Sena Parani-SD1000U User manual

Parani-SD1000U
User Guide
Version 1.0.0
2010-10-22

00019500
User Guide for the Parani-SD1000U
Version 1.0.0
Firmware version 1.0.X
Printed in Korea
Copyright
Copyright 2010, Sena Technologies, Inc. All rights reserved.
Sena Technologies reserves the right to make changes and improvements to its product without
providing notice.
Trademark
Parani™ is a trademark of Sena Technologies, Inc.
Windows® is a registered trademark of Microsoft Corporation.
Ethernet® is a registered trademark of XEROX Corporation.
Notice to Users
When a system failure may cause serious consequences, protecting life and property against such
consequences with a backup system or safety device is essential. The user agrees that protection
against consequences resulting from system failure is the user's responsibility.
This device is not approved for life-support or medical systems.
Changes or modifications to this device not explicitly approved by Sena Technologies will void the
user's authority to operate this device.
Precautions and Safety
Product
Parani-SD meets the USB standards. Do not wire with non-standard products. Damage to your
products may result from improper use.
Do not drop or subject the device to impact. Damage to your products may result from improper use.
Keep away from harsh environments including humid, dusty, and smoky areas. Damage to your
products may result from improper use.
Do not use excessive force on the buttons or attempt to disassemble the device. Damage to your
products may result from improper use.
Do not place heavy objects on the product. Damage to your products may result from improper use.

02
TA
FCC Information to User
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is con-
nected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution
Modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
FCC Compliance Information : This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired
operation
IMPORTANT NOTE:
FCC RF Radiation Exposure Statement:
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 20
centimeters between the radiator and your body.This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
This device has been designed to operate with the antennas listed below, and having a maximum gain
of 8.92dB. Antennas not included in this list or having a gain greater than 8.92 dB are strictly
prohibited for use with this device. The required antenna impedance is 50 ohms.
Antenna list :
Antenna type Model name Max gain(dBi)
Patch Antenna HIF-2400 Max Gain 8.92 dBi
Dipole Antenna R-AN2400-1901RS Max Gain 5.37 dBi
Dipole Antenna R-AN2400-5801RS Max Gain 3.27 dBi
Dipole Antenna AN2400-3306RS Max Gain 1.40 dBi
To reduce potential radio interference to other users, the antenna type and its gain should be so
chosen that the equivalent isotropically radiated power (EIRP) is not more than that required for
successful communication.
Technical Support
Sena Technologies, Inc.
210 Yangjae-dong, Seocho-gu
Seoul 137-130, Korea
Tel: [phone]
Fax: [phone]
E-Mail: suppor[email protected]
Website: http://www.sena.com

02
TA
Revision History
Revision Date Name Description
V1.0.0 2010-10-22 JH Park Initial Writing

02
TA
Contents
1. Introduction 8
1.1. Overview ....................................................................................................................................8
1.2. Product Specification..................................................................................................................9
2. Getting Started 10
USB Driver Installation ..................................................................................................................10
2.1....................................................................................................................................................10
2.2. Operation Modes......................................................................................................................11
2.3. LED Indicators..........................................................................................................................11
2.4. Serial Ports...............................................................................................................................12
2.5. Data Bit.....................................................................................................................................12
2.6. Hardware Flow Control ............................................................................................................12
2.7. Reset to Factory Defaults.........................................................................................................13
2.8. Dipswitch..................................................................................................................................13
2.9. Pairing Button...........................................................................................................................14
2.10. Software and Utility ................................................................................................................15
2.11. ParaniWIN..............................................................................................................................15
2.12. Parani Multi Wizard................................................................................................................21
2.13. ParaniUpdater........................................................................................................................22
2.14. Terminal Program...................................................................................................................23
3. Multiple Connection Mode 25
3.1. Overview ..................................................................................................................................25
3.2. Configuration............................................................................................................................26
3.3. AT Commands..........................................................................................................................27
3.3.1. AT+MULTI,n...................................................................................................................27
3.3.2. AT+MLIST?....................................................................................................................27
3.3.3. ATHx, ATHbdaddr..........................................................................................................27
3.3.4. ATOx, ATObdaddr.........................................................................................................27
3.4. Notes........................................................................................................................................28
4. RF Information 29
4.1. Radio Frequency Range..........................................................................................................29
4.2. Number of Frequency Channel................................................................................................29
4.3. Transmission Method...............................................................................................................29
4.4. Modulation Method...................................................................................................................29
4.5. Radio Output Power.................................................................................................................29
4.6. Receiving Sensitivity ................................................................................................................29
4.7. Power Supply...........................................................................................................................29
Appendix A: AT Commands 29
A.1. Terminology..............................................................................................................................29
A.1.1. AT Command.................................................................................................................29
A.1.2. AT Response .................................................................................................................29
A.1.3. Operation Mode.............................................................................................................29
A.1.4. Operation Status............................................................................................................29
A.1.5. Security..........................................................................................................................29
A.1.6. Symbols.........................................................................................................................29
A.2. Command Category.................................................................................................................29
A.3. Command Description .............................................................................................................29
A.3.1. ATZ..............................................................................................................................29
A.3.2. AT&F............................................................................................................................29
A.3.3. AT.................................................................................................................................29
A.3.4. AT+UARTCONFIG,Baudrate,Parity,Stopbit.................................................................29
A.3.5. AT+USEDIP?...............................................................................................................29
A.3.6. AT+BTINFO?...............................................................................................................29

