Sena SM10 User manual

User's Guide
www.senabluetooth.com
SM10
Dual Stream Bluetooth®
Stereo Transmitter

English
© 1998-2012 Sena Technologies, Inc. All rights reserved.
Sena Technologies, Inc reserves the right to make any
changes and improvements to its product without providing
prior notice.
Sena™ is a trademark of Sena Technologies, Inc. or its
subsidiaries in the USA and other countries. SMH10™,
SMH5™, SPH10™, SPH10S™, SPH10H™, SR10™,
SM10™ are trademarks of Sena Technologies, Inc. or its
subsidiaries. These trademarks may not be used without
the express permission of Sena.
The Bluetooth®word mark and logos are owned by
the Bluetooth SIG, Inc. and any use of such marks by
Sena is under license. Harley-Davidson®is a registered
trademarks of H-D Michigan, Inc. and Harley-Davidson,
Inc. Honda®and Gold Wing®are trademarks of Honda
Motor Co., Ltd. Sena Technologies, Inc. is not affiliated with
Harley-Davidson, H-D Michgan, Inc. or Honda Motor Co.,
Ltd. Other trademarks and tradenames are those of their
respective owners.

1. INTRODUCTION
2. PACKAGE CONTENTS
3. INSTALLING THE SM10
3.1 Installing on the Handle Bar
3.2 Placing on the Mounting Cradle (optional)
4. POWERING ON/OFF AND CHARGING
4.1. Power ON & OFF
4.2 Battery Check
4.3 Charging
4.4 Low Battery Warning
5. PAIRING THE SM10 WITH OTHER BLUETOOTH DEVICES
5.1 Bluetooth pairing with the first headset
5.2 Bluetooth pairing with the second headset
6. USING THE SM10
6.1 Connections
6.2 Using with a headset
6.3 Mute or un-mute AUX
6.4 Reset to Factory Default Settings
CONTENTS
6
8
10
10
10
11
11
11
11
12
13
13
14
15
15
16
16
17

English
6.5 Fault Reset
7. QUICK REFERENCE
BATTERY INFORMATION
MAINTENANCE AND CARE
DISPOSAL
CERTIFICATION AND SAFETY APPROVALS
• FCC Compliance Statement
• FCC RF Exposure Statement
• FCC Caution
• CE Declaration of Conformity
• Industry Canada Statement
• Bluetooth License
WAIVER AND GENERAL RELEASE
• Two-Year Limited Warranty
• Limitation of Liability
• Return for Full Refund
WARNING
17
18
19
20
21
22
22
23
23
24
24
25
26
30
31
32
33

6
1. INTRODUCTION
Thank you for choosing the Sena SM10. The SM10 is a
Bluetooth dual stream stereo transmitter based on Bluetooth
2.1+EDR technology. You can connect various audio devices
such as mobile phone or MP3 player by using the SM10. It also
supports onboard audio systems of specific brands by using
optional audio cables. Along with the dual streaming feature of
the SM10, both you and your passenger may listen to the same
music or radio at the same time by using most any Bluetooth
headsets in the market. The SM10 has an AUX audio input that
enables you to connect additional non-Bluetooth audio devices
such as a radar detector or GPS navigation.
Please read this user’s guide carefully before using the SM10.
Also refer to www.senabluetooth.com for the latest version
of the user’s guide and additional information related to Sena
Bluetooth products.

English
7
SM10 features:
•Dual audio streams for two Bluetooth headsets
•Auxiliary stereo input for GPS or radar/laser detector
•Water resistant for use in inclement weather
•Optional interface cable for onboard motorcycle audio
systems of Harley-Davidson and Honda Gold Wing
•Firmware upgradeable
•Two-year limited warranty
Technical Specifications:
•Bluetooth 2.1+EDR
•Advanced Audio Distribution Profile (A2DP), Audio Video
Remote Control Profile (AVRCP)
•Operating time: 8 hours
•Standby time: 3 days
•Battery charging time: 3 hours
•Lithium polymer battery
•Dimensions: 83 mm × 45 mm × 25 mm
(3.3 in × 1.8 in × 1.0 in)
•Weight: 50g (1.76 oz)
•CE, FCC, IC

