Sega SONIC DASH EXTREME User manual

IMPORTANT
• Before using this product, read this manual carefully to understand the
contents herein stated.
• After reading this manual, be sure to keep it near the product or in a
convenient place for easy reference when necessary.
OWNER'S MANUALSONIC DASH EXTREME ARCADE 420-0024-01UK
Sega Amusements International Limited.
42 Barwell Business Park, Leatherhead Road, Chessington, Surrey, KT9 2NY. United Kingdom.
Telephone: [phone] Facsimile: [phone]
email: [email protected] Web: http://www.segaarcade.com
© SEGA
420-0024-01UK
1st PRINTING

BEFORE USING THE PRODUCT, BE SURE TO READ THE FOLLOWING:
To maintain safety:
To ensure the safe operation of this product, be sure to read the following before usage.
The following instructions are intended for the users, operators and the personnel in charge of the
operation of the product. After carefully reading and sufficiently understanding the warning displays
and cautions, handle the product appropriately. Be sure to keep this manual close to the product or
in a convenient place for future reference.
Herein, explanations which require special attention are enclosed with dual lines. Depending on
the potentially hazardous degrees, the terms of DANGER, WARNING, CAUTION, etc. are used.
Be sure to understand the contents of the displays before reading the text.
Indicates that mishandling the product by disregarding this pictograph will
cause severe injury or death.
Indicates that mishandling the product by disregarding this warning will cause
a potentially hazardous situation which can result in death or serious injury.
Indicates that mishandling the product by disregarding this caution will cause
a slight hazardous situation which can result in personal injury and/or material
damage.
For the safe usage of the product, the following pictographs are used:
Indicates "HANDLE WITH CARE." In order to protect the human body and equipment,
this display is attached to places where the instruction manual should be referred to.
Indicates a "protective earth terminal." Before operating the equipment, be sure to connect
it to the ground.
(The step may be omitted for products in which a power cable with earth is used.)
• Perform work in accordance with the instructions herein stated.
Instructions for work are explained by paying attention to the aspect of accident prevention.
Failing to perform work as per the instructions can cause accidents. In the case where only
those who have technical expertise should perform the work to avoid hazardous situation, the
instructions herein state that the site maintenance personnel should perform such work.
• Be sure to turn off the power before working on the machine.
To prevent an electric shock, be sure to turn off the power and unplug the power cable before
carrying out any work that requires direct contact with the interior of the product. If the work is
to be performed in the power-on status, the instruction manual herein always states to that effect.
• Be sure to ground the earth terminal.
(This is not required in the case where a power cable with earth is used.)
This product is equipped with the earth terminal. When installing the product, connect the earth
terminal to the "accurately grounded indoor earth terminal" by using an earth wire. Unless the
product is grounded appropriately, the user can be subject to an electric shock. After performing
repair, etc. for the control equipment, ensure that the earth wire is firmly connected to the control
equipment.
• Ensure that the power supply used is equipped with an earth leakage breaker.
Using a power supply which is not equipped with the earth leakage breaker can cause a fire when
earth leakage occurs.
• Be sure to use fuses which meet the specified rating.
(Only for the machines which use fuses.)
Using fuses exceeding the specified rating can cause a fire and an electric shock.

• Specification changes (removal of equipment, conversion and addition) not
designated by SEGA are not allowed.
The parts of the product include warning labels for safety, covers for personal protection, etc. It
is very hazardous to operate the product by removing parts and/or modifying the circuits. Should
doors, lids and protective parts be damaged or lost, refrain from operating the product, and
contact where the product was purchased from or the office herein stated.
SEGA shall not be held responsible for any accidents, compensation for damage to a third party,
resulting from the specifications not designated by SEGA.
• Ensure that the product meets the requirements of appropriate electrical
specifications.
Before installing the product, check for electrical specifications. SEGA products have a
nameplate on which electrical specifications are described. Ensure that the product is compatible
with the power supply voltage and frequency requirements of the location. Using any electrical
specifications different from the designated specifications can cause a fire and an electric shock.
• Install and operate the product in places where appropriate lighting is available,
allowing warning labels to be clearly read.
To ensure safety for the customers, labels and printed instructions describing potentially
hazardous situations are applied to places where accidents can be caused. Ensure that where the
product is operated has sufficient lighting allowing the warnings to be read. If any label is peeled
off, apply it again immediately. Please place an order with where the product was purchased from
or the office herein stated.
• When handling the monitor, be very careful.
(Applies only to products with monitors.)
Some of the monitor parts are subject to high tension voltage. Even after turning off the power,
some portions are still subject to high tension voltage sometimes. Monitor repair and replacement
should be performed only by those technical personnel who have knowledge of electricity and
technical expertise.
• Be sure to adjust the monitor properly.
(Applies only to products with monitors.)
Do not operate the product leaving on-screen flickering or blurring as it is. Using the product
with the monitor not properly adjusted may cause dizziness or a headache to an operator, a
player, or the customers.
• When transporting or reselling this product, be sure to attach this manual to the
product.
* In the case where commercially available monitors and printers are used in this product, only the
contents relating to this product are explained herein. Some commercially available equipment
has functions and reactions not stated in this manual. Read this manual together with the specific
instruction manual of such equipment.
* Descriptions herein contained may be subject to improvement changes without notice.
* The contents described herein are fully prepared with due care. However, should any question
arise or errors be found, please contact SEGA.
INSPECTIONS IMMEDIATELY AFTER TRANSPORTING THE PRODUCT TO THE LOCATION
Normally, at the time of shipment, SEGA products are in a status allowing for usage immediately
after transporting to the location. Nevertheless, an irregular situation may occur during
transportation. Before turning on the power, check the following points to ensure that the product
has been transported in a satisfactory status.
Are there any dented portions or defects (cuts, etc.) on the external surfaces of the cabinet?
Are casters and adjusters damaged?
Do the power supply voltage and frequency requirements meet with those of the location?
Are all wiring connectors correctly and securely connected? Unless connected in the correct way,
connector connections can not be made accurately. Do not insert connectors forcibly.
Do power cables have cuts and dents?
Are all accessories available?
Can all doors and lids be opened with the accessory keys? Can doors and lids be firmly closed?

