Citrus Juicer
SCJ 1051GR
EN
EN-7
2015
11/2015
BEFORE FIRST USE
1) Remove packaging materials from the appliance and its accessories. Take the juicing cone A3out
of the juicing cone A2.
2) Thoroughly wash the cover A1, the juicing cone A2and A3, the strainer A4and the juice
container A6using warm water with kitchen detergent. Then rinse all these parts under clean
running water and thoroughly wipe dry with a fine wiping cloth.
ASSEMBLING AND DISASSEMBLING THE CITRUS JUICER
1) Place the base unit A7on an even, dry and stable surface. The appliance must be disconnected
from the el. power socket during assembly and disassembly.
2) Place the juice container A6on to the base unit A7so that the shaft of the motor A5is located
in the hole in the middle part of the juice container A6.
3) Place the strainer A4into the juice container A6.
4) If you are going to juice smaller citrus fruits, place the juicing cone A3on to the motor shaft.
If you are going to juice larger citrus fruits, first insert juicing cone A3into cone A2. Make sure
that the cones fit together properly. Place the cone assembled in this way on to the motor shaft.
5) If you wish to disassemble the citrus juicer, proceed in the reverse sequence.
OPERATING THE CITRUS JUICER
1) Make sure that the citrus juicer is correctly assembled and then connect it to a power socket.
2) Slice the citrus fruits that you wish to juice transversely in half.
3) Take one half of the citrus fruit and gently push the cut side on to the juicing cone A2or A3.
When the citrus fruit is pushed on to the cone, the motor will engage automatically and the cone
will begin to rotate. When you release the pressure, the motor will stop. Take the pressed out half
of the citrus fruit off the cone and you can continue pressing more fruit.
Tip:
You will extract the most juice from the fruit by pressing it down several times on to the juicing
cone for a short time.
Attention:
Do not exert too much pressure on to the juicing cone because this could choke the motor.
The maximum continuous operating time is 2 minutes. After 2 minutes of continuous operation
leave the appliance to rest for 3 minutes.
4) After you finish using the citrus juicer, disconnect the power cord from the power socket.