8
2. PACKAGE CONTENTS
Blue LED
Red LED
AUX Port for auxiliary
audio input
Charging LED
Pairing Button
Power Switch
AUDIO IN Port for main stereo
audio input
DC Power Charging & Firmware
Upgrade Port
• Main Unit

English
9
• USB Power & Data Cable
• Cigarette Charger
• Audio Cable 3.5mm 4 pole
• Audio Cable 3.5mm 3 pole
• Handlebar Mounting Kit
• Mounting Cradle

10
3.1 Installing on the Handle Bar
1. Attach the mounting kit on the back of the SM10 along the
guide rail.
2. Place the main unit on the handle bar, wind the rubber band
around the handle bar, and hang it on the hook.
3.2 Placing on the Mounting Cradle (optional)
1. Locate a proper surface on your motorcycle body, clean the
body surface location with a moistened towel, and allow to
dry thoroughly
2. Peel off the cover of the adhesive tape of the mounting cradle
and attach the unit on the proper surface of your motorcycle.
3. INSTALLING THE SM10

English
11
4.1 Power ON & OFF
To power on the SM10, slide the Power Switch to on. The Blue
and Red LEDs will turn on. To power off, slide the Power Switch
to off.
4.2 Battery Check
You can check the battery level when the SM10 is powering on.
4.2.1 LED Indicator
When the SM10 is powering on, the Red LED flashes rapidly
indicating the battery level.
4 flashes = High, 70~100%
3 flashes = Medium, 30~70%
2 flashes = Low, 0~30%
4.3 Charging
It takes about 3.5 hours to be completely charged. The
Charging LED becomes solid blue from solid red when it is
completely charged.
4. POWERING ON/OFF AND CHARGING

12
4.4 Low Battery Warning
When the battery is running low, the Red and Blue LED will
flash.

English
13
The SM10 must be paired with a Bluetooth headset to stream
audio from the non-Bluetooth audio source. If you want to
stream audio to two separate headsets, you need to perform
a pairing for both headsets. Pairing to the first headset will be
automatically done without using the Pairing Button, whereas
the pairing to the second headset requires manual operation
using the Pairing Button. Please take the following steps to pair
with your Bluetooth headsets.
5.1 Bluetooth pairing with the rst headset
1. Turn on the Bluetooth headset (Refer to the headset user
guide).
2. Place the Bluetooth headset in pairing mode (Refer to the
headset user guide).
3. Turn on the SM10.
4. Press the Pairing Button for 5 seconds until the Blue LED is
rapidly flashing.
5. PAIRING THE SM10 WITH OTHER
BLUETOOTH DEVICES

14
5. The SM10 will detect the Bluetooth headset nearby and
connection will be made accordingly.
6. If the first headset is connected, the Blue LED will slowly
flash.
5.2 Bluetooth pairing with the second headset
1. Turn on the second Bluetooth headset. (Refer to the headset
user guide).
2. Place the second Bluetooth headset in pairing mode (Refer
to the headset user guide).
3. Press the Pairing Button for 9 seconds until the Red LED is
rapidly flashing.
4. The SM10 will detect the Bluetooth headset nearby and
connection will be made accordingly.
5. If the second headset is connected, the Red LED will slowly
flash.

English
15
6.1 Connections
The SM10 has one AUDIO IN Port and one AUX Port for wired
connection with other devices.
• AUDIO IN: Main stereo audio input
Two types of stereo audio cables are included in the package,
3.5mm 4-pole stereo audio cable and 3-pole stereo cable. If
you need to use playback control over Bluetooth (AVRCP)
for the stereo audio device with playback control such as
iPhone, you may use the 3.5mm 4-pole stereo audio cable.
• AUX: Auxiliary audio input
You may use a 3.5mm stereo audio cable, either 3-pole or
4-pole to connect the auxiliary audio devices.
Whenever there is an incoming AUX signal, the volume of
AUDIO IN signal is down to a certain level. If you are riding
motorcycle with onboard audio system, you may use optional
accessory cables for model-specific audio systems. For more
information on the optional accessories, please visit www.
senabluetooth.com.
6. USING THE SM10

16
6.2 Using with a headset
1. Turn on Bluetooth headsets that are already paired with the
SM10.
2. Turn on audio device connected with SM10 and play the
music.
3. Turn on the SM10.
4. The SM10 automatically connects to the paired Bluetooth
headsets. You will then hear the music or other audio sound.
5. If you can’t hear any sound, press the Pairing Button of
the SM10. The SM10 tries to connect the paired Bluetooth
headset again.
Note:
The SM10 does not allow all control functions of your audio device over
Bluetooth AVRCP. In this case, the play/pause functions are controlled
from the audio device itself with the forward/backward tracking functions
supported by the SM10.

