USER GUIDE
Model: E1C-NB7
Sengled Smart Plug
smart lighting expert

Introduction:
Sengled Smart Plugs enable automation of your non-smart
devices and home appliances. You can control devices
remotely and set schedules through the Sengled Home app,
or use your voice to control your devices through our
partner programs like Amazon Alexa, Google Assistant or
Apple HomeKit (Sengled smart hub E39-G8C required).
Note: A hub is required to control these Smart Plugs.
Important Safety Information:
Before installing the Sengled Smart Plug, please read and
follow all precautions, including:
• Risk of electric shock. Do not attempt to disassemble
Smart Plug.
• Suitable for use in operating environment between
-4°F and 104°F (-20°C and 40°C).
• Do not use where directly exposed to water.
• Indoor use only.
Wireless Specification：
Wireless Frequency Range:2405MHz~2480MHz
Zigbee Operating channels : 11-26
Maximum Transmitted Output Power: +10.5dBm
1

Installation Instructions:
The following instructions are applicable to adding your
Smart Plug to a Sengled Smart Hub. If you DO NOT have
Sengled Smart Hub and Sengled Home app previously
installed, please install your hub according to its user
guide in the package before installing bulbs. If you have
third-party hubs, such as SmartThings or Amazon Echo
Plus, you also can connect Sengled Smart bulbs to these
hubs according to their instructions in apps. If you would
like to find our latest list of supported third party hubs,
please refer to support.sengled.com.
Note: Please ensure your mobile device is connected to
the same wireless router that your Sengled smart hub is
connected with using 2.4G Hz.
1Open the Sengled Home app.
Go to Devices, select the + sign,
and choose Smart Plugs or Smart
LEDs and Accessories (Use with Hub).
Follow in-app instructions to finish installation.
2Ensure your Sengled Home app can discover the
plugs. If the app unsuccessfully discovers the
plugs, please refer to the next section "Reset
Instructions" for how to reset your plug before
attempting to add it back in.
Congratulations on successfully installing your
smart plugs!
Reset Instructions:
To reset your Sengled Smart Plug, please make sure it’s
plugged into an outlet, then push the power button and
hold it for more than five seconds, then release. The
purple indicator light will flash five times, then slowly
pulse red on and o. If it does not pulse, please try
power cycle and reset it again. Once successfully reset,
please pair your Smart Plug again in your Sengled
Home app.
2

Operation:
The following section outlines some of the popular
operational modes of the Sengled Smart plugs.
On / O
Smart Plug can be controlled through a variety of
means:
• Via the physical power button
• Through Sengled Home app (including Widget)
• Through partner programs like Alexa, Google
Assistant, HomeKit, etc.
Scheduling
Schedules can be created with Sengled Home app.
Check the in-app how-to pages through “Settings” for
the following two operations:
Voice Control
• Set up Amazon Alexa by adding
Sengled Home Skill.
• Set up Google Assistant by adding
Sengled Home Service.
• Setup Apple HomeKit by “Add Accessory" from
iOS Home app. (Sengled smart hub E39-G8C
required)
Power Measurement
Select the smart plug from Devices page and check
average power and cumulative power consumption.
A
B
C
D
3

Frequently Asked Questions:
1. Can I use my Smart Plug simultaneously with other
Sengled Smart devices?
Yes, it works with Sengled Smart LED bulbs and
devices that use the Sengled Smart Hub. Sengled
Smart Plug E1C-NB7 also works as a ZigBee router
device and can connect other end devices with
Sengled Smart Hub. For the latest Sengled Smart
Device selection, please check out sengled.com.
2. What should I do if my Sengled Smart Hub can’t be
found when I try to add my Smart Plug device?
Please check the Wi-Fi settings of your cell-phone. It
has to be on the same Wi-Fi network as your Smart
Hub. Also make sure your smart plug is on pairing
mode.
3. What should I do if my Smart Plug is unresponsive?
Please confirm the following before reattempting to
connect:
1) the outlet has power.
2) the Hub has power by checking that the Power
“ ” and Internet Connection “ ” indicator lights
are on.
3) the hub is online via the Sengled Home app.
4) the Plug is within range of the Hub. If not, please
move your Plug within 15 feet.
4. What do the color codes of the LED's indicator
mean?
4
Smart Plug Status
Pairing mode
Paired successful
Reset successful
Paired with Power on
Paired with Power o
LED indicator status
Red, slowly pulse
Purple 3times, quickly pulse
Purple 5times, quickly pulse
Blue
O

Limited Warranty:
2-year Limited Warranty from original purchase date.
Sengled restrict warranty service for smart home device
to the country where Sengled or its authorized
retailor originally sold the device. To learn more about
the Limited Warranty for Sengled products, please visit
www.sengled.com/warranty. To learn more, please visit
support.sengled.com.
Support:
If you encounter any issues, please reach out to your
local Sengled Support team.
Visit the following website for web support:
https://support.sengled.com/
Send emails to:
[e-mail] (USA)
[e-mail] (CA)
Dial Customer Support Line 1-877-401-5990
10:00am-8:00 pm CST on Mon-Fri
11:00am-8:00 pm CST on Sat
5

FCC Statement：
Any Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including
interference that may cause undesired operation.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment. This equipment should be
installed and Operated with minimum distance 20cm between the
radiator & your body.
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However,there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
ISED RSS Warning:
This device complies with Innovation, Science and Economic
Development Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference
that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'ISED applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux
deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
ISED RF exposure statement:
This equipment complies with ISED radiation exposure limits set forth
for an uncontrolled environment. This equipment should be installed
and operated with minimum distance 20cm between the radiator&
your body. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
Le rayonnement de la classe b repecte ISED fixaient un environnement
non contrôlés.Installation et mise en œuvre de ce matériel devrait avec
échangeur distance minimale entre 20 cm ton corps.Lanceurs ou ne
peuvent pas coexister cette antenne ou capteurs avec d’autres.
