SellEton Scales SL-720 User manual

[e-mail] (844)-735-5386 www.selletonscales.com
SL-720
WEIGHING KIT
INSTALLATION
MANUAL
OVERVIEW
Our SL-720 floor scale weighing kit has everything you need to build your own weighing scale. It
enables you to use any platform of your choice (platform not included with the kit). This weighing
kit is mostly used for floor scale, livestock scale applications or to turn any object, platform into a
scale with Maximum capacity of 10,000 lbs.
You can increase the kit's weighing capacity by adding more load cells or buy higher capacity kits.
The kit can also be customized to Accessories such as printer, scoreboard, software, custom ramps,
stands & much more! All load cells come with 200% overload protecton.

[e-mail] (844)-735-5386 www.selletonscales.com
SL-720
INSTALLATION MANUAL - WEIGHING KIT
Our SL-720 weighing kit comes with all the accessories you need for installation.
ACCESSORIES
• x 4 load cells with 10' cable
• x 4 load spacers ( installed in-between the load cell & the mounting block )
• x 4 load cell Mounting blocks ( typically welded to steel structures ) or bolted to wood.
• x 8 Hexagon bolts
• x 8 washers
• x 8 lock washers
• x 1 Junction Box ( Plastic or Stainless steel )
• x 1 Quick Connect Cable ( you will hard wire it to the Junction Box, Refer to wiring diagram with in
this Manual.
• x 1 Digital Weight Indicator ( Either in mild steel or Stainless steel LCD or LED, depends on your
purchase.
Once you've ensured these items are included in your kit, proceed with the
installation.

[e-mail] (844)-735-5386 www.selletonscales.com
FOR WOODEN PLATFORMS
Step 1: Make sure the wooden platform you've built – or are in the process of building – can withstand
the maximum weight you'll put on it.
Step 2: Turn the platform upside down.
Step 3: Drill 2 holes ( Same size & spacing between the holes as the mounting block. Use the mounting
block to draw out the holes first & then drill. Ultimately they need to match up to the load cells, be sure
to take time to do it correctly. this can impact readings if load cells are not positioned correctly.
NOTE: At all four corners of the platform (x 2 holes should be drilled on every corner). Each hole should
be drilled as close to its respective edge as possible. You need to purchase longer bolts for thicker
platforms. Measure the mounting block & load cell along with the thickness of the platform &
purchase the correct length of bolts. so that the load cell, mounting block & the platform are all
connected firmly.
Step 4: Use the 1/16" load spacers to bolt the load cells onto the platform. The spacers should be placed
between the load cell & the mounting block. This is necessary to give the load cells adequate room for
accurate readings. ( refers to the picture in this manual)
Step 5: Take out the junction box. See the below diagram to understand where each of the 4 load cell
cables will need to go into the junction box.
SL-720
INSTALLATION MANUAL - WEIGHING KIT
OVERALL INSTALLATION

[e-mail] (844)-735-5386 www.selletonscales.com
IF YOU'RE USING A STEEL PLATFORM:
You will need to weld each mounting block to the corner of the platform. Only weld on the outside of
the mounting block & ensure that all blocks are positioned in the same way, with the feet of the load
cell located in the corner of the platform (not facing inside the platform).
Picture below demonstrates the correct installation format.
WARNING:
Do not weld the mounting blocks
to the platform with the load cell
attached to it, it will damage the
load cells.
SL-720
INSTALLATION MANUAL - WEIGHING KIT

[e-mail] (844)-735-5386 www.selletonscales.com
Please refer to the diagram below for the indicator cable & load cell wiring:
SL-720
INSTALLATION MANUAL - WEIGHING KIT
CAPACITY & ACCURACY CHOICES:
- 1000 lb Capacity x .2 lb Accuracy
- 2500 lb Capacity x .5 lb Accuracy
- 5000 lb Capacity x 1 lb Accuracy
- 10,000 lb Capacity x 1 lb Accuracy

