENU TITLE: SUPER THUNDER BLADE
A renegade army has focused its sights on domination of the
free world, and has unleashed its deadly troops from a secret
power base in the East. Use the state-of-the-art defense
system at your fingertips - the Super Thunder Blade - to find
the central enemy base and blow it sky high.
Control the direction.
Start game. Pause game.
Shoot.
Hover.
Shoot.
No function.
No function.
No function.
Game title: Virtua Fighter 2
MENU TITLE: VIRTUA FIGHTER 2
The call for the greatest fighters in the world has once again
been issued! The World Fighting Tournament is back with
greater fighters, more special moves and greater numbers of
spectacular locations in which to do battle. The champions of
the first tournament are back with some new faces as well. You
must use all of your skills to survive the challenges that await!
Control the direction.
Start game. Pause and un-pause game.
Defense.
Punch.
Kick.
No function.
No function.
No function.
Game title: Shining Force: The Legacy of Great Intention
MENU TITLE: SHINING FORCE
The land of Rune, in the kingdom of Guardiana, has been
at peace for centuries, until the hordes of Runefaust attack.
Now, the evil force of Runefaust are spotted near the Gate of
the Ancients. As a young swordsman of Guardiana, find out
what Runefaust is after, stop their ambition, and bring back
peace to the land of Rune.
Control the direction.
Start game.
Confirm. Menu.
Cancel.
Confirm. Menu.
No function.
No function.
No function.

25
24
Game title: Jack's Pea
MENU TITLE: JACK'S PEA
Two green platforms are floating in the air (one higher and
one lower) and moving from one side to another. The player
is always on the lower one and has to jump onto the upper
platform when the two platforms are almost overlapping in
the vertical direction. When a certain amount of jumps are
reached, the player enters the next level. Each time a level
is passed, the platforms move faster. If the player does not
land on any platform, the player will fall into the abyss and
lose a life. When all 3 lives are lost, the game is over.
Control the direction.
Start game. Pause and un-pause game.
Jump up.
No function.
No function.
Game title: Jewel Magic
MENU TITLE: JEWEL MAGIC
When the game starts, 3 vertical jewels appear on the screen
and drop down vertically. The player can control the jewels
to land in the appropriate places, and if there are three or
more jewels that have the same color and pattern in the
horizontal, vertical, or diagonal direction, these jewels will
blow up and disappear, and the player will be rewarded with
points. When the score reaches a certain value, the level is
passed, and the jewels will start to drop faster. If the piled up
jewels reach the top of the screen, the game is over.
Control the direction.
Start game. Pause and un-pause game.
Change the stack sequence of the dropping jewels.
No function.
No function.
Make the jewels drop faster.
Game title: Adventure in the Park
MENU TITLE: ADVENTURE IN PARK
There are 5 total levels in this game. The player is required
to collect all keys on a level within a limited time, then
unlock the lock to save the hostage and move onto the next
level. The player has 3 lives. When touched by a monster,
the player loses one life. The game is over when all lives are
lost. The player may shoot the monsters. There are many
treasures scattered in the game: some may add score, some
may lengthen the game time, and some may add a life.
Control the direction.
Start game. Pause and un-pause game.
Shoot bullets.
No function.
No function.
Game title: Cross the Road
MENU TITLE: CROSS THE ROAD
In this game, the player needs to control the dogs at the
bottom of the screen to cross the busy street within a limited
time and arrive at the cabins on the opposite side of the
street without being run over. Dogs can jump onto the roof
of cars and move with it. Whenever all 3 dogs have arrived
in cabins, one level (out of 10) is passed. Each time you pass
a level, the speed and quantity of cars is increased. A dog
loses a life if it is hit by a car or enters a non-vacant cabin.
When all of the 4 lives are lost, the game is over.
Control the direction.
Start game. Pause and un-pause game.
Control dog to jump a step forward.
Control dog to jump onto the roof of a car.
No function.
ARCADE GAMES