INTRODUCTION
iii
INTRODUCTION
This manual is intended to provide detailed descriptions together with all necessary information covering the general
operation of electronic assemblies, electro-mechanicals, servicing control, spare parts, etc. for the product,
"SONIC DASH EXTREME" Arcade
This manual is intended for the owners, personnel managers in charge of operation of this product.
Operate the product after carefully reading and sufficiently understanding the instructions.
In the unlikely event that the product does not function correctly, DO NOT allow anyone other than a technician
to touch the internal system. Turn off the power to the machine, making sure to unplug the electrical cord from the
outlet, and contact the office listed below or the point-of-purchase for this product.
Use of this product is unlikely to cause physical injuries or damage to property. However, points that require special
attention are indicated by bold text, the word “IMPORTANT” and the symbol below.
Indicates important information that, if ignored, may result in the mishandling
of the product and cause faulty operation or damage to the product.
Sega Amusements International Limited.
42 Barwell Business Park, Leatherhead Road, Chessington, Surrey, KT9 2NY. United Kingdom.
Telephone: [phone] Facsimile: [phone]
email: [email protected] Web: http://www.segaarcade.com
SPECIFICATIONS
Standard Cabinet
Machine Dimensions: 1,09m (42.9in.) [Width] x 1.70m (49.2in.) [Depth]
Machine Height: 2.6m (102.3.) (Installed)
Machine Weight: 159kg Approx (Installed)
Power, maximum current: AC115-240V 60~50Hz 1.1A (253W)

iv
INTRODUCTION
Parts replacement, maintenance inspections and troubleshooting should be carried out by site maintenance personnel
or other qualified professionals. This manual includes directions for potentially dangerous procedures which should
only be carried out by professionals with the appropriate specialised knowledge.
The site maintenance personnel or other qualified professionals mentioned in this manual are defined as follows:
Site maintenance personnel:
Individuals with experience in maintaining amusement equipment, vending machines, etc., working under the
supervision of the owner/operator of this product to maintain machines within amusement facilities or similar
premises by carrying out everyday procedures such as assembly, maintenance inspections, and replacement of units/
expendable parts.
Activities to be carried out by site maintenance personnel:
Amusement equipment/vending machine assembly, maintenance inspection and replacement of units/expendable
parts.
Other qualified professionals:
Persons employed by amusement equipment manufacturers, or involved in design, production, testing or
maintenance of amusement equipment. The individual should have either graduated from technical school or hold
similar qualifications in electrical/electronics/mechanical engineering.
Activities to be carried out by other qualified professionals:
Amusement equipment/vending machine assembly, repair/adjustment of electrical/electronic/mechanical parts.
Definition of 'Site Maintenance Personnel or Other Qualified Individuals
Definition of 'Site Maintenance Personnel or Other Qualified Individuals
Procedures not described in this manual or marked as ‘to be carried out by site
maintenance personnel or other qualified professionals’ should not be carried
out by personnel without the necessary skill or technology. Work carried out by
unqualified persons may cause serious accidents, including electrocution.

INTRODUCTION
v
Waste of Electrical and Electronic Equipment (WEEE) Statement.
Waste of Electrical and Electronic Equipment (WEEE) Statement.
The WEEE (Waste of Electrical and Electronic Equipment) directive places an obligation on all EU based
manufacturers and importers of Electrical and Electronic Equipment to take back products at the end of their
useful life. Sega Amusements Europe Ltd accepts its responsibility to finance the cost of treatment and recovery of
redundant WEEE in the United Kingdom in accordance with the specified WEEE recycling requirements.
The symbol shown below will be on all products manufactured from 13th August 2005, which indicates this product
must NOT be disposed of with other normal waste. Instead, it is the user’s responsibility to dispose of their waste
equipment by arranging to return it to a designated UK collection point for the correct recycling of waste electrical
and electronic equipment.
For more information about where you can send your waste equipment for recycling contact your local authority
office.
For non-UK users contact your local authority office for information on the recycling of Waste Electrical and
Electronic Equipment.
Battery Recycling Statement.
Battery Recycling Statement.
The EC Directive on Batteries and Accumulators (2006/66/EC) aims to minimise the impact of batteries on
the environment and encourage the recovery of the materials they contain. To achieve increased collection and
recycling of waste batteries, the Directive places ‘producer responsibility’ obligations on manufacturers and
importers of portable, industrial and automotive batteries.
The symbol shown below will be on all equipment fitted with batteries from 26th September 2008 and indicates
they must NOT be disposed of with other normal waste. Instead, it is the user’s responsibility to dispose of used
batteries by arranging to return them to a designated collection point for the correct recycling.
For more information about where you can send your waste batteries for recycling contact your local authority
office.
REGISTERED IN ENGLAND REGISTERED NO. 1711515
REGISTERED OFFICE: BLOCK C 42 BARWELL BUSINESS PARK, CHESSINGTON, SURREY KT9 2NY