[e-mail] (844)-735-5386 www.selletonscales.com
SL-720
INSTALLATION MANUAL - WEIGHING KIT
CALIBRATION PROCEDURE
1. Turn on the scale by holding ON/OFF for 2 seconds.
2 Press HOLD and PRINT together to access the setup menu.
3. If done correctly, the display should now show C01.
4. Press PRINT to access the C1 channel. The display should show [CI #].
5. Press ZERO to choose which unit you want to calibrate in (1 = kg, 2 = lb).
6. Press PRINT to set the value. The display will now show C02.
7. Press PRINT to access the C2 channel. The display should show [C2 #].
8. Press ZERO to change the setting to the decimal places desired (The C2 channel is used to
adjust the decimal point on the scale. A value of 1 means there is one digit behind the decimal
point.)
9. Press PRINT to set the value. The display will now show C03.
10. Press PRINT to access the C3 channel. The display should show [C3 #].
11. Press ZERO to cycle through the values until the desired graduation appears. (The C3 channel
adjusts the divisions on the scale. A value of 1 selected and C2 set to 1, the scale will read in 0.1 lb.
increments.)
12. Press PRINT to set the value. The display will now show CO4.
13. Press PRINT to access the C4 channel. The display will show [######].
14. Enter in the maximum capacity you want to use for this scale by using UNIT and COUNT to
move the cursor left and right, and TARE and ZERO to move the values down and up. (The C4
channel is used to enter in the max capacity of the scale; Make sure this doesn't exceed the max
capacity of the scale; Max capacity divided by the increment set in C02 and C03 above cannot
exceed 5000.)
15. Press PRINT to set the value. The display will now show C05.
16. Press PRINT to access the CS channel. The display should show [C5 0].
17. The CS channel calibrates zero on the scale. Make sure the scale is empty.

[e-mail] (844)-735-5386 www.selletonscales.com
SL-720
INSTALLATION MANUAL - WEIGHING KIT
SL-7510 offers 2 calibration methods, Single Point which uses one weight to calibrate or
Linear Calibration, which uses multiple (2-7) weights for a more accurate calibration.
To Calibrate using only 1 calibration weight (Single Point Calibration)
20. Press PRINT to continue. The display will now show C06.
21. Press PRINT to access the C06 channel. The display will show [C6 0].
22. The C6 channel is used to calibrate the scale with a known weight. Press ZERO to set the value
of C6 to [C6 1]. Press PRINT . The display will flash SPAn, and then show [######].
18. Press ZERO to change the value to 1.
19. Press PRINT The display will count down from 10-1 while the scale is calibrating zero. When
the display shows 0 the zero calibration is complete.

[e-mail] (844)-735-5386 www.selletonscales.com
SL-720
INSTALLATION MANUAL - WEIGHING KIT
For Additional support please reach out to [e-mail]
or Call 844-735-5386.
1. Overload
2. Wrong connection with load cell
3. Load cell has quality problem
1. Reduce the weight
2. Check load cell connection
3. Inspect load cell; Check the input/output
4. See Q&A section
1. Check all wire connections
2. Check load cell
3. Recalibrate
4. PCB replacement needed if steps 1-3 fail
1. Make sure scale is level
2. Check load cell connection
3. Check load cell input and output resistance
4. See Q&A section
1. Calibration is no good
2. Wrong connection with load cell
3. Load cell has quality problem
During calibration, weight is not used or
the weight is above the max. capacity Use correct weight within the defined range
During calibration the weight is below
the minimum required weight
The calibration weight minimum is 10% of
the max. capacity set in C04.
Recommended to use 60%-80% of max.
capacity if possible
During calibration, the input signal is
negative
During calibration signal is unstable After the platform is stable start calibration
Change PCB
See Q&A section
EEPROM Error
Exceed Zero Range
uuuuuu
e 1
e 2
e 3
e 4
e 5
e 6
Error Reason Solution
TROUBLESHOOTING
Error Codes