27
26
Game title: Bubbles Master
MENU TITLE: BUBBLES MASTER
In this game, a string of colored beads moves along a track
towards a skull. When the beads reach the skull, the hole
under the skull will open and the beads fall down. When this
occurs, the player loses one life. After all 3 lives are lost, the
game is over. The player can release beads in different colors
onto the string. Any time when there are 3 or more successive
same-colored beads, they will blow up and disappear,
and the two sections of the broken string will connect up
automatically. The player wins the game when all of the beads
blow up and disappear. The player will get bonus points if
gold coins appear on the screen and are hit with a bead.
Some beads have special properties, like making the bead
string go slower.
Control the direction.
Start game. Pause and un-pause game.
Release beads.
Cycle the jewels.
No function.
Game title: Break the Fireline
MENU TITLE: BREAK THE FIRELINE
In this game, the player controls a plane that must destroy
the enemy’s planes, while at the same time, evade enemy
bullets and crashing into their planes. If shot or rammed
by enemy planes, the player’s plane will explode. After all
3 lives are lost, the game is over. If all the enemy planes on
the screen are destroyed, the player passes the level. Each
time the player passes a level, the enemy’s bullets speed up.
Treasures may be released after some enemy planes have
been destroyed. Catching these treasures may strengthen
bullets or destroy certain enemy planes.
Control the direction.
Start game. Pause and un-pause game.
Shoot bullets.
No function.
No function.
Game title: Curling 2010
MENU TITLE: CURLING 2010
The player and the computer are positioned at the opposite
sides of the table with 5 balls each. Whoever throws all of
the 10 balls to the other end first or has fewer balls left when
the time is up wins the game, and enters the next round. The
player must avoid the balls thrown from the other side. If
struck by a ball, the player will be dazed for a while.
Control the direction.
Start game. Pause and un-pause game.
Throw a ball.
No function.
No function.
Game title: Plumbing Contest
MENU TITLE: PLUMBING CONTEST
In this game, the player needs to select proper pipes and
connect the start and end points on the screen within a
limited time; otherwise, the game is over.
Control the direction.
Start game. Pause and un-pause game.
Change types of pipes.
No function.
No function.
Game title: Wall-Breaking
MENU TITLE: WALL-BREAKING
The player must destroy all of the 20 enemy tanks to enter
the next level. When an enemy tank is destroyed, treasures
will appear. These treasures may add an additional life,
increase bullet power, add a shield, or even add bombs. If
all of the player's lives are destroyed by enemy tanks, the
game is over.
Control the direction.
Start game. Pause and un-pause game.
Shoot bullets.
No function.
No function.

29
28
Game title: Memory
MENU TITLE: MEMORY
Move the pointing cursor to a face-down tile, and press
A button to flip it over. When 2 identical tiles are opened
they will be removed from the board. The game is finished
when all pairs of tiles have been removed from the board.
4 levels can be selected at the beginning. 4, 6 or 8 tiles can
be opened at one time in different levels. Fewer tiles can be
opened in higher levels.
Control the direction.
Start game.
Press to start the game. Press to confirm the tile selection.
Start game.
Quit current game.
Game title: Snake
MENU TITLE: SNAKE
Score points and pass levels by having the snake eat magic
berries in the playing area while avoiding the snake's tale and
walls. Each time the snake eats a piece of food, its tail grows
longer. The level is completed when all the items are collected.
Control the direction.
Start game.
Start game. Play game. Exit game.
Start game. Exit game.
No function.
Game title: Air Hockey
MENU TITLE: AIR HOCKEY
Use the directional pad to strike the puck toward the goal
or to defend your table’s side. You can play against the
computer using the 1-Player Mode or challenge a friend
using 2-Player Mode. Whoever achieves seven goals first is
the winner!
Control the direction.
Start game. Pause and un-pause game.
Select the game and game mode.
Select the game and game mode.
Select the game and game mode.
Select the game and game mode.
Game title: Mahjong Solitaire
MENU TITLE: MAHJONG SOLITAIRE
The object of the game is to clear the playing area of tiles
by matching pairs of tiles. The player can remove only those
matching pairs of tiles where each tile has at least one side
(left or right) free and no other tiles placed on top. Matching
tile pairs can be removed by clicking on each tile in the pair.
Control the direction.
Start game.
Start game and select.
Back. Start game.
Quit current game.
Game title: Warehouse Keeper
MENU TITLE: WAREHOUSE KEEPER
The goal of this game is to place all boxes with goods onto
their designated spots in a warehouse. The player should
push boxes to the spots marked with crosses. Only one box
at a time can be moved and it cannot be pulled. Push boxes
to the right places to beat the stage.
Control the direction.
Start game.
Enter the game. Press to mark current stage as completed.
Press again to enter next stage.
Press to mark current stage as failed. Press again to restart current stage.
No function.
Game title: Chess
MENU TITLE: CHESS
Chess is a game played between two opponents on opposite
sides of a board containing 64 squares of alternating colors.
Each player has 16 pieces: 1 king, 1 queen, 2 rooks, 2
bishops, 2 knights, and 8 pawns. The goal of the game is to
checkmate the other king. Checkmate happens when the
king is in a position to be captured (in check) and cannot
escape from capture.
Control the direction.
Start game. Or invoke the menu in game.
Take or place a piece.
Reverse move.
Menu.