MICROSOFT SOFTWARE LICENSE AGREEMENT
WINDOWS EMBEDDED 8 STANDARD
Thank you for choosing a device preinstalled with Windows Embedded 8 Standard. This is a license agreement between you and SEGA. This agreement describes your rights to use the
Windows Embedded 8 Standard software included on this device. The Windows Embedded 8 Standard software also includes any separate media on which you received the software. For
your convenience, we’ve organized this agreement into two parts. The first part includes introductory terms phrased in a question and answer format; the Additional Terms follow and contain
greater detail. You should review the entire agreement, including any linked terms, because all of the terms are important and together create this contract that applies to you. You can review
linked terms by pasting the forward link into your browser window once the software is running. The Additional Terms contain a binding arbitration clause and class action waiver. If
you live in the United States, these affect your rights to resolve a dispute with SEGA, or with Microsoft, and you should read them carefully.
By accepting this agreement or using the software, you agree to all of these terms and consent to the transmission of certain information for Internet-based features of the software.
If you do not accept and comply with these terms, you may not use the software or features. Instead, you may contact SEGA to determine its return policy for a refund or credit under
that policy.
How can I use the software? The software is licensed, not sold. Under this agreement, we grant you the right to install and run one copy only on the device with which you acquired the
software (the licensed device), for use by one person at a time, but only if you comply with all the terms of this agreement. The software is not licensed to be used as server software or for
commercial hosting – so, for example, you may not make the software available for simultaneous use by multiple users over a network. For more information on multiple user scenarios, see
the Additional Terms.
May I make a backup copy? Yes, you may make a single copy of the software for backup purposes, and use that backup copy as described below.
Can I transfer the software to another user? You may transfer the software directly to another user, only with the licensed device. The transfer must include the software, proof of pur-
chase, and, if provided with the device, an authentic Windows label such as the certificate of authenticity label, including the product key. You may not keep any copies of the software or any
earlier version. Before any permitted transfer, the other party must agree that this agreement applies to the transfer and use of the software.
Does the software collect my personal information? If you connect your licensed device to the Internet, some features of the software may connect to Microsoft or service provider com-
puter systems to send or receive information, including personal information. You may not always receive a separate notice when they connect. If you choose to use any of these features, you
agree to send or receive this information when using that feature. Many of these features can be switched off or you can choose not to use them.
How does Microsoft use your information? Microsoft uses the information it collects through the software features to upgrade or fix the software and otherwise improve its products and
services. In certain circumstances, Microsoft also shares it with others. For example, Microsoft shares error reports with relevant hardware and software vendors, so that the vendors can use
the information to improve how their products run with Microsoft products. You agree that Microsoft may use and disclose the information as described in Microsoft’s Privacy Statement at
go.microsoft.com/fwlink/?LinkId=190175.
What does this agreement apply to? The Windows Embedded 8 Standard software on this licensed device includes software licensed from Microsoft Corporation or its affiliate. This agree-
ment (including any printed-paper license terms that accompany the software) applies to the software, any separate media on which you received the software, and any Microsoft updates,
supplements, and services for the software, unless other terms come with them.
Are there things I’m not allowed to do with the software? Yes. Because the software is licensed, not sold, SEGA and Microsoft reserve all rights (such as rights under intellectual property
laws) not expressly granted in this agreement. In particular, this license does not give you any right to, and you may not: use features of the software separately; publish, copy (other than the
permitted backup copy), rent, lease, or lend the software; transfer the software (except as permitted by this agreement); attempt to circumvent technical protection measures in the software;
or reverse engineer, decompile, or disassemble the software, except if the laws where you live permit this even when this agreement does not. In that case, you may do only what your law al-
lows. When using Internet-based features , you may not use those features in any way that could interfere with anyone else’s use of them, or to try to gain access to any service, data, account,
or network in an unauthorized manner.
ADDITIONALTERMS
1. License Rights and Use Scenarios
a. Device. In this agreement, “device” means a hardware system with internal storage capable of running the software. The software is licensed to run on up to two
processors on the licensed device at any one time.
b. Specific Use. SEGA designed the licensed device for a specific use. You may only use the software for that use.
c. Other Software. You may use other programs with the software as long as the other programs
• directly support the specific use for the licensed device, or
• provide system utilities, resource management, or anti-virus or similar protection.
Software that provides consumer or business tasks or processes may not run on the licensed device. This includes word processing, spreadsheet, database,
scheduling and personal finance software. The licensed device may use terminal services protocols to access such software running on a server.
d. Device connections. You may not use the software as server software. In other words, more than one device may not access, display, run, share or use the soft
ware at the same time. You may allow up to 20 other devices to access the software installed on the licensed device for the purpose of using file services, print
services, Internet information services, and Internet connection sharing and telephony services on the licensed device. The 20 connection limit applies to devices
that access the software indirectly through “multiplexing” or other software or hardware that pools connections. You may use unlimited inbound connections at
any time via TCP/IP.
e. Remote Access Technologies. The software contains Remote Desktop and Remote Assistance technologies that enable the software or applications installed on
the licensed device to be accessed remotely from other devices.
• Remote Desktop. The single primary user of the licensed device may access a session from any other device using Remote Desktop or similar tech-
nologies. A “session” means the experience of interacting with the software, directly or indirectly, through any combination of input, output and display
peripherals. Other users, one at a time, may access the licensed software running on this host device, from any device using Remote Desktop, but only
if the remote device is separately licensed to run Windows Embedded 8 Standard.
• Remote Assistance. You may use Remote Assistance or similar technologies to share an active session without obtaining any additional licenses for the
software. Remote Assistance allows one user to directly connect to another user’s device, usually to correct problems.
2. Binding Arbitration and Class Action Waiver
a. Application. This Section 2 applies to any dispute EXCEPT IT DOES NOT INCLUDE A DISPUTE RELATING TO THE ENFORCEMENT OR VALIDITY
OF YOUR, SEGA’S, OR EITHER OF OUR LICENSORS’ INTELLECTUAL PROPERTY RIGHTS. Dispute means any dispute, action, or other controversy
between you and SEGA, or you and Microsoft, concerning the software (including its price) or this agreement, whether in contract, warranty, tort, statute,
regulation, ordinance, or any other legal or equitable basis. “Dispute” will be given the broadest possible meaning allowable under law.
b. Notice of Dispute. In the event of a dispute, you or SEGA must give the other a Notice of Dispute, which is a written statement of the name, address, and
contact information of the party giving it, the facts giving rise to the dispute, and the relief requested. Send it by U.S. Mail to SEGA, ATTN: LEGAL DEPART
MENT. SEGA will send any Notice of Dispute to your U.S. Mail address if available, or otherwise to your e-mail address. You and SEGA will attempt to
resolve any dispute through informal negotiation within 60 days from the date the Notice of Dispute is sent. After 60 days, you or SEGA may commence
arbitration.
c. Small claims court. You may also litigate any dispute in small claims court in your county of residence or the SEGA’s principal place of business, if the dispute
meets all requirements to be heard in the small claims court. You may litigate in small claims court whether or not you negotiated informally first.
d. Binding arbitration. If you and SEGA, or Microsoft, do not resolve any dispute by informal negotiation or in small claims court, any other effort to resolve the
dispute will be conducted exclusively by binding arbitration. You are giving up the right to litigate (or participate in as a party or class member) all disputes in
court before a judge or jury. Instead, all disputes will be resolved before a neutral arbitrator, whose decision will be final except for a limited right of appeal
under the Federal Arbitration Act. Any court with jurisdiction over the parties may enforce the arbitrator’s award.
e. Class action waiver. Any proceedings to resolve or litigate any dispute in any forum will be conducted solely on an individual basis. Neither you, SEGA, nor
Microsoft, will seek to have any dispute heard as a class action, as a private attorney general action, or in any other proceeding in which any party acts or pro
poses to act in a representative capacity. No arbitration or proceeding will be combined with another without the prior written consent of all parties to all af
fected arbitrations or proceedings.
f. Arbitration procedure. Any arbitration will be conducted by the American Arbitration Association (the “AAA”), under its Commercial Arbitration Rules.
If you are an individual and use the software for personal or household use, or if the value of the dispute is $75,000 or less whether or not you are an individual
or how you use the software, the AAA Supplementary Procedures for Consumer-Related Disputes will also apply. To commence arbitration, submit a Com
mercial Arbitration Rules Demand for Arbitration form to the AAA. You may request a telephonic or in-person hearing by following the AAA rules. In a dispute
involving $10,000 or less, any hearing will be telephonic unless the arbitrator finds good cause to hold an in-person hearing instead. For more information, see
adr.org or call 1-800-778-7879. You agree to commence arbitration only in your county of residence or in the SEGA’s principal place of business. SEGA agrees
to commence arbitration only in your county of residence. The arbitrator may award the same damages to you individually as a court could. The arbitrator may
award declaratory or injunctive relief only to you individually, and only to the extent required to satisfy your individual claim.
vi
MICROSOFT SOFTWARE LICENSE AGREEMENT