02
TA
A.3.7. AT+BTINQ?.................................................................................................................29
A.3.8. AT+BTLAST?...............................................................................................................29
A.3.9. AT+BTVER?................................................................................................................29
A.3.10. AT+MLIST?................................................................................................................29
A.3.11. AT+BTMODE,n..........................................................................................................29
A.3.12. AT+MULTI,n...............................................................................................................29
A.3.13. +++............................................................................................................................29
A.3.14. AT+SETESC,nn.........................................................................................................29
A.3.15. ATO(ATOx, ATObdaddr) ...........................................................................................29
A.3.16. AT+BTCANCEL.........................................................................................................29
A.3.17. AT+BTSCAN..............................................................................................................29
A.3.18. AT+BTSCAN,n,to.......................................................................................................29
A.3.19. AT+BTSCAN112233445566,to..................................................................................29
A.3.20. ATD............................................................................................................................29
A.3.21. ATD112233445566....................................................................................................29
A.3.22. ATH(ATHx, ATHbdaddr)............................................................................................29
A.3.23. AT+BTKEY=$string....................................................................................................29
A.3.24. AT+BTSD? ................................................................................................................29
A.3.25. AT+BTCSD................................................................................................................29
A.3.26. AT+BTFP,n.................................................................................................................29
A.3.27. AT+BTSEC,Authentication,Encryption......................................................................29
A.3.28. AT+BTNAME=$string................................................................................................29
A.3.29. AT+BTLPM,n.............................................................................................................29
A.3.30. AT+BTRSSI,n(Single Connection Mode Only).........................................................29
A.3.31. AT&V..........................................................................................................................29
A.3.32. ATSnn? .....................................................................................................................29
A.3.33. ATSnn=mm................................................................................................................29
A.4. Command Validity....................................................................................................................29
Appendix B: S-Register 29
B.1. S1: Force to Reconnect (default 1)..........................................................................................29
B.2. S3: Stream UART Policy (default 0) ........................................................................................29
B.3. S4: Enable Remote Name Query (default 1)...........................................................................29
B.4. S6: Enable Low Power Mode (default 0).................................................................................29
B.5. S10: Enable Response Message (default 1)...........................................................................29
B.6. S11: Enable Escape (default 1)...............................................................................................29
B.7. S12: Clear Data Buffer When Disconnected (default 1)..........................................................29
B.8. S13: Enable DCD Signal (default 1)........................................................................................29
B.9. S14: Enable DTR Transfer (default 1) .....................................................................................29
B.10. S15: Enable Disconnect by DTR (default 0)..........................................................................29
B.11. S22: Faster Connection (default 0)........................................................................................29
B.12. S23: Intercharacter Timeout Setting (default 0).....................................................................29
B.13. S24: Maximum Number of Inquiry Result (default 15)...........................................................29
B.14. S26: Intercharacter Timeout (default 0).................................................................................29
B.15. S28: Escape Sequence Character (default 43).....................................................................29
B.16. S31: Page Timeout (default 20).............................................................................................29
B.17. S33: Inquiry Timeout (default 30)...........................................................................................29
B.18. S37: Supervision Timeout (default 5) ....................................................................................29
B.19. S43: COD (default 001F00)...................................................................................................29
B.20. S44: COD Filter (default 0)....................................................................................................29
B.21. S45: Inquiry Access Code (default 0x9E8B33)......................................................................29
B.22. S46: BD Address of Last Connected Device.........................................................................29
B.23. S48: Low Power Max Interval (default 5000).........................................................................29
B.24. S49: Low Power Min Interval (default 4500)..........................................................................29
B.25. S52: Low Power Timeout (default 5)......................................................................................29
B.26. S54: BD Address of Last Connected Device.........................................................................29
B.27. S55: BD Address of Last Connected Device.........................................................................29

