SELECT
LOCOMOTION
LOCO-501
INSTRUCTIONS
AND SERVICE MANUAL
Select Healthcare (UK) Ltd, Unit 2 Albert Road, Rushden, Northants, NN10 0BU
Tel: [phone] Fax: [phone] Email [email protected]
Designed and Developed by: Proto Magic Innovations Ltd
Page 1
LOCOMOTION INSTRUCTIONS Ver 09 04/03/2022
ENSURE THESE INSTRUCTIONS ARE READ AND FULLY UNDERSTOOD BEFORE USE.
PLEASE KEEP INA SAFE PLACE FOR FUTURE REFERENCE AS REQUIRED.
The Select Locomotion is packed in a strong purpose-built carton, to ensure safe delivery. Please
retain the carton if possible.
This user manual contains
1.0 Unpacking instructions.
2.0 Assembly instructions.
3.0 Instructions for adjustments and pre-use checks.
4.0 Instructions for use.
5.0 Maintenance and cleaning.
6.0 Some Do`s and Don’ts.
7.0 Technical Specification.
8.0 Service instructions.
Mast
Shin Pad
Accessory Attachment
Point
Base
Front Wheel
Anti-TippingPad
Fig F0.1

SELECT
LOCOMOTION
LOCO-501
INSTRUCTIONS
AND SERVICE MANUAL
Select Healthcare (UK) Ltd, Unit 2 Albert Road, Rushden, Northants, NN10 0BU
Tel: [phone] Fax: [phone] Email [e-mail]
Designed and Developed by: Proto Magic Innovations Ltd
Page 2
LOCOMOTION INSTRUCTIONS Ver 09 04/03/2022
1.0 Unpacking Instructions
1.1 The Select Locomotion is supplied in a custom-made packing box.
1.2 Carefully remove the Select Locomotion from the packing box.
1.3 Retain the packing box if possible.
1.4 The Select Locomotion is in two parts.
1.5 Carefully remove the protective materials taking care not to damage the product.
2.0 Assembly instructions
Refer to Fig F2.1
2.1 Place the Base on the ground.
2.2 Rotate the Clamping Knob (K) anti-clockwise until its rotation starts to become stiff.
2.3 Offer the Mast to the socket in the Base as shown in Fig F2.1, ensuring that it is correctly orientated.
Note there is a keyway on the bottom of the Mast and at the entry into the base that prevents the Mast
from being assembled in the wrong orientation.
2.4 Lower the Mast into the Base socket as far as it will go. The hole (H) will now be inside the Base.
2.5 Rotate the Clamping Knob clockwise until rotation starts to become stiff.
2.6 Rotate the Clamping Knob anti-clockwise a half turn.
2.7 The Mast will now not be clamped allowing it a small movement in the Base.
2.8 In this position the Clamping member (that cannot be seen) attached to the Clamping Knob will be
located inside the Hole (H).
2.9 In this position the Mast is not clamped in position and is free to make small movements, but it cannot
be lifted out of the Base. THIS IS AN IMPORTANT SAFETY FEATURE.
2.10 Check that the Mast cannot be lifted out of the Base.
2.11 Rotate the Clamping Knob clockwise until it is tight.
2.12 The Locomotion is now fully assembled.
2.13 The Locomotion can be disassembled simply by rotating the Clamping knob anti-clockwise and lifting
the Mast out of the Base.
2.14 An oval shaped hole in the client side of the Base provides a handhold to assist in carrying it.