g. Arbitration fees and incentives
i. Disputes involving $75,000 or less. SEGA will promptly reimburse your filing fees and pay the AAA’s and arbitrator’s fees and expenses. If you
reject the SEGA’s last written settlement offer made before the arbitrator was appointed (“last written offer”), your dispute goes all the way to an
arbitrator’s decision (called an “award”), and the arbitrator awards you more than the last written offer, SEGA will give you three incentives: (1) pay
the greater of the award or $1,000; (2) pay twice your reasonable attorney’s fees, if any; and (3) reimburse any expenses (including expert witness
fees and costs) that your attorney reasonably accrues for investigating, preparing, and pursuing your claim in arbitration. The arbitrator will deter
mine the amounts.
ii. Disputes involving more than $75,000. The AAA rules will govern payment of filing fees and the AAA’s and arbitrator’s fees and expenses.
iii. Disputes involving any amount. In any arbitration you commence, SEGA will seek its AAA or arbitrator’s fees and expenses, or your filing fees it
reimbursed, only if the arbitrator finds the arbitration frivolous or brought for an improper purpose. In any arbitration SEGA commences, it will pay
all filing, AAA, and arbitrator’s fees and expenses. It will not seek its attorney’s fees or expenses from you in any arbitration. Fees and expenses are
not counted in determining how much a dispute involves.
h. Claims or disputes must be filed within one year. To the extent permitted by law, any claim or dispute under this agreement to which Section 2 applies must be
filed within one year in small claims court (Section 2.c) or in arbitration (Section 2.d). The one-year period begins when the claim or dispute first could be filed. If
such a claim or dispute is not filed within one year, it is permanently barred.
i. Severability. If the class action waiver in Section 2.e is found to be illegal or unenforceable as to all or some parts of a dispute, then Section 2 will not apply to those
parts. Instead, those parts will be severed and proceed in a court of law, with the remaining parts proceeding in arbitration. If any other provision of Section 2 is
found to be illegal or unenforceable, that provision will be severed with the remainder of Section 2 remaining in full force and effect.
j. Third-Party Beneficiary. Microsoft Corporation is not a party to this agreement but is a third-party beneficiary of your and the SEGA’s agreement to resolve disputes
through informal negotiation and arbitration. If your dispute is with Microsoft, Microsoft agrees to do everything SEGA agrees to do in Section 2, and you agree to
do everything regarding Microsoft that Section 2 requires you to do regarding SEGA. Mail a Notice of Dispute with Microsoft to Microsoft Corporation, ATTN:
LCA ARBITRATION, One Microsoft Way, Redmond, WA 98052-6399. You may commence an arbitration or small claims court case against Microsoft in your
county of residence or King County, Washington.
3. CHOICE OF LAW
The laws of the state or country where you live govern all claims and disputes under this agreement, including breach of contract claims and claims under state consumer protection laws, unfair
competition laws, implied warranty laws, for unjust enrichment, and in tort. If you acquired the software in any other country, the laws of that country apply. This agreement describes certain le-
gal rights. You may have other rights, including consumer rights, under the laws of your state or country. You may also have rights with respect to the party from whom you acquired the software.
This agreement does not change those other rights if the laws of your state or country do not permit it to do so.
4. INTERNET-BASED FEATURES; PRIVACY
The following software features use Internet protocols, which send to Microsoft (or its suppliers or service providers) device information, such as your Internet protocol address, the type of
operating system, browser and name and version of the software you are using, and the language code of the device where the software is installed. Microsoft uses this information to make the
Internet-based features available to you, in accordance with the Windows 8 Privacy Statement, at go.microsoft.com/fwlink/?LinkId=190175. Some Internet-based features may be delivered at a
later date via Microsoft’s Windows Update service—if, for example, you acquire an application that relies on one of those services. SEGA may have elected to turn on one or more of the follow-
ing features in the licensed device.
a. Windows Update. If you use the Windows Update service in the software, updates or downloads to the Windows Update service will be required for proper func
tioning of the service, from time to time, and will be downloaded and installed without further notice to you.
b. Windows Digital Rights Management technology. Some content owners use Windows digital rights
management technology (WDRM) to protect their copyrights and other intellectual property, including by disabling the software’s ability to play protected content if
WDRM fails. You agree that Microsoft may include a revocation list with the licenses.
c. Windows Media Player. When you use Windows Media Player, it checks with Microsoft for compatible online music services in your region and new versions of
the player. You may only use Windows Media Player as described at go.microsoft.com/fwlink/?LinkId=104605.
d. Windows Defender. If turned on, Windows Defender will search your licensed device for many types of malicious software, including viruses, worms, bots, rootkits,
“spyware”, “adware” and other potentially unwanted software. If it finds potentially unwanted software, the software will ask you if you want to ignore, disable
(quarantine) or remove it. If you choose the “recommended” security settings when you first start using the software, such malware and other potentially unwanted
software rated “high” or “severe” will automatically be removed. This removal may result in other software on your licensed device ceasing to work or your breach
ing a license to use that software. It is possible that software that is not unwanted may be removed or disabled. If you use Windows Defender and Windows Update,
Windows Defender is regularly updated through Windows Update.
e. Malicious software removal. If you use Windows Update, at least once each month the software will scan for and remove from your licensed device the malware