02
TA
B.28. S56: BD Address of Last Connected Device.........................................................................29
B.29. S57: Slave Disconnect Timeout (default 3) ...........................................................................29
B.30. S58: MAX TX POWER (default 0).........................................................................................29
B.31. S59: Current Slave in Communication (default 0).................................................................29
B.32. S60: Reconnect Time Interval (default 5)..............................................................................29
B.33. S62: Sleep IC (default 1) .......................................................................................................29
Appendix C: Trouble Shooting 29
C.1. No Data Transmission .............................................................................................................29
C.1.1. COM Port Settings ........................................................................................................29
C.2. Data Loss or Malfunctioning....................................................................................................29
C.2.1. Hardware Flow Control..................................................................................................29
C.2.2. Response Message.......................................................................................................29
C.3. Transmission Delay .................................................................................................................29
C.3.1. RF Processing Delay.....................................................................................................29
C.3.2. RF Transmission Environment......................................................................................29
Appendix D: Warranty 29
D.1. GENERAL WARRANTY POLICY............................................................................................29
D.2. LIMITATION OF LIABILITY......................................................................................................29
D.3. HARDWARE PRODUCT WARRANTY DETAILS....................................................................29
D.4. SOFTWARE PRODUCT WARRANTY DETAILS ....................................................................29
D.5. THIRD-PARTY SOFTWARE PRODUCT WARRANTY DETAILS ...........................................29

02
TA
1. Introduction
1.1. Overview
Parani-SD1000U is a terminal device for wireless serial communication using Bluetooth 2.0+EDR
technology that is an international standard of short range wireless communications. Parani-SD1000U
can communicate with other Bluetooth devices; user may connect other Bluetooth devices that
support the Serial Port Profile.
The working distance of SD1000U with default antenna is 100m
SD1000U has a compact design, which allows it to be placed conveniently into various devices or
equipment. Its detachable antenna has the ability to optimize the quality and distance of wireless
communications.
SD1000U supports FHSS (Frequency Hopping Spread Spectrum), which is a technique, native to
Bluetooth that allows the SD1000U minimize radio interference while decreasing the likelihood of over-
air hijacking. SD1000U also supports authentication and Bluetooth data encryption.
SD1000U can be configured and controlled by a set of AT commands. Users can easily configure
SD1000U on a terminal program, such as HyperTerminal, and configure for wireless communication
without modifying user’s existing serial communication program. User friendly ParaniWIN can also be
used for easy setup on Microsoft Windows.

02
TA
1.2. Product Specification
Parani-SD1000U
Bluetooth v2.0 + EDR
Class 1
Bluetooth Interface
Working distance:
Dipole Antenna - Dipole Antenna 150 meters
Dipole Antenna - Dipole Antenna 200 meters
Dipole Antenna - Dipole Antenna 300 meters
Configuration ParaniWIN, Modem AT command set
Firmware Update ParaniUpdater
Diagnostic LED Mode, Connect, Serial Rx/Tx
Environmental Operating temperature: -20 ~ 70 oC
Storage temperature: -40 ~ 85 oC
Humidity : 90% (Non-condensing)
Physical properties - Dimension (L x W x H)
68 x 22 x 11.5 (mm)
- Weight
14g
Warranty 3-year limited warranty
Note *:Bluetooth v2.0 supports improved AFH function. AFH function is to mitigate the
interference between WiFi and Bluetooth radios by automatically avoiding the active WiFi channel
from Bluetooth link. However, AFH does not provide a complete solution making WiFi and Bluetooth
work together in harmony. It is highly recommended for users to test their wireless system enough
before deployment since the overall system performance is affected by various environmental factors
such as distance between them.

02
TA
2. Getting Started
2.1. USB Driver Installation
In case the USB interface is used for the communication between the development board and the
computer, the corresponding software driver needs to be installed on the computer. Windows XP and
later versions already include the USB driver. When Windows asks for the location of the USB driver,
you can select the option to “install the software automatically” as shown in Figure 2-7. You can also
choose to install the driver from the CD included if the driver is not installed correctly for some reason.
Figure 2-1 USB Driver Installation
