semmco EEBD User manual

Expert manufacturers
of short duration
breathing apparatus
specialists in escape and working rescue
Semmco EEBD
Emergency escape oxygen
breathing device to protect from:
• Smoke
• Toxic contamination
• Oxygen deciency

Semmco EEBD
TheSemmcoEEBDisaself-containedshortduration
oxygen(O2) breathing apparatus that provides a supply
offreshoxygensothatthewearercanbreathefreelyin
acontaminatedoroxygendecientenvironment,ensuring
aquickandsafeescape.
TheSemmcoEEBDisavailableintwodifferentversions:
•15minutedurationforMilitary,Maritime&Offshore
•20minutedurationforIndustrial
Eachversioniscontainedinanorange,rigidcase,
that is discarded once the Semmco EEBD is in use.
HowtheSemmcoEEBDworks
TheSemmcoEEBDusesKO2(potassiumsuperoxide)to
provideoxygentotheuser.AstheEEBDispulledfromits
carrycase,achloratecandleprovidesoxygenfortheuser’s
rstbreath.Astheuserexhalesintothebag,moisturefrom
theirexhaledbreathactivatestheKO2thatthen‘scrubs’the
CO2andliberatesoxygen.Oxygencontinuestobegenerated
while the EEBD is being used and depending on the version
deployed,willlastfor15or20minutes.
Mainfeaturesandbenets
•Automaticstart–instantO2supply once the EEBD
is removed from the carry case
•Quickandsimpletodon
•Lightweight-2kg(withcase)1.3kg(withoutcase)
•Easytomovearoundwhenwearingtheset
•ClearvisualindicatoronthecaseconrmsEEBDviability
•Fitsexistingstoragesystems
•15yearshelf-life
Storage
TheSemmcoEEBDcanbestoredforupto15yearsbut
duringitslife,visualchecksmustbecarriedoutonaregular
basis to ensure that:
•Thecaseisnotdamaged
•Theanti-tamperlabelandsealarestillintact
•Theunitiswithintheexpirydate
•Thevisualindicatorisblueandnotpink
Iftheseconditionsarenotmettheunitmustn’tbeused
and must be replaced with a new unit.
TechnicalData
Temperatureinhaledgas35L/min <50°C
Breathing Bag Volume ≥6litre
CO2content(inhaledgas) <3vol%
Operatingtimeaccordingto
EN13794
20mins
Operatingtimeatrestto
EN13794
60mins
Operatingtimeaccordingto
ISO23269-1
15mins
Weightwithcase(approx.) 2kg
Weightwithoutcase(approx.) 1.3kg
Casedimensions(approx.) 210x230x100mm
Temperature–storage -20°Cto+60°C
Temperature–inuse -6°Cto+50°C

Donning the Semmco EEBD
1.
Liftyellowclip
2.
Remove lid
3.
Remove set from case by pulling
on the base of breathing hose
4.
Remove set from case
5.
Onremovalthebungsdetach,
startinginitialoxygengeneration
6.
Takeabreath,putneckstrap
over head
7.
Insertmouthpiece
8.
Adjustneckstrap,tnoseclip,
exhaleintomouthpiece
9.
Ifneeded,donfaceshieldand
pull yellow loops to tighten
aroundneck
10.
ESCAPE

Donning the Semmco EEBD
Regulations and Approvals
Semmco EEBD has been designed and tested in accordance
with the following regulations:
•EN13794andISO23269-1–todemonstratecompliance
with the essential safety requirements with PPE Regulation
(EU)2016/425
•SOLAS(InternationalConventionForTheSafetyofLife
atSea)–EmergencyEscapeBreathingDevices
•MarineEquipmentDirective2014/90/EU
Approvals–UKCA&CE(IndustrialPPE
&MarineSOLAS)
•IsinconformitywiththeMerchantShipping(Marine
Equipment)RegulationsSI2016/1025,asamendedby
SI2019/470&MSN1874Amend4andwiththerelevant
requirements of the appropriate sections of the designated
standardsBSEN13794:2002,BSISO23269-1:2008for
general,itisdeemedtomeetthebasicsafetyandhealth
requirements of the PPE Regulation.
•IsinconformitywiththeMarineEquipmentDirective
2014/90/EUincludingRegulation(EU)2021/1158and
with the relevant requirements of the appropriate sections
oftheharmonizedstandardsEN13794:2002,ISO23269-
1:2008forgeneral,itisdeemedtomeetthebasicsafety
and health requirements of the PPE Regulation.
•IsinconformitytoaTechnicalSpecicationtosatisfyAnnex
IIofthePPERegulation(EU)2016/425asbroughtinto
UKlawandamendedwiththerelevantrequirements
of the appropriate sections of the designated standards
EN13794:2002,ISO23269-1:2008tomeettheessential
healthandsafetyrequirements(AnnexII)ofthe
PPE Regulation.
•IsinconformitytoaTechnicalSpecicationtosatisfy
AnnexIIofthePPERegulation(EU)2016/425withthe
relevant requirements of the appropriate sections of the
harmonizedstandardsEN13794:2002,ISO23269-1:2008
to meet the essential health and safety requirements
(AnnexII)ofthePPERegulation.