listed at go.microsoft.com/fwlink/?LinkId=241725. After the scan completes, a report will be sent to Microsoft with specific information about malware detected,
errors, and other information about your device. This information is used to improve the software and other Microsoft products. You may disable the software’s
reporting functionality by following the instructions found at go.microsoft.com/fwlink/?LinkId=241725.
f. SmartScreen Filter. If enabled, the SmartScreen Filter will check the addresses of webpages and downloads you attempt to view against a frequently updated list
of webpages and downloads that have been reported to Microsoft as unsafe or suspicious. SmartScreen will also check downloaded programs that you attempt to
run against a list of commonly downloaded or run programs to help you make more informed trust decisions. More information can be found by visiting the Internet
Explorer Privacy Statement go.microsoft.com/fwlink/?LinkId=239590. By enabling SmartScreen in either Windows or Internet Explorer, you consent to this fea
ture, and you agree to use the SmartScreen Filter only in conjunction with Windows or Internet Explorer. You may not, either manually or by enabling or author
izing any software or service, copy, display, distribute, collect or store any data provided by the SmartScreen Filter.
g. IPv6 Network Address Translation (NAT) Traversal service (Teredo). Each time you start your licensed device, Teredo will attempt to locate a public Internet
Protocol version 6 (IPv6) service on the Internet. This occurs automatically when your licensed device is connected to a public or private network, but does not
occur on managed networks such as enterprise domains. If you use a program that requires Teredo to use IPv6 connectivity, or if you configure your firewall to
always enable IPv6 connectivity, then Teredo will periodically contact the Microsoft Teredo service over the Internet. The only information sent to Microsoft is
standard computer information and the name of the service requested (for example teredo.ipv6.microsoft.com). The information sent from your licensed device by
Teredo is used to determine if your licensed device is connected to the Internet and if it can locate a public IPv6 service. Once the service is located, information is
sent to maintain a connection with the IPv6 service.
h. Plug and Play and Plug and Play Extensions. Your licensed device may not have the drivers needed to communicate with hardware that you connect to your licensed
device. If so, the update feature of the software can obtain and install the correct driver on your licensed device. An administrator can disable this update feature.
i. Digital certificates. The software uses digital certificates to confirm the identity of Internet users sending X.509 standard encrypted information, to digitally sign files
and macros, and to verify the integrity and origin of file contents. The software may retrieve and update certificates, certificate
revocation lists, and the list of trusted certification authorities, over the Internet.
j. Network awareness. This feature determines whether a system is connected to a network by either passive monitoring of network traffic or active DNS or HTTP
queries. The query transfers only standard TCP/IP or DNS information for routing purposes. You can switch off the active query feature through a registry setting.
k. Accelerators. When you click on or move your mouse over an Accelerator in Internet Explorer, any of the following may be sent to the applicable service provider
(which may not be Microsoft): the title and full web address or URL of the current webpage, standard computer information, and any content you have selected. For
more information, see go.microsoft.com/fwlink/?LinkId=239590.
l. Search provider update. The software will download an update to the data on your device about search providers. This update upgrades your providers with the
latest features, such as new icons or search suggestions. This is a one-time update, but the software will try to perform the update several times if it does not success
fully download the update. For more information, see go.microsoft.com/fwlink/?LinkId=239590.
m. Cookies. If you choose to use online features in the software, such as online Help and Support, cookies may be set. To learn how to block, control and delete cook
ies, please read the cookies section of the privacy statement at go.microsoft.com/fwlink/?linkId=74170.
n. Customer Experience Improvement Program (CEIP). This software uses CEIP. CEIP automatically sends Microsoft information about your hardware and how you
use this software. We do not use this information to identify or contact you. CEIP will also periodically download a small file to your computer. This file helps us
collect information about problems that you have while using the software. When available, new help information about the errors might also be automatically
downloaded. To learn more about CEIP, see http://go.microsoft.com/fwlink/?LinkID=52097.
o. Automatic Updates. Software with Click-to-Run technology may check with Microsoft now and then for updates and supplements. If the software finds updates and
supplements, it might download and install them on your licensed device.
p. Auto Root Update. The Auto Root Update feature updates the list of trusted certificate authorities. You can switch off the Auto Root Update feature.
q. Microsoft Error Reporting Service. This feature helps Microsoft and Windows partners diagnose problems in the software and provide solutions. Not all problems
will have a solution but when a solution is available, it will be offered as a step to solve a problem you have reported or as an update to install. As part of setup and
installation, the Microsoft Error Reporting Service sends to Microsoft information about setup and installation failures in order to attempt to diagnose the problem.
To help prevent problems and make the software more reliable, some solutions are also included in service packs and future versions of the software.
r. Silverlight and Silverlight Software Development Kit. Silverlight contains an Automatic Update feature that is on by default. You may turn off this feature while
Silverlight is running (“opt out”). Unless you expressly opt out of this feature, this feature will
MICROSOFT SOFTWARE LICENSE AGREEMENT
vii

