Select Engineered Systems SPRFC1 User manual

SPRFC1 & SPRF1WR User Manual
600SPRFC1
5/11
(Optional)
Standard
Exterior Weather-Resistant

Wiring instructions:
Red = + 12-24 VDC or 12-24 VAC
Black: - 12-24 VDC or 12-24 VAC
White: Normally closed relay contact
Brown: Common relay contact
Green: Normally open relay contact
Optional:
15’ Antenna extender cable may be added to SPRFC1
Programming SPRFC1:
TO ENTER PROGRAMMING:
1) Press * & 0 keys at same time.
2) Key in 4 digit pass code
(Factory default = 7777)
3) Press *
4) For correct pass code display will show:
* OR SEL. FUNCTION
5) Press * to step through menu choices.
SPRFC1 Programming menu choices:
1) Add Xmit (Add transmitter code number)
Key in 5-digit code between 00001—65535
Press * to confirm.
2) Bulk Load (Allows range of code numbers to be entered)
Key in starting 5 digits and press *
Key in ending 5 digits and press *
3) Pin Length
Will only accept digits 0, 3, 4 or 5. If a 1 or a 2 is entered as the pin length,
the system will force it to a “3”. Programming a pin length of “0” will turn OFF
the pin function. PIN codes are treated the same as Xmitter codes.
4) Relay On Time
½ second or 1—9 seconds (Factory Default = 1)
Press 1 –9 for seconds desired and *
Press 0 and * for ½ second
5) Password
To change passcode, key in all 4 digits and press *

SPRFC1 Programming menu choices:
6) Facility Code
10 facility codes may be programmed into the SPRFC1. When programming in a facili-
ty code you must first assign a memory location to the facility code, by preceding the
facility code with a number from 0 – 9, then key in the 3 digit facility code. All 3 digits
must be programmed or the command will not be accepted. If a facility code of 256 or
greater is programmed, the number will NOT be accepted and a long beep will be
heard and “NUMBER TOO BIG” will be displayed. Duplicate facility codes are NOT
tested for, so a facility code may be entered more than once. To remove a facility code
from the list enter the memory location number (0 – 9) followed by a single “0” then
press *
7) System Type
Key in 0, 1, or 2 to select system type and press *
0 = Xmitter Facility code recognized only
1 = Xmitter Code number recognized only (Factory Default)
2 = Both facility code and xmitter code number are required.
8) Master Xmitter
This is a list of 10 master xmitter numbers WITH facility code, that will place the sys-
tem into programming by xmitter. When programming the code location (0 – 9), 3 dig-
its of facility code and 5 digits of the xmitter number must be entered. If the facility
code or xmitter number is out of range the beeper will sound and the “NUMBER TOO
BIG” will be displayed. The system does NOT test for duplicate entries, so the same
xmitter with the same facility code may be entered more than once. Once a xmitter is
in the MASTER XMITTER list it will NOT work like a regular xmitter to activate the re-
lay. The MASTER XMITTER may be any facility code that is not one of the ones in the
facility code list. To remove a master xmitter from the list enter the code number of the
master xmitter followed by a single “0” and then press *
9) Erase Xmitters
To erase all xmitter numbers in memory, key in 999 and *
1) Delete Xmitter
To delete a single xmitter code number, key in number and press *

Select Engineered Systems, Inc.
7991 West 26th Avenue
Hialeah, Florida 33016
Phone: [phone]
Fax:[phone]
www.selectses.com
07/13
SPRFC1
600SPRFC1
10/11
FCC
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not in-
stalled and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the re-
ceiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
IC
This device complies with Industry Canada license-exempt RSS standard(s). Opera-
tion is subject to the following two conditions. (1) this device may not cause interfer-
ence, and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