SELECT
LOCOMOTION
LOCO-501
INSTRUCTIONS
AND SERVICE MANUAL
Select Healthcare (UK) Ltd, Unit 2 Albert Road, Rushden, Northants, NN10 0BU
Tel: [phone] Fax: [phone] Email [e-mail]
Designed and Developed by: Proto Magic Innovations Ltd
Page 3
LOCOMOTION INSTRUCTIONS Ver 09 04/03/2022
3.0 Instructions for adjustments and pre use checks.
Refer to Fig F3.1
3.1 Adjust the height of the Shin Pad height to suit the client.
3.1.1 To unlock the shin pad for height adjustment, pull out the spring-loaded Shin Pad Height Locking
Knob (SL) on Fig F 3.1
3.1.2 Move the Shin Pad Assembly up or down to the height required.
3.1.3 Release the Shin Pad Height Locking Knob and move the shin pad up or down a little until the
locking knob engages with one of the 11 height adjustment holes (SH).
3.1.5 Check that the Shin Pad Assembly is now locked in the new position.
3.2 The shin pads can be adjusted independently laterally and rotationally to suit individual situations, for
example to accommodate a plastered leg.
3.3 To adjust a shin pad, take a firm hold, top and bottom, of the subject shin pad and `wriggle` it on its
shaft to the required position.
3.4 Check that the Clamping Knob (K) is tight and that the Mast is secure in the Base.
3.5 Check the operation of the brakes on both central wheels by pushing the Brake Pedal (BP) down for
braked and up for released.
3.6 Check the two castors and two wheels are free to rotate and that the Anti-Tipping Pads at the front of
the Locomotion shown on Fig 0.1 are clear of the ground.
3.7 Check that the four Accessory Attachment Points shown on Fig 0.1 are tight and not damaged.
3.8 Check the Locomotion is clean and shows no signs of damage.
3.9 Your Locomotion is now ready for use.

SELECT
LOCOMOTION
LOCO-501
INSTRUCTIONS
AND SERVICE MANUAL
Select Healthcare (UK) Ltd, Unit 2 Albert Road, Rushden, Northants, NN10 0BU
Tel: [phone] Fax: [phone] Email [e-mail]
Designed and Developed by: Proto Magic Innovations Ltd
Page 4
LOCOMOTION INSTRUCTIONS Ver 09 04/03/2022
4.0 Instructions for use
4.1 NB ALL CLIENT MOVING AND HANDLING TASKS SHOULD ONLY BE CARRIED OUT IN
ACCORDANCE WITH APPROVED CLIENT MOVING AND HANDLING TECHNIQUES AND AFTER A
FULL ASSESSMENT OF THE CLIENT, THE TASK AND THE ENVIRONMENT* IN WHICH THE
TASK IS TO BE CARRIED OUT.
4.2 The Locomotion has been designed to allow one or two carers to transfer a client from one seated
position tothe Locomotion, move the Locomotion to another location across a firm flat floor and then
transfer the client to another seated position.
4.2.1 *Moving the Locomotion on a soft floor surface may produce a tipping hazard. As part of
the environment the floor must be assessed as compatible and safe before use .
4.3 Before a transfer is started carers must satisfy themselves by an appropriate assessment that the
client is able to bear weight independently.
4.4 Before every use of the Locomotion ensure that both the Mast and Shin Pad are secure, the Brakes
are operational and that the equipment is in no way damaged.
4.5 Before using your Locomotion adjust the height, rotation and lateral position of the Shin Pads to suit
the client as described in above.
4.6 The Locomotion can now be manoeuvred and brought to a position in front of the client.
4.7 Put the brake on.
4.8 Assist the client to the front of their chair, ready to stand and place the client’s feet on the non-slip foot
plate. The Locomotion should now have the client’s feet on the non-slip foot plate and shins firmly
against the shin pad.
4.9 Encourage the client to use the handle to pull themselves into a standing position. Note, as the client
stands the Locomotion may tilt slightly towards the client as the Anti-Tip Pads engage with the ground,
this is normal operation**. The carer should position themselves at the side of the client ready to assist if
required. Once the client is in a stable standing position, release the Brake and move the Locomotion to
the required location.
4.9.1 **As described below (4.14.1), if desired this small ‘tilt’ can be eliminated by the carer counterbalancing
the Locomotion.
4.10 When at the new location put the Brake on.
4.11 Reverse the above procedure to seat the client.
4.12 Release the Brake and move the Locomotion away from the client.
4.13 The Locomotion is not intended for outdoor use or for transporting clients over long distances.
4.14 If the client is unable to stand with a natural standing pattern but has still been assessed as a safe user of
the Locomotion it may be necessary for a carer to counterbalance the Locomotion…
4.14.1…by placing their foot on the brake pedal and holding the hand rail as the client stands or sits.
4.2.0 Locomotion Accessories
4.2.1 See instructions included with the Accessories.
4.2.2
Locomotion Assist Belt
LOCO-514 Small
LOCO-515 Medium
LOCO-516 Large