• connect to Microsoft or service provider computer systems over the Internet,
• use Internet protocols to send to the appropriate systems standard computer information, such as
• your computer’s Internet protocol address,
• the type of operating system, browser and name and version of Silverlight you are using, and
• the language code of the device where you installed Silverlight, and
• automatically download and install, or prompt you to download and/or install, current updates to Silverlight.
In some cases, you will not receive a separate notice before this feature takes effect. By installing the software, you consent to the transmission of standard computer information
and the automatic downloading and installation of updates.
s. Microsoft Digital Rights Management. If you use Silverlight to access content that has been protected with Microsoft Digital Rights Management (DRM), in order
to let you play the content, the software may automatically
• request media usage rights from a rights server on the Internet and
• download and install available DRM Updates.
For more information about this feature, including instructions for to turning the Automatic Updates off, go to go.microsoft.com/fwlink/?LinkId=147032.
t. Windows Rights Management Services. The software contains a feature that allows you to create content that cannot be printed, copied or sent to others without
your permission. You must connect to Microsoft to use this feature for the first time. Once a year, you must re-connect to Microsoft to update it. You may choose not
to use this feature.
u. Windows Time Service. This service synchronizes with time.windows.com once a week to provide your licensed device with the correct time. You can turn this
feature off or choose your preferred time source within the Date and Time Control Panel applet. The connection uses standard NTP protocol.
v. Windows (or Microsoft) Update Feature. You may connect new hardware to the licensed device. Your licensed device may not have the drivers needed to communi
cate with that hardware. If so, the update feature of the software can obtain the correct driver from Microsoft and install it on your licensed device. You can switch
off this update feature.
5. PROOF OF LICENSE
The elements of a valid license include a genuine product key, successful activation of the software, an authentic Windows label such as a Certificate of Authenticity (COA), and proof of
purchase from a supplier of genuine Microsoft software. A valid license may also include a Windows activation file installed on the licensed device by SEGA. If there is a COA or other Windows
label, it must be affixed to the licensed device or appear on the SEGA’s software packaging or peripherals when purchased. If you receive an authenticity label separate from your licensed device,
it does not establish proof of license. For further information about Microsoft genuine software, see howtotell.com.
6. UPDATES AND UPGRADES
You may only obtain updates or upgrades for the software from Microsoft or authorized sources. You may not be able to obtain certain updates or upgrades from SEGA, or Microsoft, if your
copy of the software is improperly licensed. Certain upgrades, support, and other services may be offered only to users of genuine Microsoft software. For more information about Genuine
Windows, see go.microsoft.com/fwlink/?LinkId=104612.
To use upgrade software, you must first be licensed for the software that is eligible for the upgrade. Upon upgrade, this agreement takes the place of the agreement for the software you upgraded
from. After you upgrade, you may no longer use the software you upgraded from.
7. FONTS, ICONS, IMAGES, AND SOUNDS
a. Font components. While the software is running, you may use its fonts to display and print content. You may temporarily download the fonts to a printer or other
output device to print content, and you may embed fonts in content only as permitted by the embedding restrictions in the fonts.
b. Icons, images, and sounds. While the software is running, you may access and use its icons, images, sounds, and media only from the licensed device. You may not
share the sample images, sounds and media provided with the software or use them for any other purpose.
8. .NET FRAMEWORK
The software includes one or more components of the .NET Framework, which you may use only as described at go.microsoft.com/fwlink/?LinkId=66406 if you use the .NET Framework
components to conduct internal benchmark testing.
9. VHD BOOT. Additional copies of the software created using the software’s Virtual Hard Disk functionality (“VHD
Image”) may be pre-installed on the physical hard disk of the licensed device. These VHD Images may only be used for maintaining or updating the software installed on the physical hard disk
or drive. If the VHD Image is the only software on your device, it may be used as the primary operating system but all other copies of the VHD Image may only be used for maintenance and
updating.
10. NOT FAULT TOLERANT. The software is not fault tolerant. SEGA installed the software on the licensed device and is responsible for how it operates on the device.
11. RESTRICTED USE. The Microsoft software was not designed for systems that require fault-tolerant performance. You may not use the Microsoft software in any device or system in which
a failure or fault of any kind of the software could reasonably be seen to lead to death or serious injury of any person, or to severe physical or environmental damage.
12. EXPORT RESTRICTIONS. You must also comply with all domestic and international export laws and regulations that apply to the software, which include restrictions on destinations, end
users, and end use. For further information on geographic and export restrictions, visit go.microsoft.com/fwlink/?LinkId=141397 and microsoft.com/exporting.
13. NO WARRANTIES FOR THE SOFTWARE. The software is provided “as is”. You bear all risks of using it. Microsoft gives no express warranties, guarantees or conditions. Any warran-
ties you receive regarding the licensed device or the software do not originate from, and are not binding on, Microsoft or its affiliates. When allowed by your local laws, SEGA and Microsoft
exclude implied warranties of merchantability, fitness for a particular purpose and non-infringement.
14. LIABILITY LIMITATIONS. You can recover from Microsoft and its affiliates only direct damages up to two hundred fifty U.S. Dollars (U.S. $250.00), or equivalent in local currency. You
cannot recover any other damages, including consequential, lost profits, special, indirect or incidental damages.
This limitation applies to:
· anything related to the software, services, content (including code) on third party internet sites, or third party programs, and
· claims for breach of contract, breach of warranty, guarantee or condition, strict liability, negligence, or other tort to the extent permitted by applicable law.
It also applies even if Microsoft should have been aware of the possibility of the damages. The above limitation may not apply to you because your country may not allow the exclusion or limita-
tion of incidental, consequential or other damages.
15. REFUND PROCEDURES
If you are seeking a refund, contact SEGA to determine its return policy for a refund or credit. You must comply with that policy, which might require you to return the software with the entire
licensed device on which the software is installed for a refund.
16. ENTIRE AGREEMENT
This agreement (together with printed-paper license terms or other terms accompanying any software supplements, updates, and services that are provided by SEGA, or Microsoft, and that
you use), and the terms contained in web links listed in this agreement, are the entire agreement for the software and any such supplements, updates, and services (unless SEGA, or Microsoft,
provides other terms with such supplements, updates, or services).
17. FOR AUSTRALIA ONLY. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and
compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not
amount to a major failure. Goods presented for repair may be replaced by refurbished goods of the same type rather than being replaced. Refurbished parts may be used to repair the goods.
For further information regarding this warranty and to claim expenses in relation to the warranty (if applicable), please contact the manufacturer or installer; see the contact information provided
in the system packaging.
viii
MICROSOFT SOFTWARE LICENSE AGREEMENT

