Senmeo PX-P001 User manual

s
PTC Fan Heater
User Manual
MODEL: PX-P001
uk[email protected]

s
Thanks for Choosing
Your support means the world to us. We hope you
enjoy our product as much as we did creating it.
Senmeo！
EXTEND YOUR
WARRANTY FOR FREE
In the unlikely event of a product failure, we
offer a 12-month warranty for peace of mind.
In addition, we will extend the warranty period
for another 12 months if you provide us with
your order number via e-mail (uk-support@sen-
meo.com).
uk[email protected] www.senmeo.com
s

s
CONTENTS
IMPORTANT SAFETY INSTRUCTIONS 01
04
USING YOUR HEATER
04
Package Contents
04
Product Diagram
04
Operations and Functions
05
Other Features
06
CLEANING AND MAINTENANCE
07
TROUBLE SHOOTING
08
Senmeo-CUSTOMER SERVICE
s

s
IMPORTANT SAFETY
INSTRUCTIONS
When using electrical appliances, basic precautions should always
be followed to reduce the risk of fire, electric shock, and injury to
persons, including the following:
●Read all instructions before using this heater.
●This heater is hot when in use. To avoid burns, do not let bare skin touch hot
surfaces. If provided, use handles when moving this heater. Keep combustible
materials, such as furniture, pillows, bedding, papers, clothes, and curtains at
least 3 feet (0.9 m) from the front of the heater and keep them away from the
sides and rear.
●Always unplug heater when not in use.
●Extreme caution is necessary when any heater is used by or near children or
invalids and whenever the heater is left operating and unattended.
●Do not operate any heater with a damaged cord or plug or after the heater
malfunctions, has been dropped or damaged in any manner.
●Do not use outdoors.
●This heater is not intended for use in bathrooms, laundry areas and similar
indoor locations. Never locate heater where it may fall into a bathtub or other
water container.
To reduce the risk of electric shock or personal
injury, the following basic precautions should be
strictly observed when using electrical products.
WARNING: Do not cover the heater. There is a risk
of overheating.
Do not use the fan heater near combustible
materials!
Do not use the fan heater near combustible
materials!
01 Senmeo PTC Fan Heater

●Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or
similar coverings. Do not route cord under furniture or appliances. Arrange cord
away from traffic area and where it will not be tripped over.
●To disconnect heater, turn controls to off, then remove plug from outlet.
●Do not insert or allow foreign objects to enter any ventilation or exhaust
opening as this may cause an electric shock or fire, or damage the heater.
●To prevent a possible fire, do not block air intakes or exhaust in any manner. Do
not use on soft surfaces, like a bed, where openings may become blocked.
Heaters has hot and arcing or sparking parts inside. Do not use it in areas where
gasoline, paint, or flammable liquids are used or stored.
●Use this heater only as described in this manual. Any other use not recom-
mended by the manufacturer may cause fire, electric shock, or injury to persons.
●Always plug heaters directly into a wall outlet/receptacle. Never use with an
extension cord or relocatable power tap (outlet/power strip).
●If there is a loose fit between the plug and the socket or the plug becomes very
hot, the socket may need to be replaced. Check with a qualified electrician to
replace the socket.
●It is normal for the plug and cord to feel warm to the touch. A plug or cord which
becomes hot to the touch or becomes distorted in shape may be a result of a
worn electrical outlet. Worn outlets or receptacles should be replaced prior to
further use of the heater. Plugging the heater into a worn outlet / receptacle may
result in overheating of the power cord or fire.
●The output of this heater may vary and its temperature may become hot
enough to burn exposed skin. Use of this heater is not recommended for persons
with a high sensitivity to heat or an inability to react to avoid burns.
●Ensure the heater is on a stable, secure surface to eliminate the potential of
tipping it over.
●Make sure that no pieces of polystyrene or other packaging material have been
left between elements of the appliance. It may be necessary to pass over the
appliance with a vacuum cleaner.
●Do not attempt to modify or repair the product by yourself. Doing so could void
the warranty and cause damage or personal injury. Only a repair technician may
disassemble or repair this product.
●If the machine is not working as it should, has received a sharp blow, has been
dropped, damaged, left outdoors, or dropped into water, do not use and contact
Customer Support.
●NOTE: There may be a trace of smoke or odor when the unit is first operated.
This indicates that a drop of oil fell on the heating coil during the manufacturing
process. It will quickly evaporate and should not re-occur.
Senmeo PTC Fan Heater 02

