Sena 5R Lite User manual

1.0.0
SENA
QUICK START GUIDE
ENGLISH
5R L ITE
MOTORCYCLE BLUETOOTH®
COMMUNICATION SYSTEM

SENA Technologies, Inc.
Customer Support: sena.com
Downloadable Sena Software
Download the SENA MOTORCYCLES App on Google Play
Store or App Store.
SENA MOTORCYCLES
• Device Configuration Setting
Download the following items at sena.com.
Firmware
Sena Device Manager
• Firmware upgrade
• Device configuration setting
Quick Start Guide,
User’s Guide
Follow us on Facebook, YouTube, Twitter and Instagram to check
the latest information and helpful tips.

Product Details
Speakers and
Microphone Port
LCD Display
DC Power Charging &
Firmware Upgrade Port
(+) Button
(-) Button
Multi-function Button
Installation
• For more information about installation, refer to the User’s Guide.
Using the Clamp for Headset Main Unit
12

3
Using the Glued Surface Mounting Adapter for Headset Main Unit
1 2
3 4

Installing the Speakers
1 2
3

Icon Legend
1x
TAP Tap button the specified
number of times 10s
HOLD Press and Hold button for the
specified amount of time
“Hello” Audible prompt
Basic Operations
Powering On
1s
HOLD
READY
Powering Off
1x
TAP GOOD BYE
Volume Up/Down
1x
TAP
or
1x
TAP

Checking the Battery Level
LCD Display
Battery Indicator
READY
= High
= Medium
= Low
= Extremely Low
= Charging
Phone Pairing
① 10s
HOLD
“Configuration menu”
② 1x
TAP
“Phone pairing”

③ Select 5R LITE in the list of
Bluetooth devices detected.
Device B
Pi
Bluetooth
5R LITE
• The headset will enter the Phone Pairing mode automatically
when you initially turn on the headset.
• For more information on phone pairing, refer to the User’s Guide.
Using the Phone
LCD Display
Call Status
010 1234 5678
= Incoming Call
= Outgoing call
= On the Phone Call
= Reject a call

Answer a Call
1x
TAP
End a Call
2s
HOLD
Reject a Call
2s
HOLD
Voice Dialer
3s
HOLD In
stand-by
mode

Music Control
Play/Pause
1s
HOLD or
Track Forward
1s
HOLD
Track Backward
1s
HOLD

Bluetooth Intercom
Up to three other people can be paired with the headset for
Bluetooth intercom conversations.
A
B
C
D
YOU
Intercom Pairing
There are two ways to pair the headset.
Using the Smart Intercom Pairing (SIP)
SIP allows you to quickly pair with your friends for intercom
communication by scanning the QR code on the SENA
MOTORCYCLES App without remembering the button operation.
① Pair the mobile phone with the headset.
② Open the SENA MOTORCYCLES App and tap
(Smart
Intercom Pairing Menu).
③ Scan the QR code displayed on your friend (B)’s mobile phone.
• Your friend (B) can display the QR code on the mobile phone by
tapping > QR code ( ) on the SENA MOTORCYCLES App.

④ Tap Save and check that your friend (B) is paired with you (A)
correctly.
⑤ Tap Scan ( ) and repeat steps 3-4 to pair with Intercom Friends
(C) and (D).
Note: The Smart Intercom Pairing (SIP) is not compatible with
Sena products that use Bluetooth 3.0 or below.
Using the Button
AB
YOU
① Users (You, B) enter into Intercom Pairing.
5s
HOLD
“Intercom pairing”

② Tap the Multi-function Button on either headset.
1x
TAP
Confirms intercoms are paired
AB
YOU
③ Repeat the steps above to pair with other headsets (C and D).
Last-Come, First-Served
If the headset has multiple paired headsets for intercom conversations,
the last paired headset is set as the First Intercom Friend.
Intercom Pairing Order Last-Come, First-Served
A
B
C
D
YOU
1
2
3
ADCB
YOU Intercom
Friend 1
Intercom
Friend 2
Intercom
Friend 3

Two-way Intercom
Start/End Conversation with the First Intercom Friend D
1x
TAP
Start/End Conversation with the Second Intercom Friend C
2x
TAP
Start/End Conversation with the Third Intercom Friend B
3x
TAP
Intercom Conversation with Intercom Friend
FRIEND B

Configuration Menu
Accessing the Configuration Menu
10s
HOLD
“Configuration menu”
Navigating Between Menu Options
1x
TAP or 1x TAP
Execute Menu Options
1x
TAP

Troubleshooting
Fault Reset
Pinhole Fault
Reset Button
Note: Fault Reset will not restore the headset to factory default
settings.
Factory Reset
① 10s
HOLD
“Configuration menu”
② 2x
TAP
“Factory reset”
③ 1x
TAP “Headset reset,
good-bye”

Quick Reference
TYPE OPERATION BUTTON COMMANDS
Basic
Operations
Power on /
Power off
1s
HOLD
1x
TAP
Volume up / Volume down or 1x
TAP
Mobile
Phone
Answer phone call 1x
TAP
End phone call 2s
HOLD
Reject phone call 2s
HOLD
Voice dial 3s
HOLD

TYPE OPERATION BUTTON COMMANDS
Intercom
Intercom pairing
5s
HOLD
1x
TAP
Start/End intercom 1x
TAP
Music
Play/Pause music 1s
HOLD
Track forward 1s
HOLD
Track backward 1s
HOLD
1.0.0_EN_May2022