31
30
Game title: Cannon
MENU TITLE: CANNON
The arrow in the middle of the screen indicates the direction
and strength of the wind. Pay attention to the wind because
it can influence the missile trajectory. If you are lucky, maybe
there will be no wind to worry about! You can play against
the computer or challenge a friend.
Control the direction.
Start game. Pause and un-pause game.
Select the angle. Press again to select the power and fire.
Select the angle. Press again to select the power and fire.
Select the angle. Press again to select the power and fire.
Game title: Fight or Lose
MENU TITLE: FIGHT OR LOSE
In this game, the player controls the knight and needs to
capture all the pawns. The movement follows chess rules.
The knight moves 2 squares in one direction and 1 square in
the other. Every time the horse moves, the pawns move one
step forward. If one of the pawns manages to reach the end
of the board, the player loses. If all the pawns are captured,
the player receives one point and goes to the next level!
Control the direction.
Start game.
Play game. Select or Move and capture the pawns.
Play game. Select or Move and capture the pawns.
Play game. Select or Move and capture the pawns.
Game title: Bottle Taps Race
MENU TITLE: BOTTLE TAPS RACE
Use your skill to move your little tap through the sand track.
On the track selection menu you can see the number of turns
and the track length. On each round the taps are moved in
sequence. Be careful not to run outside the track, or your tap
will be returned to the spot where it was moved from. The
one to complete all the laps first will be the winner.
Change the direction.
Start game. Pause and un-pause game.
Confirm the direction. Press again to select the power.
Confirm the direction. Press again to select the power.
Confirm the direction. Press again to select the power.
Game title: Spider
MENU TITLE: SPIDER
You must protect your cake from the arachnid invasion! You
have a pesticide which will help you keep the spiders away
from the cake.
Aim your target.
Start game. Pause and un-pause game.
Start game and get into instruction. Play game. Fire.
Start game and get into instruction. Fire.
Start game and get into instruction. Fire.
Game title: Naval Power
MENU TITLE: NAVAL POWER
Command your squad in a life or death battle! Sink all of the
opponent’s ships to win.
Select your target.
Start game. Pause and un-pause game.
Fire.
Fire.
Fire.
Game title: Mr. Balls
MENU TITLE: MR. BALLS
Mr. Balls and his brothers got caught in a mysterious machine!
Your mission is to free all of them. The problem is that the
machine has a strange rule. When you release or lock one of
them, those which are to the left, right, above, or below, switch
their state, meaning that if they were unlocked they become
locked, and if they were locked they become unlocked. There
are many levels to be solved, including one which is random.
Control the direction.
Start game. Pause and un-pause game.
Start game and see instructions. Lock or unlock.
Start game and see instructions. Lock or unlock.
Start game and see instructions. Lock or unlock.
Choose the initial shape. Back to the game menu.

33
32
Game title: Hexagonos
MENU TITLE: HEXAGONOS
There are two things you can do: jump and duplicate. The
stone is duplicated when it is moved to a neighboring
hexagon. Move your piece next to your opponent's piece to
make their piece become yours. Whoever has more stones
when there are no more possible moves, wins.
Control the direction.
Start game. Pause and un-pause game.
Select the piece you want to move.
Press again to select and confirm the movement.
Cancel the movement.
Cancel the movement.
Game title: Whack A Wolf
MENU TITLE: WHACK-A-WOLF
Use direction pad to hit the wolf.
Control the direction.
Start game.
Play game.
Exit game.
No function.
Game title: Mirror Mirror
MENU TITLE: MIRROR MIRROR
Uncover the hidden letter using the direction control and
compare it to the square next to it to find a match.
Control the direction.
Start game.
Play game. Select the pane.
Exit game.
No function.
Game title: Bomber
MENU TITLE: BOMBER
Blow up your enemies! But be careful to not explode the
items or yourself. Collect cool bomb upgrades that can allow
you to drop more than one bomb at a time or give you a
bigger explosion, thus allowing you to destroy more blocks
and enemies.
Control the direction.
Start game. Pause and un-pause game.
Place bombs.
No function.
No function.
Game title: Checker
MENU TITLE: CHECKER
Checker is composed of 1 board and 32 pieces. It is for only
one player, and the goal is to leave just one piece on the
center of the board. There are several initial positions for the
pieces; the most common one is the one which has all holes
occupied except the one in the center. The capture is made
by having one piece jump over another. Each time one piece
jumps over another, the one that is jumped over is removed
from the board. Pieces can only be captured in a straight
line, which means no diagonal jumps. The game proceeds
until it becomes impossible to capture another piece.
Control the direction.
Start game. Pause and un-pause game.
Select the piece to be moved or to cancel the selected piece.
Select the piece to be moved or to cancel the selected piece.
Select the piece to be moved or to cancel the selected piece.
Game title: Skeleton Scale
MENU TITLE: SKELETON SCALE
Use the direction control to figure out and delete the
unnecessary number to make the scales weigh the same.
Control the direction.
Start game.
Play game. Delete unnecessary number.
Exit game.
No function.