English
17
6.3 Mute or un-mute AUX
To mute or un-mute AUX, press and hold the Pairing Button
for 2 seconds
6.4 Reset to Factory Default Settings
1. Power on the SM10, press the Pairing Button on the SM10 for
14 seconds until the Blue and Red LED is rapidly flashing.
2. Within 10 seconds, press Pairing Button to confirm reset.
The SM10 will be restored to factory settings and returns to
standby mode.
3. If you don’t press the Pairing Button within 10 seconds, the
reset attempt is canceled and the SM10 returns to standby
mode.
6.5 Fault Reset
If the SM10 is not working properly or is in a faulty status for any
reason, you may reset by pushing the small reset button at the
back of the SM10 Main Unit. By using a paper clip or a pencil
tip, lightly press and hold the reset button for 1 second. The
SM10 will be switched off and automatically switched on again.
Turn the SM10 back on to use it. However, this will not restore
the SM10 to factory default settings.

18
7. QUICK REFERENCE
Button Description Duration LED
Power Switch ON Power-on 1 sec Solid blue & solid red
Power Switch OFF Power-off 1 sec LED off
Pairing Button
Fisrst headset
pairing 5 sec Blue rapid flashing
Second headset
pairing 9 sec Red rapid flashing
Factory reset 14 sec Rapid flashing on both blue
and red LEDs
Factory reset
confirm Tapping LED off
LED LED Status
Description
Blue LED
Solid
The first headset Idle
Slow Flashing
The first headset connected / Audio Streaming to the first headset
Double Flashing
AUX muted
Rapid Flashing Pairing with the first headset
Red LED
Slow Flashing
The second headset Idle
Solid
The second headset connected
Double Flashing
AUX muted
Rapid Flashing
Pairing with the second headset / Audio Streaming to the second
headset
LED Description
Solid Blue Fully charged
Solid Red Charging
•Buttons
•LED Status
•LED Status While Charging

English
19
BATTERY INFORMATION
The SM10 has an internal, non-removable, rechargeable
battery. Do not attempt to remove the battery from the device
as you may damage the device. The battery can be charged
and discharged hundreds of times, but it will eventually wear
out. Recharge the battery only with Sena approved chargers
designated for this device. Use of an unapproved charger may
present a risk of fire, explosion, leakage, or other hazard.
Always try to keep the battery between 15°C and 25°C (59°F
and 77°F). Extreme temperatures reduce the capacity and
lifetime of the battery. A device with a hot or cold battery may
not work temporarily. Battery performance is particularly limited
in temperatures well below freezing.
Do not dispose of batteries in a fire as they may explode.
Batteries may also explode if damaged. Never use any charger
that is damaged. Operating times are estimates only and
depend on the devices used together, features used, battery
age and condition, temperatures to which battery is exposed,
and many other factors.

20
The product should be treated with care and the following
suggestions will help you protect your warranty coverage.
1. Do not use or store the device in dusty, dirty areas. Its
moving parts and electronic components can be damaged.
2. Do not store the device in hot areas. High temperatures can
shorten the life of electronic devices, damage batteries, and
wrap or melt certain plastics.
3. Do not store the device in cold areas. When the device
returns to its normal temperature, moisture can form inside
the device and damage electronic circuit boards.
4. Do not attempt to open the product.
5. Do not drop or knock the device. Rough handling can break
internal circuit boards and fine mechanics.
6. Do not use harsh chemicals, cleaning solvents, or strong
detergents to clean the device.
7. Do not paint the device. Paint can clog the moving parts and
prevent proper operation.
MAINTENANCE AND CARE

English
21
The crossed-out wheel bin symbol on the
product, literature, or packaging reminds you
that all electrical and electronic products,
batteries, and accumulators must be taken to
separate collection at the end of their working
life. This requirement applies to the European
Union and other locations where separate collection systems
are available. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, please do not
dispose of these products as unsorted municipal waste, but
hand it in at an official collection point for recycling.
DISPOSAL