FOR HOUSEHOLD USE ONLY
READ AND SAVE THESE
INSTRUCTIONS
Check the appliance regularly and refer to TROUBLE SHOOTING or
contact our customer support if it shows any of the following signs:
●Power cord or plug is damaged.
●Unsaual smell or excessive heat.
HOT SURFACE
THE FRONT SURFACE CAN BE
VERY HOT DURING USE.
DO NOT TOUCH WHEN IN USE.
Product Size
Rated Power
Input
Model PX-P001
19*10*22 cm
1000W
AC 220-240V 50/60Hz
Specifications
03 Senmeo PTC Fan Heater

USE YOUR HEATER
1 x PTC Fan Heater
1 x User Manual
1 x Description of Power Plugs
Operations and Functions
Product Diagram
Front view Back view Bottom view
Power ON/OFF
●Press the power switch on the back of the heater to "I" or
"II" the heater starts to work.
●"I" is for warm air wattage 650w, "II" is for hot air wattage
1000w.
●Press the power switch to "0" and the heater stops
heating.
Package Contents
Senmeo PTC Fan Heater 04

Adjustable Up and Down 30°
●The heater can be manually adjusted with the front body
up or down 30°.
Carrying Handle
●The heater comes with a strap that can be used to move
the heater around to avoid burns.
Tip-Over Protection
●When the product is heating and the body tips over, the
bottom tipping protection device pops up and will automat-
ically turn off the heater.
Overheating Protection
●When the heater is running and the temperature exceeds
the stall temperature, the bimetal in the body will be
heated to produce internal stress and quickly cut off the
circuit to stop heating, thus playing a role in temperature
control. When the heater cools down to the set stall
temperature, the heater resumes normal operation.
Other Featrues
05 Senmeo PTC Fan Heater

CLEANING AND
MAINTENANCE
It is recommended that the heater be cleaned at least one
time during the operating season and before off-season
storage in order to provide the optimum level of performance.
●Turn off the heater, unplug it and wait for the heater to cool down.
●Use only a soft cloth to gently wipe the outer surfaces of the
heater clean.
●Do not use any cleaning agents or detergents.
●Never immerse the heater in water and never allow water to drip
into the motor housing. Be sure not to wet the heating element and
the switches.
●For storage, you may leave the heater covered to protect it from
dust. Store it in a cool, dry location and arrange the cable away from
traffic areas so that it will not be tripped over or damaged.
●Always disconnect the appliance from the mains by switching it off
and removing the plug from the power outlet before cleaning.
Caution：
●Do not allow water to run into the interior of the heater as this
could result in a fire or electric shock hazard.
●Any other servicing should be performed by an authorized service
representative.
●Except cleaning, any other servicing should be performed by an
authorized service representative.
●Carefully fold the power supply cord and tie it up with a cord, then
put the heater into the packing box. Keep it in a cabinet away from
any hot or wet location.
Dust Cleaning Care
Senmeo PTC Fan Heater 06

TROUBLE SHOOTING
The following trouble shooting guide addresses the
most common problems. If problems persist, contact
the Customer Support at uk[email protected].
Problem
Heater does
not start
Connect the plug to a
powered electrical outlet
Ensure that your circuit
breaker or fuse is working
properly
Power cord is not
properly
plugged in
The heater is tipped
over
The heater is tipped
over
Place it on a flat, level and
stable surface
Possible
Causes Solution
No power is passing
through the unit
Ensure your heater is
placed on a flat and even
surface
07 Senmeo PTC Fan Heater

Senmeo-CUSTOMER
SERVICE
Default 12-month warranty
Thanks for choosing Senmeo heater. This product is
covered with Senmeo product and labor warranty for 12
months from the date of its original purchase.
Extend your warranty
Contact us by email (uk[email protected]) with the
correct order number and the warranty will be extended
for a further 12 months.
The warranty will not apply in cases of:
●Accident, misuse, or repairs performed by unauthorized
personnel.
●Any unit that has been tampered with or used for
commercial purposes.
●Normal wear and tear of wearable parts.
●Use of force, damage caused by external influences.
●Damage caused by non-observance of the User Guide,
e.g. connection to an unsuitable mains supply or non-com-
pliance with the instructions.
●Partially or completely dismantled appliances.
●Defects caused by or resulting from damages from
shipping or from repairs, service, or alteration to the
product or any of its parts that have been performed by a
repair person not authorized by Senmeo.
We can only provide after-sales service for products that
are sold by Senmeo or Senmeo authorized retailers and
distributors. If you have purchased your unit from a
different place, please contact your seller for return and
warranty issues.
uk[email protected]
ZHONGSHAN CHUNKAI ELECTRONICS CO., LTD
* Please have your order confirmation number ready before
contacting Customer Support.
Senmeo PTC Fan Heater 08

Senmeo PX-P001
We’re Here to Help!
Contact our customer support!
www.senmeo.com
uk[email protected] www.senmeo.com