35
34
Game title: Brain Switch
MENU TITLE: BRAIN SWITCH
Use the direction pad to indicate if the combination of vowel
and even number is correctly shown.
Control the direction.
Start game.
Play game.
Exit game.
No function.
Game title: Mega Brain Switch
MENU TITLE: MEGA BRAIN SWITCH
Confirm the number (left side) or letter (right side)
combination matches the category it is placed into.
Move left to select No or right to select Yes.
Start game.
Play game.
Exit game.
No function.
Game title: Hidden Agenda
MENU TITLE: HIDDEN AGENDA
Determine the underlying rule according to the series
of images on the screen. Answer “Follow the Rule” if you
believe the current image follows the rule, and answer
“Does Not Follow the Rule” if otherwise. For example, if the
underlying rule is the color red, then red images
match the underlying rule. The rules can be:
Color: Blue, Green, Red. Shade: Empty, Full, Gradient Color.
Shape: Dog, Rabbit, Ox, Cat. Quantity: 1, 2 or 3.
Control the direction.
Start game.
Play game.
Exit game.
No function.
Game title: Panic Lift
MENU TITLE: PANIC LIFT
Help the customers to get to the right floor when the correct
floor is reached.
Control the direction.
Start game.
Play game. Select the floor.
Exit game.
No function.
Game title: Black Sheep
MENU TITLE: BLACK SHEEP
Look at the sheep in the center of the screen and use the
direction pad to lead the sheep to the direction it is turned to.
Control the direction.
Start game.
Play game.
Exit game.
No function.
Game title: Flash Memory
MENU TITLE: FLASH MEMORY
When the numbers are shown, remember their location. Using
direction pad, indicate the sequence in increasing order.
Control the direction.
Start game.
Play game. Select.
Exit game.
No function.

37
36
Game title: Jura Formula
MENU TITLE: JURA FORMULA
Using direction control, indicate if two given numbers have
the same (=), bigger (>) or smaller (<) value.
Control the direction.
Start game.
Play game.
Exit game.
No function.
Game title: Lost World Sudoku
MENU TITLE: LOST WORLD SUDOKU
Solve the puzzle by filling all the blank squares in a game
with the correct numbers: Every row of 9 numbers must
include all digits 1 through 9 in any order. Every column of
9 numbers must include all digits 1 through 9 in any order.
Every 3 by 3 subsection of the 9 by 9 square must include all
digits 1 through 9.
Control the direction.
Start game.
Play game. Select.
Exit game.
No function.
Game title: Meatloaf Rotation
MENU TITLE: MEATLOAF ROTATION
Press the A button to rotate the squares and place the
number in the right order. Press the C button to retry.
Control the direction.
Start game.
Play game. Select.
Exit game. back to the game menu.
Retry. Give up.
Game title: Dinosaur Puzzle
MENU TITLE: DINOSAUR PUZZLE
Confirm the color on the right based on the name on the left
in this dino-themed puzzler.
Move left to select No or right to select Yes.
Start game.
Play game.
Exit game.
No function.
Game title: Dominant Amber
MENU TITLE: DOMINANT AMBER
Within given time, select with direction control button “UP”
or “DOWN” to indicate which color more dominates the
given square.
Control the direction.
Start game.
Play game.
Exit game.
No function.
Game title: Hide and Seek
MENU TITLE: HIDE AND SEEK
Follow the dinosaur eggs and find the hidden dinosaur babies.
Control the direction.
Start game.
Play game. Select.
Exit game.
No function.
