SEI ALLEGHENY User manual

For assistance with assembly contact:
Southern Enterprises Inc.
Customer Service 1-800-633-5096
[email protected]
www.seidal.com
"ALLEGHENY"PETITE FIREPLACE
FA9108 – HAND-PAINTED
Assembly Instructions

A Quantity
of 13
CAM BOLT
B Quantity
of 9
H
WOOD DOWELSHORT FLAT HEAD
C Quantity
of13
CAM LOCK
D Quantity
of 8
LONG SOCKET HEXAGON
E Quantity
of 8
SPRING WASHER
F Quantity
of 8
FLAT WASHER
G Quantity
of 1
SOCKET HEAD WRENCH
H Quantity
of 4
FLAT HEAD LONG SCREW
I Quantity
of 1
FIREBOX
SOLD IN A SEPARATE CARTON
"ALLEGHENY"PETITE FIREPLACE
Parts List
Please review all parts and hardware before disposing of any packaging.
Call Customer Service if missing hardware. Do not return to store/retailer.
Screws shown in actual size. Using a screw that is too long will cause damage.
Before beginning assembly, separate each type of screw. Carefully study the
screw diagrams below (SHOWN ACTUAL SIZE). You may receive extra

(1) Quantity
of 1
RIGHT SIDE PANEL
(2) Quantity
of 1
LEFT SIDE PANEL
(3) Quantity
of 1
UPPER FRONT PANEL
(4) Quantity
of 1
BOTTOM FRONT PANEL
(5) Quantity
of 1
TOP PANEL
(6) Quantity
of 1
FIREBOX SUPPORT
(7) Quantity
of 1
ADJUSTABLE FOOT
(8) Quantity
of 2
WOOD HOLDER
Care and Cleaning Instructions:
Before using, wipe with a clean, dry cloth.
Periodically apply furniture wax to renew
the finish . Avoid rubbing or scratching the
surface with rough or abrasive objects.
For replacement parts or questions, please
Call Customer Service at 1-800-633-5096
Do not return product to store, please call
Manufacturer for assistance, questions or
Parts.
Assembly Tool Required
No.2 Phillips Screwdriver (Not Included)
"ALLEGHENY"PETITE FIREPLACE
Parts List
Please review all parts and hardware before disposing of any packaging.
Call Customer Service if missing hardware. Do not return to store/retailer.
Screws shown in actual size. Using a screw that is too long will cause damage.
Before beginning assembly, separate each type of screw. Carefully study the
screw diagrams below (SHOWN ACTUAL SIZE). You may receive extra

Figure 1
INSERT 4PCS WOOD DOWEL (B) AND 8PCS
CAM BOLT (A) INTO PREDRILLED HOLES ON
END OF LEFT AND RIGHT FRONT PANELS
(1&2) AND FIT INTO CORRESPONDING
HOLES OF UPPER FRONT PANEL (3) AND
BOTTOM FRONT PANEL (4),THEN INSERT
8PCS CAM-LOCK (C) INTO BIG HOLES ON
EDGES OF UPPER FRONT PANEL (3) AND
BOTTOM FRONT PANEL(4), WITH SLOT FOR
SCREWDRIVER FACING OUTWARD,ROTATE
CAM-LOCK CLOCKWISE TO SESURE CAM
BOLT. AS FIGURE 1 SHOWN.
Figure 2
PLACE THE TOP PANEL (5) ONTO THE UNIT,
AND INSERT 4PCS WOOD DOWEL (B) INTO
THE UNIT AND 5PCS CAM BOLT (A) INTO
TOP PANEL(5) FIT INTO CORRESPONDING
HOLE TO ASSEMBLE TOP PANEL(5) AND
UNIT TOGETHER,THEN INSERT 5PCS CAM
LOCK(C) INTO THE BIG HOLES ON UNIT
AND USE SCREWDRIVER TIGHTEN IT., AS
FIGURE 2 SHOWN.
Figure 3
USE LONG SOCKET HEXAGON TO ATTACH
SPRING WASHER(E) AND FLAT WASHER (F)
THROUGH THE PREDRILLED HOLE TO
ASSEMBLE FIREBOX SUPPORT(6) AND
ADJUSTABLE FOOT(7) TOGETHER,THEN
TIGHTEN IT WITH SOCKET HEAD
WRENCH(G). AS FIGURE 3 SHOWN.
"ALLEGHENY"PETITE FIREPLACE
Assembly Instructions
A
A
A
5

Figure 4
USE 6PCS LONG SOCKET HEXAGON (D) TO
ATTACH 6PCS SPRING WASHER (E) AND
6PCS FLAT WASHER (F) TO ASSEMBLE TWO
FRAME TOGTHER.
Figure 5
INSERT THE FIREBOX FROM THE BACK OF
FIREPLACE. MAKE SURE FIREBOX IS
PRESSED TIGHTLY AGAINST THE
ASSEMBLED UNIT. ATTACH WOOD
HOLDER(8) ON THE SIDES OF FIREBOX
W/SCREEN KIT. INSERT 4PCS FLAT HEAD
LONG SCREWS (H) THROUGH PREDRILLED
HOLES ON WOOD HOLDER(8) AND TIGHTEN
INTO CORRESPONDING HOLES ON BACK OF
LEFT AND RIGHT SIDE PANELS (1&2) AS
FIGURE 4 SHOWN.
We'd love to hear from you! Email us photos of our products in your home at [email protected]
and we might feature it on our site or use it to model one of our inspirational photos.
"ALLEGHENY"PETITE FIREPLACE
Assembly Instructions
8

Customer Service 1-800-633-5096
[email protected]
Southern Enterprises, Inc.
2915 Merrell Road
Dallas, Texas 75229
Missing or damaged hardware and/or parts will be replaced free of charge. We do not sell parts. Southern
Enterprises Inc. will provide replacement parts for only those items purchased within the last 9 months. If
this product has not been purchased from our retail affiliates (within 9 months), we are under no obligation
to provide parts or replacement merchandise. Parts will not be available for items arriving fully assembled.
Parts will be sent if available from SEI. The fireplace mantel will fit both gel fuel and electric firebox inserts.
Depending on the insert ordered only one insert will be included.
WARNING: positioning anything on top of your fireplace mantel poses a degree of risk especially in the case
of electronic appliances or equipment. If you elect to display a television we recommend that it be a slim
profile flat-screen and that it be positioned away from the front edge of the mantel where there is a degree
of heat generated from the firebox. You may also want to tether your flat screen tv to the wall behind it for
added safety and security. Manufacturer assumes no responsibility for items placed on top of a fireplace
mantel.
Customer Information
Name
Address
City/State/Zip Code
Phone Number
Please indicate where you purchased this item: Store/Website/Catalog
Please indicate color/size/style number:
StyleNo PartsLetter PartsDescription Quantity Needed
FA910800TX - Parts Replacement Form