LIST OF 3rd PARTY RIGHTS
ix

x
TABLEOFCONTENTS
INTRODUCTION iii
1 HANDLING PRECAUTIONS 1
2 PRECAUTIONS REGARDING INSTALLATION 4
3 PRECAUTIONS REGARDING OPERATION 7
4PART DESCRIPTIONS 10
5ACCESSORIES 11
6 ASSEMBLY AND INSTALLATION 12
6-1 INSTALLING THE CABINET 13
6-2 FIXATION TO SITE 17
6-3 POWER SUPPLY AND OTHER CONNECTIONS 19
6-4 TURNING ON THE POWER 20
6-5 CONFIRMATION OF ASSEMBLY 22
6-6 APPLYING WARNING LABELS (EPILEPTIFORM SEIZURES) 23
7PRECAUTIONS WHEN MOVING THE MACHINE 24
7-1 PRECAUTIONS WHEN MOVING FROM SITE 25
8GAME DESCRIPTION 26
8-1 HOW TO PLAY 26
9EXPLANATION OF TEST AND DATA DISPLAY 33
9-1 SWITCH UNIT AND COIN METER. 34
9-2 SYSTEM TEST MODE 35
9-3 SYSTEM INFORMATION 37
9-4 STORAGE INFORMATION 39
9-5 JVS TEST 41
9-6 MONITOR TEST 44
9-7 SPEAKER TEST 45
9-8 COIN ASSIGNMENTS 46
9-9 CLOCK SETTING 52
9-10NETWORK SETTING 54
9-11GAME TEST MENU 58
9-12BOOKKEEPING 59
9-13INPUT TEST 64
9-14OUTPUT TEST 65
9-15TICKET TEST 66
9-16GAME ASSIGNMENTS 67
9-17TICKET SETTINGS 69
9-18BONUS SETTINGS 70
9-19DIFFICULTY SETTINGS 71
9-20BACKUP DATA CLEAR 72
9-21TICKET ERROR 73

xi
10 CONTROLLER UNIT(S) 74
10-1 REMOVING THE CONTROLLER 75
11 GRAPHICS DISPLAY 78
11-1 SAFETY PRECAUTIONS WHEN HANDLING THE MONITOR 78
12 COIN HANDLING 84
12-1 CLEANING THE COIN SELECTOR 84
12-2 FAULT FINDING 87
12-3 ADJUSTING THE PRICE OF PLAY (EXCEL) 88
13 LAMPS AND LIGHTING 92
13-1 COIN DOOR LAMP 92
13-2 BILLBOARD LED LIGHTING 93
13-3 HALF HOOP LED LIGHTING 95
13-4 FULL HOOP LED LIGHTING 97
14 PERIODIC INSPECTION 99
15 TROUBLESHOOTING 101
15-1 TROUBLESHOOTING (WHEN NO ERROR MESSAGE IS SHOWN) 101
16 GAME BOARD (NuSX) 104
16-1HANDLING PRECAUTIONS 105
16-2 GAME BOARD (NuSX) - LOCATION 106
16-3NuSX CLEANING 107
16-4REPLACING THE LITHIUM BATTERY 108
16-5NuSX CONNECTIONS 113
16-6ERROR CODES 114
17 DESIGN RELATED PARTS 123
18 PARTS LIST 124
19 COLOUR CODE TABLE 145
20 SCHEMATIC DIAGRAMS 146

xii
This page intentially left blank

HANDLING PRECAUTIONS
1
1
1
1 HANDLING PRECAUTIONS
When installing or inspecting the machine, be very careful of the following points and pay attention to ensure that
the player can enjoy the game safely.
Non-compliance with the following points or inappropriate handling running counter to the cautionary matters
herein stated can cause personal injury or damage to the machine.
●Proceed with checks and tasks as indicated in these instructions. If instructions
are not followed, or if tasks and/or checks are neglected, an electric shock or
other very serious accident, even fatal accident can occur. Also, customers
could be injured while operation the product.
●Before performing work, be sure to turn the power off. Performing the work with-
out turning the power off can cause an electric shock or short circuit. In cases
where work should be performed in the status of power on, this manual always
states to that effect.
●To avoid an electric shock or short circuit, do not plug in or unplug quickly.
●To avoid an electric shock, do not plug in or unplug with a wet hand.
●Do not expose power cords or earth wires on the surface, (floor, passage, etc.)
If exposed, the power cords and earth wires are susceptible to damage. Dam-
aged cords and wires can cause an electric shock or short circuit.
●To avoid causing a fire or an electric shock, do not put things on or damage
the power cords.
●When or after installing the product, do not unnecessarily pull the power cord. If
damaged, the power cord can cause a fire or an electric shock.
●In case the power cord is damaged, ask for a replacement through where the
product was purchased from or the office herein stated. Using the cord as is
damaged can cause fire, an electric shock or leakage.
●Be sure to perform grounding appropriately. Inappropriate grounding can
cause an electric shock.
●Be sure to use fuses meeting the specified rating. Using fuses exceeding the
specified rating can cause a fire or an electric shock.
●Be sure that connections such as IC BD are made properly. Insufficient insertion
can cause an electric shock.
●Specification changes, removal of equipment, conversion and/or addition, not
designated by SEGA are not permitted.
- Failure to observe this may cause a fire or an electric shock. Non-compliance
with this instruction can have a bad influence upon physical conditions of the
players or the onlookers, or result in injury during play.
- SEGA shall not be held responsible for damage, compensation for damage to
a third party, caused by specification changes not designated by SEGA.
●Do not perform any work or change parts not listed in this manual. Doing so
may lead to an accident.

2
HANDLING PRECAUTIONS
1
1
For the IC board circuit inspections, only the use of a logic tester is
recommended. Using a Multi Tester or General Purpose Tester may result in
damage to IC Circuits.
Static electricity from your body may damage some electronics devices
on the IC board. Before handling the IC board, touch a grounded metallic
surface so that the static electricity can be discharged.
This video gaming cabinet utilises a motorised steering feedback system.
Do not attempt to service this part or any other part in close proximity to the
steering mechanism whilst power is applied.
Some parts are not designed and manufactured specifically for this game
machine. The manufacturers may discontinue, or change the specifications of
such general-purpose parts. If this is the case, SEGA cannot repair or replace
a failed game machine whether or not a warranty period has expired.
●If you need to perform any work not listed in this manual, request work from the
office indicated in this manual or the point of purchase, or inquires for details.
●Be sure to perform periodic maintenance inspections herein stated.
●Do not touch undesignated places. Touching places not designated can cause
an electric shock or short circuit.
●Whenever any fasteners (e.g. screws, nuts) have been lost, be sure to use re-
placement fasteners with the proper dimensions as specified in this manual.
If fasteners or any other fixings are used which do not correspond with the di-
mensions as outlined in this manual it may cause damage and/or separation of
parts that may result in secondary accidents.
●When connecting a connector, check the direction carefully. Connectors must
be connected in only one direction. If indiscriminate loads are applied in mak-
ing connections, the connector to its terminal fixtures could be damaged, re-
sulting in electric shock, short circuit or fires.