SELECT
LOCOMOTION
LOCO-501
INSTRUCTIONS
AND SERVICE MANUAL
Select Healthcare (UK) Ltd, Unit 2 Albert Road, Rushden, Northants, NN10 0BU
Tel: [phone] Fax: [phone] Email [e-mail]
Designed and Developed by: Proto Magic Innovations Ltd
Page 5
LOCOMOTION INSTRUCTIONS Ver 09 04/03/2022
5 Maintenance and cleaning
5.1 Wash with detergent and hot water, then dry thoroughly.
5.2 Decontaminate during general use with universal sanitising wipes.
5.3 Decontaminate before reissue with 70% isopropyl alcohol or 10,000 ppm chlorine solution or dry
superheated steam vapour cleaning. No other methods are approved or recommended please contact
customer service if more advice is needed.
5.4 Always be vigilant and check for damage.
5.5 Annual servicing is recommended. See service instructions.
5.6 Check for grit or other contamination on the Base and Wheels.
6 Some Do's and Don'ts.
6.1 DO ensure that you have read these instructions and understood them fully.
6.2 DO ensure that you carry out an inspection of the Locomotion on a regular basis and have it serviced
annually.
6.3 DON'T let children play with the Locomotion.
6.4 DON'T exceed the safe working load of 200kgs person (31 stones).
6.5 Always ensure that the Brake is on before a carer starts standing or sitting a client.
7 Technical Specification
7.1 Warranty to specification
12 months
7.2 Safe working load
200 Kg / 31 Stone
7.3 Overall length
685 mm
7.4 Width
520 mm
7.5 Height
1200 mm
7.6 Height adjustment discrimination
25 mm
for Shin Pads
7.7 Height of Client Platform 42mm
7.8 Number of height adjustment steps 11
for Shin Pad
7.9 Weight Mast 6Kg, Base 8Kg
7.10 Construction Mostly aluminium, steel and plastics
7.11 Intended use Client transportation over short distances indoors.
7.12 Approvals CE UKCA marked
7.13 Patents GB 1908712.1, GB1910263.1

SELECT
LOCOMOTION
LOCO-501
INSTRUCTIONS
AND SERVICE MANUAL
Select Healthcare (UK) Ltd, Unit 2 Albert Road, Rushden, Northants, NN10 0BU
Tel: [phone] Fax: [phone] Email [e-mail]
Designed and Developed by: Proto Magic Innovations Ltd
Page 6
LOCOMOTION INSTRUCTIONS Ver 09 04/03/2022
8 Annual service procedure
Refer to Fig F8.1
8.1 All the check points referred toare examples of the positionsto check, ensure the similarand
mirrored positions are checked.
8.2 Checkall the weldsfor cracks and damage marked (W). If anyfaults are detected,then the
unit must not be used until the damage has been rectified.
8.3 Check the Anti-Tipping Pads (ATP) for wear or damage. Replace if necessary, note that the
large plastic Base moulding needs to be raised by removing the 6 Base Retention Straps (BRS)
in order to replace the Anti-Tipping Pads.
8.4 Check the operation of theBrake. If thereis some wear on the brake Pads (BPA)or on the
front wheels then the Brake function can beadjusted using an Allenkey inserted in the Brake
Adjusting (BA) bolt, note the bolt is horizontal to the ground.
8.5 Ifthe Brake Pads (BPA) or Brake Pedal (BP) aredamaged ortoo worn then replace them.
8.6 Checkthe 6 Base Retention Straps (BRS) are not damaged and that their retention screws
are all tight. Tighten screws, renew parts as required.
8.7 Check that the Clamp Knob (K) istightly screwed inand that the Mast isfirmly attached to
the Base.
8.8 Checkthe 4 Accessory Attachment Points (AAP) are tightly fixed and are not damaged,
replace parts as required.
8.9 Pull out the Shin Pad Height Locking Knob (SL) and move the Shin Pad assembly up past its highest
setting point. Release the Shin Pad Height Locking Knob and slowly lower the Shin Pad down until the
Shin Pad Height Locking Knob locates in the top setting hole location. Check that the Shin Pad is firmly
retained. Pull out the Shin Pad Height Locking Knob and slowly lower the Shin Pad assembly down until
the next setting hole location is reached. Check that the Shin Pad is firmly retained. Repeat for all 11
setting points.
8.10 Check the condition of the shin pads, replace if damaged. To remove a shin pad, remove the
retention screw (SS) and gently pull the old shin pad off the retaining bar.
8.12 Check the condition of the wheels and all other parts.
8.13 Carry out all checks listed for Pre-Use in section 3.
8.14 Ensure all parts are clean.