UK:
SemmcoLPSLtd
9KestrelWay
Woking
SurreyGU213BA
UK
Tel:+44(0)1483757200
[email protected]
USA:
SemmcoInc.
Suite101
917WestMayeldRoad
Arlington
Texas76015
USA
Tel:+16822524148
[email protected]
Middle East:
SemmcoDWC-LLC
BusinessCentre
DubaiWorldCentral
P.O.Box390667
Dubai
UAE
Tel:+971(0)563937781
[email protected]
www.semmco.com
IntelligentEngineering
Todiscussanyrequirementsyoumayhaveortorequestaquote,pleasegetintouchwithamember
of our sales team at the following locations:
Expertmanufacturersofshortduration
breathingapparatus-specialistsinescapeand
workingrescue
SemmcoLifeProtectionSystemsspecialisesinthedesignand
manufactureofescapeandworkingrescuebreathingdevices
toprotectthoseworkinginirrespirableatmospheres.Insuch
criticalsituations,escapeandworkingrescuebreathingdevices
mustbeeasytodon,simpletouseandtotallyreliable.
HEADEscapeandWorking/RescueDevices
InApril2000,SemmcoLPSlaunchedthe10minuteHEAD
EscapeDevice.Thisrevolutionary,head-worndesignprovides
asafeandconstantsupplyofoxygenforthewearersothat
theycanescapefromacontaminatedortoxicatmosphere.
TheDeviceincorporatesauniquealarmsystemsothatthe
wearerknowstheexactremainingdurationofthedeviceto
enable them to complete a safe escape.
(N.B.thealarmsoundsat2/3theduration,indicatingthe
wearer has 1/3duration remaining).
SopopularisthisDevicethat15and30minutesetswere
developedandin2009,SemmcoLPSlauncheditsHEAD
CSREWorking/RescueDevice,specicallydevelopedforuse
bycorrectionalofcersworkinginprisonsandcustodysuits.
ThisDeviceisnowinstalledineveryGovernmentandprivate
prisoninEngland,WalesandNorthernIreland.
TheHEADrangeismaintenancefreefor12years,with
revalidationat6and9yearsprovidingconsiderablethrough-
life cost savings.
Semmco EEBD
Thelatestadditiontotheescapeandworkingrescuedevices
range,theSemmcoEEBDisaself-contained,singleuse,short
durationoxygen(O2)breathingdevicespecicallyforuse
intheMaritime&Offshore,Industrial,MilitaryandMining
markets.Itisavailableinthefollowingcongurations:
•Marine-15minuteset
•Industrial-20minuteset
UnliketheHEADDevices,itissimplerindesignwitha
mouth-piece,noseclipandfaceshieldandcanbestoredfor
upto15years.Duringthattimeregularvisualchecksensure
its viability.
RP100CorproRange–Mask&Filters
TheSemmcoLPSRP100CorproFullFaceMaskand
HalfMaskareinnovativelydesignedtoprovidehighlevels
of protection while still being comfortable and lightweight to
wear.BothmasksareavailableinthreesizesandtheRP100
CorproFilterRangeincludesninedifferentcombinations,
ultra-lowbreathingresistance,optimisedcapacityandeasy
tconnectiondesign.
Tondoutmoreaboutourrangeofescapeandworking
rescue devices please visit: www.semmco.com