HANDLING PRECAUTIONS
3
1
1
CONCERNING THE STICKER DISPLAY
This SEGA product has stickers attached describing the product manufacture No. (Serial No.) and Electrical
Specifications. It also has a Sticker describing where to contact for repair and for purchasing parts.
When inquiring about or asking for repairs, mention the Serial No. and Name of Machine indicated on the Sticker.
The Serial Number indicates the product register. Identical machines could have different parts depending on the
date of production. Also, improvements and modifications might have been made after the publication of this
manual. In order to ensure you order the correct parts, mention the Serial No. when contacting the applicable places.
CONCERNING WARNING DISPLAYS
This SEGA product has warning displays on stickers, labels and/or printed instructions adhered/attached to or
incorporated in the places where a potentially hazardous situation could arise. The warning displays are intended
for accident prevention for customers and for avoiding hazardous situations relating to maintenance and servicing
work. Some portions of the cabinet contain high voltage and may cause accidents if touched. When performing
maintenance, be very careful of the warning displays. It is especially important that any complex repair and
replacement work not mentioned herein should be performed by those technical personnel who have knowledge of
electricity and technical expertise.
In order to prevent accidents, caution any customer ignoring the warnings to cease and desist immediately.
If you or your child have experienced a convulsive attack, loss of
consciousness, etc. due to light stimulus or TV games, or fear that you
might experience such symptoms, be very careful of using this
machine.
If you feel sick while playing the game, immediately discontinue use
and take a rest.

4
PRECAUTIONS REGARDING INSTALLATION LOCATION
2
2
2 PRECAUTIONS REGARDING INSTALLATION
• This product is an indoor game machine. Do not install it outside. Even indoors,
avoid installing in places mentioned below so as not to cause a fire, electric
shock, injury and/or malfunction.
• Places subject to rain or water leakage, or places subject to high humidity in
the proximity of an indoor swimming pool and/or shower, etc.
• Places subject to direct sunlight, or places subject to high temperatures in the
proximity of heating units, etc.
• Places filled with inflammable gas or vicinity of highly inflammable/volatile
chemicals or hazardous matter.
• Dusty places.
• Sloped surfaces.
• Places subject to any type of violent impact.
• Vicinity of anti-disaster facilities such as fire exits and fire extinguishers.
• Areas where the temperature exceeds the applicable temperature (ambient
temperature) range of 5 to 30 degrees centigrade.
LIMITATIONS OF USAGE
• Be sure to check the Electrical Specifications. Ensure that this product
is compatible with the location's power supply, voltage, and frequency
requirements. A plate describing Electrical Specifications is attached to the
product. Non-compliance with the Electrical Specifications can cause a fire
and electric shock.
• This product requires a breaker and earth mechanism as part of the location
facilities. Using the product without these can cause a fire and electric shock.
• Ensure that the indoor wiring for the power supply is rated at 15 A or higher
(AC single phase 100 V ~ 120 V area), and 7 A or higher (AC 220 V ~ 240 V
area). Non-compliance with the Electrical Specifications can cause a fire and
electric shock.
• Be sure to use an independent power supply equipped with an earth leakage
breaker. Using a power supply without an earth leakage breaker can cause
an outbreak of fire if a power surge occurs.
• Putting many loads on one electrical outlet can cause generation of heat and
a fire resulting from overload.
• When using an extension cord, ensure that the cord is rated at 15 A or higher
(AC 100 V ~ 120 V area) and 7 A or higher (AC 220 V ~ 240 V area). Using a
cord rated lower than the specified rating can cause a fire and electric shock.

PRECAUTIONS REGARDING INSTALLATION LOCATION
5
2
2
OPERATION AREA
Securing a safe area for operation as described in this manual will ensure
safe operation for players and observers.
SEGA shall not be held responsible for damage or compensation for damage
to a third party, resulting from the failure to observe this instruction.
For the operation of this machine, secure a minimum area of 1.7m (W) x 2.0m (D).
Be sure to provide sufficient space specified in this manual. Do not allow objects
to block the ventilation ports. It can cause generation of heat and a fire.
Sufficient space either side of the playing area must be allowed for the player to
enter or exit the game safely.
1700mm
2000mm
200mm
300mm

6
PRECAUTIONS REGARDING INSTALLATION LOCATION
2
2
To install this product, the entrance must be at least 1.2m in width and 2.1 m
in height (without Assy Billboard) and 2.7m (with Assy Billboard).
Do not attempt to push/pull whilst holding onto the Assy Billboard. This may
result in part damage and or personal injury.

PRECAUTIONS REGARDING PRODUCT OPERATION
7
3
3
3 PRECAUTIONS REGARDING OPERATION
To avoid injury and trouble, be sure to pay attention to the behavior of visitors and players.
In order to avoid accidents, check the following before starting the operation:
• To ensure maximum safety for the players and the customers, ensure that
where the product is operated has sufficient lighting to allow any warnings to be
read. Operation under insufficient lighting can cause bodily contact with each
other, hitting accident, and/or trouble between customers.
• Be sure to perform appropriate adjustment of the display (LCD, Plasma, CRT
or Projector). For operation of this machine, do not leave monitor's flickering or
deviation as is. Failure to observe this can have a bad influence upon the players'
or the customers' physical conditions.
• It is suggested to ensure a space allowing the players who feel sick while
playing the game to take a rest.
• Check if all of the adjusters are in contact with the surface. If they are not, the
Cabinet can move and cause an accident.
• Do not put any heavy item on this product. Items, if placed on this product
may fall and cause injury to the player / observer.
• Do not climb on the product. Climbing on the product can cause falling down
accidents. To check the top portion of the product, use a step ladder.
Each leg adjuster MUST be lowered so that the
casters are raised approximately 5mm off the
floor.
